Columbus P-9 RACE User manual

•No signal received: Always on
•Signal received: Flashing
Parts Description
GNSS Status Lamp Bluetooth Lamp
1 2
CAUTION
GB
The protection class of the external active antenna is IP67,
which can work normally in all-weather environments such as
rain, snow and high dust, but do not immerse the antenna
completely in water. The main unit of the P-9 Race is not
waterproof.
As a precision electronics, the product contains no component
that can be repaired by your own. Any attempt to disassemble
the product will void the original manufacturer's warranty.
Thank you for choosing our product.
This manual is intended to guide you through the safe and
correct use of the product and its accessories, avoiding improper
operations that may result in injury of yourself or any other
person or cause device damage.
•Connected: always on
•Disconnected: off
Bluetooth LampGNSS Status Lamp
SMA Connector (Female)
SMA Connector (Male)
USB Type-A Connector
Professional Racing GNSS Receiver
Quick Start
Steps to Use
Connect the P-9 Race to the external active antenna, and
tighten the antenna connector clockwise.
Place the external active antenna in a position with a good
view of the sky, such as the roof of the car, the top of the
helmet.
The main unit of the P-9 Race is not waterproof.
The placement of the antenna significantly affects the
accuracy of the tracks. For more placement
suggestions, please visit:
cbgps.com/p9/q
9
External Active Antenna
(Magnetic Mount with Adhesive)

Connect to the Terminal Device
The P-9 Race supports two connection modes: wired and
wireless. Both connection modes are supported to connect
the device simultaneously.
DEVICE
12
DEVICE
3
The operating systems and connection modes supported by
the P-9 Race are as follows:
Linux
USB
SPP
USB
SPP
USB
SPP
BLE
USB OTG
SPP/BLE BLE
Plug the USB connector into
the computer.
Wired Connection
Plug the USB connector into
the mobile device via an OTG
cable.
44
How to connect with terminal device please visit:
cbgps.com/p9/q
Connect with the power
bank during portable use.
Bluetooth Connection
Connect with the car charger
while driving.
The P-9 Race supports two Bluetooth protocols:
BLE5.1 and SPP 2.1.
How to connect with the App, please visit:
55
cbgps.com/p9/q
BLE
5.1
SPP
2.1

The P-9 Race supports applications for multiple platforms,
please refer to the support page for usage.
We will continuously update the list of supported App.
56
cbgps.com/p9/q
How to Use the App
Protection class
External Active Antenna IP67
Operating temperature
-20 to +50 °C °C / -4 °F to +122 °F
Constellation
GPS (L1C/A, 1575.42MHz), BeiDou (B1I,
1561.098MHz), Galileo (E1-B/C, 1575.42MHz),
GLONASS (L1OF, 1602MHz), QZSS (L1C/A,
1575.42MHz), SBAS (EGNOS, GAGAN, MSAS, WAAS,
QZSS L1S)
Accuracy *
Horizontal: 0.7m/CEP(50%), 2.0m/CEP(95%)
Vertical: 15m
Acquisition time *
Reacquisition: <2s, Hot start: <2s, Cold start: <29s
Output sentences
Protocol: NMEA 0183
Messages: GNRMC, GNGGA, GNGSV, GNGSA (Default)
Geodesics
WGS84
Update rate
25Hz (Default)
Bluetooth
SPP 2.1, BLE 5.1
Range: >10m (33 feet)
Connectors
Antenna connectors: SMA
USB device: USB 2.0 Type-A
Power consumption
Antenna: DC 3.3V / 35mA
Main unit: DC 5V / 70mA
Dimensions (WxHxD)
Main unit: 65×18×10mm / 2.6×0.7×0.4in
Antenna feeder: 300cm / 9.8feet
Weight
Main unit: 22g / 0.74oz
Antenna: 118g / 4.2oz
* The test was done outdoor, in an open area.
On content unmentioned in the instruction, please visit the
official website at any time to learn about the latest use skill
and information.
Specifications
±
Reproduction, transfer, distribution or storage of part or all of
the contents in this document in any form without the prior
written permission of VICTORY is prohibited.
Under no circumstances shall VICTORY be responsible for
any loss of data or income or any special, incidental,
consequential or indirect damages howsoever caused.
is a trademark of Victory Co., Ltd.
Other product and company names mentioned herein may
be trademarks or trade names of their respective owners.
App Store Google Play
Trademark
