comoc CM1500 S Instruction manual

1
MANUAL USE AND MAINTENANCE
CM1500 S – CM1500 V
ED. 12-2004 EN
Doc. 10004516

2
The contained descriptions in the present publication are not binding. COMAC S.p.A.
therefore reserves itself the right to bring in whatever moment possible organs changes,
details or supplies of accessories, that it holds convenient for an improvement, or for any
demand of constructive or commercial character.
The partial reproduction of the texts and diagrammes contained in the present catalog, is
forbidden by law.
COMAC S.p.A. reserves itself the right to bring changes of technical character and/or of
endowment. The images are meant of pure reference and not binding in terms of design
and endowment.
Symbols used in the manual
Symbol of the book open with letter i
It points out that this document is a manual of instructions.
Symbol of the open book
It points out to the operator to read the manual of use before using
the machine.
Symbol of warning
Read attentively the sections preceded by this symbol for the safety
of the operator and the machine

3
SUMMARY
RECEIVING THE MACHINE........................................................................................................................................4
FOREWORD ................................................................................................................................................................4
TECHNICAL DESCRIPTION .......................................................................................................................................4
SYMBOLS USED IN THE MANUAL ...........................................................................................................................5
PREPARING THE MACHINE ......................................................................................................................................6
BEFORE STARTING TO USE THE MACHINE..........................................................................................................................6
MOVING THE PACKAGED MACHINE.......................................................................................................................................6
UNPACKING THE MACHINE.....................................................................................................................................................6
INSTALLING THE HANDLEBAR................................................................................................................................................7
INSTALLING THE PAD ..............................................................................................................................................................7
PREPARING THE MACHINE ......................................................................................................................................8
GENERAL SAFETY REGULATIONS..........................................................................................................................9
OPERATION...............................................................................................................................................................10
GETTING SET TO OPERATE THE MACHINE........................................................................................................................10
OPERATING THE MACHINE...................................................................................................................................................10
AFTER WORK IS TERMINATED ..............................................................................................................................11
REMOVING THE PAD..............................................................................................................................................................11
DAILY MAINTENANCE .............................................................................................................................................12
CLEANING ...............................................................................................................................................................................12
CHECKING OPERATION..........................................................................................................................................13
THE MACHINE DOES NOT CLEAN WELL, VIBRATES OR OSCILLATES.............................................................................13
THE MACHINE STOPS WHEN IT IS AT WORK......................................................................................................................13
MOTOR SIGNAL LAMP ON.....................................................................................................................................................13
POLISHING PADS SELECTION AND USE..............................................................................................................14

4
Receiving the machine
Immediately check, when receiving the machine,
that all the material indicated on delivery
documents has been received and also that the
machine has not been damaged in transit. If it
has been damaged, this damage must be
immediately reported to the shipper and also to
our customer service department. Only acting
promptly in this manner will make it possible to
receive missing material and to be compensated
for damage.
Foreword
This machine is designed for professional
cleaning of hard and vinyl interior flooring which
is to be done by following instructions. Any use
of the machine for other purposes is dangerous
and consequently prohibited. The machine is
designed for community use such as in hotels,
schools, hospitals, factories, shops, offices and
residential facilities.
Even the best machines will only operate
efficiently and work with profit if they are used
properly and kept in perfect operating order.
This booklet gives you all the information you
require to use the” Comac One-brush machines"
in a proper, safe and suitable manner. It must
always be kept on hand and available for the
user.. Read this instruction booklet carefully and
consult it every time problems arise with
machine operation. Remember that, if
necessary, our service organization, in
collaboration with our dealers, is always
available for helpful hints or direct intervention.
TECHNICAL DESCRIPTION M/U CM UHS
Working width mm 510
Machine width mm 540
Machine length mm 610
Machine height (to the motor) mm 300
Machine height (to the handlebar) mm 1260
Disk RPM RPM 1500
Supply voltage V 230
Motor power W 1100
Type of drive semiaut.
Frequency Hz 50/60
Machine weight Kg 43
Cable length m 15
Wheel diameter Ømm 100x24

5
SYMBOLS USED IN THE MANUAL
Warning symbol
Read sections preceded by this symbol with care: they concern the safety of the operator
and the machine

