ALPHASERVER DS10
USER REFERENCE CARD
This document is intended as a quick reference for
the user. Additional information can be found in
the AlphaServer DS10 / AlphaStation VS10 Console
Reference guide, EK-DS10S-CR.
Overview
•Environmental Specifications
•Mechanical Specifications
•Electrical Specifications
•Front Buttons and LEDs
•Ethernet LEDs
•Beep Codes
•PCI Slots
•Memory Configuration
•SRM Console Commands
•Remote Management Console
(RMC) Commands
•Acoustics
WARNING: To prevent injury, access is limited
to persons who have appropriate technical
training and experience. Such persons are
expected to understand the hazards of working
within this equipment and take measures to
minimize danger to themselves or others.
CPU modules and memory modules have parts
that operate at high temperatures. Wait 2
minutes after power is removed before touching
any module. Wear an antistatic wrist strap
when working on this system.
To reduce the risk of electrical shock or damage
to the equipment: Do not disable the power
cord grounding plug. The grounding plug is an
important safety feature. Plug the power cord
into a grounded (earthed) electrical outlet that
is easily accessible at all times. Disconnect
power by unplugging the power cord from the
electrical outlet or the workstation.
Environmental Specifications
Storage
temperature range –40º C to 66º C (–40º F to 151º F)
Operating
temperature range 10º C to 40º C (50º F to 104º F)
Max. rate of change 11º C (20º F) per hour
Storage
humidity range
(noncondensing)
10% to 90% relative humidity;
maximum wet bulb 65º C
(149º F)
Operating
humidity range
(noncondensing)
10% to 90% relative humidity
(without removable media) or
20% to 80% relative humidity
(with removable media);
maximum wet bulb 2º C (36º F)
Max. altitude Nonoperating–4867 m (16,000
ft.);
Operating—2400 m (8,000 ft.)
Nonoperating shock 30 G, 25 ms halfsine
Mechanical Specifications
Leave ventilation room at the front and rear of the
system.
PK1015
Height 13 cm (5 in.)
Width 43 cm (17 in.)
Depth 46 cm (18 in.)
Weight 14.5 kg (32 lb)
Electrical Specifications
•Check your power supply setting.
•Secure the power cord by turning the safety
latch clockwise over the power cord. Secure
the latch by tightening it with a screwdriver.
115V
230V
PK1047a

2
Front Buttons and LEDs
The LEDs are located in the lower right corner on
the front of the system.
PK1043a
Symbol Function
Halt button.Open VMS, Tru64
UNIX: suspends the operating system
and returns control to the SRM console.
Windows NT: resets the system.
Environmental amber LED. On
indicates Temperature or Fan LEDs are
on. Flashes when operating system
invokes it as an alert.
Temperature amber LED. On
indicates internal temperature exceeds
operating conditions. The system shuts
down 30 seconds after this LED lights.
Fan amber LED. On indicates at least
one of the three fans in the system has
failed. The system shuts down 30
seconds after this LED lights.
Disk Activity green LED. Flashes
when internal system disks are accessed.
Power Present green LED. On when
power is present in the system.
Power button. Push in to start the
system and connect power. Push again
to remove power and stop the system.
Ethernet LEDs
The Ethernet LEDs are on the back of the system,
lower right corner.
Link
Speed/Activity
PK1050-99
LED Meaning
Link Steady green indicates Ethernet connection
Speed Green for Ethernet speed of 100
Amber for Ethernet speed of 10
Activity LED blinks with Ethernet activity
Beep Codes
The speaker in the front of the system reports errors
using a series of beeps.
Beeps Meaning
1-2-3 Valid firmware image not found
4Valid ROM header not found
6Memory error (or bad checksum) detected
7DIMMs in a memory bank do not match
PCI Slots
For OpenVMS and Tru64 UNIX systems, the SRM
console command show config will display PCI
information. For Windows NT system, see the
AlphaBIOS PCI Configuration screen.
64 Bit
64 Bit
64 Bit
32 Bit
PCI Slot 4
PCI Slot 3
PCI Slot 2
PCI Slot 1
PK1045-99
Memory Configuration
For OpenVMS and Tru64 UNIX systems, the SRM
console command show memory displays the
memory configura- tion. For Windows NT system,
see the AlphaBIOS Memory Configuration screen.
DIMM
BANKS
DIMM CONFIGURATION RULES:
• Always fill at least one bank (0 or 1).
• Use the same two DIMMs within a bank (size and vendor).
PK1046a
1
0
1
0

