SERVICE MANUAL
1581
3.5 DISK DRIVE
JUNE 1987 PN-314982-01
Commodore Business Machines, Inc.
1200 Wilson Drive, West Chester, Pennsylvania 19380 U.S.A.
Commodore makes no expressed or implied war
ranties with regard to the information contained
herein. The information is made available solely on
an as is basis, and the entire risk as to quality and
accuracy is with the user. Commodore shall not be
liable for any consequential or incidental damages
in connection with the use of the information con
tained herein. The listing of any available replace
ment part herein does not constitute in any case
a recommendation, warranty or guaranty as to
quality or suitability of such replacement part.
Reproduction or use without expressed permission,
of editorial or pictorial content, in any matter is
prohibited.
' This manual contains copyrighted and proprietary information. No part
of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written permis
sion of Commodore Electronics Limited.
Copyright © 1987 by Commodore Electronics Limited.
All rights reserved.

1581 SERVICE MANUAL
TABLE OF CONTENTS
TITLE PAGE
GENERAL SPECIFICATIONS
CHARACTERISTICS 1
HARDWARE SUMMARY 1
SPECIFICATIONS 1
FORMAT ORGANIZATION 2
MEMORY MAP — I/O 2
MEMORY MAP — RAM 3
SERIAL INTERFACE 3
PROGRAMMABLE BAUD RATE 4
SELF TEST DIAGNOSTICS 4
CHIP SPECIFICATIONS
6502 MPU 5
8520A CIA 7
WD1770 FDC 9
PARTS LIST — MAJOR/COMPONENT 12
ASSEMBLY DRAWING 13
BOARD LAYOUT 14
SCHEMATICS 15

1581 SERVICE MANUAL
GENERAL SPECIFICATIONS
1 CHARACTERISTICS
A) 3.5 inch, +800K storage
B) Increased buffers, fixed BAM locations
C) Expanded controller commands
D) Track cache buffer
E) Configurable auto boot file
F) User alterable physical/logical track and sector translation
G) Fully vectored jump table
H) Partition capabilities
I) Wild card enhancements
J) Standard, fast and burst serial capabilities
K) Expanded burst command set
2 HARDWARE SUMMARY
PROCESSORS: 6502A, WD1770
ROM: 32K
RAM: 8K
I/O: 8520A
3 SPECIFICATIONS
GROSS DATA ORGANIZATION:
3.5 Inch Disk
Double-Sided
80 Cylinders/160 Tracks
PER TRACK ORGANIZATION:
Hex 4E written as a gap, with 10 sectors of data, with full gaps written for motor
speed variation.
PER SECTOR ORGANIZATION:
MFM Encoding
12 Bytes of 00
3 Bytes of Hex A1 (Data Hex A1, Clock Hex 0A)
1 Byte of FE (ID Address Mark)
1 Byte (Track Number)
1 Byte (Side Number)
1 Byte (Sector Number)
1 Byte (Sector Length, 02 for 512 Byte Sectors)
2 Bytes CRC (Cyclic Redundancy Check)
22 Bytes of Hex 22

1581 SERVICE MANUAL
STORAGE:
SPECIFICATIONS (continued)
12 Bytes of 00
3 Bytes of Hex A1 (Data Hex A1, Clock Hex 0A)
1 Byte of Hex FB (Data Address Mark)
512 Bytes of Data
2 Bytes of CRC (Cyclic Redundancy Check)
38 Bytes of Hex 4E
FORMAT ORGANIZATION
PHYSICAL:
Cylinders 0 thru 79
Sectors 1 thru 10 on Side 1
Sectors 1 thru 10 on Side 2
Sector Size 512
LOGICAL:
Tracks 1 thru 80
Sectors 0 thru 39 (Using physical Sectors 1 ...10 — Side 1 and 2)
Sector Size 256 Bytes
Total Unformatted Capacity 1 Megabyte
Total Formatted Capacity 808, 960 Bytes
Maximum Sequential File Size 802, 640 Bytes
Maximum Relative File Size 182, 880 Bytes
Records Per File 65, 535
Files Per Diskette *296
Cylinders Per Diskette 80
Logical Sectors Per Cylinder 40
Physical Sectors Per Cylinder 20
Logical Bytes Per Sector 256
Physical Bytes Per Sector 512
Free Blocks Per Disk 3160
*More with Sub-Disk Partitioning
MEMORY MAP — I/O LOCATIONS
8Kx8 RAM $0002-$1FFF
8520A $4000-$4010 Controller, Serial Bus
WD 1770 $6000-$6003 MFM Disk Controller
32K x 8 ROM $8000-$FFFF DOS, Controller Code

