USER’S GUIDE
Compaq TFT5010 Flat Panel Monitor

Part Number: 157254-001 - Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:18 PM
File Path: P:\Docs\Monitors\Nina\157253U1
Notice
The information in this guide is subject to change without notice.
COMPAQ COMPUTER CORPORATION SHALL NOT BE
LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR
OMISSIONS CONTAINED HEREIN; NOR FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.
This guide contains information protected by copyright. No part of
this guide may be photocopied or reproduced in any form without
prior written consent from Compaq Computer Corporation.
1999 Compaq Computer Corporation.
All rights reserved.
Compaq and Deskpro are registered in the U. S. Patent and
Trademark Office.
Microsoft, MS-DOS, Windows, Windows NT, and other names of
Microsoft products referenced herein are trademarks or registered
trademarks of Microsoft Corporation.
ENERGY STARis a U.S. registered mark.
Product names mentioned herein may be trademarks and/or
registered trademarks of their respective companies.
The software described in this guide is furnished under a license
agreement or nondisclosure agreement. The software may be used
or copied only in accordance with the terms of the agreement.
First Edition (October 1999)
Part Number 157253-001
Compaq Computer Corporation
User’s Guide
Compaq TFT5010 Flat Panel Monitor

English 1
ttttt
Part Number: 157254-001 Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:16 PM
File Path: P:\Docs\Monitors\Nina
English
Product Features
The Compaq TFT5010 Flat Panel Monitor has an active matrix, thin-
film transistor (TFT), liquid crystal display (LCD). The monitor
features include:
■ 15-inch (38.1-cm) viewable area display
■ 1024 × 768 resolution, plus full-screen support for lower
resolutions
■ Wide viewing angle to allow viewing from a sitting or standing
position, or when moving side-to-side
■ Tilt and swivel capabilities
■ Removable base for flexible mounting solutions
■ Includes DVI signal connector (two DVI cables included - one
digital and one analog); a digital connection requires a special
digital-compatible graphics adapter card
■ Plug and Play capability if supported by your system
■ On-Screen Display (OSD) adjustments in six different languages:
English, Dutch, French, German, Italian, and Spanish for ease of
set-up and screen optimization
■ Programmable Sleep Timer
■ CD-ROM includes an information file (INF), Image Color
Matching file (ICM), Colorific Software package, the Compaq
LCD Display Assistant setup and configuration utility, the
Compaq Display LiteSaver utility, and product documentation
■ Model with additional protective panel available
■ Security lock slot
■ AssetControl
■ Energy Saver feature for Energy Starcompliance
■ Monitor base includes a housing space for an optional USB hub

2English
Part Number: 157254-001- Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:16 PM
File Path: P:\Docs\Monitors\Nina
■ Compliance with the following regulated specifications:
❏ EPA ENERGY STAR
❏ European Union CE Directives
❏ Swedish MPR II 1990
❏ Swedish TCO '99
Universal Driver Manager
This monitor may require a graphics driver (and/or .INF file) that is
compatible with your computer’s graphics adapter. The CD-ROM
included with this monitor contains an .INF file (see the section on
Information Files). Compaq has also created a Universal Driver
Manager (UDM) release that supports all graphics adapters found on
Compaq Deskpro and Compaq Workstation products. The UDM eases
graphics driver deployment across Compaq platforms ensuring cross-
compatibility and backward-compatibility. The resulting solution
enables customers to manage and control ongoing software
maintenance costs. The UDM is available on the Compaq Support
Software CD for Compaq Desktop, Portable, and Workstation
Products and the Compaq World Wide Web site (www.compaq.com).
Information Files
This monitor includes a CD-ROM with two information files to be
installed onto your computer—an .INF file and an .ICM file.
■ The .INF file defines monitor resources and provides
specifications used by Microsoft Windows 95 and Windows 98
to install support software for certain hardware devices. The .INF
file ensures monitor compatibility and optimization with your
computer’s graphics adapter.
■ The .ICM file provides color matching consistency from monitor
screen to printer and is activated from within the graphics
programs that have this feature.
To install these files on your computer, follow the instructions on the
CD-ROM or on the “Configuring Your Compaq LCD Monitor” card
located in the Program License Agreement packet along with the CD-
ROM. INF file updates are downloadable by clicking on:
www.compaq.com/products/monitors/index.html

English 3
Part Number: 157254-001- Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:16 PM
File Path: P:\Docs\Monitors\Aoki
Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the
monitor, computer system, and other attached devices, then follow
these steps:
1. Place the monitor in a convenient, well-ventilated location near
your computer.
2. Connect the DVI-I monitor signal cable to the VGA connector
1on the rear panel of the computer.
✎The monitor is shipped with the DVI-I cable already
connected to the monitor. When the monitor is connected
to the computer using the DVI-I signal cable, it is using an
analog signal interface.
3. Connect one end of the AC power cord to the AC adapter 2and
the other end 3to an electrical outlet that is easily accessible
and close to the monitor.

