Comica CVM-VM10-K5 User manual

User Manual
VM10-K5
Multi-functional Smartphone Video Kit

Foreword
Main Features
Thanks for purchasing CVM-VM10-K5 Multi-functional Smartphone Video Kit
. 360° Adjustable Rotation Ball Head, Support Horizontal and Vertical Shooting
. Equipped with Cold Shoe Rod for Matching Dierent Accessories
. Integrated with Bi-color LED Light for Versatile Shooting
. Professional Microphone, Cardioid Pattern
. Adjustable Width of Smartphone Holder, Wide Range of Applications
. Loading up to 3.5kg for Stable Usage
Notice
Packing List
Do not use this equipment in the vicinity of heat source or interference source
This product belongs to high-precision instruments, please avoid falling, collision or
pounding
Do not use the equipment in rain or in a damp environment to avoid short-circuit
danger
User Manual
VM10-K5
Multi-functional Smartphone Video Kit
Cold Shoe RodMicrophone Shock Mount LED Light
Wind MuSmartphone Clamp Ball Head Tripod
Warranty Card3.5mm TRS – TRRS Audio Cable Charging Cable User Manual
1

Power Switch Button: Long press to turn on or o
Color Temperature/Brightness Switch Button: Short press to switch color
temperature or brightness. The red light shows the color temperature, and the
blue light shows the brightness
Color Temperature/Brightness+: Short or long press to increase the color
temperature or brightness
Color Temperature/Brightness－: Short or long press to reduce the color
temperature or brightness
USB-C Charge Port: Connect the LED light with the external power through the
charging cable to charge
Power Indicator Light: There are four power indicator lights, one of
which represents 25% of the power
Components Introduction
Color Temperature/Brightness
Switch Button
Power Switch Button
Cold Shoe
Color Temperature/Brightness+
Color Temperature/Brightness－
Cold Shoe
USB-C Charge Port
1/4 Threaded Hole
Cold Shoe
Cold Shoe Mount
2

3.5mm TRS Audio Output Port: It can be inserted with 3.5mm TRS audio
cable for audio output
3.5mm TRS Audio Output Port
1/4 Threaded Hole
Cold Shoe Mount
Windscreen
3

Cold Shoe Mount
Cold Shoe
Screwing Plate
Locking Plate
1/4 Male Screw
Lever
1/4 Male Screw
Cold Shoe Rod
Additional accessories can be attached to the cold shoe rod
4

Shooting Horizontally (With Cold Shoe Rod)：
1. Install as shown below
Installation and Operation
5

2. Adjust the smartphone clamp to an appropriate height through the screwing plate,
then install the smartphone and fix it
3. Connect the microphone and smartphone through the 3.5mm TRS-TRRS audio
cable. TRS plug is for microphone, TRRS plug is for smartphone
TRS Plug TRRS Plug
6

Shooting Horizontally (Without Cold Shoe Rod)：
1. Install as shown below
7

2. Connect the microphone and smartphone through the 3.5mm TRS-TRRS audio
cable. TRS plug is for microphone, TRRS plug is for smartphone
8

Shooting Vertically：
1. Install as shown below
9

2. Rotate the smartphone clamp through 90° via the lever, then connect microphone
and smartphone through the 3.5mm TRS-TRRS audio cable
Lever
90°
10

Specification
Microphone：
Polar Pattern
Frequency Response
S/N
Maximum SPL
Sensitivity Range
Operating Voltage
Output Interface
Dimensions
Net Weight
Operating Temperature
Storage Temperature
Cardioid
60Hz ~ 20KHz
>75dB
>105dB
-35dB±2dB
1V~5V DC
3.5mm TRS Interface
Φ21mm x 85mm
35g
0~50℃
-10~60°
Power
Color Temperature Range
Brightness Range
Battery Capacity
Duration
Weight
Size
Operating Temperature
Storage Temperature
MAX:3.7W
3200K-6500K
0.5m：≥430LUX
0.3m：≥1100LUX
Lithium-polymer Battery(3.7V/1000mAh)
80±5% MINS(Duration under the brightest conditions)
75g
85*55*20mm
0~55°C
-10~60°C
LED Light：
