Commax DRC-4FC User manual

•Thank you for purchasing COMMAX products.
•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
•The company is not responsible for any safety accidents caused by abnormal operation of the product.
Door Camera DRC-4FC
User Manual

2. Installation & Wiring
1. O er iew
LED & Sensor
Microphone
Camera Lens
Speaker
Call Button
Screw Hole
Door Release
Connection
Monitor
Connection
Terminal
❶Secure it to the wall hole and wall
❷Wire the household monitor cables
[FIG-2] (#1:Voice, #2:GND,
❸In the wall-hanging, check the screen
and check if the screen is working
❹Wire the switch cables as shown
❺Fix it at the bottom of the product
T4X18
Screw Cover
Wrench M4x10
mounted hole to install. [FIG-1]
with matched polarity as shown below.
of monitor inserted from the groove
well as you want.
below. [FIG-2]
with screw.[FIG-1]
#3:DC12V, #4:Video)
[Installation]
[Wiring]
olume Control
( [ - ] driver avilable)
[FIG.2]
[FIG.1]
▶Position of camera
66.5°

4. Specifications
MODEL NO. DRC-4FC
Raged Viltage 12V (From Monitor)
Wiring 4 Wire In Polarity
(House/Door Release) 2 Wire In Non-polarity
Pickup Device 1/3" CMOS IMAGE SENSOR (0.41Mega)
Conversation Method Synchronous
TV System NTSC or PAL
Min. Illumination 0.1 LUX (300mm From Camera)
Illumination White LED(3pie) 2EA
Image Adjustment Horizontal 82 °, Vertical 66.5 °
ANGLE ADJUSTMENT Up Down Left Right 12°
Operating Temperature -10°C(tested up to -40°C) ~ +50°C
Dimension (mm) 119.4(W) x 178(H) x 20.1(D)
Distance(TIV Cable) Diameter (pie) 0.5 0.65 0.8 1
Distance(Miter) 28 50 70 115
3. PARTS
DRC-4FC WALL BRACKET
MOUNTING
SCREW SCREW
WLENCH
MANUAL
SCREW
COVER
HEXAGON MOUNTING
T4X18
WLENCH
M4x10
SCREW
WHM M3x30
(HEXAGON 3x30)

Printed In Korea / 2016.04.105
513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea
Int’l Business Dept. : Tel.; [phone]~550 Fax.; [phone]
Web site : www.commax.com
