Mytee Flood Hog 7000SX User manual

1
Instructions for
7000SX Flood Hog™
13655 Stowe Dr., Poway, CA 92064
Model #
Serial #
Form # ADM-7000SX
10-17
Please read before use.
Register your product
at: www.mytee.com/
support/register
General Information p. 2
Set Up p. 4
Parts & Pricing p. 8
Wiring Diagram p. 10
Notes p.11
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

2
Dear Customer:
Congratulations on the purchase of your new 7000SX Flood Hog™. As you
are already aware, the scene of the equipment world is becoming more high tech,
and we at Mytee Products Inc. strive to keep you on the cutting edge with superior
quality and technology.
Keep in mind that the 7000SX Flood Hog™ is a machine, so neglect or abuse will
cause unnecessary damage and void the warranty. However with simple mainte-
nance the Flood Hog™ will give quality performance for many years to come.
If warranty questions arise, please consult your user manual or get in touch with
your distributor. If you have questions about maintenance, replacing parts or
ordering parts, please call an authorized Mytee Products Inc. Service Center.
To see an updated list, visit our website at www.mytee.com
Before you begin cleaning, please read your manual thoroughly.
Sincerely,
Mytee Customer Care Dept.
Grounding Instructions
This machine must be grounded. If it should malfunction or break down, grounding
provides a path of least resistance for electrical shock. This machine is equipped
with a cord having an equipment-grounding conductor and grounding plug. The plug
must be plugged into an appropriate outlet that is properly installed in accordance
with all local code and ordinances. Do not remove ground pin; if missing, replace
plug before use.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualied electrician or service person if you are in doubt
as to whether the outlet is properly grounded. Do not modify the plug provided with
the machine. If it will not t the outlet, have a proper outlet installed by a qualied
electrician.
This appliance is for use on a nominal 120 volt circuit, and has a grounding plug
that looks like the plug illustrated in Figure 1 below. A temporary adapter illustrated
in Figures 2 and 3 may be used~to connect this plug to a 2-pole receptacle as
shown in Figure 2 if a properly grounded outlet is not available. The temporary
adapter should be used only until a properly grounded outlet (Figure 1) can be
installed by a qualied electrician. The green colored rigid ear, tab or the like
extending from the adapter must be connected to a permanent ground such as a
properly grounded outlet box cover. Whenever the adapter is used, it must be held
in place by a metal screw. Grounding adapters are not approved for use in Canada.
Replace the plug if the grounding pin is damaged or broken.
The green (or green-yellow) wire in the cord is the grounding wire. When replacing
a plug, this wire must be attached to the grounding pin only.
DO NOT use extension cords.
Please Note for America use only
Parts and Service
Repairs, when required, should be performed by Mytee service personnel or Mytee
authorized Service Center using Mytee original replacement parts and accessories.
Call Mytee for repair parts or service. Please specify the Model and Serial Number
when discussing your machine.
Name Plate
The Model and Serial Number of your machine are shown on the Nameplate on the
back panel of the machine. This information is needed when ordering repair parts
for the machine. Use the space provided on the front cover to note the Model and
Serial Number of your machine for future reference.
Unpacking the Machine
When the machine is delivered, carefully inspect the shipping carton and the
machine for damage. If damage is evident, save the shipping carton so that it can
be inspected by the carrier that delivered it. Contact the carrier immediately to le a
freight damage claim.
Caution and Warnings
Symbols
Mytee uses the symbols below to signal potentially dangerous conditions. Always
read this information carefully and take the necessary steps to protect personnel
and property.
Is used to warn of immediate hazards that will cause severe personal injury or death.
Is used to call attention to a situation that could cause severe personal injury.
Is used to call attention to a situation that could cause minor personal injury or
damage to the machine or other property. When using an electrical appliance, basic
precautions should always be followed, including the following: Read all instructions
before using this machine. This product is intended for commercial use only.
To reduce the risk of re, electrical shock, or injury:
1. Read all instructions before using equipment.
2. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
3. Always unplug power cord from electrical outlet before attempting any adjustments
or repairs.
4. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
5. Do not pull by cord. Do not close a door on cord or pull cord around sharp edges
or corners.
6. Do not run appliance over cord. Keep cord away from heated surfaces.
7. Do not use with damaged cord or plug. If cord is damaged, repair immediately.
8. Always unplug or disconnect the appliance from power supply when not in use.
9. Do not allow to be used as a toy. Close attention is necessary when used by or
near children.
10. Do not use in areas where ammable or combustible material may be present.
11. Do not leave the unit exposed to harsh weather elements. Temperatures below
freezing may damage components and void warranty.
12. Use only the appropriate handles to move and lift unit. Do not use any other parts
of this machine for this purpose.
13. Keep hair, loose clothing, ngers, and all parts of the body away from all
openings and moving parts.
14. Use extra care when cleaning on stairs.
15. To reduce the risk of re or electric shock, do not use this machine with a solid-
state speed control device.
16. The voltage and frequency indicated on the name plate must correspond to the
wall receptacle supply voltage.
17. When cleaning and servicing the machine, local or national regulations may apply
to the safe disposal of liquids which may contain: chemicals, grease, oil, acid,
alkalines, or other dangerous liquids.
18. Do not leave operating unattended.
Figure 1
Grounding Pin
Grounded Outlet
Grounded Outlet Box
Adapter
Tab for Grounding
Screw
Metal
Screw
Figure 2 Figure 3
GENERAL INFORMATION
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

