Coleman MONTANA 2000001594 User manual

STITCH LINE
MONTANATM 8 TENT MODEL 2000001594
To Set Up Tent
1. Unfold tent and spread out on a clean, level surface with the door
facing the desired direction. (Fig. 1)
2. Assemble all poles by interlocking the shock-corded, sections
together.
3. Insert grey Side Body Poles through the grey trimmed sleeves on
both sides of tent; then insert black Main Body Poles through black
trimmed sleeves, in center of tent, forming a “X”. Make sure black
Main Body Poles overlap the grey Side Body Poles. (Fig. 1)
To Attach Rainfly
1. Insert black Rainfly Pole with through sleeve in underside of
Rainfly. (Fig. 9)
2. Drape Rainfly over tent with Rainfly Pole centered above front door
& the dark blue vestibule flaps located in the front. (Fig 9)
(continued on other side)
Fig. 2
Door
2C
Fig. 1
Door
Front of Tent
Black, Shock-corded Main Body Poles
Grey, Shock-corded Side Body Poles
Sleeve with
Grey Trim
Sleeves with Black Trim
Sleeve with
Grey Trim
Fig. 9
Black Rainfly
Pole
Door
Rainfly Sleeve
Pole Descriptions
Pole Pole Pole
Description Qty. Dia. Repair Kit Replacement Kit
Main Body Pole, black 2 11mm 501000539 501000549
Side Body Pole, grey 2 9.5mm 501000540 501000548
Rainfly Pole, black 1 11mm 501000539 501000549
Vertical Door Pole, black,
short w/rubber tips 1 6.3mm 501000543 501000545
Door Pole, black,
long w/rubber tips 1 6.3mm 501000543 501000545
Before you begin
Read all instructions before set up.
• Select a level site clear of rocks, branches, and other hard or sharp
objects, to install your tent.
WARNING: Keep clear of overhead power lines.
• Do not set up your tent under trees because of potential lightning
strikes or falling tree limbs in inclement weather.
• Secure with all stakes and guylines provided to prevent property
damage or personal injury.
• For best results in windy conditions, position narrow end of tent into
the wind.
• Enlist the help of at least one other person to assist you when it is
time to assemble the tent.
4. Insert end of each black Main Body Poles & grey Side Body Poles
into pins. (Fig. 2 & 2A)
5. Go to opposite end of each pole and gradually apply pressure to
each forming arches. Insert the pin into each pole end at the sides
and corners of tent. (Fig. 2 & 2A)
6. Attach frame clips along edges of tent to the black Main Body Poles
& grey Side Body Poles. (Fig. 2B)
7. Stretch tent until taut, then secure metal loops located on both
sides and web loops located at four corners of tent with stakes.
(Fig. 2C)
Hinged, Rigid Door
1. Assemble Vertical Door Pole (shorter black pole with plastic tips);
then insert through zippered vertical pole sleeve on hinged side of
door. (Fig. 3)
2. Insert end of Vertical Door Pole into bottom hinge plate, apply
pressure to form a slight bow, then insert other tip of pole into top
hinge. Zip up vertical pole sleeve. (Fig. 4 & 5)
3. Assemble Door Pole (longer black pole with plastic cap tips); then
insert into zippered pole sleeve at top of door. (Fig. 6)
4. Insert end of Door Pole into top hinge plate, apply pressure to form
a bow, then insert other tip of pole into the bottom hinge. (Fig. 7)
5. Zip up pole sleeve to enclose Door Pole. (Fig. 8)
Fig. 3 Fig. 4 Fig. 5
Fig. 6 Fig. 7
Fig. 8
Vertical Pole
Sleeve
Door Hinge
Pole
Sleeve
Top
Door
Hinge Pole
Sleeve
Top
Door
Hinge
Rainfly
2B 2A

STITCH LINE
To Attach Rainfly continued
3. Insert end of each black Rainfly Pole into pin on either side of front
door. (Fig. 10 & 10A)
4. Go to opposite end of Rainfly Pole and gradually apply pressure to
form an arch. Insert the pin into pole end at other side of the door.
(Fig. 10 & 10A)
5. Locate all hook & loop fasteners on underside of Rainfly and wrap
around black and grey poles to secure. (Fig. 10B)
6. Stretch elastic straps and hook clip on each to the metal loops at
the front and back of the tent. (Fig. 10C)
7. Extend out vestibule flaps and secure with metal stakes through the
loops in the web straps (Fig. 10 & 5D)
8. Stretch guylines until taut, then secure with stakes. (Fig. 10 & 10E)
The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
MADE IN CHINA • PRINTED IN CHINA
© 2008 The Coleman Company, Inc.
Coleman®, , and are registered trademarks and MontanaTM is a trademark of
The Coleman Company, Inc.
4010004002 (20081030)
Things You Should Know:
• Under certain conditions (cold weather, high humidity, etc.) condensa-
tion will form on the inside of your tent. Condensation is caused by water
vapor from your breath, perspiration, or any wet clothing inside the tent.
It is NOT LEAKAGE through the tent fabric. It can be minimized by
removing wet clothing from your tent and by providing good ventila-
tion through the tent.
• Tree limbs, tree sap, bird droppings, or moisture steadily dripping off
tree limbs can cause damage to the tent fabric and its coating resulting
in leaks or loss of flame-resistant properties.
• Never store tent, even for a short period of time, without drying it
thoroughly and brushing off caked dirt. Do not pack stakes or poles
inside your tent. Use a separate storage bag.
• Stakes should be removed by pulling on the stake itself. NEVER PULL ON
THE TENT TO REMOVE STAKES AS THIS COULD RESULT IN PROPERTY
DAMAGE OR PERSONAL INJURY.
• Tent poles should not be left telescoped together during storage.
• Do not leave your tent set-up for weeks at a time. Be aware that exposure
to ultraviolet rays from the sun can seriously damage material and/or
cause it to become discolored.
WARNING: Keep all flame and heat sources away
from this tent fabric.
This tent meets the flammability requirements of CPAI-84. The
fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may
render the flame-resistant properties ineffective.
Cooler Access
The smaller zippered opening at the side of tent is
designed for added ventilation and easy access to
your beverage cooler.
1. To use as a vent, unzip flap to expose screen.
2. To use as a cooler access, unzip other flap to
make an avenue to bring beverages into tent. (Fig. 17)
To Store
1. All poles and stakes must be placed in the storage bag to prevent
damage to the fabric items placed in the carry case.
2. Make sure tent is clean and dry before placing in carry case.
3. Remove rainfly, spread out on floor of tent, then unzip door & vents
before taking tent down for storage.
4. Neatly fold tent to width of pole storage bag, place on tent, roll
tightly, and place in carry case.
5. Store in a clean, dry area.
Electrical Cord Access
1. Unzip the access panel in the lower
left corner of tent and bring in an
electrical cord.
NOTE: Use only UL approved cords
rated for outdoor usage. (Fig. 16)
Fig. 17
Fig. 16
Fig. 10
10A10B
10C
10E 10D
Guylines