1581 SERVICE MANUAL
n
6 MEMORY MAP — RAM USAGE
$0002-$00FF Zero Page Variables
$0100-$01FF Vectors, Variables and Stack Area
$0200-$02FF Command/Error Buffer and Variables
$0300-$03FF Buffer #0
$0400-$04FF Buffer #1
$0500-$05FF Buffer #2
$0600-$06FF Buffer #3
$0700-$07FF Buffer #4
$0800-$08FF Buffer #5
$0900-$09FF Buffer #6
$0A00-$0AFF BAM
$0B00-$0BFF BAM
$0C00-$1FFF Track Cache Buffer
7 COMMODORE SERIAL INTERFACE
The 1581 supports Standard, Fast, and Fast Serial communication like the 1571.
A HRF (Host Request Fast) command places the drive in fast serial mode. The 1581 remains in
fast serial mode until an Unlisten, Untalk, or serial bus error. The 1581 will also source a DRF (Device
Request Fast) message. This message lets the host know that the addressed peripheral can receive
bytes fast (or slow).
The bus consists of the following:
PIN 1 — SRQ (Service Request)
Unused by the current serial bus. Fast serial will use this line as a bi-direction fast clock line.
PIN 2 — GND
Chassis ground.
PIN 3 — ATN(in)
The host brings this signal low which then generates an interrupt on the controller board. The
attention sequence is followed by an address. If the device does not respond within a preset
time, the host will assume the device addressed is not on the bus.
PIN 4 — CLK (in/out)
This signal is used for timing the data sent on the serial bus (software clocked).
PIN 5 — DATA (in/out)
Data on the serial bus is transmitted one bit at a time (software toggled). In addition, this line
is wire 'ored' and used as a FAST DATA line to compliment the FAST CLOCK on the SRQ line.
PIN 6 — RESET
> This line will reset the peripheral upon host reset.

1581 SERVICE MANUAL
8 PROGRAMMABLE BAUD RATE GENERATOR
The 8520 contains a programmable baud rate generator which is used for fast serial transfers. Timer
A is used for the baud rate generator. In the output mode data is shifted out on SP at 1/2 the underflow
rate of Timer A. The maximum baud rate possible is phi 2 divided by 4, but the maximum usable
baud rate will be determined by line loading and the speed at which the receiver responds to the
input data. Transmission will start following a write to the Serial Data Register (provided Timer A
is running and in continuous mode). The clock derived from Timer A appears on the CNT pin. The
Data in the Serial Data Register will be loaded into the shift register then shifted out to the SP pin.
After 8 pulses on the CNT pin, a bit in the ICR (interrupt control register) is set and if desired, an
interrupt may be generated. All incoming fast bytes generate an interrupt within the Fast Serial Drive.
Bytes are shifted out; most significant bit first.
NOTE: When the 8520 is put in output mode the SP pin (data) will go low.
Baud Rate
Phi2 = 2MHz
166k
143k
100k
50k
25k
12.5k
Hi
Timer
Value
00
00
00
00
00
00
Low
Timer
Value
06
07
10
20
40
80
9 SELF TEST DIAGNOSTICS
The 1581 performs a self-test of RAM, ROM, and Controller. If an error is detected, the DOS will
blink all LED's a specific number of times. The flash code is repeated continuously.
# OF FLASHES
RESOURCE
COMPONENT
1
2
3
Zero Page
ROM
100H-1FFFH
8K x 8 RAM
25256
8K x 8 RAM
In addition, the 1581 performs a Controller Test. If a failure is detected, the error channel will con
tain 76, controller error 00,00. If an extensive test of ROM is required, the 1581 provides a signature
analysis via command 'UO>T'. If a failure is detected, the LED's will blink 4 times continuously.
4

