Columbia CSFH-3 WATER Instruction manual

P/N 27512601, Rev. A [01/09]

OIL FIRED CAST IRON BOILER
INSTALLATION, OPERATION &
MAINTENANCE MANUAL
Co l u m b i a bo i l e r Co m p a n y
Main ofces and Factory: Pottstown, PA


Tested for 75 PSI ASME
Working Pressure








 
 
 
 
 
 
 
 
 

e following dened symbols are used throughout this
manual to notify the reader of potential hazards of vary-
ing risk levels.
IMPORTANT: Read the following instructions COM-
PLETELY before installing!
NOTICE
KEEP THIS MANUAL NEAR BOILER AND
RETAIN FOR FUTURE REFERENCE.
!
DANGER
Indicates an imminently hazardous situation
which, if not avoided, WILL result in death, seri-
ous injury or substantial property damage.
!
WARNING
Indicates an imminently hazardous situation
which, if not avoided, may result in death, seri-
ous injury or substantial property damage.
!
WARNING
1. Keep boiler area clear and free from combus-
tible materials, gasoline and other ammable
vapors and liquids.
2. DO NOT obstruct air openings to the boiler
room.
3. Modication, substitution or elimination of
factory equipped, supplied or specied compo-
nents may result in property damage, personal
injury or the loss of life.
4. To the owner: Installation and service of this
boiler must be performed by a qualied installer.
5. To the installer: Leave all instructions with
the boiler for future reference.
6. When this product is installed in the Com-
monwealth of Massachusetts the installation
must be performed by a Licensed Plumber or
Licensed Gas Fitter.
!
CAUTION
Indicates an imminently hazardous situation
which, if not avoided, may result in injury or
property damage.
NOTICE
Indicates information which should be followed
to ensure proper installation and operation.


NOTES:
1. Add sux “T” to denote boiler with tankless heater.
2. I=B=R burner capacity is based on an oil heating value
of 140,000 Btu/gal. and with 13% CO2.
3.Netratingsbasedon1700Ftemperatureinradiatorsand
include 15% allowance for normal piping and pickup
load. Consult manufacturers for unusual piping and
pick-up requirements.
* All ratings subject to verication.
4. For equivelent square feet of radiation, divide I=B=R
output by 150.
5. 120 Volts, 15 Amps, & 60 Hz. required to operate this
boiler.
6. e MEA number for the series is 182-86E
7. For altitudes above 2,000 . ratings may be reduced at
the rate of 4% for every 1,000 . above sea level.
7. e MEA number for the Beckett burners used on the
are as follows: AF – 156-77-E, AFG – 213-83-E, AFII
85 – 24-92-E, AFII 150 – 456-90-E.
BOILER
SEC-
TION
A
LENGTH
OF
FLUSH
JACKET
B
FRONT OF CAST-
ING
TO CENTER LINE
OF
FLUE OUTLET
C
DIA. OF
FLUE
OUTLET
3 17 ⅞" 11 ¼" 6"
4 21 ½" 12 ⅝" 6"
5 25 ⅛" 14 ¼" 7"
6 29 ¼" 15 15⁄16" 8"
7 32 ⅞" 17 15⁄16" 8"


!
WARNING
All installations of boilers and venting should
be done only by a qualied expert and in ac-
cordance with the appropriate utica boilers
manual. Installing or venting a boiler or any
other gas appliance with improper methods or
materials may result in serious injury or death
due to re or to asphyxiation from poisonous
gases such as carbon monoxide which is odor-
less and invisible.


STANDARD EQUIPMENT: Crated Boiler, Flush Jacket, Oil Burner, Target Wall/Liner, Circulator- 1¼”, ASME Relief
Valve,eralitimeterGauge, DrainCock,Wiring Harness,Burner ElectricalDisconnect, PlasticCover, SupplyTapping-2”,
Return Tapping-1 1/2”, High Limit and Circulator Control, Primary Control. For Tankless Heater Units-add Tanlkess
Hot Water Coil, Flow Restrictor and Triple Aquastat Relay.