3
Pre-Operation
1. Remove furniture and other items from the area you are going to treat.
2. Make sure debris lter is clear and electrical cord is in good repair.
3. Make sure a 20A grounded wall outlet is available for cord. Do not use
extension cord.
Operation
1. Attach one end of the vacuum hose to the front of the machine. Then, attach a
scalloped or squeegee vacuum head to the other end of the vacuum hose.
2. If using the Auto Pump-Out feature: On the rear of the machine, attach the pump-
out hose. Secure the hose to the tting using the cam lock. Push the hose cuff onto
the tting, making sure the silver ears and rings are extended forward. Pull the ears
down using the rings until connection is tight. Place the end of the hose in a location
where dirty water can drain.
3. Plug in the power cord(s). Two power cords are located in the back of the ma-
chine. To power Vacuum 1 and Pump, plug in the top cord. To power the Vacuum
2, plug in the bottom cord. Plug each of the two power cords into two separate, 20A
grounded wall outlets. Do not use extension cords.
4. Turn on the machine. Three switches are located on the lower left side of the
machine. To use Vacuum 1, turn on the Vacuum 1 switch. To use Vacuum 2, turn on
the Vacuum 2 switch. To use the pump, turn on the Pump switch.
5. Place wand over ooded area and begin extracting.
6. If pump must be accessed during extraction, use the recovery tank lid on top of
the machine. Pull the lever up and turn counter clockwise until it faces the side of the
machine. Pull up and take the lid off. Use reverse procedure to replace.
7. When ood extraction is nished, turn off the machine.
After Use
1. Unplug power cords and remove hose.
2. Inspect hoses and replace if damaged.
3. Inspect lter and clean.
4. The debris lter inside the machine protects the vacuum motor from damaging
debris. Keep it clean by removing vacuum hose and turning the top latch counter-
clockwise and opening the lid. Remove stainless steel basket and gently rinse with
water. Dry with a soft cloth. Replace basket, lid and hose.
5. Flush out recovery tank and pump-out to prevent silt buildup around the
pump-out intake.
6. Open recovery tank to promote air circulation.
7. Make sure machine and hoses are completely drained and dry.
8. Store the machine in a clean, dry place.
Maintenance Schedule
Maintenance item Daily Once a week
Clean and inspect Tanks
Clean and inspect Hoses
Flush out recovery tank and pump-out to prevent sift
buildup around the pump-out intake.
Inspect lters
Check electrical cord
Clean machine with all purpose cleaner and cloth
Inspect vacuum hoses for holes and loose cuffs
Lubricate wheels with water-resistant oil
Inspect machine for water leaks and loose hardware
x
x
x
x
x
x
x
x
x
Troubleshooting
There is no power.
1. Plug machine in proper outlet.
2. Check circuit breaker; reset circuit breaker, other items should not run on the
same circuit as machine. Outlet must be a 20 amp circuit. For 7000SX models, two
separate 20 amp circuits are required.
Pump-out does not work properly.
1. Check pump-out wire. May need to reconnect wire.
2. Switch plate switch may need to be replaced.
3. If pump motor brushes are worn, replace pump.
4. Float switch obstructed. Clean.
5. Pump-out intake is obstructed. Flush out recovery tank and pump-out to clear
pump-out intake.
Vacuum motor does not work properly.
1. Check that hose is tightly connected.
2. Close drain hose valve completely.
3. Secure the vacuum tank tightly.
4. If water is coming out of vacuum motor, use a low foaming detergent.
Machine Specications
Recovery Tank 12 gallons
Vacuum Dual 3-stage high performance, in series
CFM 113
Water Lift 249”
Pump-Out 66 GPM
Filter Stainless steel strainer basket
Power
Consumption
Cord 1: 18 amps @ 115V 60Hz
Cord 2: 13 amps @ 115V 60Hz
Machine Weight 124 lbs.
Machine
Dimensions 29” x 17.5” x 35”
Power Cord Dual 50’ 12/3
230V Conguration Information
Model Number 7000SX-230
Power
Consumption
Cord 1: 10 amps @ 230V 60Hz/50Hz
Cord 2: 7 amps @ 230V 60Hz/50Hz
FAQs
Q: What comes standard with the 7000SX?
A: The 7000SX comes with a 2” x 1.5” Cuff Lynx™ (H141), a 50’ lay-at pump-out
hose (AH121), and pack of lters (G008).
Q: Where do I plug the machine in?
A: Plug each power cord into a separate, 20A grounded wall outlet. Outlets must
be on two separate breakers. When the amber light on the switch plate illuminates,
the machine is on separate circuits (not necessarily 20A circuits). You can identify the
primary cord by the yellow tag.
Q: Is there anything I can do to increase the expected life of my machine?
A: Running the vacuum motors with the tank empty and lid off will allow excess
moisture in the vacuums to dry off.
GENERAL INFORMATION
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

