Coleman Tent Power System with Fan User manual

COLEMAN®TENT POWER SYSTEM
TENT POWER SYSTEM
WITH FAN
How to Use and Enjoy Your Coleman
®
COLEMAN®TENT POWER SYSTEM
FCC REMOTE CONTROL SPECIFICATION
1、Frequency : 433.92MHZ
2、Voltage: 12V/23A
3、DataRate: 10Kbps
4、Power: 4dbm
5、Current: 8mA
6、
Modulate Mode: ASK

TO OPERATE THE FAN/LIGHT WITH REMOTE CONTROL
NOTE: Tent light and fan may be in operation at the same time or separately.
FOR THE TENT LIGHT:
1. Point the remote control at the fan/light unit on ceiling of tent.
2. Press the light button on the remote control to turn on the light. The number of times
you press the button will allow you to choose your lighting preference (Fig. 10):
• Once for HIGH • Twice for LOW • Three for Night Light • Fourth Time for OFF
FOR THE TENT FAN:
1. Point the remote control at the fan/light unit on ceiling of tent.
2. Press the fan button on the remote control to turn on the fan.
The number of times you press the button will allow you to
choose the fan speed (Fig. 10):
• Once for HIGH • Twice for LOW • Third time for OFF
TO OPERATE THE FAN/LIGHT WITH BUTTONS ON FAN HOUSING
1. The light and fan may be operated manually with the use of the
light and fan buttons on the fan/light housing. (Fig. 11)
2. Press the appropriate button the number of times (as stated
above) to select the lighting or fan speed you prefer.
Carefully read all instructions before use and save for future reference.
TO INSTALL OR REPLACE POWER PACK BATTERIES
Your new Coleman®Tent Lighting System operates on 8 “D” cell batteries. For longest life
use alkaline batteries.
1. If Red Button on front of battery pack is glowing, push button to turn power “OFF”. (Fig. 1)
2. Turn battery pack over and place coin into slot and rotate to unlock. (Fig. 2)
3. Lift up lid and install 8 “D” cell batteries in the correct orientation as shown on the
battery compartment. Always be careful that batteries are installed correctly. (Fig. 3)
4. Close lid, insert coin into slot and rotate to locked position.
5. Place battery pack on floor, on inside of tent, near a corner seam. (Fig. 4)
TO REPLACE REMOTE CONTROL BATTERY
1. Remove 4 screws from back of transmitter and install one
12v, 23AE alkaline battery. (Fig. 7)
2. Reassemble transmitter.
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 18 of the FCC Rules.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a resi-
dential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that which the receiver is needed.
• Consult the dealer or an experienced radio/TV technician for help.
Note: This product may cause interference to radio equipment and should not be installed near maritime safety commu-
nications equipment or other critical navigation or communication equipment operating between 0.45-30 MHz.
The Responsible Party information as below:
• Applicant name in full: The Coleman Company, Inc. • Phone: [phone]
• Address: 3600 N. Hydraulic, Wichita, KS 67219 • Fax: [phone]
• Contact in USA: Randy Hoover / Director of Product Safety Compliance • Email address: [email protected]
Fig. 4
Fig. 2
Fig. 1
Fig. 3
TENT FLOOR
Fig. 7
TO SET UP & CONNECT POWER PACK T0 FAN/LIGHT
1. Unsnap rubber plug from side of power
pack and plug the power cord that you ran
down the seam of your tent into the
power pack. (Fig. 8)
2. Push the red button on the power pack to
turn on main power. The button on the
power pack and the red light in center of
fan/light unit will glow when main power
is “ON”. (Fig. 9) Fig. 8
Fig. 10
Fig. 9
GLOWS RED WHEN
POWER IS ON
RED
BUTTON
LIGHT
BUTTON
TO INSTALL POWER HUB WITH WIRING TO TENT
NOTE: If tent is tall, position and mount the power hub with wiring before raising tent.
1. Position power hub with wiring on the inside of tent at the desired location near the
highest center point.
2. While holding power hub with wiring stationary inside the tent, place mounting plate
on the outside of the main tent fabric (not on outside of tent fly). Align mounting plate
and magnet on power hub. (Fig. 5)
3. Be sure the mounting plate is making good contact with the magnet before installing
the fan/light.
4. Attach fan/light by inserting threaded end into the socket and turning clockwise until
tightened (Fig. 6). Do not over tighten.
5. Run wiring from power hub down seam in tent and attach to seam with provided
wiring clips.
MOUNTING
PLATE
TENT MATERIAL
POWER HUB
WITH WIRING
MAGNET
Fig. 5
TENT
SEAM
SOCKET
POWER HUB
Fig. 6
FAN/LIGHT
WIRING
TENT
SEAM
RUBBER
PLUG
FAN
BUTTON
Fig. 11
LIGHT FAN

FCC WARNING STATEMENT
FCC NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH
MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE
EQUIPMENT.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired operation.
