COLORATO CLJ-230SHD User manual

www.colorato.net
INSTRUCTION MANUAL
OF CITRUS JUICER
MODEL: CLJ-230SHD
Read carefully these instructions before using the
appliance

1
Contents
COLORATO recommends safety first …………………………………………………..
2
Important safety for your Citrus juicer …..…………………………........................... 2
Exploded view of Spare parts.……………………………………………….................. 3
Technical Parameters …………………………………………………………………….. 3
Before use …………………………………………………………………………………...
How to operate ….….……………………………………………………………………….
Cleaning ……………………………………………………………………………………...
4
4
4

2
COLORATO recommends safety first
We at COLORATO are very safety conscious. We design and manufacture
consumer products with the safety of you, our valued customer foremost in mind.
In addition, we ask that you exercise a degree of care when using any electrical
appliance and adhere to the following precautions:
Important safeguards for your Citrus Juicer
Before using the electrical appliance, the following basic precautions should
always be followed, including the following:
 Read carefully these instructions and save
them for future reference.
 Before use, check that the voltage of wall
outlet corresponds to the one shown on
the rating plate.
 Unplug from the outlet when not in use,
before putting on or taking off parts, and
before cleaning. Clean motor housing with
wet cloth, and wipe dry. Don't dip in water
for rinse.
 The instrument is not intended to be used
by persons disabled, with mental
aberration or without related experiences
and knowledge (including children), except
they are supervised and directed by
persons who are responsible for their
safety to use the product.
 Close supervision is necessary for any
appliance being used by or near children.
 Do not operate any appliance with a
damaged supply cord or plug or after the
appliance malfunctions, or is dropped or
damaged in any manner. Return the
appliance to the nearest authorized
service facility for examination, repair, or
electrical or mechanical adjustment.
 Don't let supply cord hang over edge of
table or worktop, or touch hot surface.
 If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in
order to avoid hazard.
 Don't use the appliance if the rotating cone
is damaged.
 Switch off the appliance before changing
accessories or approaching parts which
move in use.
 Keep hands, hair, clothing, as well as
scraper and other utensils away from
juicer during operation to reduce the risk of
injury to persons, and damage to the
juicer.

3
Exploded view of Spare parts
Technical Parameters
Model CLJ-230SHD
Power 230 W
Voltage 220V-50Hz
Speed of motor 980 r/min
Dimensions 28 x 20 x 47 cm
The symbol on the product means that at the end of its life, the appliance has not to be
considered a common waste. It is a special waste and has to be demolished in specific recovery
and disposal area, as prescribed by the EC Directive 2002/96/EC(WEEE). By disposing this
product correctly, you can avoid negative consequences for the environment and for the human
health, due to the presence of potentially dangerous substances in the product.

4
Before use
1. Read all instructions.
2. Check the voltage of your juicer before plugging it in. Before plugging in, ensure switch is
off.
3. Wash all parts and components that are in contact with the juice. Flush them with water
and then dry them.
How to operate
1. Cut the fruit in half
2. Place a cup under the spout.
3. Plug in the socket. Switch to the position “1”. Align the center of the cut fruit with the top of
juicer head and put it down. Press the handle to make the juicer head rotate. Impose even
pressure until juice is flowing out (see Fig.2). Then take out the peel and place the other cut
fruit. Repeat the above operation. Pay attention to clean the pulp in the filter to avoid overflow
of pulp.
4. Switch to the position of “0” when you stop using the appliance. Pull out the plug.
Don’t press too tight. If you hear that the motor is rotating more slowly or that it stops, it means
that you are pressing too tight. The motor will not become damaged because the thermal
protective device turns the motor off in case of over-straining. If this occurs, we advice you to
turn the juicer off, using the on/off switch. After a few minutes, the motor will cool off and the
juicer can be used again. Make sure to always switch off the juicer after use.
Cleaning
Never use steel wool abrasive cleaning ball or erosive liquid (such as alcohol, gasoline or
acetone) to clean the appliance.
1. Always switch off the motor and unplug the juicer.
2. Never immerse the motor housing in water. Wipe it with a damp cloth to clean it and wipe it to
dry it.
3. It is easy to detach all parts and components that are in contact with juice, such as juicer
head, filter, juice bowl etc, rapidly. Bowl pressing assembly shall be detached in
counterclockwise direction holding the handle. It is quite sharp on the bowl edge; pay more
attention to avoid scratches to your hands. When assembling the bowl pressing assembly, note
to ensure the bowl is always in contact with the bench. Screw up in clockwise direction. Please
operate carefully to avoid scratches in your hands.
4. Rinse all parts that are coming into contact with the juice immediately after use.
5. Make sure that you wash all parts that are in contact with the juice before using the appliance
for the first time.
