Comfort-n-Motion GS60 User manual

OWNER’S MANUAL—GS60
Customer Care
Toll Free 888-846-3840
Email: [e-mail]
by
WW. Silve. SilverrPPrroductsoducts
with
the touch
of a button”
“Changing
your life

Safety Information 3
Weight Restrictions 4
Cleaning 4
Parts List 5
Base Assembly 6
How to program two TwinXLs
to work as a King 7
Location of Controls on Remote 9
Resetting the Adjustable Bed Electronics 10
Troubleshooting 11
Warranty 12
Warranty Registration Form 14
Page 2
Contents
User Information
Please take a moment and write down the serial
number in the space provided below, in case you
need to refer to it in the future. This information
can be found on the side of the power supply, on the
underside of the adjustable base, on the outside of
the box on the main label and on the warranty regis-
tration card.
Model # GS60
Serial Number:

Safety Information
Attention!
Important safety instructions. Please
read this manual thoroughly before
using this product. Save this manual!
Electrical Safety
Always unplug this adjustable bed frame from the
electrical outlet before any maintenance or cleaning
of the frame. To safely disconnect, make sure all of the
controls are in the off position, and then remove the
plug from the outlet. To prevent re or shock hazard,
do not expose this unit to moisture. Keep the power
cord away from heated surfaces. Do not operate this
adjustable bed frame and contact the manufacturer
for repair if (1) it is not working properly, (2) it has
a damaged cord or plug, (3) it has been dropped or
damaged or (4) has been dropped into water.
Electrical Grounding
This product is equipped with a polarized or
grounded electrical power cord. The power cord will
only t into a grounded, electrical surge protection
device (not included) or a grounded electrical outlet.
The use of adapters is not recommended unless the
outlet is checked by a qualied electrician to ensure
the proper grounding of the adapter.
For optimal safety, your adjustable
bed should be plugged into a surge
protector.
Electrical Rating
Input—100-240V, 50/60Hz, 1.6A; Output
29VDC, 2.0A
Battery Precautions
Please follow these precautions when using bat-
teries in this adjustable bed frame:
1. Danger of explosion if the battery is incor-
rectly replaced. Replace only with the 6LR61
9V batteries and LR03 AAA batteries.
2. Do not mix different types of batteries toge-
ther (Alkaline, Rechargeable and Carbon-
Zinc) or old batteries with new batteries.
3. Be sure to follow the correct polarity when
installing new batteries as indicated in the
battery compartment.
4. If the adjustable bed is not going to be
used for a long period of time, remove the
batteries from the battery compartment
to prevent damage or injury from possible
battery leakage.
5. Do not attempt to recharge a battery that is
not intended to be recharged. This may result
in an overheating of the battery or rupture
that could result in injury.
In Home Use & Hospital Disclaimer
Your adjustable bed frame is strictly designed for
in-home use only. It is NOT designed for hospital use
and is NOT designed to meet hospital standards. Do
not use this bed with TENT TYPE oxygen therapy
equipment or near explosive gases.
Lubrication and Cleaning
Your adjustable bed is designed to be maintenance
free. The lift motors are permanently sealed and
lubricated, no additional lubrication is required. Do
not apply any lubricant to lift motor lead screws or
any nylon nuts or the base may inadvertently creep
downward from the elevated position.
Warranty Warning
Please do not open any control box, motors or hand
controls (with the exception of the battery compart-
ment, if equipped). The product warranty may be
void if any of these components are tampered with.
Do not attempt to alter component wiring or adjust
or modify the structure of the product in any way or
the warranty will be void. Only WSP can authorize
any repairs or replacement of parts on your adjus-
table bed.
Pets and Small Children Warning
Immediately dispose of all packing materials as it
may pose a smothering risk to small children and
pets To avoid injury, it is not advised to allow chil-
dren and small pets to play on or under the bed.
Children should not operate your adjustable bed
without adult supervision.
Page 3