(1)
BOILER
MODEL
NUMBER
(2)*
I=B=R
OIL BURNER INPUT
D.O.E.
HEAT-
ING
CAPAC-
ITY
(3)(4)*
I=B=R
NET
RATINGS
WATER
MINIMUM
NATURAL DRAFT
CHIMNEY SIZE
PUMP
PRES-
SURE
A.F.U.E.
G.P.H. MBH MBH* MBH ROUND SQUARE PSI RATING
365 .65 91 79 68.7 6 8X8X15 140 86.0
3100 1.00 140 117 102 6 8X8X15 140 81.0
3125 1.25 175 144 125 7 8X8X15 140 80.0
4100 1.00 140 120 104 6 8X8X15 140 86.0
4125 1.25 175 149 130 7 8X8X15 140 82.5
5125 1.25 175 151 131 7 8X8X15 140 86.0
4150 1.50 210 175 152 7 8X8X15 140 81.0
5175 1.75 245 206 179 8 8X8X15 140 81.5
5200 2.00 280 231 210 8 8X8X15 140 81.0
6150 1.50 210 181 157 8 8X8X15 140 86.0
6225 2.25 315 254 221.0 8 8X12X15 140 ———
7275 2.75 385 307 267.1 8 8X12X15 140 ———

BOILER
MODEL
NUMBER
FIRING
RATE
G.P.H.
TANKLESS
HEATER
NUMBER
TANKLESS
HEATER CAPACITY
INTERMITTENT DRAW
G.P.M.
BOILER
WATER CONTENT
GALS.
365 .65 T3 available on request 10.5
3100 1.00 T3 3.25 10.5
4100 1.00 T4 3.25 13.5
3125 1.25 T3 3.75 10.5
4125 1.25 T4 3.75 13.5
5125 1.25 T4 3.75 16.5
4150 1.50 T4 4.00 13.5
6150 1.50 T4 4.00 19.5
5175 1.75 T4 4.25 16.5
5200 2.00 T4 5.50 16.5
6225 2.25 T4 5.75 19 5
7275 2.75 T4 6.00 22 5



All installations must conform to the requirements of the
authority having jurisdiction. Such applicable require-
ments take precedence over the general instructions of
this manual.
Where required by the authority having jurisdiction, the
installation must conform to the American Society of
Mechanical Engineers Safety Code for Controls and Safety
Devices for Automatically Fired Boilers, ANSI/ASME No.
CSD-1.
LOCATEBOILERS in front ofnalpositionbeforeremov-
ing crate. Provide a level solid base as near the chimney
as possible, and centrally located with respect to the heat
distribution system as practical.
Allow 24 inches in the front and top for servicing and clean-
ing, or removing tankless water heating coil.
When installed in a utility room, the door should be wide
enough to allow the largest boiler part to enter, or to permit
replacement of another appliance such as a water heater.
FOR INSTALLATION ON NON-COMBUSTIBLE
FLOORSONLY. eboilermustnotbeinstalledoncarpet-
ing or vinyl ooring. Minimum clearances to combustible
construction are:
TOP........................................................ 24 IN.
FRONT.................................................. 24 IN.
FLUE CONNECTOR............................ 9 IN.
REAR....................................................... 6 IN.
SIDES....................................................... 6 IN.
REMOVE CRATE and plastic protective wrapper and in-
spect fordamage.Allequipmentis carefullymanufactured,
inspected and packaged by experienced workers. Our
responsibility ceases upon delivery of the crated boiler to
the carrier in good condition. Any claims for damage or
shortage in shipment must be led immediately against the
carrier by the cosigner. Move boiler to permanent position
by sliding or walking.

!
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause property
damage, personal injury or loss of life.
!
WARNING
BOILER MAY NOT BE INSTALLED ON
COMBUSTIBLE FLOORING.
NOTICE
Clearance for access should exceed fore
protection clearance.


