Computer Setup Guide
Evo Desktop Family
Evo Workstation Family
Deskpro Workstations
Third Edition (September 2001)
Part Number: 215867-003
215867.book Page ii Friday, June 8, 2001 4:48 PM

Computer Setup Guide iii
Contents
Computer Setup
Computer Setup Utilities (F10) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Using Computer Setup Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
215867.book Page iii Friday, June 8, 2001 4:48 PM

Computer Setup Guide 1
Computer Setup
Computer Setup Utilities (F10)
Use Computer Setup to do the following:
■Change factory default settings.
■Set the system date and time.
■Set, view, change, or verify the system configuration, including
settings for processor, graphics, memory, audio, storage,
communications, and input devices.
■Modify the boot order of bootable devices such as hard drives,
diskette drives, CD-ROM drives, DVD-ROM drives, or LS-120
drives.
■Configure the boot priority of IDE and SCSI hard drives
controllers.
■Configure Quiet Drive options (for drives that support this
feature).
■Enable Quick Boot, which is faster than Full Boot but does not
run all of the diagnostic tests run during a Full Boot. You can set
your system to:
❏always Quick Boot (default);
❏periodically Full Boot (from every 1 to 30 days); or
❏always Full Boot.
■Enable or disable Network Server Mode, which allows the
computer to boot the operating system when the power-on
password is enabled, with or without a keyboard or mouse
attached. When attached to the system, the keyboard and mouse
remain locked until the power-on password is entered.
215867.book Page 1 Friday, June 8, 2001 4:48 PM

2Computer Setup Guide
Computer Setup
■Select Post Messages Enabled or Disabled to change the display
status of Power-On Self-Test (POST) messages. Post Messages
Disabled suppresses most POST messages, such as memory
count, product name, and other non-error text messages. If a
POST error occurs, the error is displayed regardless of the mode
selected. To manually switch to Post Messages Enabled during
POST, press any key (except F1 through F12).
■Establish an Ownership Tag, the text of which is displayed each
time the system is turned on or restarted.
■Enter the Asset Tag or property identification number assigned by
your company to this computer.
■Enable the power-on password prompt during system restarts
(warm boots) as well as during power-on.
■Establish a setup password that controls access to Computer
Setup (F10) and the settings described in this section.
■To secure integrated I/O functionality, including the serial, USB,
or parallel ports, audio, or embedded NIC, so that they cannot be
used until they are unsecured.
■Enable or disable Master Boot Record (MBR) Security.
■Enable or disable removable media boot ability.
■Enable or disable removable media write ability.
■Solve system configuration errors detected but not automatically
fixed during the Power-On Self-Test (POST).
■Replicate your system setup by saving system configuration
information on diskette and restoring it on one or more
computers.
■Execute self-tests on a specified IDE hard drive.
■Configure various energy-saving features including energy saver
mode, system and hard drive timeouts, power button mode, and
power LED behavior.
■Enable or disable DriveLock security.
215867.book Page 2 Friday, June 8, 2001 4:48 PM

Computer Setup Guide 3
Computer Setup
Using Computer Setup Utilities
To access the Computer Setup Utilities menu, complete the following
steps:
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart the Computer.
2. When the F10 = Setup message is displayed in the lower-right
corner of the screen, press the F10 key.
✎If you do not press the F10 key while the message is displayed, you
must restart the computer again to access the utility.
3. Select your language from the list and press the Enter key.
4. A choice of five headings appears in the Computer Setup Utilities
menu: File, Storage, Security, Power, and Advanced.
5. Use the Tab key to select the appropriate heading. Use the arrow
keys to select the option you want, then press the Enter key. To
return to the Computer Setup Utilities menu, press the Esc key.
6. To apply and save changes, select File > Save Changes and Exit.
❏If you selected an option that automatically restarted the
computer, changes were applied at that time.
❏If you have made changes that you do not want applied, select
Ignore Changes and Exit.
❏If you have already applied changes you now want to
eliminate, select Set Defaults and Exit. This option will
restore the original factory system defaults.
215867.book Page 3 Friday, June 8, 2001 4:48 PM