4
7000SX FEATURES
3
2
8
5
4
6
7
9
1
10
11
7000SX FLOOD HOG™
1. Switch plate
2. 4” locking casters
3. Service latches
4. Recovery tank drain valve
5. Recovery tank
6. Front handle
7. Front recovery tank lid latches
8. 2” Cuff-Lynx™ Vacuum hose connection
9. Recovery tank lid
10. Rear recovery tank lid latch
11. Rear upper wheels
12. Rear handle
13. Pump-out hose connection
14. Power cord pigtails
15. Rear 10” foam-lled wheels
7000SX SWITCHES
Three switches are located on the lower left side of the machine. To use either vacuum, turn on the Vacuum switch 1 or 2. To use the pump,
turn on the Pump switch.
Dual circuit indicator
light.
12
13
14
15
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

5
Plug each power cord into a separate, 20A grounded wall outlet. Outlets must be on two separate breakers. When the amber light on the
switch plate illuminates, the machine is on separate circuits (not necessarily 20A circuits). You can identify the primary cord by the yellow
tag.
7000SX DUAL CORDS
Top cord: Powers Vac 1 & Pump.
Bottom cord: Powers Vac 2.
7000SX FLOOD HOG™
7000SX INCLUDED ACCESSORIES A138 OPTIONAL ACCESSORY PACKAGE
(SOLD SEPARATELY)
FILTERS
D
C
B
A
A
B
C
D
1
2
3
4 5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
H226
SHEET 1 OF 1
spout, drain, 45 degree
SCALE: 1:2
REV
DWG. NO.
D
SIZE
TITLE:
NAME DATE
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
MYTEE PRODUCTS, INC. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
MYTEE PRODUCTS, INC. IS PROHIBITED.
mytee
PRODUCTS, INC.
858-679-1191
J.Cash
DO NOT SCALE
DRAWING
H908 - 2 Piece
Aluminum Wand Tube
H294 - 1.5” x 25’ Vacuum Hose
AH121 - 2.5” x 50’ Lay-Flat
Pump-Out Hose
H226 - Drain Elbow
P570 - Scalloped Vacuum Head
G200 - Squeegee Vacuum Head
H141 - 2” x 1.5”
Cuff-Lynx™ Reducer
G008 - Pack Of Filters
Yellow tag
indicates primary
cord.
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