1. Ventilation of boiler room must be adequate
enough to provide sucient air to properly support
combustion.
2. When a boiler is located in an unconned space in a
building of conventional construction frame, masonry
or metal, inltration normally is adequate to provide
air for combustion and ventilation. However, in any
building which has been altered to conserve energy
or to minimize inltration, the boiler area should be
considered as a CONFINED SPACE. If there is any
doubt, install air supply provisions for combustion
and ventilation in accordance with section 5.3, Air for
Combustion and Ventilation, of the NFPA 54 1988
code, the recommendations that follow, or applicable
provisions of the local building codes.
3. When a boiler is installed in an unconned space, in
a building of unusually tight construction, air for
COMBUSTION AIR REQUIRMENTS
(MINIMUM OPENING IN SQUARE INCHES)
BTU/HR
INPUT
*UNCONFINED AREA **CONFINED AREA
OUTSIDE
COMBUSTION AIR
INSIDE
COMBUSTION AIR
OUTSIDE
COMBUSTION AIR
1 IN2/5000BTU/HR
(PARAGRAPH 4)
1 IN2/1000 BTU/HR
(MIN 100IN2) (Figure 1)
1 IN2/4000 BTU/HR
(Figures 2&3)
1 IN2/2000 BTU/HR
(Figure 4)
91,000 19 100 23 46
140,000 28 140 35 70
175,000 35 175 44 88
210,000 42 210 53 106
245,000 49 245 61 122
280,000 56 280 61 140
* Unconned area: A space whose volume is not less than 50 cubic feet per 1000 BTU per hour of all appliances installed in that
space (cubic feet of space = height x width x length).
** Conned area: A space whose volume is less than 50 cubic feet per 1000 BTU per hour of all appliances installed in that space (cubic
feet of space = height x width x length).
combustion and room ventilation must be obtained
from outdoors or from spaces freely communicating
with the outdoors. A permanent opening or openings
having a total free area of not less than 1 square inch
per 5,000 BTU per hour of total input rating of all
appliances shall be provided. Ducts may be used to
convey make-up air from the outdoors and shall have
the same cross-sectional area of the openings to which
they are connected.
4. When air for combustion and room ventilation is from
inside buildings, the conned space shall be provided
with two permanent openings, one starting 12 inches
from the top and one 12 inches from the bottom of the
enclosed space. Each opening shall have a minimum
free area of 1 square inch per one thousand (1,000)
BTU per hour of the total input rating of all appliances
in the enclosed space, but must not be less than

!
WARNING
AIR OPENINGS TO COMBUSTION AREA MUST NOT BE OBSTRUCTED. FOLLOW THE CHART
BELOW TO OBTAIN AND MAINTAIN ADEQUATE COMBUSTION AIR.


one hundred (100) square
inches.eseopeningsmust
freely communicate with
the interior areas having
adequate inltration from
the outside. See Figure #1.
5. When the boiler is installed
in a confined space and
all air is provided from
the outdoors, the conned
space shall be provided with
two permanent openings,
one commencing within 12
inches from the top and one
commencing12inchesfrom
the bottom of the enclosure.
e openings shall commu-
nicate directly, or by ducts,
with the outdoors or spaces
(crawl or attic) that freely
communicate with the out-
doors. One of the following methods must be used to
provide adequate air for ventilation and combustion.
A. When directly communicating with the outdoors,
each opening shall have a minimum free area of 1
square inch per 4,000 BTU per hour of total input
rating of all equipment in the enclosure. See Figure
#2.
B. When communicating with the outdoors by means
ofverticalducts,eachopeningshallhaveaminimum
free area 1 square inch per 4,000 BTU per hour of
total input rating of all appliances in the enclosed
space. See Figure #3.
C. If horizontal ducts are used, each opening shall have
a minimum free area 1 square inch per 2,000 BTU





per hour total input rating of all appliances in the
enclosed space. See Figure #4.
D. When ducts are used, they shall be of the same
cross sectional area as the free area of the area of
the openings to which they connect. e minimum
dimension of rectangular air ducts shall not be less
than 3 inches.
6. In calculating free area using louvers, grills or screens for
the above, consideration shall be given to their blocking
eect. Screens used shall not be smaller than ¼ inch
mesh. If the free area through a design of louver or
grill is known, it should be used in calculating the size
opening required to provide the free area specied. If
the design andfree area is notknown,itmaybe assumed
that wood louvers will have 20-25% free area and metal
louversandgrillswillhave60-75%freearea.Louversand
grills shall be xed in the open position or interlocked
with the boiler so that they are opened automatically
during boiler operation. Refer to the Combustion Air
Requirements chart on previous page for combustion
air minimum opening requirements.