3
SRM Console Commands
alphabios Loads and starts the AlphaBIOS console.
boot Loads and starts the operating system.
clear envar Resets an environment variable to its
default value.
clear password Sets the password to zero.
continue Resumes program execution.
crash Forces a crash dump at the operating
system level.
deposit Writes data to the specified address.
edit Invokes the console line editor on a RAM
file or on the nvram file (power-up
script).
examine Displays the contents of a memory
location, register, or device.
help Displays information about the specified
console command.
initialize Resets the system to a known state.
lfu Runs the Loadable Firmware Update
Utility.
login Turns off secure mode, enabling access
to all SRM console commands during the
current session.
more Displays a file one screen at a time.
prcache Utility that initializes and displays status
of the optional PCI NVRAM device.
set envar Sets or modifies the value of an
environment variable.
set host Connects to an MSCP DUP server on a
DSSI device.
set password Sets the console password for the first
time or changes an existing password.
set secure Enables securemode without requiring a
restart of the console.
show envar Displays the state of the specified
environment variable.
show config Displays the configuration at the last
system initialization.
show cpu Displays the state of each processor in
the system.
show device Displays a list of controllers and their
devices in the system.
show memory Displays memory module information.
show pal Displays the version of the privileged
architecture library code (PALcode).
show power Displays information about the power
supplies, system fans, CPU fans, and
temperature.
show version Displays the version of the console
program.
stop Halts the specified processor. (Same as
halt.)
test Runs firmware diagnostics for the
system.
Remote Management Console (RMC)
Commands
alert_clr Clears alert flag, stopping dial-out alert
cycle.
alert_dis Disables the dial-out alert function.
alert_ena Enables the dial-out alert function.
disable Disables remote access to the modem port.
enable Enables remote access to the modem port.
halt Halts the server.
haltin Causes a halt assertion.
haltout Terminates a halt assertion created with
haltin.
hangup Terminates the modem connection.
help or ? Displays the list of commands.
poweroff Turns off power.
poweron Turns on power.
quit Exits console mode and returns to system
console port.
reset Resets the server. Emulates pressing the
Reset button.
setesc Changes the escape sequence for invoking
command mode.
setpass Changes the modem access password.
status Displays system status and sensors.

4
Acoustics
Preliminary declared values per ISO 9296 and ISO 7779:
LWAd, B LpAm, dBA
(bystander positions)
Idle Operate Idle Operate
with 0xHDD
with RZ1DF 5.3
5.4 5.3 5.5 38 38 38 41
Current values for specific configurations are available from Compaq
representatives. 1 B = 10 dBA.
Schallemissionswerte — Vorläufige Werteangaben nach
ISO 9296 und ISO 7779/DIN EN27779:
Schalleistungspegel
LWad, B Schalldruckpege
LpAm, dBA
(Zuschauerpositionen)
Leerlauf Betrieb Leerlauf Betrieb
mit 0xHDD
mit RZ1DF 5,3 5,4 5,3 5,5 38 38 38 41
Aktuelle Werte für speziele Ausrüstungsstufen sind uber die Compaq
Computer Vertretungen erhältelich. 1 B = 10 dBA.
For More Information
•AlphaServer DS10 / AlphaStation VS10
Console Reference (EK-DS10S-CR)
•AlphaServer DS10 Quick Setup
(EK-DS10S-CP)
•Using a Web browser, follow links to the
appropriate documentation from the URL:
http://www.compaq.com/showroom/