6
PREPARING THE MACHINE
BEFORE STARTING TO USE THE MACHINE
Delivery of the machine, explanation relating to the safety regulations,
operation, maintenance as well as the first start-up are usually
performed by an authorized COMAC operator. If this is not done then
the user is responsible for training those who shall use the machine
concerning the operating and safety regulations illustrated in the
following pages of this manual.
MOVING THE PACKAGED MACHINE
The machine is contained in specific packing with a platform so that it
can be moved by a fork-lift. The pallet contains both the packing with
the base and that with the handlebar. More than two packings cannot
be stacked.
Total weight is 50 kg.
Packing dimensions are:
A: 65 mm
B: 80 mm
C: 120 mm
UNPACKING THE MACHINE
1. Open the top part of the external packing
2. Lift the base of the machine up and out
3. Remove the handlebar from its packing
4. Mount the handlebar on the base (see the paragraph:
"INSTALLING THE HANDLEBAR")
5. Keep the packing in storage for any future shipping
requirements.

7
PREPARING THE MACHINE
INSTALLING THE HANDLEBAR
Insert the handlebar in its vertical position, placing the support in the
four holes on the base. Insert the four M8 screws.
Tighten the screws one at a time, holding the self-locking nuts below
the base in their seats.
Connect the gas spring to the support by pressing it in by hand.
Connect the power cable to the motor.
INSTALLING THE PAD
WARNING! Check that the power plug is
disconnected from power mains and wear suitable
protective gloves before you proceed to install the
pad.
Use the handlebar to slope the machine back until it rests on the floor
(handlebar horizontal, machine vertical). Remove the clip from the
motor hub and screw on the drive disk. Mount the pad on the disk,
supporting it with one hand and tightening fastening ring (2) with the
other
(
turnin
g
it clockwise
)
, usin
g
the special handle
(
1
)
provided with
Use the handlebar to bring the machine back up into its vertical
position.
The machine must be perfectly horizontal and positioned on the
vertical of the disk.
Connect the power plug into the power mains. Move the handlebar
horizontally until you achieve proper rotation stability. Then release
the levers to turn the machine off.

8
PREPARING THE MACHINE
Pull positioning lever (A) to lower the handlebar until the user's arms
are at a comfortable angle. Push lock lever (B) down with your thumb
and then actuate the motor using the two levers (C).
The lock lever must be released every time the machine is started up.
For safety reasons the motor cannot be activated when the handlebar
is in its vertical position.
WARNING! Use only special high speed disks as
specified in the last chapter of this manual, "Polishing
pads selection and use". Order these disks from
COMAC or from one of their authorized dealers.

9
GENERAL SAFETY REGULATIONS
Any use of the machine different from that described in the operating instructions or from the uses specified by the
contract is prohibited. It is prohibited to use the machine whenever it is not in perfect condition or whenever the following
regulations cannot be complied with:
Read the labels on the machine with care. Do not cover them for whatever reason and replace them immediately
whenever they are damaged.
Read the operating instructions CAREFULLY before starting up the machine or performing maintenance.
Use of the machine in enclosed interior areas is subject to standards applicable in the country where the machine is
used.
Never use the machine for purposes other than those for which it is designed.
Never use the machine to collect incandescent materials (burning cigarette stubs, for example).
Never use the machine to collect toxic waste or dust.
Never set containers of liquid on the machine.
Always make sure that work surfaces, floor slabs and ramps are able to support the weight of the machine.
Always keep a safe distance from persons present in the work zone when working. Be especially careful of children.
Do not put your hands in the machine when it is operating.
Never remove covers and/or guards when the machine is operating.
Never operate the machine without its safety guards.
Never approach the machine with garments that could get caught in it. AVOID wearing scarves, shawls, ties and
loose garments.
Avoid working with pieces of rope, wires, cables: these could get caught in the brush and create friction.
The machine is not designed to clean carpets or textile flooring.
Use only disks provided with the appliance or disks specified in this operating and maintenance manual. Use of
other disks may jeopardize safety.
The machine must only be used by authorized persons who have been properly trained regarding machine operation
and are aware of these safety regulations.
The power cable outlet must have a proper grounding.
Avoid touching or running over the power cable when the disk is operating. Avoid damaging it by crushing, bending
or stressing it.
Whenever you encounter damage in the power supply cable you must immediately stop the machine if it is at work,
pull the plug out from the power supply mains and replace the cable with a new one from a COMAC service center.
Do not set containers of liquid on the machine.
Machine storage temperatures must be between -25°C and +55°C.
The optimum working temperature is between 0°C and 40°C.
Humidity must be between 30 and 95%.
Never use the machine in explosive atmospheres or in the presence of inflammable liquids or powders that are
harmful to health.
Avoid running the disk with the machine stopped to prevent damage to the floor.
Use a powder fire extinguisher in case of fire. Do not use water.
Do not hit against scaffolding or shelving where there is a danger of falling objects.
Polishing procedures must be done in zones where the passage of unauthorized personnel is prohibited. Put up
special signs to indicate the work zones.
Whenever you encounter malfunctions in machine operation check that they are not caused by insufficient routine
maintenance. Ask for help from your nearest COMAC service center if this is not the case.
When replacing parts always ask for ORIGINAL spare parts from an Authorized Retailer and/or dealer.
Always interrupt the electrical supply to the machine whenever performing maintenance, cleaning or when converting
the machine to another function.
Do not remove guards that require tools in order to be removed.
Never wash the machine with direct jets of water or jets of pressurized water or with corrosive substances.
Have the machine checked each year by a COMAC service center.
The machine contains materials subject to standards for disposal in special waste centers and consequently must not
be left when it is being scrapped.
Never cut off power to the machine when it is working.