 


1. Connect supply and return piping as suggested in Figure #5, below. When the boiler is used in connection
with refrigerated systems:
A. e chilled medium MUST BE IN PARALLEL with
the boiler.
B.Use appropriatevalvestopreventthechilledmedium
from entering the heating boiler.
2. During the heating cycle open valves A and B, close
valves C and D.
3. During heating cooling cycle open valves C and D, close
valves A and B.
A. Maintain a minimum clearance of one inch to hot
water pipes.
In air handling units where they may be exposed to
refrigerated aircirculation,the boilerpipingsystemMUST
be supplied with ow control valves or other automatic
means to prevent gravity circulation of the boiler water
during the cooling cycle.
4. Hot water boilers installed above radiation level must be
provided with a low water device either as part of the
boiler or at the time of boiler installation.
5. When a boiler is connected to a heating system that
utilizes multiple zoned circulators, each circulator
must be supplied with a ow control valve to prevent
gravity circulation.
* Reduced pressure back ow preventer must be used under
provisions required by the Environmental Protection
Agency, (EPA).
6. Bypass piping is an option which gives the ability to




adjust the supply boiler water temperature to t the
system or condition of the installation. Although, this
method of piping is not typically required for baseboard
heating systems.
A. This method is used to protect boilers from
condensate forming due to low temperature return
water. Generally noticed in large converted gravity
systems or other large water volume systems. See
Figure #6.
B. ese methods are used to protect systems using
radiant panels and the material they are encased
in from high temperature supply water from the
boiler and protect the boiler from condensation.
See Figures #7 and #8 following page.
C. This method is used to protect boilers from
condensateformingaswellasprotectingtheheating
system from high water temperature. See Figure #8
following page.
7. Note: When using bypass piping, adjust valves A and B
until desired system temperature is obtained.
8. Bypass loop piping must be the same size piping for the
supply and return.









11. For further piping information refer to the I=B=R
installation and piping guide.
9. Typical installation using circulators is shown in Figure
#9.
10. Typical installation using zone valves is shown in
Figure #10.





• An automatic mixing valve must be installed on the
outlet of the domestic coil. Installation must comply
with the valve manufacture’s recommendations, and
instructions.
• Do not remove the bolts or aquastat at the time of
installation.
• Pipeinaccordancewiththeinstallationmanual.
• Due to varying water conditions, an adjustable ow
restrictor must be installed in the cold water inlet of
this coil.


!
DANGER
Water temperatures exceeding 125ºF will
cause severe burns instantly or death by
scalding.







INSPECT CHIMNEY to make certain it is constructed
according to the latest revision of the NFPA211. Local
codes may dier from this code and should be checked.
Where there is a conict, the local code will prevail. In
Canada refer to the National Building Code or CSA-A405
as applicable.
is boiler must be installed into a chimney which has a
masonry or metallic chimney liner.
An unlined chimney will have leaks that will cause poor
chimney performance (NO DRAFT), and could result in
poor positive pressure in the combustion chamber.
Horizontalportionsoftheventingsystemshouldnotexceed
10 feet in length. Horizontal lengths over 10 feet will have
a negative eect on the chimney performance.
e chimney should extend at least 2 feet above any por-
tion of the building within 10 feet. See gure 14 below. It
should produce a negative dra of .06 to .08 inches of water
column, (W.C.), as measured with a dra gauge between
the boiler and barometric dra control while maintaining
an .02 inch W.C. negative dra in the combustion chamber.
See chart below for recommended chimney or vent sizes.
Inadequatedrawillcauseimpropercombustion,resulting
in dirty ue ways and high fuel bills.
CONNECT FLUE PIPE same size as boiler outlet to chim-
ney, sloping upward continuously toward the chimney
approximately ¼” per foot. Bolt or screw joints together
to avoid sag.
If an oil red water heater is vented into the same ue as the
boiler, provide a separate hole into the chimney whenever
possible. When this isn’t possible, use a “Y” connection in
the ue pipe, using a separate dra regulator for each unit.
When a chimney will not provide adequate dra to handle
the input from the water heater and boiler simultaneously,
wire the units so that only one will operate at a time, favor-
ing the water heater.
MORE THAN 10'(3.1 M)
10' (3.1 M)
2' (.61 M)
HEIGHT ABOVE ANY
ROOF SURFACE WITHIN
10' (3.1 M)
HORIZONTALLY
CHIMNEY 3'
RIDGE
MIN. (.92 M) MIN.
GAS VENT OR
TYPE L VENT 2'
(.61 M) MIN.
CHIMNEY OR VENT SIZES
MODEL NO.
ROUND
INCHES
SQUARE
INCHES
HEIGHT
FEET
MIN MAX MIN MAX MIN MAX
365,3100
4100 6 8 8X8 8X8 15 40
4125,3125
4150, 5125 7 8 8X8 8X10 15 40
5175,5200 8 10 8X8 8X12 15 50
6150,6225 8 10 8x8 8x12 15 50
7275 8 10 8x8 8x12 15 50




