CommRadio CR-1a User Manual – Rev 1 Edition: 15 July 2015 7
5. Frequency Stepping [STEP]
The CR-1a Steps sequentially through frequencies and does not stop on a
channel or frequency if a signal is present (not a scanner).
•Push [STEP] to start stepping in increments corresponding with the
cursor position.
•Cursor range: 00 kHz to 0 Hz.
•Steps within the selected band boundaries.
•To stop stepping: Push [STEP] or rotate [T].
•To reverse stepping direction (while stepping): [<] or [>]
6. Memory [MEM]: Save-Recall-Step
•Save a frequency example:
Save 8. 50 MHz to Memory page 2, slot (memory location) 4.
Push [MEM]. There are 8 pages of memory. Each page has 8
slots. Use [<] or [>] to index through pages. Select page 2. Note the tuned
frequency is shown in upper right of display.
Push [MEM] to enter the selected page. Use [<] or [>] to
index through memory slots.
Hold [MEM] 2 seconds.
Exit options (return to Main display):
•Rotate [T] increment CW or CCW. The frequency will not change until next increment.
•Timeout (see Menu Timeout selections on page ).
•Recall a frequency example:
Recall 8. 50 MHz from Memory page 2, slot 4.
Push [MEM]. There are 8 pages of memory. Use [<] or [>] to index through
pages. Select page 2. Note the tuned frequency is shown in upper right of
display.
Push [MEM] to enter the selected page. Use [<] or [>] to
index through memory slots. Select slot 4.
Push [MEM] (momentarily).
Exit options if frequency not selected:
•Rotate [T] increment CW or CCW.