1581 SERVICE MANUAL
6502 MICROPROCESSOR
Features of 6502
65K Addressable Bytes of Memory (A0-A15)
TR(5 Interrupt
On-the-chip Clock
TTL Level Single Phase Input
RC Time Base Input
Crystal Time Base Input
SYNC Signal
(can be used for single instruction execution)
RDY Signal
(can be used to halt or single cycle execution)
Two-Phase Output Clock for Timing of
Support Chips
NMT Interrupt
vss-
RDY-
Trq-
N.C.-
NMI-
SYNC-
VCC-
AO-
A1-
A2-
A3-
A4-
A5-
A6-
A7-
A8-
A9-
A1O-
A11-
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
40
39
38
37
36
35
34
33
32
6502 3-|
/iPRO- 30
CESSOR 29
28
27
26
25
24
23
22
21
RES
02(OUT)
S.O.
N.C.
N.C.
R/W
DO
D1
D2
D3
D4
D5
D6
D7
A15
A14
A13
A12
VSS
ADDRESS J
BUS A
r
A0 -«—
A1 -«—
A2 -*-
A3 ^~
A 4 -<—
A5 -*—
A6 -*-
A7 **-
A8 -*—
A9 ^_
A10 **—
A11 -«—
A12 -*—
A13 -«—
A14 -<—
A15 -<—
6512,13,14,15
6502.3.4.5,6.7

1581 SERVICE MANUAL
^ 6502 SIGNAL DESCRIPTION
Clocks (O19 02) - The 651X requires a two phase non-overlapping clock that runs at the Vcc voltage level.
The 650X clocks are supplied with an internal clock generator. The frequency of these clocks is externally
controlled.
Address Bus (A0-A15) — These outputs are TTL compatible, capable of driving one standard TTL load and 130 pf.
Data Bus (D0-D7) — Eight pins are used for the data bus. This is a bi-directional bus, transferring data to and
from the device and peripherals. The outputs are tri-state buffers capable of driving one standard TTL load and
130 pf.
Data Bus Enable (DBE) — This TTL compatible input allows external control of the tri-state data output buffers
and will enable the microprocessor bus driver when in the high state. In normal operation, DBE would be driven
by the phase two (02) clock, thus allowing data output from microprocessor only during 02. During the read
cycle, the data bus drivers are internally disabled, becoming essentially an open circuit. To disable data bus
drivers externally, DBE should be held low.
Ready (RDY) — This input signal allows the user to single cycle the microprocessor on all cycles except write
cycles. A negative transition to the low state during, or coincident with, phase one (O1) and up to 100ns after
phase two (02) will halt the microprocessor with the output address lines reflecting the current address being
fetched. This condition will remain through a subsequent phase two (02) in which the Ready signal is low. This
feature allows microprocessor interfacing with low speed PROMS as well as fast (max. 2 cycle) Direct Memory
Access (DMA). If Ready is low during a write cycle, it is ignored until the following read operation.
Interrupt Request (IRQ) — This TTL level input requests that an interrupt sequence begin within the
microprocessor. The microprocessor will complete the current instruction being executed before recognizing
the request. At that time, the interrupt mask bit in the Status Code Register will be examined. If the interrupt
mask flag is not set, the microprocessor will begin an interrupt sequence. The Program Counter and Processor
Status Register are stored in the stack. The microprocessor will then set the interrupt mask flag high so that
[) no further interrupts may occur. At the end of this cycle, the program counter low will be loaded from address
FFFE, and program counter high from location FFFF, therefore, transferring program control to the memory vec
tor located at these addresses. The RDY signal must be in high state for any interrupt to be recognized. A 3KQ
external resistor should be used for proper wire-OR operation.
Non-Maskable Interrupt (NMI) — A negative going edge on this input requests that a non-maskable interrupt
sequence be generated within the microprocessor. NMI is an unconditional interrupt. Following completion of
the current instruction, the sequence of operations defined for IRQ will be performed, regardless of the interrupt
mask flag status. The vector address loaded into the program counter, low and high, are locations FFFA and
FFFB respectively, thereby transferring program control to the memory vector located at these addresses. The
instructions loaded at these locations cause the microprocessor to branch to a non-maskable interrupt routine
in memory. NMI also requires an external 3KQ resistor to Vcc for proper wire-OR operations. Inputs IRQ and NMI
are hardware interrupt lines that are sampled during 02 (phase 2) and will begin the appropriate interrupt routine
on the O1 (phase 1) following the completion of the current instruction.
Set Overflow Flag (S.O.) — A NEGATIVE going edge on this input sets the overflow bit in the Status Code
Register. This signal is sampled on the trailing edge of d.
SYNC — This output line is provided to identify those cycles in which the microprocessor is doing an OP CODE
fetch. The SYNC line goes high during O1 of an OP CODE fetch and stays high for the remainder of that cycle.
If the RDY line is pulled low during the O1 clock pulse in which SYNC went high, the processor will stop in its
current state and will remain in the state until the RDY line goes high. In this manner, the SYNC signal can
be used to control RDY to cause single instruction execution.
Reset — This input is used to reset or start the microprocessor from a power down condition. During the time
that this line is held low, writing to or from the microprocessor is inhibited. When a positive edge is detected
on the input, the microprocessor will immediately begin the reset sequence. After a system initialization time
of six clock cycles, the mask interrupt flag will be set and the microprocessor will load the program counter
from the memory vector locations FFFC and FFFD. This is the start location for program control. After Vcc reaches
4.75 volts in a power up routine, reset must be held low for at least two clock cycles. At this time the R/W
/""""^ and (SYNC) signal will become valid. When the reset signal goes high following these two clock cycles, the
microprocessor will proceed with the normal reset procedure detailed above.

