Comprehensive CVE-TRX01 User manual

VGA UTP Extender 1X1 Splitter with Audio
１
USER MANUAL
Table of Contents
1.0 Introduction……………………………………………………..2
2.0 Specifications…………………………………….………..……2
3.0 Package Contents………………………………………….…..3
4.0 Panel Descriptions…………………………………….…….…4
5.0 Connection and Operation..................................................5
Cable and Connectivity Company
CVE-TRX01

VGA UTP Extender 1X1 Splitter with Audio
２
VGA UTP Extender 1X1 Splitter with
Audio
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
1.0 Introduction
This VGA UTP Extender 1X1 Splitter with Audio is an ideal device for local
displaying and remote viewing. It combines split function and extension function. It
distributes the input of the VGA signal and audio signal into the local and remote
outputs simultaneously. Receiver by Cat5 x1 works with the Sender as a full
functional module by receiving the distributed signal from the sender and
transmitting to display. Only by the most inexpensive UTP cable with cross stand
inside, the full functional module extend the VGA display max up to 300 meters.
It offers solutions for VGA retail and show site and Projector factory, noise, space
and security concerns, data center control, information distribution, conference
room presentation, school and corporate training environments.
1.1 FEATURES
This device has many features that enable it to perform in a superior manner.
Among those features you will find:
Extend VGA video and stereo audio signal max up to 300m over one UTP
cable with cross stand inside
Adjusting GAIN and PEAK to adapt for the different length of UTP cable.
GAIN: Brightness adjustment.
PEAK: Skew adjustment.
Supports resolution max up to 1920x1200.
Dual output at local unit: 1 x VGA output for local site, plus 1 x UTP output for
remote site.
Work with monitors projectors, HDTV, and flat panels.
2.0 SPECIFICATIONS
Input /Output Connector
oiduAoeretS,)nip51elameF(AGVrotcennoctupnI
,)nip51elameF(AGVrotcennoctuptuO
Stereo Audio,1xRJ45
Operating Frequency
Vertical Frequency Range 60/75/85Hz
Resolutions(PC)

VGA UTP Extender 1X1 Splitter with Audio
３
640X480
800X600
1024X768
1280X720
1280X768
1280X960
1280X1024
1600X900
1600X1200
1920X1080
1920X1200
Mechanical
Size of VGA UTP Extender 1X1
Splitter
100×65×25.5mm
Weight of VGA UTP Extender 1X1
Splitter
208g
Size of Receiver (L-W-H) 81.5×43×23MM
Weight of Receiver (Net) 108g
Warranty
robaLdnastraPrsaeY2ytnarraWdetimiL
Environmental
Operating Temperature 0℃to +70℃
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10℃to +80℃
)noitasnednocon(HR%09ot%5ytidimuHegarotS
Power Requirement
Power Supply for VGA UTP Extender
1X1 Splitter
5V@2A, max 5W
Power Supply for Receiver 5V@2A, max 5W
Regulatory Approvals
LU,EC,CCFtinUretrevnoC
CCF,EC,LUylppuSrewoP
Accessories Adapter
AC Power Adapter US standard, UK standard and so on
noisreVhsilgnElaunaMresU
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1) VGA UTP Extender 1X1 Splitter
2) User’s Manual.

VGA UTP Extender 1X1 Splitter with Audio
４
3) One Receiver
4) Two pieces of 5V@2A DC Power Supply.
4.0 PANEL DESCRIPTIONS
Sender
VGA UTP Extender
1X1 With Audio
VGA Output
1
6
11
5
10
15
Audio Out
15
10
5
11
6
1
VGA Input
Audio In
Receiver
VGA UTP Extender
With Audio
5.0 CONNECTION AND OPERATION
1) Connect the single VGA source to the main VGA input using a piece of VGA
cable.
2) Connect VGA output of the Sender to a local display and Audio output of the
Sender to a local Sounder
3) Connect Sender and each Receiver using a piece of each pieces of CAT-5e/6
4) Connect VGA outputs of Receivers to remote displays and Audio output of
Receivers to remote sounders.

VGA UTP Extender 1X1 Splitter with Audio
５
5) Plug one 5V@ 2A power supply into the VGA UTP 1X1Splitter and the others
5V@2A power suppliers to Receiver.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