4Computer Setup Guide
Computer Setup
Computer Setup
Heading Option Description
File System Information Lists:
• Product name
• Processor type/speed/stepping
• Cache size (L1/L2)
• Installed memory size
• System ROM (includes family name and
version)
• System board revision
• Chassis serial number
• Asset tracking number
• Integrated MAC address for embedded,
enabled NIC (if applicable)
About Displays copyright notice.
Set Time and Date Allows you to set system time and date.
Save to Diskette Saves system configuration, including
CMOS, to a blank, formatted 1.44-MB
diskette.
Restore from Diskette Restores system configuration, including
CMOS, from a diskette.
Set Defaults and Exit Restores factory default settings, which
includes clearing any established passwords.
Ignore Changes and
Exit
Exits Computer Setup without applying or
saving any changes.
Save Changes and Exit Saves changes to system configuration and
exits Computer Setup.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
215867.book Page 4 Friday, June 8, 2001 4:48 PM

Computer Setup Guide 5
Computer Setup
Storage Device Configuration Lists all installed storage devices. When a
device is selected, detailed information and
options are displayed. The following options
may be presented:
Diskette Type
Identifies the highest capacity media type
accepted by the diskette drive.
Legacy Diskette Drives
Options are 3.5” 1.44 MB, 3.5” 720 KB, 5.25”
1.2 MB, 5.25” 360 KB, and Not Installed.
Multibay Superdisk Drives
Options are LS-120 and LS-260.
Drive Emulation
Allows you to select a drive emulation type
for a storage device. (For example, a Zip
drive can be made bootable by selecting
diskette emulation.)
LS-120 and ATAPI Zip Drives
Drive Type Emulation Options
IDE LS-120 None (treated as
diskette drive)
Disk (treated as hard
drive)
ATAPI Zip drive None (treated as Other)
Diskette (treated as
diskette drive)
Disk (treated as hard
drive)
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 5 Friday, June 8, 2001 4:48 PM

6Computer Setup Guide
Computer Setup
Storage
(continued)
Device Configuration
(continued)
Drive Emulation (continued)
IDE Devices
Drive Type Emulation Options
Hard Disk No emulation options
available.
Diskette None (treated as
diskette drive)
Disk (treated as hard drive)
CD-ROM None (treated as CD-ROM
drive)
Diskette (treated as
diskette drive)
Disk (treated as hard drive)
Transfer Mode
(IDE devices only
)
Specifies the active data transfer mode.
Options (subject to device capabilities) are
PIO 0, Max PIO, Enhanced DMA,
Ultra DMA 0, and Max UDMA.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 6 Friday, June 8, 2001 4:48 PM

Computer Setup Guide 7
Computer Setup
Storage
(continued)
Device Configuration
(continued)
Translation Mode
(IDE disks only)
Lets you select the translation mode to be
used for the device. This enables the BIOS to
access disks partitioned and formatted on
other systems and may be necessary for
users of older versions of UNIX (e.g., SCO
UNIX version 3.2). Options are Bit-Shift, LBA
Assisted, User, and None.
ÄCAUTION: Ordinarily, the translation
mode selected automatically by the BIOS
should not be changed. If the selected
translation mode is not compatible with
the translation mode that was active
when the disk was partitioned and
formatted, the data on the disk will be
inaccessible.
Translation Parameters
(IDE Disks only)
Allows you to specify the parameters (logical
cylinders, heads, and sectors per track) used
by the BIOS to translate disk I/O requests
(from the operating system or an application)
into terms the hard drive can accept. Logical
cylinders may not exceed 1024. The number
of heads may not exceed 256. The number of
sectors per track may not exceed 63. These
fields are only visible and changeable when
the drive translation mode is set to User.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 7 Friday, June 8, 2001 4:48 PM

8Computer Setup Guide
Computer Setup
Storage
(continued)
Device Configuration
(continued)
Multisector Transfers
(IDE ATA devices
only)
Specifies how many sectors are transferred
per multi-sector PIO operation. Options
(subject to device capabilities) are Disabled,
8, and 16.
Quiet Drive
(This feature is supported on
select models only.)
• Performance—Allows the drive to operate
at maximum performance.
• Quiet—Reduces noise from the drive
during operation. When set to Quiet, the
drive will not operate at maximum
performance.
✎
✎✎
✎If the drive does not support Quiet mode,
the Quiet Drive option will not be
displayed.
Options Removable Media Boot
Enables/disables ability to boot the system
from removable media.
Removable Media Write
Enables/disables ability to write data to
removable media.
✎
✎✎
✎This feature applies only to legacy
diskette, IDE LS-120 Superdisk, IDE
LS-260 Superdisk and IDE PD-CD
drives.
✎
✎✎
✎After saving changes to Removable
Media Write, the computer will restart.
Turn the computer off, then on, manually.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 8 Friday, June 8, 2001 4:48 PM

