Coleman 5059A703 User manual

Assembly and Instruction Sheet
for 30” Round Fireplace
Model 5059A703
®
Follow these instructions for assembly and read carefully, particularly the
safety statements. The safety alert symbol, is a universally recognized
symbol used to identify safety information about hazards that can result in
personal injury. When this symbol is used you should pay very close
attention to what is written. Review these instructions before beginning
assembly or using your fireplace.
• Check package for all parts needed for assembly.
• Check all items for shipping damage. Call Coleman at 1-800-835-3278 or
TDD: 316-832-8707 if you have any problems.
FOLLOW INSTRUCTIONS AND WARNINGS TO AVOID FIRE,
SERIOUS INJURY OR DEATH.
• Outdoor use only. Never use in enclosed area. Use in unventilated areas
will endanger your life.
• Keep away from all combustible materials including gasoline and other
flammable liquids and vapors.
• Use on a level, noncombustible surface only. Keep away from house,
garage, balconies, or eave overhangs.
• Keep out of the reach of children.
• Be sure screen is in place while in use and do not use in windy conditions.
• Do not overfill firebowl or use to burn leaves and trash.
• Exercise the same care you would with an open fire.
• Never leave unit unattended when hot or in use.
• Completely extinguish fire before leaving.
• Use gloves when handling or moving. Ashes can remain warm for a long
time after extinguishing.
• Dispose of cold ashes properly.
• Do not modify in any way nor use with parts not expressly approved by
Coleman.
• Combustion by-products produced when using this product contain
chemicals known to the State of California to cause cancer, birth defects,
or other reproductive harm.
Contact local authorities regarding possible burn restrictions before using product.
WARNING
Assembly
1. Carefully unpack all parts from shipping box.
2. Assemble Leg Brackets to Leg Support Ring as shown. Attach with
screws. Hand tighten.
Fireplace Parts Check List Assembly (cont.)
3. Place Firebowl Support Ring on top of Leg Brackets as shown. Attach
with screws. Hand tighten.
4. Tighten all screws in Leg Support Ring and Firebowl Support Ring.
Align holes
Firebowl Support Ring
Leg Bracket
Leg Support
Ring
Leg
Bracket
(continued on other side)
9
7
4
8
5
■■1. Protective Cover
■■2. Firebowl
■■
3. Leg Support Ring
■■ 4. Firebowl Support Ring
■■5. Leg Brackets
■■6. Screen Lifting Tool
■■7.
Screen Assembly
■■8. Hardware Kit w/Handle
■■9. Grate
6
2
13

The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, KS 67219
1-800-835-3278 • TDD: 316-832-8707
© 2006 The Coleman Company, Inc. All rights reserved. Coleman® and are registered
trademarks of The Coleman Company, Inc.
Assembly (cont.)
5. Place Firebowl into
Firebowl Support.
6. Place Grate into Firebowl.
Set Up and Use
WARNING
Never leave unit unattended when hot or in use. Keep out of reach of children. For
outdoor use only. Never use in enclosed area. Use in unventilated areas will
endanger your life.
1. Place unit on a level, noncombustible surface. Keep well away from
house, garage, balconies or eave overhangs. Do not use on wooden decks.
2.Be sure grate is placed in firebowl. Add newspaper, kindling & wood on
top of grate.
3. Ignite newspaper &
kindling with match or
butane lighter.
4. Once fire is lit, place
screen assembly on top
of firebowl.
5. Screen handle is hot
when in use. Use the
Screen Lifting Tool to
remove screen.
After Use
WARNING
To avoid burns – use heavy gloves to remove screen assembly and grate.
1. Completely extinguish fire before leaving.
2. Do not use water to douse the fire as this may warp the firebowl.
3. Dispose of cold ashes properly.
4. Be careful – fire may be out but firebowl can still be hot. Handle carefully.
5. Store in covered enclosure.
Repair Parts List
®
Coleman Limited One-Year Warranty
The Coleman Company, Inc. ("Coleman") warrants that for a period of one year from the date
of original retail purchase, this product will be free from defects in material and workmanship.
Coleman, at its option, will repair or replace this product or any component of the product
found to be defective during the warranty period. Replacement will be made with a new or
remanufactured product or component. If the product is no longer available, replacement may
be made with a similar product of equal or greater value. This is your exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase
and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain
warranty performance. Coleman dealers, service centers, or retail stores selling Coleman®
products do not have the right to alter, modify or in any way change the terms and conditions
of this warranty.
This warranty does not cover normal wear and tear, including chips, scratches, abrasion,
discoloration or fading from use or exposure to sunlight. Damage caused by misuse, abuse,
neglect, alterations, repairs by unauthorized persons, use of non-Coleman accessories or
parts, commercial use, or failure to follow recommended care or maintenance instructions.
Further, the warranty does not cover Acts of God, such as fire, flood, hurricanes and
tornadoes.
COLEMAN SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
CAUSED BY THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY OR CONDITIONS.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED IN DURATION
TO THE DURATION OF THE ABOVE WARRANTY OR CONDITIONS. SOME STATES,
PROVINCES, OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS THAT VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
How to Obtain Warranty Service
Take the product to an authorized Coleman service center. You can find the nearest authorized
Coleman service center by visiting www.coleman.com or calling 1-800-835-3278 or TDD 316-
832-8707 in the United States. If a service center is not conveniently located, attach to the
product a tag that includes your name, address, daytime telephone number and description of
the problem. Include a copy of the original sales receipt. Carefully package the product and
send either by courier or insured mail with shipping and insurance prepaid to:
For products purchased in the United States:
The Coleman Company, Inc.
3600 North Hydraulic
Wichita, KS 67219
Do not mail products with fuel in tanks, or with disposable propane cylinders. Remove glass
globes from lanterns and wrap separately.
DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE.
If you have any questions regarding this warranty please call 1-800-835-3278 or
TDD 316-832-8707 in the United States.
5059-054 (2/22/06)
Note:
An inch or two of
sand should be used
in firebowl beneath
the grate.
7. Assemble handle to
Screen Assembly and
secure with screw.
Model DESCRIPTION
5059A703
Part No.
5059-1001 Protective Cover
5059-1501 Leg Support Ring
5059-1301 Firebowl Support Ring
5059-5001 Leg Bracket (1 pk)
5059-3041 Screen Lifting Tool
5059-2001 Screen Assembly
5059-4301 Hardware Kit w/Handle
5059-4001 Grate