Safety Information
Consumers with Pacemakers
Your adjustable bed may be equipped with a
massage motor that produces a vibrating motion. It
is possible that some pacemakers may interpret this
type of motion as a false sense of movement and/
or exercise. This may or may not affect your pace-
maker. If you have any concerns, please consult
your physician.
Your adjustable bed also contains Neodymium
(magnets) which may interfere with devices such
as pacemakers, ICD’s and any other device sensitive
to magnetic elds. It is strongly recommended that
owners of such medical devices consult their physi-
cian prior to using this product.
Product Ratings
The lift motors in your adjustable bed are NOT
designed for continuous use. Reliable operation and
full life expectancy will be attained as long as the
lift motors do not operate more than 2 minutes over
an 18 minute period, or approximately 10% duty
cycle. To ensure reliable functionality and full life of
your adjustable bed, do not attempt to exceed these
limits. Attempting to circumvent or exceed
this rating will shorten the life expectancy
of your adjustable bed and may void the
warranty.
Acoustics
Your adjustable bed may contain the optional
massage motor. This massage function will emit a
noticeable tone during operation. As the massage
intensity level is increased, the volume of the tone
will increase. The volume of the tone is directly
related to the location of your adjustable bed. As an
example, the surrounding environmental noise that
might have been present in the showroom where
you purchased your adjustable bed could have
covered some of the noise from your adjustable bed
massage motors. When your adjustable bed was
installed in your home you might notice an increase
in volume in wood oorings or carpets. In some
normal base operations, you might notice some noise
coming from the wheels which allow your adjustable
bed to maintain its distance from the wall. These
wheels will make contact with the steel platform
supports of your adjustable bed creating a contact
noise when you enter, exit or shift weight while on
the bed. This is normal.
FCC Compliance
This device complies with part 15 of the FCC rules.
Operation is subject to the following two condi-
tions: (1) This device may not cause harmful inter-
ference; (2) This device must accept any interfe-
rence received, including interference that may
cause undesired operation. To comply with the FCC
RF exposure compliance requirements, no change
to the antenna or the device is permitted. Any
change to the antenna or the device could result in
the device exceeding the RF exposure requirement
and void user’s authority to operate the device.
Radio Frequency is 2.4-2.48 GHz
Weight Restrictions
The structure of your adjustable bed will support
the recommended weight when distributed evenly
across the bed. The adjustable bed is not designed
to support or lift this amount in the head or foot
sections alone. You should enter and exit your
adjustable bed with the base in the at (horizontal)
position. DO NOT STAND ON THE BASE AT ANY
TIME. The recommended weight limits are Twin/
TwinXL/ Split Queen/Split Cal King: 450lbs., Full/
FullXL: 500 lbs., and Queen 600 lbs. Exceeding this
weight restriction could damage the bed and/or
cause injury and will void the warranty.
Moving After Installation
Do not place adjustable bed base vertically on its
head or foot sections. This may cause injury to
persons or damage to the base.
Fabric Cleaning Information
Spot clean only with a water based shampoo or a
foam upholstery cleaner. Pretest a small, incons-
picuous area before proceeding. Do not over wet
or use solvents to spot clean. Hot water extraction
or steam cleaning is not a recommended cleaning
method. To prevent overall soiling, frequent vacuu-
ming or light brushing with a non-metallic stiff bristle
brush to remove dust or grime is recommended.
PLEASE SAVE THIS MANUAL!
Page 4

Parts List
NOTE: BEFORE DISCARDING ANY PACKING
MATERIALS, CHECK THE CARDBOARD BOX
OF THE ADJUSTABLE BED AND VERIFY THE
FOLLOWING ITEMS ARE INCLUDED.
ALL ELECTRONICS AND COMPONENTS THAT
NEED TO BE INSTALLED ARE LOCATED IN
BOXES UNDER THE BASE OR ATTACHED TO
THE ADJUSTABLE BED FRAME.
Page 5
Remote Control
with AAA Batteries (1)
Mattress Retainer
Brackets Kit (1)
Power Supply (1)
Tools
needed
When using your
own headboard:
Plain screwdriver
and a 1/4”
wrench
Connecting
strap (1)
(only available
on Twin XL)
Legs (4)