1581 SERVICE MANUAL
8520A COMPLEX INTERFACE ADAPTER
vss-
PAO-
PA1-
PA2-
PA3-
PA4-
PA5-
PA6-
PA7-
PBO-
PB1-
PB2-
PB3-
PB4-
PB5-
PB6-
PB7-
PC-
TOD-
VCC-
1
2
3
4
CJI
6
7
8
9
10 8520
11 CIA
12
13
14
15
16
17
18
19
20
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
-CNT
-SP
-RSO
-RS1
-RS2
-RS3
-RES
-DBO
-DB1
-DB2
-DB3
-DB4
-DB5
-DB6
-DB7
-02
-FLAG
-CS
-R/W
-IRQ
INTERFACE SIGNALS
02 Clock Input — The 02 clock is a TTL, compatible input used for internal device operation and as a timing
reference for communicating with the system data bus.
CS — Chip Select Input — The CS input controls the activity of the 8520. A low level on CS while 02 is high
causes the device to respond to signals on the R/W and address (RS) lines. A high on CS prevents these lines
from controlling the 8520. The CS line is normally activated (low) at 02 by the appropriate address combination.
R/W—Read/Write Input — The R/W signal is normally supplied by the microprocessor and controls the direction
of data transfers of the 8520. A high on R/W indicates a read (data transfer out of the 8520), while a low indicates
a write (data transfer into the 8520).
RS3-RS0 — Address Inputs — The address inputs select the internal registers as described by the Register Map.
DB7-DB0 — Data Bus Inputs/Outputs — The eight bit data bus transfers information between the 8520 and
the system data bus. These pins are high impedance inputs unless CS is low and R/W and 02 are high, to read
the device. During this read, the data bus output buffers are enabled, driving the data from the selected register
onto the system data bus.
IRQ — Interrupt Request Output — IRQ is an open drain output normally connected to the processor interrupt
input. An external pullup resistor holds the signal high, allowing multiple IRQ-outputs to be connected together
The IRQ output is normally off (high impedance) and is activated low as indicated in the functional description.
RES — Reset Input — A low on the RES pin resets all internal registers. The port pins are set as inputs and
port registers to zero (although a read of the ports will return all highs because of passive pullups) The timer
control registers are set to zero and the timer latches to all ones. All other registers are reset to zero

1581 SERVICE MANUAL
REGISTER MAP
D0-D7
DATA BASE BUFFERS!
SP<
CNT <
FLAG
IRQ
SP SERIAL
PORT
PRA
DORA
PA
BUFFERS
»PA0-PA7
PB0-PB7
A A A A A ATI
S3
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
RS2
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
RS1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
R/W 02
RSO
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
CS RS3
REG
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
RS2 RSI RSO
PRA
PRB
DDRA
DDRB
TALO
TAHI
TBLO
TB HI
SDR
ICR
CRA
CRB
RES
Peripheral Data Reg. A
Peripheral Data Reg. B
Data Direction Reg. A
Data Direction Reg. B
Timer A Low Register
Timer A High Register
Timer B Low Register
Timer B High Register
Event LSB
Event 8-15
Event MSB
No Connect
Serial Data Register
Interrupt Control Register
Control Register A
Control Register B
8