4English
Part Number: 157254-001- Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:16 PM
File Path: P:\Docs\Monitors\Nina
CAUTION: When connecting the monitor, be sure to use the
AC adapter supplied with the monitor. Failure to use this
AC adapter may result in damage to the monitor.
!WARNING: To reduce the risk of electric shock or damage
to your equipment:
„#
Do not disable the power cord grounding plug. The
grounding plug is an important safety feature.
„#
Plug the power cord into a grounded (earthed)
electrical outlet that is easily accessible at all times.
„#
Disconnect power from the monitor by unplugging
the power cord from the electrical outlet.
„#
Do not place anything on power cords or cables.
Arrange them so that no one may accidentally step on
or trip over them. Do not pull on a cord or cable.
When unplugging from the electrical outlet, grasp the
cord by the plug.
✎For security purposes, this monitor has been fitted with a
slot 4for use with a security cable lock that can be
purchased separately at most computer stores.
✎After you turn on the monitor, install the Compaq LCD
Display Assistant utility included on the CD-ROM. Use
the on-screen instructions to adjust the picture quality of
your monitor. To install this utility onto your computer,
follow the instructions on the “Configuring Your Compaq
LCD Monitor” card located in the Program License
Agreement packet.
IMPORTANT: Always activate a screen saver program, the program-
mable sleep timer, the Compaq Display LiteSaver utility, or turn off
the monitor when it is not in use for a prolonged period of time. All
LCD monitors that display the same static image on the screen for a
prolonged period of time may exhibit screen image retention. Please
note that image retention is not a permanent condition and will fade
over a period of time. Image retention is a condition that may occur on
all LCD screens.

English 5
Part Number: 157254-001- Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:16 PM
File Path: P:\Docs\Monitors\Aoki
Connecting the DVI-D Cable
To connect the DVI-D (Digital Visual Interface-Digital) cable to the
DVI-I (Digital Visual Interface-Integrated) connector on the back of
the monitor, you must first remove the monitor base cover and the
monitor back panel and disconnect the DVI-I connector.
CAUTION: Before beginning to disassemble the monitor, be
sure the monitor is turned off and the power and signal
cables are both disconnected.
✎The DVI-D cable supplied with this monitor is for digital
to digital connection only. Your computer must have a
DVI-compatible graphics card installed for use with this
cable. When connecting the DVI-D signal cable to the
DVI connector on the monitor, you must connect the other
end of the DVI-D cable to the DVI connector on the
computer.
To remove the monitor base cover and back panel, complete the
following steps:
1. Lay the front bezel down on a soft area to prevent it from
getting scratched, defaced, or broken.
2. Remove the cover 1from the monitor base by placing your
fingers in the opening on the bottom of the base and pulling
upward, then pulling out to remove the cover.
3. Remove the back panel 2from the monitor by pushing the
bottom tabs upward and pulling out to remove the panel.

6English
Part Number: 157254-001- Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:16 PM
File Path: P:\Docs\Monitors\Nina
4. Connect the DVI-D cable to the DVI-I connector 1on the back
panel of the monitor by threading the cable through the neck
yoke on the monitor base to the DVI-I connector, then connect
the other end of the cable 2to the DVI connector on the back
panel of the computer.

English 7
Part Number: 157254-001- Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:16 PM
File Path: P:\Docs\Monitors\Aoki
5. Replace the monitor back panel and monitor base cover.
6. Reconnect the power cable and power on the monitor and
computer.
The DVI connector on this monitor uses digital video information to
provide higher speed for higher display resolution. The results are
more precise video displays without manually adjusting screen display
quality.
DVI Cables included
DVI-I Cable (Analog) to VGA Connector (15 pin)
DVI-D Cable (Digital only) to Digital Connector

8English
Part Number: 157254-001- Writer: Marianne Silvetti - Saved by: MSilvetti
Saved date: 10/12/99 6:16 PM
File Path: P:\Docs\Monitors\Nina
Adding a Compaq Powered USB Hub
The monitor base is designed to house an optional Compaq Powered
USB hub. The Compaq Powered USB hub is not included with the
monitor. It is sold separately. For information on purchasing the
Compaq Powered USB hub (part no. 138638-xxx), call your Compaq
authorized dealer, seller, or reseller. To locate a reseller near you, call
Compaq at 1-800-AT-COMPAQ or visit the Compaq web site at
http://www.compaq.com .
To remove the housing cap from the base:
1. Press down on the top of the cap.
2. Pull the cap outwards to remove it.
The following are required to operate the Compaq Powered USB hub:
■ Your computer must be fitted with a USB port.
■ Your computer must have Microsoft Windows 95 OSR2.1 or
later, or Microsoft Windows 98 as the operating system.
USB connectors are used to connect USB-compatible Plug and Play
devices such as a keyboard, mouse, or joystick to the USB hub using
Plug and Play install procedures. Plug and Play install procedures
consist of plugging in the USB device while the system is turned on
and using it without reconfiguring your computer.