Computer Setup Guide 9
Computer Setup
Storage
(continued)
Options
(continued)
Primary IDE Controller
Allows you to enable or disable the primary
IDE controller.
Secondary IDE Controller
Allows you to enable or disable the
secondary IDE controller.
Diskette MBR Validation
Allows you to enable or disable strict
validation of the diskette Master Boot
Record (MBR).
✎
✎✎
✎If you use a bootable diskette image that
you know to be valid, and it does not boot
with Diskette MBR Validation enabled,
you may need to disable this option in
order to use the diskette.
IDE DPS Self-Test Allows you to execute self-tests on IDE hard
drives capable of performing the Drive
Protection System (DPS) self-tests.
✎
✎✎
✎This selection will only appear when at
least one drive capable of performing the
IDE DPS self-tests is attached to the
system.
Controller Order
(This feature is
supported on select
models only.)
Allows you to specify the order of attached
hard drive controllers. The first hard drive
controller in the order will have priority in the
boot sequence and will be recognized as
drive C (if any devices are attached).
✎
✎✎
✎This selection will not appear if all of the
hard drives are attached to the
embedded IDE controllers.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 9 Friday, June 8, 2001 4:48 PM

10 Computer Setup Guide
Computer Setup
Storage
(continued)
SCSI Narrow
Termination
(This feature is
supported on select
models only.)
Allows you to configure SCSI termination on
the external SCSI connector for narrow SCSI
drives. This feature should only be enabled if
you are using a narrow SCSI drive to
terminate the external SCSI channel.
Boot Order Allows you to specify the order in which
attached peripheral devices (such as a
diskette drive, hard drive, CD-ROM, or
network interface card) are checked for a
bootable operating system image. Each
device on the list may be individually
excluded from or included for consideration
as a bootable operating system source.
✎
✎✎
✎MS-DOS drive lettering assignments
may not apply after a non-MS-DOS
operating system has started.
To boot one time from a device other than
the default device specified in Boot Order,
restart the computer and press F9 when the
F10 = Setup message appears on the
screen. When POST is completed, a list of
bootable devices is displayed. Use the
arrow keys to select a device and press the
Enter key.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 10 Friday, June 8, 2001 4:48 PM

Computer Setup Guide 11
Computer Setup
Security Setup Password Allows you to set and enable setup
(administrator) password.
✎
✎✎
✎If the setup password is set, it is required
to change Computer Setup options, flash
the ROM, and make changes to certain
plug and play settings under Windows.
Also, this password must be set in order
to use some Compaq remote security
tools.
See the
Troubleshooting Guide
for more
information.
Power-On Password Allows you to set and enable power-on
password.
See the
Troubleshooting Guide
for more
information.
Password Options
(This selection will
appear only if a
power-on password is
set.)
Allows you to:
• Enable/disable network server mode.
• Specify whether the password is required
for warm boot (CTRL+ALT+DEL).
✎
✎✎
✎This selection is available only when
Network Server Mode is disabled.
See the
Desktop Management Guide
for
more information.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 11 Friday, June 8, 2001 4:48 PM

12 Computer Setup Guide
Computer Setup
Security
(continued)
Smart Cover Allows you to:
• Enable/disable the Smart Cover Lock.
✎
✎✎
✎
Notify User alerts the user that the
sensor has detected that the cover has
been removed.
Setup Password requires
that the setup password be entered to
boot the computer if the sensor detects
that the cover has been removed.
This feature is supported on select models
only. See the
Desktop Management Guide
for more information.
DriveLock* Allows you to assign or modify a master or
user password for certain hard drives. When
this feature is enabled, the user is prompted
to provide one of the DriveLock passwords
during POST. If neither is successfully
entered, the hard drive will remain
inaccessible until one of the passwords is
successfully provided during a subsequent
cold-boot sequence.
✎
✎✎
✎This selection will only appear when at
least one drive that supports the
DriveLock feature is attached to the
system.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
*Option not supported on all products.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 12 Friday, June 8, 2001 4:48 PM

Computer Setup Guide 13
Computer Setup
Security
(continued)
Master Boot Record
Security*
Allows you to enable or disable Master Boot
Record (MBR) Security.
When enabled, the BIOS rejects all requests
to write to the MBR on the current bootable
disk. Each time the computer is powered on
or rebooted, the BIOS compares the MBR of
the current bootable disk to the
previously-saved MBR. If changes are
detected, you are given the option of saving
the MBR on the current bootable disk,
restoring the previously-saved MBR, or
disabling MBR Security. You must know the
setup password, if one is set.
✎
✎✎
✎Disable MBR Security before
intentionally changing the formatting or
partitioning of the current bootable disk.
Several disk utilities (such as FDISK and
FORMAT) attempt to update the MBR. If
MBR Security is enabled and disk
accesses are being serviced by the
BIOS, write requests to the MBR are
rejected, causing the utilities to report
errors. If MBR Security is enabled and
disk accesses are being serviced by the
operating system, any MBR change will
be detected by the BIOS during the next
reboot, and an MBR Security warning
message will be displayed.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
*Option not supported on all products.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 13 Friday, June 8, 2001 4:48 PM

