Preface
This Maintenance and Service Guide is a troubleshooting guide that can be used for
reference when servicing the Compaq Presario 1660 Model Portable Computers. Compaq
Computer Corporation reserves the right to make changes to the Compaq Presario 1660
Model Portable Computers without notice.
Symbols
The following words and symbols mark special messages throughout this guide.
WARNING: Text set off in this manner indicates that
failure to follow directions in the warning could result in
bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure
to follow directions could result in damage to equipment or
loss of data.
IMPORTANT: Text set off in this manner presents clarifying information or specific
instructions.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%201660/preface.html (1 of 2)6/27/2004 3:00:15 AM

"Compaq.com - Compaq Presario 1660 Model Maintenance and Service Guide
NOTE: Text set off in this manner presents commentary, sidelights, or interesting points of
information.
Technician Notes
WARNING: Only authorized technicians trained by Compaq should
repair this equipment. All troubleshooting and repair procedures are
detailed to allow only subassembly/module level repair. Because of
the complexity of the individual boards and subassemblies, the user
should not attempt to make repairs at the component level or to
make modifications to any printed circuit board. Improper repairs can
create a safety hazard. Any indications of component replacement or
printed circuit board modifications may void any warranty
Serial Number
When requesting information or ordering spare parts, the computer serial number should be
provided to Compaq. The serial number is located on the bottom of the computer.
Locating Additional Information
The following documentation is available to support this product:
●Compaq Presario 1660 Model Portable Computer documentation set
●Introducing Windows 95 Guide
●Service Training Guides
●Compaq Service Advisories and Bulletins
●Compaq QuickFind
●Compaq Service Quick Reference Guide
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%201660/preface.html (2 of 2)6/27/2004 3:00:15 AM

"Compaq.com - Compaq Presario 1660 Model Maintenance and Service Guide -
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 1660 Model
MSG Index | Home Page | Notice | Preface | Product Description |
Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Product Description
Models and
Features
Upper Unit
Components
Front Bezel
Buttons
Front Bezel
Lights
Left Side
Components
Right Side
Components
Bottom of
Unit
Rear
Connectors
Power
Management
for Windows
98
Compaq