10
OPERATION
GETTING SET TO OPERATE THE MACHINE
Pull positioning lever (A) to lower the handlebar until the user's arms are at a
comfortable angle. Push lock lever (B) down with your thumb and then
actuate the motor using the two levers (C). The lock lever must be released
every time the machine is started up. For safety purposes the motor cannot
be activated while the handlebar is in its vertical position.
OPERATING THE MACHINE
The first time you use the machine you must become familiar with the
movements to impart on the handlebar in order to be sufficiently sure about
the direction the machine will move. Do not use the machine near persons or
obstacles until you have become familiar with it.
Work by performing back and forth movements and if possible going
backwards so that the operator is always standing on a floor that has not yet
been polished.
Keep the power supply cable behind the operator. Be careful not to work with
the machine near this cable in order not to damage it.
Do not work too long on the same zone in order to avoid damage to the
floor.

11
AFTER WORK IS TERMINATED
REMOVING THE PAD
To remove the pad bring the handlebar up to vertical by pulling on the
positioning lever. Then tilt the machine back by resting it on the wheels. Use
the specific handle to unscrew the ring that clamps the pad in place and
remove the pad. Now unscrew the fastening screw located in the center of
the pad.
The machine must never remain resting on the pad.
In fact the weight of the machine could permanently deform the pad or the
disk and create vibrations and oscillations when working.
WARNING! Pull the plug out of the power supply outlet
before performing any type of maintenance and at the end of
the work cycle.
WARNING! Abrasive disks can be installed manually only
after pulling the power supply plug out from the power outlet
and only when wearing suitable protective gloves.

12
DAILY MAINTENANCE
CLEANING
Before you put the machine away:
- examine the power cable and check it has not been damaged;
- clean the machine with a damp cloth.
- Periodically check the condition of the pad and replace as
necessary.

13
CHECKING OPERATION
THE MACHINE DOES NOT CLEAN WELL, VIBRATES OR OSCILLATES
Check the condition of the abrasive pad.
If the machine has been resting too long on the abrasive pad the pad may
have been permanently deformed. This will cause the machine to vibrate. If
the pad is ruined or worn then it must be replaced with a new pad.
To replace the pad consult the paragraphs: "REMOVING THE PAD" and
"INSTALLING THE PAD".
THE MACHINE STOPS WHEN IT IS AT WORK
The machine has an amperometric safety switch located behind the handlebar
that cuts off power to the brush motor whenever a predetermined load is
exceeded. To give current back to the motor you must press the push-button.
If the switch continues to cut off power then you must call your nearest
COMAC service center.
MOTOR SIGNAL LAMP ON
The machine has a device that checks the state of wear of the motor brushes.
The motor brushes must be replaced when the red signal lamp turns on (see
the figure). This procedure must be done by qualified personnel from a
COMAC service center.
WARNING! Ask for service from a COMAC service center
whenever you encounter any other malfunction.

14
POLISHING PADS SELECTION AND USE
POLISHING PAD TABLE
Machine No. of Pads ∅Pad
CM UHS
1
508
