Connect Frame to Tent
–Insert one end of main tent pole end
onto pin of ring and pin system, at tent
corner. (illus. 4)
–Go to opposite end of pole and
gradually apply pressure to the pole
forming an arch until you are able to
insert the pin into the pole
–Repeat for second pole
SUNDOME™ 10’x8 ’
1Layout & Positioning
of Tent, Pole Assembly
–Layout and position tent with door
facing desired direction. (illus. 1)
–Unzip door
–Stake down tent corners only, using the
rings at the end of the stake loops.
Keep the floor taut.
–Assemble Frame Poles by
interlocking shock-corded poles.
This will make two long poles.
–Insert the poles diagonally into Pole
Sleeves.The center of the poles should
cross forming an “X” in the middle of
tent. (illus. 1)
–Fasten Frame Tie on top of tent over
both poles. (illus. 1), (illus. 3)
2
WhenYou Are ReadyTo Set Up
Your Tent
–Select a level campsite clear of rocks,
branches and other hard or sharp objects.
–Do not set up your tent under trees.
–For best results in windy conditions,
position the end of tent into the wind.
–See owners manual for more tips.
Rainfly
Pole Rainfly Part No. 9260C304
Main Tent
Poles
POLE ASSEMBLY PARTS
Assembled
poles
inserted
through
pole
sleeves
Frame Tie
Instructions apply to Part Number 9260D108
illus. 1
Tent frame
set-up
illus. 3
Frame Tie
Part No. 9260C302
Part No. 9260B303
illus. 2 Tent stake
through ring
illus.4
Insert pole end onto
pin & ring

3Attach Tent to Frame
Using “ Quik-Up” Clips
–Attach “ Quik-Up” Clips along
the edges of tent to frame poles
(illus. 5), (illus. 6)
–Make any adjustments to the tent
corner stakes that are needed.
4Attach Rainfly
–Assemble Rainfly Pole by
interlocking shock-corded pole
–Insert Rainfly Pole into reinforced
pockets located at the center edges
of the underside of Rainfly
(illus. 7), (illus. 8)
–Tie underside of Rainfly to the Rainfly
Pole with Frame Ties (illus. 8)
–Drape Rainfly over tent frame, pole
side down. Rainfly Pole should
point out over door and rear window.
–Connect the four elastic loops with
“S” hooks, (found at the Rainfly
corners) to the four rings
located at the end of the Stake Loops
at the corners of the tent.
–Secure Rainfly with Frame Ties
located on underside of fly (illus. 9)
–Stake out tent with two side
guylines (illus. 10)
illus. 6
Assembled tent without Rainfly.
Note the “
Quik-Up” Clips located on edge of tent.
illus. 5
“Quik-Up” Clips
illus. 7 Insert Rainfly
Pole piece into
pocket on underside
of Rainfly
illus. 9 Completed tent with Rainfly.
Note where Rainfly Pole pockets ,
rings, and under ties are located
illus. 8
illus.
10
Underside
of Rainfly
attaches to
frame poles
“S” Hooks attach
Rings at the corners
Rainfly
pockets
Rainfly Pocket
Hook &
Loop
THE COLEMAN CO., INC.
3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
Rev. 7/01
Things You Should Know
• Under certain conditions (cold weather, high humidity, etc.)
condensation will form on the inside surfaces of your tent. Condensation is
caused by water vapor from your breath, perspiration, or any wet clothing
inside your tent. It is NOT LEAKAGE through the tent fabric. It can be mini-
mized by removing wet clothing from your tent and by providing good ventila-
tion through the tent.
• Never store tent, even for a short period of time, without drying it thorough-
ly and brushing off caked dirt. Do not pack stakes or poles inside your tent.
Use separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF.
NEVER PULL ON THE TENT FABRIC OR TENT STAKE LOOP TO
REMOVE STAKE.
• TENT POLES SHOULD NOT BE LEFT TELESCOPED
TOGETHER DURING STORAGE.
• Seam sealer has not been provided with your tent. It is necessary
and we recommend seam sealing your tent prior to camping. Seam sealer
may be purchased through your local retailer or at your local sporting goods
store.
• Do not leave your tent set-up for weeks at a time, be aware that expo-
sure to the ultraviolet rays of the sun can seriously damage nylon material
and/or cause it to become discolored.
• See owners manual for more tips.
WARNING: KEEP ALL FLAME AND HEAT SOURCES
AWAY FROM THIS TENT FABRIC. This tent meets the flammability
requirements of CPAI-84. The fabric will burn if left in continuous contact
with any flame source. The application of any foreign substance to the
tent fabric may render the flame-resistant properties ineffective.