6
7000SX DRAIN VALVE AND SPOUT
When not using the Auto Pump-out, empty the tank by using the
drain valve on the front of the machine with the included drain
elbow (part # H226).
7000SX WATER LEVEL CONTROL SWITCHES
As the water level reaches the pump-out water level control
switch, the pump is activated. Once the water level reaches the
vacuum water level control switch, the vaccum shuts off prevent-
ing the water from going into the vacuum stack, damaging the
vacuum motors. At the top of the vaccum stack, there is a lter.
Clean it weekly.
7000SX FLOOD HOG™
Attach the second hose bearing cam lock to the Auto Pump-out
tting. Secure the hose to the tting using the cam lock. Push the
hose cuff onto the tting, making sure the silver ears and rings are
extended forward. Pull the ears down using the rings until con-
nection is tight. Place the end of the hose in a location where dirty
water can drain.
7000SX AUTO PUMP-OUT HOSE HOOK UP
Attach the hose (not included) with the 1.5” Cuff-Lynx™ reducer to
the machine. Attach other end of same hose to wand tube.
7000SX FRONT VACUUM HOSE HOOK UP
Pump-out water
level control switch
Vacuum water level
control switch
Vacuum stack lter
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

7
7000SX FLOOD HOG™ IN USE
Flood Hog™ pumps up to 66 GPM.
The lter protects the vacuum motor from damaging debris. Keep
it clean by removing the vacuum hose and opening the recovery
tank lid via the latch on the front of the machine. Remove stain-
less steel basket and gently rinse with water. Dry with a soft cloth.
Replace basket, lid and hose.
7000SX LATCHES AND LIFT HANDLE7000SX STRAINER BASKET
7000SX FLOOD HOG™
The Flood Hog™ features a series of latches to remove the
recovery tank lid for access to the strainer basket. There are also
two latches on the front of the unit allowing access to the internal
components. When opening the machine, lift the recovery tank
section using the lift handle on the front of the unit.
FLOODED AREA
DRAIN
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