Step 1
It is highly recommended to use two
people for the installation of this
product. Before assembly, place the
unit in the appropriate nal position
to make the assembly process easier.
The unit should be placed top side
down on the oor according to the box
instructions. Remove the 2 boxes included
and untie the mattress retainer.
Step 2
Screw in the provided legs (4) in each corner of the base
rotating clockwise until tight. DO NOT OVERTIGHTEN
THE LEGS.
Step 3
Remove the twist ties and
release the DC cord.
Step 5
Insert the AC cord into the
Power Supply and lock it
using the clip. NOTE: DO
NOT PLUG BASE INTO THE
POWER OUTLET YET.
Step 4
Plug the two 9 volt batteries
(included) in the compart-
ment of the Power Supply
and insert the cover to close.*
NOTE: THESE BACKUP BATTERIES WILL ALLOW THE BED TO BE LOWERED IF A POWER OUTAGE
OCCURS. IT IS RECOMMENDED NOT TO DO ANYTHING EXCEPT TO LOWER THE BED AS THE BATTERY
BACKUP WILL NOT ELEVATE THE BED SECTIONS.
*It is recommended to replace the two 9 volt batteries every 12 months. These backup batteries will allow the
bed to be lowered if a power outage occurs. It is also recommended not to do anything except to lower the
bed, as the battery backup will not elevate the bed section.
Page 6
Base Assembly

Page 7
Base Assembly
Step 6
If you are setting two Twin XL’s bases to use with one king size
mattress.
First, connect the power source to the control box of base number 1.
Place base number 2 besides base number 1 and connect its control box to the power
source.
On the remote control from base number 1 press the “head down” and “foot up”
buttons while at the same time pressing the Coding/Reset button on the control box of
base number 2. Do this until you hear a “beep” sound.
Your new King Size bed should be ready to work seamlessly with just one remote.
Control Box
from Base #2
otherwise, you can skip this step.

Base Assembly
Step 8
For safety reasons, the following step should be
performed by 2 people. Lift and rotate the bed to
its nal position, holding the metal frame. DO
NOT LEAN THE BED AGAINST THE
SIDE OF THE LEGS.
Step 10
Plug the power cord into a grounded electrical
outlet. NOTE: FOR OPTIMAL SAFETY,
A SURGE PROTECTOR SHOULD BE
USED (NOT SUPPLIED WITH THIS
ADJUSTABLE BED)
Step 9
Insert the
mattress
retainer into
the base.
1) attach the two
brackets with screws
and nuts provided
2) join the new part
to the bed frame as
you need it
3) after nishing the
assembly, you can
attach the legs of the
headboards to the
headboard brackets
using the nuts and
bolts that are provided.
Page 8
Step 7
If your bed has a
headboard, you can
use the optional Headboard
Bracket kit to attach the
base to your headboard. If
you do not require a
headboard bracket,
then you can skip
this step

Remote Control Operations
Head Down
Press and hold
to lower the head
Foot Down
Press and hold
to lower the foot
Head & Foot Off
Press to turn off
the massage motors
Zero/G
Press to achieve a
Zero-G position
LED Light
Press to turn on/off
the under bed light
Flat
Press to put the bed
in at position
Head Up
Press and hold
to raise the head
Foot Up
Press and hold
to raise the foot
Head & Foot On
Press to turn on
the massage motors
Page 9

Page 10
Resetting the Adjustable
Bed Electronics
Press the head down & the foot
up buttons while simultaneously
pressing the coding/reset button
until you hear a “beep” sound.
Coding / Reset Button
Your adjustable bed is already programmed to work
with the base. Please use this step in the event that
you need to reset the electronics. Skip this step during
initial installation.