1581 SERVICE MANUAL
WD1770 FLOPPY DISK CONTROLLER
cs-
R/W-
A0-
A1-
DALO-
DAL1-
DAL2-
DAL3-
DAL4-
DAL5-
DAL6-
DAL7-
MR-
GND-
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
-INTRQ
-DRQ
-DDEN
-WPRT
-IP
-TR00
-WD
-WG
-MO
-RD
-CLK
-DIRC
-STEP
-vcc
1
2
3,4
CS
R/W
A0,A1
CHIP SELECT
READ/WRITE
ADDRESS 0,1
5-12 DALO- DATA ACCESS
DAL7 LINES 0 THRU 7
13 MR MASTER RESET
14 GND GROUND
15 Vcc POWER SUPPLY
16 STEP STEP
17 DIRC DIRECTION
18 CLK CLOCK
19 RD READ DATA
20 MO MOTOR ON
21 WG WRITE GATE
22 WD WRITE DATA
23 TROO TRACKOO
24 IP INDEX PULSE
25 WPRT WRITE PROTECT
26 DDEN DOUBLE DENSITY
ENABLE
27 DRQ DATA REQUEST
28 INTRQ INTERRUPT
REQUEST
CS
0
0
0
0
A1
0
0
1
1
AO R/W = 1
0 Status Reg
1 Track Reg
0 Sector Reg
1 Data Reg
A logic low on this input selects the chip and enable Host communication with the
device.
A logic high on this input controls the placement of data on the D0-D7 lines from
a selected register, while a logic low causes a write operation to a selected register.
These two inputs select a register to Read/Write data:
R/w = 0
Command Reg
Track Reg
Sector Reg
Data Reg
Eight bit bidirectional bus used for transfer of data, control, or status. This bus is
enabled by CS and R/W. Each line will drive one TTL load.
A logic low pulse on this line resets the device and initializes the status register (in
ternal pull-up).
Ground.
+ 5V ±5% power supply input.
The Step output contains a pulse for each step of the drive's RW head. The WD1770
and WD1772 offer different step rates.
The Direction output is high when stepping in towards the center of the diskette,
and low when stepping out.
This input requires a free-running 50% duty cycle clock (for internal timing) at 8 MHZ
±1%.
This active low input is the raw data line containing both clock and data pulses from
the drive.
Active high output used to enable the spindle motor prior to read, write or stepping
operations.
This output is made valid prior to writing on the diskette.
FM or MFM clock and data pulses are placed on this line to be written on the diskette.
This active low input informs the WD1770 that the drive's R/W heads are position
ed over Track zero (internal pull-up).
This active low input informs the WD1 770 when the physical index hole has been
encountered on the diskette (internal pull-up).
This input is sampled whenever a Write Command is received. A logic low on this
line will prevent any Write Command from executing (internal pull-up).
This input pin selects either single (FM) or double (MFM) density. When DDEN = 0,
double density is selected (internal pull-up).
This Active high output indicates that the data register is full (on a READ) or empty
(on a Write operation).
This Active high output is set at the completion of any command or reset or read
of the status register.
9