8
Part prices are subject to change.Order parts at: www.mytee.com
7000SX FLOOD HOG™ PARTS & PRICING
ITEMS NOT SHOWN
ITEM
NO.
PART NO.
DESCRIPTION
QTY.
MSRP
1
H135
Cuff-Lynx, 2" m cuff x 2" mpt
1
$3.99 ea
2
H230
screw, 10-32 x 1/2" phil pan head, s/s
59
$0.99 ea
3
H486
latch, front
5
$13.99 ea
4
P746
lid, 7000SX 1
$89.99 ea
5
G092
gasket, lid, 7000SX
1
$39.99 ea
6
H253
plate, dual manifold, 9" x 13"
1
$14.99 ea
7
H302
cuff, hose, 2" x 2.5", swivel, grey
1
$12.99 ea
8
PH627-15
vac hose, 1-1/2", black, wire reinforced
1
$4.99 ft
9
P735
manifold, single vac, no gasket
2
$14.99 ea
10
G004
gasket, vacuum motor
2
$8.99 ea
11
H202
bolt, 1/4-20 x 3/4" hex head, s/s
6
$0.99 ea
12
H501
vac support, 3 stage, 4-1/16"
6
$4.99 ea
13
H770
bolt, 1/4-20 x 1/2" serrated hex flange, zinc
6
$0.99 ea
14
C302A
vac motor, 3-stage hp, 120V, 145"
2
$148.99 ea
15
G059
exhaust boot, plastisol
1
$4.99 ea
16
PH628-10
vac hose, 2", black, wire reinforced
1
$8.99 ea
17
H217
clamp, hose, 2-1/4 dia
5
$1.49 ea
18
H225
valve, drain, 1-1/2" 1
$20.99 ea
19
H485
handle, aluminim grip, black
1
$6.99 ea
20
G052
washer, buna 1-1/8" od x 3/16" id
6
$1.99 ea
21
H211
washer, 1/4"id x 1"od, flat, s/s
2
$0.99 ea
22
H768
bolt, 1/4-20 x 3/4" serrated hex flange, zinc
2
$0.99 ea
23
P745
vac tank, 7000SX
1
$149.99 ea
24
H023
filter basket, flood hog
1
$64.99 ea
25
C388
pump out, 66 gpm, stainless, 115v
1
$695.99 ea
26
H256
screw, 10-32 x 3/4" phil pan head, zinc
1
$0.99 ea
27
H059
bracket, ETM, pump-out
2
$9.99 ea
28
H273
nut, kep, #10-32 zinc
17
$0.99 ea
29
H216
nut, lock, 1/4-20, nylon insert, s/s
13
$0.99 ea
30
H342
bolt, 1/4-20 x 1" hex head, s/s 9
$0.99 ea
31
P686
swing check valve, pump out
1
$24.49 ea
32
PH627-15
vac hose, 1-1/2", black, wire reinforced
1
$4.99 ft
33
H396
barb, 1-1/2" x 1-1/2" fpt, pump out 1
$19.99 ea
34
H207
cam & grovve fitting 1-1/2", male
1
$21.99 ea
35
H205
cam & groove fitting 1-1/2", female
1
$32.99 ea
36
AH121
hose, layflat, 50', pump-out
1
$49.99 ea
37
PH633-1
pipe, pvc, 1-1/2"
1
$4.99 ft
38
G003 filter, foam, 2" x .50" o.d.
1
$1.99 ea
39
G097
screen, mesh filter, 1-1/2" dia
1
$4.99 ea
40
P502
adapter, 1.5" pvc, fslip x fslip
1
$5.00 ea
41
PH633-12
pipe, pvc, 1-1/2"
1
$4.99/ft
42
H244
adapter, pvc, 1-1/2" fms x fmpt
1
$4.99 ea
43
H229
inlet, pvc, 1-1/2", gray
1
$5.99 ea
44
P609
handle, 7000SX
1
$5.99 ea
45
H089
axle, 9.63" x .50" dia
1
$10.99 ea
46
H358B
wheel, 3"
2
$10.99 ea
47
H042
c-clip, 12mm, external
4
$0.99 ea
48
E373
level switch, vacuum shut-off, rear threads
2
$24.99 ea
49
B103
elbow, brass, 90 deg, 1/4"mpt x 1/4" fpt
3
$4.49 ea
50
B142A
coupling, brass, 1/4" fpt x 1/4" fpt
1
$4.49 ea
51
B303
nipple, 3" x 1/4" npt x 1/4" npt
2
$8.99 ea
52
B113
tee, brass, 1/4" fpt
1
$6.99 ea
53
B199 coupler, 1/2" fpt x 1/4" fpt
1
$8.99 ea
54
H384
washer, 3/8 flat, s/s 3
$0.99 ea
55
B210
bushing, brass, 1/2"mpt x 3/8" fpt, hex
2
$2.49 ea
56
B216
nipple, brass, 3/8" x close
1
$1.99 ea
57
H210
washer, 1/4" flat, s/s
20
$0.99 ea
58
H169
bolt, 1/4-20 x 2", hex head
4
$3.99 ea
59
G040
grip, handle, floor machine
2
$1.99 ea
60
H548
handle, 1" bar, s/s 1
$45.99 ea
61
H641
plate, switch, RL1200, 7000DX
1
$6.99 ea
62
E512B
light, indicator, 125v (amber)
1
$9.99 ea
ITEM
NO.
PART NO.
DESCRIPTION
QTY.
MSRP
63
P967A
plug, switch
1
$1.99 ea
64
H389
screw, 10-32 x 1/2" SHCS, alloy 1
$0.99 ea
65
H612
washer, 8 flat, s/s
1
$0.99 ea
66
E515
switch, rocker, 2 position
3
$13.99 ea
67
E564
controller, circuit light
1
$62.99 ea
68
E370
controller, water level, single, 115v
1
$114.99 ea
69
H186
screw, 10-32 x 3/4, phil flat full thread
6
$0.99 ea
70
E628
controller, water level, single, 115V
1
$114.99 ea
71
H221
nut, lock, 1/2" steel
2
$1.99 ea
72
H220
fitting, strain relief, cord
2
$3.19 ea
73
E550
power cord, pigtail, 30", 12/3, black
2
$11.49 ea
74
H487
bracket, hinge
2
$4.49 ea
75
P696
base, 7000SX
1
$114.99 ea
76
H254
washer, axle, cut 1/2" id
2
$0.99 ea
77
H371
axle, 18.03" x .50" dia
1
$9.99 ea
78
H109
wheel, 10", foam filled
2
$79.99 ea
79
H668
caster, 4", black hub & gray tread
2
$19.49 ea
PART NO.
DESCRIPTION
QTY.
MSRP
H141
Cuff-Lynx, 2" x 1.5" reducer
1
$3.99 ea
G109
gasket, strip, vac lid, 7000S
1
$10.99 ea
E530
power cord, ext 50', 12/3
2
$74.99 ea
P568A
cord lock, s-type
2
$8.99 ea
H226
spout, drain, 45 degree
1
$3.99 ea
H294
hose, vac 1-1/2" x 25' sw cuff
1
$74.99 ea
D
C
B
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
7000SX
SHEET 1 OF 3
Flood Hog
6/2015
OD
SCALE: 1:32
REV
DWG. NO.
C
SIZE
TITLE:
NAME
DATE
COMMENTS:
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
A
DO NOT
SCALE DRAWING
858-679-1191
mytee
PRODUCTS, INC.
M.LaBarbera
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