Oil tank and piping should be installed in accordance with
the National Board of Fire Underwriters and local regula-
tions. Oil storage tank, vent, ll pipe and caps should be
as prescribed by local codes. In no case should the vent
pipe be smaller than 1¼” I.P.S. e ll pipe should not be
less than 2” I.P.S.
e suction line from the tank to the burner should be
one continuous piece of tubing to prevent air entering the
line. e suction line, must be ⅜” O.D. copper tubing for
runs of 50 feet or less, and ½” O.D. for longer runs. An oil
return line, same size as the suction line, must be used on
any installation where the bottom of the tank is below the
fuel unit of the burner. Oil lines should be buried or oth-
erwise protected from mechanical injury. Flare ttings on
all oil lines are recommended. Compression ttings on the
suction line oen allow air to be drawn into the fuel pump,
making it dicult to maintain oil pressure at the nozzle.
Do not run overhead fuel lines from tank to oil burner.
Fuel pump connections and by-pass should be made ac-
cording to instructions attached to the fuel pump. If tank is
more than 20’ from the boiler, a two stage fuel unit should
be installed in place of the single stage pump supplied as
standard equipment with the burner. Make certain the
rotation and speed are the same and the pump is suitable
for the burner horsepower rating.
An oil line lter and shut-o valve should be installed in
the suction line. Shut-o valves should be installed in both
the suction and return lines at the burner for convenience
in servicing burner. Allow extra tubing at burner so burner
may be removed from boiler for cleaning without discon-
nectingtubing.(SeeFigures#15&#16,below).Anoptional
exible oil line is available.
TYPICAL INSTALLATION
SINGLE PIPE OIL SYSTEM
BOILER
BAROMETRIC
DRAFT CONTROL
OIL LINE MUST BE BURIED OR
OTHERWISE PROTECTED FROM
DAMAGE. MINIMUM 3/8" IPS OR
APPROVED FITTINGS
3/8" O.D. COPPER TUBING
OIL BURNER
SWING JOINTS
OIL TANK
OIL FILTER
SHUT OFF VALVE
REFER TO NATIONAL
BOARD OF FIRE UNDERWRITERS
VENT PIPE
OIL GAUGE
FILLER
PIPE
MINIMUM
UTICA
BOILERS
TYPICAL INSTALLATION
TWO PIPE OIL SYSTEM
BOILER
BAROMETRIC
DRAFT CONTROL
OIL LINE MUST BE BURIED OR
OTHERWISE PROTECTED FROM
DAMAGE. MINIMUM 1/2" IPS OR
OIL FILTER
SHUT OFF VALVE
JOINTS
APPROVED
FITTINGS
SUCTION
FILL
PIPE
1/2" O.D. COPPER TUBING
OIL
SWING
RETURN LINE
REFER TO LOCAL
CODE
CHECK
VA LV E
LINE
*
TANK
OIL BURNER
UTICA
BOILERS







1. ermostat should be installed on an inside wall about
four feet above the oor.
2. NEVER install a thermostat on an outside wall.
3. Do not install a thermostat where it will be aected
by:
A. Dras
B. Hot or cold pipes
C. Sun light
D. Lighting xtures
E. Television sets
F. A replace or chimney
4. Check thermostat operation by raising and lowering
thermostat as required to start and stop the burner.
5. Instructions for the nal adjustment of the thermostat
are packaged with the thermostat ( adjusting heating
anticipator, calibration, ect.).
Electrical wiring must conform with the National Electri-
cal Code, ANSI/NFPA No. 70-1990 when installed in the
United states, the CSA C22.1 Canadian Electrical Code,
Part 1, when installed in Canada, and/or the local authority
having jurisdiction.

Install a fused disconnect switch between boiler and me-
ter at a convenient location.
On a call for heat, the thermostat will actuate, completing
the circuit to the aquastat. In turn, the circulator and igni-
tion systems are activated and ignition will begin.
In the event the boiler water temperature exceeds the
high limit setting on the boiler mounted aquastat, power
will be interrupted between the aquastat and the ignition
system. e power will remain o until the boiler water
temperature dropsbelow thehigh limitsetting.ecircula-
tor will continue to operate under this condition until the
thermostat is satised.