Page 11
Troubleshooting
SYMPTOM
Remote control illuminates and
appears to be working, but no
features of the base will activate.
Remote control will
not illuminate.
No features on the bed
will operate
Head or foot section will elevate,
but will not return to the hori-
zontal (at) position.
Head or foot lift function has
minor interference during
operation.
Massage motors seem excessi-
vely loud during operation
SOLUTION
• Verify the power cord is plugged into a working grounded elec-
trical outlet. A grounded, electrical surge protector device is recom-
mended. Test the outlet by plugging in another appliance that you
know works properly.
• Replace the batteries in the remote control.
• Verify the batteries are installed correctly in the remote control.
• Re-Program the remote control (as indicated in page 10)
• Unplug the power cord and wait 45 seconds before plugging the
cord back into an electrical outlet.
• The electrical circuit breaker in your home may have been tripped.
Check your electrical service breaker box and reset if necessary.
• The surge protection device or electrical outlet may be defective.
Test the outlet by plugging in another working appliance.
• The base mechanism may be obstructed. Elevate the base and check
for obstruction and remove the obstruction if necessary.
• The headboard may be too close to the edge of the mattress. Verify
that the distance between the headboard brackets and the mattress
is 1.5” (38.1mm) to 2” (50.8mm) and adjust if required.
• The head section may be too close to the wall. Adjust if necessary.
• Remove the battery cover on the hand remote and replace the batte-
ries if necessary.
• Make sure you are following the duty cycle of the motor (do not
operate over 2 minutes over an 18 minute period, or approximately
10% duty cycle).
• The hand remote may be experiencing common radio frequency
interference from other radio transmitting devices.
• Press the lift buttons squarely and accurately.
• If the base is located on a hard surface, place rubber caster cups or
carpet pieces under each leg.
• Elevate the head or foot section a short distance (with the remote
control) to realign the lift/lower mechanisms with the base support.
• If the base is installed over a bed frame, then make sure the massage
motors are not causing the bed frame, or it’s components, to vibrate.
• Verify the headboard attachment hardware is securely fastened, if
being used.

Page 12
W. Silver Products
20 Year Limited Warranty
W. Silver Products (“WSP”) extends this 20
Year Limited Warranty to the original consumer
purchaser (hereinafter referred to as the
“purchaser”) of this adjustable bed to be warranted
against defects in materials or workmanship as
provided herein. This Limited Warranty is not trans-
ferrable and the coverage will terminate if the
purchaser sells or otherwise transfers the product.
This warranty begins on the “warranty commen-
cement date,” or the purchase date for new and
unused adjustable beds. In the event your adjus-
table bed was used for a display model, the
“warranty commencement date” is the date the
adjustable bed was manufactured. Therefore, a
display model is only covered by a portion of the
limited warranty. The purchaser must show original
proof of purchase for any warranty to be valid. If
proof of purchase is not presented to WSP, then
WSP shall have the nal option to determine if the
adjustable bed is covered by any portion of this
Limited Warranty. WSP retains the option of using
the manufacturing date as the warranty commence-
ment date. This warranty is not transferrable and is
extended solely to the original purchaser
Year 1: Full Coverage of Parts and Labor
This adjustable bed is warranted against defects in
the workmanship or materials for a period of up to
(1) year for the date of purchase and for up to (1)
year from the date of manufacture for those beds
that were purchased as display models. When noti-
ed by the purchaser within the rst year, WSP
will supply replacement parts (at no cost to the
purchaser) for any defective or malfunctioning
adjustable bed part. WSP must approve the part
is defective or malfunctioning. Once approval is
granted by WSP, WSP will authorize all labor costs
and transportation costs associated with the repair
or replacement. All defective or malfunctioning
parts must be returned to WSP within 15 days or
this (1) year warranty shall not apply.
Years 2 & 3: Full Coverage of Parts Only
If the defect or malfunction occurs during the
second or third year from the Warranty Commen-
cement Date, WSP will replace any defective or
malfunctioning part that is not excluded by this
warranty. The purchaser is responsible for all
service, transportation, labor and shipping and
handling costs related to the delivery and/or repla-
cement of the defective or malfunctioning part(s).
This 2 & 3 Year Parts Warranty is valid once the
purchaser returns all defective or malfunctioning
parts to WSP, or by an authorized WSP in-home
technician or agent within 15 days.
Years 4 through 20: Pro-rated Coverage of
Non-Electrical Parts Only
Starting in the fourth year from the Warranty
Commencement Date and through the end of the
20th year from the Warranty Commencement Date,
WSP will issue replacement parts for any mecha-
nical part found to be defective or malfunctio-
ning. This does not apply to electronics, electrical
components, massage motors and lift motors. The
purchaser is responsible to pay all service and trans-
portation costs related to receiving and installa-
tion of the new part and a portion of the cost of
the defective or malfunctioning mechanical part.
The Purchaser will be required to pay 1/17th of the
(then) current replacement cost of the part multi-
plied by the number of years past the third year
from the Warranty Commencement Date. This
seventeen (17) year warranty is valid once the
purchaser returns all defective or malfunctioning
parts to WSP, or by an authorized WSP in-home
technician or agent within 15 days.
Additional Terms and Conditions
This Limited Warranty does not include reimburse-
ment for inconvenience, removal, part (s) installa-
tion, bed set up, loss of use, shipping, set-up time or
any other costs or expensed not expressly covered
in this warranty.
This warranty does not apply: (a) if any damage