1581 SERVICE MANUAL
DATA OUT
BUFFERS
DATA
REG.
COMMAND
REG.
DATA
SHIFT
REG.
SECTOR
REG.
AM DETECTOR
TRACK
REG.
STATUS
REG.
WRITE
PRECOMP
DATA
SEPERATOR
^ DRO
^ INTRO
MR
CS
R/W
AO
A1
CLK(8 MHZ)
DDEN
w
COMPUTER
INTERFACE
CONTROL
CONTROL
PLA
CONTROL
(240 X 19)
CONTROL
DISK
INTERFACE
CONTROL
WG
WPRT
IP
TROO
STEP
niRr
MOTOR ON
-►
-►
ARCHITECTURE
The Floppy Disk Formatter block diagram is illustrated on page 11. The primary sections include the parallel processor
interface and the Floppy Disk Interface.
Data Shift Register — This 8-bit register assembles serial data from the Read Data input (RD) during Read
operations and transfers serial data to the Write Data output during Write operations.
Data Register — This 8-bit register is used as a holding register during Disk Read and Write operations. In Disk Read
operations, the assembled data byte is transferred in parallel to the Data Register from the Data Shift Register. In Disk
Write operations, information is transferred in parallel from the Data Register to the Data Shift Register.
When executing the Seek command, the Data Register holds the address of the desired Track position. This register
is loaded from the DAL and gated onto the DAL under processor control.
Track Register — This 8-bit register holds the track number of the current Read/Write head position. It is incremented
by one every time the head is stepped in and decremented by one when the head is stepped out (towards track 00).
The contents of the register are compared with the recorded track number in the ID field during disk Read, Write, and
Verify operations. The Track Register can be loaded from or transferred to the DAL. This Register should not be loaded
when the device is busy.
Sector Register (SR) — This 8-bit register holds the address of the desired sector position. The contents of the register
are compared with the recorded sector number in the ID field during disk Read or Write operations. The Sector Register
contents can be loaded from or transferred to the DAL. This register should not be loaded when the device is busy.
Command Register (CR) — This 8-bit register holds the command presently being executed. This register should not
be loaded when the device is busy unless the new command is a force interrupt. The command register can be loaded
from the DAL, but not read onto the DAL.
Status Register (STR) — This 8-bit register holds device Status information. The meaning of the Status bits is a func
tion of the type of command previously executed. This register can be read onto the DAL, but not loaded from the DAL.
CRC Logic — This logic is used to check or to generate the 16-bit Cyclic Redundancy Check (CRC). The polynomial is:
G(X) = X16 + X12 + X5 + 1.
The CRC includes all information starting with the address mark and up to the CRC characters. The CRC register is
preset to ones prior to data being shifted through the circuit.
10

1581 SERVICE MANUAL
Arithmetic/Logic Unit (ALU) — The ALL) is a serial comparator, incrementor, and decrementor, and is used for register
modification and comparisons with the disk recorded ID field.
Timing and Control — All computer and Floppy Disk interface controls are generated through this logic. The internal
device timing is generated from an external crystal clock. The FD1770 has two different modes of operation according
to the state of DDEN. When DDEN = 0, double density (MFM) is enabled. When DDEN = 1, single density is enabled.
AM Detector — The address mark detector detects ID, data and index address marks during read and write operations.
Data Separator— A digital data separator, consisting of a ring shift register and data window detection logic, provides
read data and a recovery clock to the AM detector.
PROCESSOR INTERFACE
The interface to the processor is accomplished through the eight Data Access Lines (DAL) and associated control signals.
The DAL are used to transfer Data, Status, and Control words_out of, orjnto the WD1770. The DAL are three state
buffersjhat are enabled as output drivers when Chip Select (CS) and R/W = 1 are active or act as imput receivers
when CS and R/W = 0 are active.
When transfer of data with the Floppy Disk Controller is required by the host processoMhe device address is decoded
and CS is made low. The address bits A1 and AO, combined with the signal R/W, during a Read operation or
Write operation are interpreted as selecting the following registers:
A1 - AO
0 0
0 1
1 0
1 1
Read (R/W= 1)
Status Register
Track Register
Sector Register
Data Register
WRITE (R/W= 0)
Command Register
Track Register
Sector Register
Data Register
During Direct Memory Access (DMA) types of data transfers between the Data Register of the WD1770 and the pro
cessor, the Data Request (DRQ) output is used in Data Transfer control. This signal also appears as status bit 1 during
Read and Write operations.
On Disk Read operations, the Data Request is activated (set high) when an assembled serial input byte is transferred
in parallel to the Data Register. This bit is cleared when the Data Register is read by the processor. If the Data Register
is read after one or more characters are lost, by having new data transferred into the register prior to processor readout,
the Lost Data bit is set in the Status Register. The Read operation continues until the end of sector is reached.
On Disk Write operations, the Data Request is activated when the Data Register transfers its contents to the Data Shift
Register, and requires a new data byte. It is reset when the Data Register is loaded with new data by the processor.
If new data is not loaded at the time the next serial byte is required by the Floppy Disk, a byte of zeroes is written on
the diskette and the Lost Data is set in the Status Register.
At the completion of every command, an INTRQ is generated. INTRQ is reset by either reading the status register,
or by loading the command register with a new command. In addition, INTRQ is generated if a Force Interrupt com
mand condition is met.
The WD1770 has two modes of operation according to the state DDEN (Pin 26). When DDEN = 1, single density is
selected. In either case, the CLK input (Pin 18) is at 8 MHZ.
UJ
o
<
Li-
CC
UJ
HOST
CK
CS
R/W
MR _
; DRQ
INTRQ
+ 5
Jdden i
GND VCC
WG
WD
RD
^TROO
WPRT
MO
DIRC
' + 5 V.
11