!
WARNING
When an external electrical source is utilized,
the boiler, when installed MUST BE electri-
cally grounded in accordance with these re-
quirements.




e venting system should be inspected at the start of each
heating season. Check the vent pipe from the boiler to the
chimney for signs of deterioration by rust or sagging joints.
Repair if necessary.
Remove the vent pipe at the base of the chimney or ue
and, using a mirror, check for obstruction.
e lever of the pressure relief valve, shown in Figure #9,
on the boiler should be operated periodically to make sure
that it is functioning properly. e pressure relief valve
should open before the water pressure exceeds the 30 lb.
reading on the gauge. If this pressure is exceeded and the
pressure relief valve leaks water when the boiler is operat-
ing at normal pressures, it should be immediately replaced.
Corrosioncan build uprapidly atthevalveseatandprevent
its functioning as a safety device.

(See oil burner instructions for nozzle and electrode setting)
A. Check oil burner nozzle to make certain it is tight in
adapter. Burner mounting bolts should be tight.
B. Check electrode setting, as they may have been jarred
out of position during transportation.
C. Lubricate burner motor and circulator motor if re-
quired. Some circulators are water lubricated and do
not require oiling.
D. Set room thermostat to call for heat, or jump thermostat
contacts on the boiler control.
E. Open all oil line valves.
F. Turn service switch on. Burner should start.
G. On one pipe fuel systems only, vent pump as soon as
burner starts. Allow oil to run until all traces of air in
the suction line disappear.
H. Turn “OFF” burner and install pressure gauge port on
pump.
I. Start burner again and check oil pressure for 140 lbs.
Adjust if necessary.
Instrumentsaretheonlyreliablemethodtodetermineprop-
er air adjustments. An improperly adjusted burner causes
soot and high fuel bills because of incomplete combustion
of the fuel oil. is in turn may require excessive boiler
maintenance, service costs, and in some instances, house
cleaning or redecorating. A competent service mechanic
should be consulted to make the proper adjustments with
a smoke tester, CO2indicator and dra gauge. Bacharach
or Dwyer test kits include these instruments.


A ¼” diameter slot is provided in the inspection cover
plate to take dra readings in the combustion chamber.
See Figure #19. A ¼” diameter hole will be required in
the ue pipe between the boiler and barometric damper
(if used) to take dra, CO2, smoke and temperature read-
ings. Adjust air shutter on oil burner to obtain a “trace” of
smoke. Measure CO2at this point. Increase air adjustment
to lower CO2approximately one (1) percent. Check to in-
sureminimumnegative.02w.c., (watercolumn), “overre”
dra and zero (0) smoke. If - .02 w.c. “overre” dra can
not be maintained, changes and/or modications may be
required in the venting or the chimney.
efollowingtable(onnextpage)isprovidedasa guideline
forinitialstart-up. Final adjustments MUSTbe made using
combustion instruments as previously mentioned.
CHECKSAFETYCONTROLCIRCUITaerburneradjust-
ments have been made for satisfactory performance.
A. High limit control: remove cover and note tem-
perature setting. See Figure #19. With the burner
operating, decrease this setting to the minimum
point. When boiler water temperature exceeds this
set point, the high limit switch will open, shutting
o the power to the oil burner. Return setting to
desired high limit point. Burner should restart.

!
WARNING
WATER WILL BE BOILING HOT.
!
CAUTION
DO NOT SET FIRE VISUALLY.


B. Primary control and ame sensor:
Check:
1. Flame failure - simulate by shutting o oil supply with
handvalvewhile burner is on.Sixtysecondsaerame-
out, the safety switch locks out, ignition stops, motor
stops and oil valve - when used - closes. To restart, open
oil supply valve and reset safety switch.
2. Ignition failure - with burner o, close oil supply valve
and run through start-up procedure, e safety switch
should lock out as in ame failure.
3. Power failure - Turn o main power supply switch while
burner is operating. When burner stops, restore power
and burner should start.
If operation is not as described as above, check wiring and
controls.
PREVENTIVE MAINTENANCE of an oil red boiler
reduces operating costs. e boiler and vent pipe should
be inspected for accumulation of soot or scale deposits
periodically but at least once every year before the start
of each heating season. When soot is present on the sec-
tion walls and ueways, improper combustion will result,
causing additional sooting and scaling until ueways are
completely closed. To remove soot and scale from the u-
eways, remove top jacket panel, top clean-out plate, open
burner swing door. (See Figure #19)
PERIODIC INSPECTION and tightening of the tankless
heater/cover plate bolts will reduce the risk of leaks. See
partnumber6,Replacement Parts“HeatExchanger”section
in the back of this manual.