Page 13
W. Silver Products
20 Year Limited Warranty
to the adjustable bed caused by the purchaser;
(b) if there has been any unauthorized repair or
replacement parts; (c) if the adjustable bed has
been damaged caused by mishandling during
transit or by other means, subjected to physical
or electrical abuse or misuse, or otherwise
operated in any way inconsistent with the opera-
tion and maintenance procedures outlined in the
Owner’s Manual, this limited warranty, and any
other applicable document published or approved
by WSP; (d) to damaged mattresses, bedding
cables, electrical cords fabric or any other items
supplied by dealers (also known as resellers or
retailers); (e) to modication of the adjustable
bed without prior written consent by WSP; (f)
to costs for unauthorized service calls for the
purpose of educating the consumer about the
adjustable base or locating proper functioning
power outlets; (g) if the recommended weight
restrictions are exceeded; (h) if used in any envi-
ronment or a commercial setting which was not
intended, such as but not limited to dormito-
ries, hotels and rentals and (i) Damage to the
foam shroud by improper handling or misuse.
WSP holds no responsibility for in-home service
on adjustable beds. WSP and its service techni-
cians will not be responsible for moving furniture
or any other items not attached to the adjustable
bed in order to perform service on the adjus-
table bed. Purchaser should contact his dealer
for any terms and conditions relating to purcha-
ser’s in-home service if any. Removal of product
tag shall void warranty. The product tag has both
the model number and the serial numbers which
serves as a means of identity.
For replacement to the Purchaser’s adjustable bed
or its components under the terms of this limited
warranty does not extend the applicable warranty
from the Warranty Commencement Date.
The decision to repair or to replace defective parts
under this warranty shall be made, or cause to be
made, by WSP at its option and in its sole discre-
tion.
This Limited Warranty replaces all other warranties
expressed or implied including the implied warran-
ties of merchantibility and tness for purpose and
no one is authorized to assume or undertake for
WSP other liability in connection with the sale of
the product. WSP shall not be liable for any conse-
quential or indirect damage of whatever kind, inclu-
ding personal injuries or damage to property, except
as provided herein.
Some states do not allow the exclusion of inci-
dental or consequential damages, therefor the
above limitation or exclusion many not apply. The
warranty gives the purchaser specic legal rights.
The purchaser may have other legal rights that vary
from state to state. This warranty is valid in all 50
states. This warranty is non-transferable.
Weight Limits:
The recommended weight limits are Twin/TwinXL/
Split Queen/Split Cal King: 450 lbs., Full/FullXL:
500 lbs., and Queen 600 lbs. This product is not
rated to support weights in excess of these amounts
inclusive of the matress and bedding. The base
will structurally support this weight, provided it is
evenly distributed across the bed base. The adjus-
table base is not designed to support or lift this
amount in the head or foot sections alone. Excee-
ding this weight restriction could damage the bed
and/or cause injury and will void the warranty.
20
YEAR
WSP

Page 14
Warranty Registration
*First Name: *Last Name:
*Address:
*City: *State: *Zip Code:
*Email:
*Phone Number: *Date of Purchase:
*Model Number: *Size of Base: *Price Paid:
*Serial Number:
*Store Where Purchased: *City: *State:
*Store Invoice Number:
EMAIL, MAIL or FAX A COPY OF YOUR PROOF OF PURCHASE
TO:
W. SILVER PRODUCTS
ATTN: WARRANTY/CLAIMS DEPARTMENT
P.O. BOX 12904
EL PASO, TEXAS 79913
Email: [e-mail]
Fax: [phone]
Or register online:
comfort-n-motion.com or wsilverproducts.com

Customer Care
Toll Free 888-846-3840
Email: [e-mail]