9
7000SX FLOOD HOG™ PARTS & PRICING
1
4
40
41
14
18
23
24
25
34
79
71
72 73
2
76 77
47
30
57
57 29
3
2
61
62
63
64 65
28
66
2
67
68
69 70 28
74
78
7
8
6
9
10
11
12 13
15
16
2
43
42
39 38
31
2
3
17
28
48
49
49
50
51
52
51
53
54
55
56
55
75
44
45
46 47
32
33
37
32
19
20
21 22
35
36
5
30
29
28
2
27
26
29 20
57
58
59
60
D
C
B
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
7000SX
SHEET 2 OF 3
Flood Hog
6/2015
OD
SCALE: 1:32
REV
DWG. NO.
C
SIZE
TITLE:
NAME
DATE
COMMENTS:
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
A
DO NOT
SCALE DRAWING
858-679-1191
mytee
PRODUCTS, INC.
M.LaBarbera
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

10
7000SX FLOOD HOG™ WIRING DIAGRAM
7000SX Wire Schematic
L1 L2
G
L1 L2
G
VAC 1
L1L2
G
VAC 2
L2L1
G
E-515 E-515
E-515
Pump
Out
L2L1
G
E-564
L1a L1b L2a L2b
light C-302A C-302A
C-384
E-512
Cord 2
Cord 1
E-628
Ground to
metal plate
3/12/2015
Float
Switch
E-370
Float
Switch
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

11
NOTES
Mytee Products Inc.
13655 Stowe Dr.
Poway, CA 92064
www.mytee.com
FX 858.679.7814
© 2017 Mytee Products Inc.
Printed in the U.S.A.
New & Reconditioned Equipment & Parts - www.southeasternequipment.net