1. Turn o power to boiler.
2. Allow boiler to cool down.
3. Disconnect power cable at factory supplied burner
electrical disconnect. See Figure #19
4. Loosen screws on the sides of the lower front jacket
panel. See Figure #19.
5. Pull the bottom part of the lower front panel for-
ward.
6. Li the lower front panel up and o the boiler. See
Figure #19.
7. Close oil valve. See Figures #15 & #16.
8. Disconnect oil line from burner.
9. Do not try to swing door with oil line attached.
10. Remove nut from swing door stud on right hand side
of door.
11. Swing open burner and door to the le.
Using a ue brush, brush the soot and scale into the com-

!
WARNING
• Useonlynumber2fueloil.
• Donotusegasoline,crankcasedrainings
or any oil containing gasoline.
• Donotattempttostarttheburnerwhen
excess oil has accumulated, when the unit
is full of vapor or when the combustion
chamber is very hot.


RIELLO SETTINGS
BOILER NO. BURNER NO. AIR DAMPER PUMP PRESS. TURB. NOZZLE
FURNISHED
365 F-3 4.0 150 PSI 0.0 .65 80W
3100 F-5 3.6 150 PSI 1.0 .85 80W
4100 F-5 3.6 150 PSI 1.0 .85 80W
3125 F-5 4.0 150 PSI 3.0 1.10 60W
4125 F-5 4.0 150 PSI 3.0 1.10 60W
5125 F-5 4.0 150 PSI 3.0 1.10 60W
4150 F-5 6.0 150 PSI 4.0 1.25 60W
5175 F-10 3.6 150 PSI 0.0 1.50 80B
5200 F-10 5.0 150 PSI 0.0 1.75 80B
CARLIN SETTINGS
BOILER NO. BURNER NO. AIR DAMPER PUMP RESS. HEAD BAR NOZZLE
FURNISHED
365 EZ-1 .60 150 PSI 60-.65 .60 70B
3100 EZ-1 .85 150 PSI .85-1.00 .85 70B
4100 EZ-1 .85 150 PSI .85-1.00 1.10 70B
3125 N/A N/A N/A N/A N/A
4125 EZ-1 1.00-1.10 150 PSI 1.10-1.25 1.10 70B
5125 EZ-1 1.00-1.10 150 PSI 1.10-1.25 1.10 70B
4150 EZ-1 1.25-1.35 150 PSI 1.10-1.25 1.25 70B
5175 EZ-2 1.65 150 PSI 1.65-1.75 1.75 70B
5200 EZ-2 1.75 150 PSI 1.65-1.75 1.50 70B
BECKETT SETTINGS
BOILER
NO.
BURNER
NO.
AIR
BAND
AIR
SHUT.
PUMP
PRESS.
STATIC
DISC
END
CONE
NOZZLE
FURNISHED
365 AFG 0 7 140 PSI 2-3/4" F0 .60 80B
3100 AFG 1 5 140 PSI 3-3/8U F3 .85 80B
4100 AFG 1 5 140 PSI 3-3/8U F3 .85 80B
3125 AFII N/A 6 140 PSI N/A N/A 1.10 60B
4125 AFG 1 8 140 PSI 2-3/4" F4 1.10 80B
5125 AFG 1 8 140 PSI 2-3/4" F4 1.10 80B
4150 AFG 2 6 140 PSI 2-3/4" F6 1.25 80B
6150 AFG 2 6 140 PSI 3-3/4” F6 1.25 80B
5175 AFG 3 5 140 PSI 3U F12 1.50 80B H
5200 AFG 5 5 140 PSI 3U F12 1.75 70B H
6225 CF375 3 6 140 PSI L1 N/A 2.00 45B
7275 CF375 5 4 140 PSI L1 N/A 2.25 60B
*NOTE: Model 3125 needs pin # 5,6225 needs a head setting of 1. Nozzle sizes with an H designation are Hago brand, all
others are Delevan.