14 Computer Setup Guide
Computer Setup
Security
(continued)
Save Master Boot
Record*
Saves a backup copy of the Master Boot
Record of the current bootable disk.
✎
✎✎
✎Only appears if MBR Security is enabled.
Restore Master Boot
Record*
Restores the backup Master Boot Record to
the current bootable disk.
✎
✎✎
✎Only appears if all of the following
conditions are true:
• MBR Security is enabled.
• A backup copy of the MBR has been
previously saved.
• The current bootable disk is the same
disk from which the backup copy of the
MBR was saved.
ÄCAUTION: Restoring a previously saved
MBR after a disk utility or the operating
system has modified the MBR may
cause the data on the disk to become
inaccessible. Only restore a previously
saved MBR if you are confident that the
current bootable disk's MBR has been
corrupted or infected with a virus.
Device Security Enables/disables Serial ports A and B,
parallel ports, USB ports, system audio
security, network controllers (some models),
and SCSI controllers.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
*Option not supported on all products.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 14 Friday, June 8, 2001 4:48 PM

Computer Setup Guide 15
Computer Setup
Security
(continued)
Network Service Boot Enables/disables the computer’s ability to
boot from an operating system installed on a
network server. (Feature available on NIC
models only; the network controller must
reside on the PCI bus or be embedded on
the system board.)
System IDs Allows you to set:
• Asset tag (16-byte identifier) and
ownership Tag (80-byte identifier
displayed during POST)
See the
Desktop Management Guide
for
more information.
• Chassis serial number or Universal
Unique Identifier (UUID) number if the
current number is invalid (These ID
numbers are normally set in the factory
and are used to uniquely identify the
system.)
• Keyboard locale setting (for example,
English or German) for System ID entry
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 15 Friday, June 8, 2001 4:48 PM

16 Computer Setup Guide
Computer Setup
Power Energy Saver Allows you to set the energy saver mode
(advanced, disable or minimal).
✎
✎✎
✎In the minimal energy saver mode
setting, the hard drive and system do not
go into energy saver mode, but the
setting allows you to press the power
button to suspend the system.
This option does not affect power
management for the ACPI-enabled operating
systems.
Timeouts Allows you to disable or manually select
timeout values for the system and/or all
attached IDE hard drives.
✎
✎✎
✎This option does not affect power
management for the ACPI-enabled
operating systems. This selection will
only appear when energy saver mode is
set to advanced.
Energy Saver Options Allows you to set:
• Power button configuration (on/off or
sleep/wake) under APM-enabled
operating systems
• Power LED blink in suspend mode
(enable/disable).
✎
✎✎
✎Energy Saver Options will appear only if
the energy saver mode is enabled. This
option does not apply under
ACPI-enabled operating systems.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 16 Friday, June 8, 2001 4:48 PM

Computer Setup Guide 17
Computer Setup
Advanced* Power-On Options Allows you to set:
• POST mode (QuickBoot, FullBoot, or
FullBoot every 1-30 days)
• POST messages (enable/disable)
• Safe POST (enable/disable) Enabling this
feature allows the ROM to monitor add-in
cards during boot. If an add-in card does
not work or initialize correctly, then on the
next boot the offending card will be
skipped during POST. (This feature is
supported on select models only.)
• F9 prompt (enable/disable) Enabling this
feature will display the text “F9 = Boot
Menu” during POST. Disabling this feature
prevents the text from being displayed.
However, pressing the F9 key will still
access the Boot Menu screen.
• F10 prompt (enable/disable) Enabling this
feature will display the text “F10 = Setup”
during POST. Disabling this feature
prevents the text from being displayed.
However, pressing the F10 key will still
access the Setup screen.
• F12 prompt (enable/disable) Enabling
this feature will display the text
“F12 = Network Service Boot” during
POST. Disabling this feature prevents the
text from being displayed. However,
pressing the F12 key will still force the
system to attempt booting from the
network.
Support for Computer Setup options may vary depending on your specific hardware
configuration.
* These options should be used by advanced users only.
Computer Setup
(Continued)
Heading Option Description
215867.book Page 17 Friday, June 8, 2001 4:48 PM