1581 SERVICE MANUAL
MAJOR PARTS LIST
PCB ASSY 1581
LED ASSY 1581
BEZEL 1581
CASE TOP 1581
CASE BOTTOM 1581
FDD BRACKET, 1581
SHIELD, BOTTOM 1581
INSULATION SHEET 1581
DISKETTE DEMO 1581
MANUAL — USERS
DRIVE ASSY (CHIN F-354E)
MANUAL — SERVICE
POWER SUPPLY 1581
C250471-01
C250793-01
C252281-01
C252282-01
C252283-01
C252287-01
C252288-01
C252290-01
C252355-01
C252358-01
C312550-01
C314982-01
C354027-01
COMPONENTS PARTS LIST
PCB ASSEMBLY 0250471-01
U1
U2
U2 Sub.
U3
U4
U4 Sub.
U5
U6
U7
U9
U10
U13
U8, U12
U11
J1 (Use only with WD1770)
J1 Sub. -13
RP1
RP2
R1, R3, R9, R10, R11
R13
R12
R2, R14
R5
C1-C14
C18, C22
C20
C15
FB1-6
EMI1-4
Y1
CN5
CN1 Polarized
CN3, CN4
CN2
CN6
SW2
SW1
Use on U2 (Item 9)
CR4
CR4 Sub.-01
IC 6502A 2MHZ CPU
IC EPROM
IC 23256 32K X 8 ROM
IC 8K X 8 SRAM
IC WD1772 FDC
IC WD1770 FDC
IC 8520A-1 2MHZ CIA
IC 74LS139
IC 74LS00
IC 74LS14
IC 74LS93
IC 74LS241
IC 7406
IC 7407
JUMPER WIRE
RES. 47 1/4W 5%
RES. PACK1K-15PIN
RES. PACK 2.7K-7 PIN
RES. 47 1/4W 5%
RES. 150 1/4W 5%
RES. 620 1/4W 5%
RES. 1K 1/4W 5%
RES. 2.7K 1/4W 5%
CAP. 0.1/iF 16V CER.
CAP. 10/tF 25V ELECTR.
CAP. 47/tF 10V -10 +50 ELECTR.
CAP. .0VF 50V CER.
FERRITE BEAD
EMI FILTER 100PF
CRYSTAL MODULE 16 MHZ
CONN. 3 PIN SIL .1"
CONN. 4 PIN SIL. .1"
CONN. 6 PIN DIN
CONN. 34 PIN DIL .1" X .1"
CONN. 5 PIN MINI DIN
SWI. DPDT
SWI. DIP 2 POS.
IC SOCKET 28-PIN
DIODE IN4148
DIODE IN914
C901435-02
C312558-02
C312558-01
310024-02
C310651-02
C310651-01
C318029-02
N/A
901521-01
901521-30
901521-07
901521-51
901522-06
901522-30
200018-13
901550-56
N/A
N/A
901550-56
901550-89
901550-40
901550-01
901550-23
252036-02
900100-01
900100-12
251069-20
903025-04
251842-02
325566-01
903326-03
325516-04
252166-01
903344-17
250471-01
252182-01
252144-02
904150-05
900850-01
900850-16
C - indicates part is stocked by CBM
12

1581 SERVICE MANUAL
ASSEMBLY DRAWING
FDD BRACKET
252287-01
DRIVE ASSY
312550-01
PCB ASSY
250471-01
INSULATION
SHEET
252290-01
SHIELD BOTTOM
252288-01
BOTTOM CASE
252283-01
13

1581
DISK
FflBR.
NO.
25232b
S
CZ3L
cm
ci5
CD
6
IK* I
CZ)?
k
30 20
CRN
RED
LEOl
(
)
V
/
U>
CD
BOARD
LAYOUT
PCS
ASSEMBLY
#250471
