CompuSTAR A311R User manual

CompuStar 2000-AS User's Manual Page 1 of 10
FCC ID : O44JA311R
CompuStar A311R
USER’S GUIDE
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
CAUTION: Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority
to operate this device.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

CompuStar 2000-AS User's Manual Page 2 of 10
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult your Authorized CompuStar dealer.
1. Transmitter Button Functions
Channel Button Function
1. Lock Arm
2. Unlock Disarm
3. Lock+Panic Aux1
4. Unlock+Panic Aux2
5. Panic Panic
6. Start Remote Starting
7. Stop Remote Stop
8. Trunk Trunk Release
9. (Lock+Unlock) SirenChip - On/Off
10. (Lock+Start) Valet Mode - On/Off
11. (Lock+Stop) Shock Sensor On/Off
13. (Unlock+Stop) Timer Mode 1.5 hour -
On/Off
15. (Lock+Trunk) Option Programming 1
16. (Unlock+Trunk) Option Programming 2

CompuStar 2000-AS User's Manual Page 3 of 10
2. Alarm Function
Upon arming, your alarm will be triggered by:
•Light Impact (first stage shock sensor). The siren will chirp 4
times and the parking lights will flash 4 times.
•Heavy impacts (second stage shock sensor). The siren will go off
and the parking lights will flash for 60 seconds.
•Door opened. The siren will go off and the parking lights will flash
for 60 seconds
•If you have installed the Optional starter kill function, your vehicle will
not start with key when system is armed.
Note: (Siren duration 30Sec. or 60Sec. refer to programming section)
3. Panic
In Case of emergency, and you want to attract attention. Press button
Panic.
4. Start Function
Press button III for 2 seconds to start the engine. The engine will start.
The engine will run 15 minutes (25 min for diesel) or 25 minutes (40 min
for diesel). Ifthe engine has a problemstartingthe system will retry 2
additional times. If the engine does not start after the 3rd attempt, please call
you Authorized Dealer.
Note: Runtime, please consult you Authorized Dealer.
Diagnosis for Remote Starting Error
If there is anerror, youwill hear three chirps when you attempt to remote
starting the vehicle. 2 seconds later, the cause for the error will be indicated
by the chirping and parking light flashes.
Error
Number Error Reason
1EngineOn
2KeyOn
3 Door Open
4 Trunk Open
5 Brake On / Valet Switch On
6 Hood Open

CompuStar 2000-AS User's Manual Page 4 of 10
7 Reservation Off (Manual Transmission Only)
5. Remote Starting for the manual transmission
IMPORTANT
1. The transmission must be in the NEUTRAL position.
2. The vehicle windows must be rolled up.
3. Do not set the reservation mode with any people in the
vehicle.
4. Do not remote start with any people inthe vehicle.
Note: The system is not recommended for vehicle with
removable tops.
Reservation Mode must be set for manual transmission.
Step 1: After arriving at the destination, and before turning the
engine OFF, place the transmission in the Neutral position.
Step 2: Remove your foot from the foot brake.
Step 3: Activate the parking brake.
Step 4. Remove the key from the ignition. The engine will remain
running.
Step 5. Exit the vehicle and close the door within two minutes from
step 3. The engine will shut off and reservation mode for the
remote starter is now complete.
Your vehicle is now ready for remote starting. However, the
reservation mode will be cancelled if the door is opened or the
CompuStar is put in Valet mode after the reservation has been set.
Once cancelled, you will have to start the vehicle withthe key and
repeat the above 5 steps if you want to restore the reservation.
Note: If you try to remote start the vehicle when the reservation
mode has not been set or cancelled, the system will not start. The
parking lights will flash three times
Canceling Reservation Mode

CompuStar 2000-AS User's Manual Page 5 of 10
If you do not want to set the reservation mode, shut off the engine
before you exit the vehicle. The engine will shut off if (a) you do
not activate your parking brake or press the foot brake when you
turn your key to off position, (b) release your parking brake while
engine is running, or if (c) you press button III between step 3 and
4.
6. Safety Shut Down
System has several Shut Down inputs. That will shut down the engine or
prevent from remote starting.
•the Hood is opened,
•the Brake is pressed,
•the Valet mode is entered, or
•the Valet switchis turned on.
7. Aux 1 & Aux 2
The system has Aux1 & Aux2 output to be utilized withoptional features.
(Consult your Authorized Dealer)
8. Valet Mode
In Valet mode, the systemwill only activate Locks, Trunk, and the
Auxiliaryonly
9. Valet Switch
Turn On the switch to shut off the Remote Starter System only. Turn Off
By-Pass switch to activate remote starting function.
10. Shock Sensor
Dual Stage Shock Sensor will activate 30 sec. After the system is armed
(Locked). When 1st stage is triggered the sirenwill chirp 4 .
11. Timer Start
To enter the Timer Mode press buttons Unlock & Stop simultaneously for
½ second. The systemwill start every 1.5 Hrs. till Timer Mode is
deactivated and automatically canceled if the vehicle is started with the Key

CompuStar 2000-AS User's Manual Page 6 of 10
or Remotely. To Exit Timer Mode press buttons Unlock & Stop
simultaneously for ½ second again.
12. Transmitter Learning Procedure
Your transmitter has been programmed at the factory. However, if
you replace or add additional Remote, follow this procedure.
Steps 1: Put the system in Valet mode with key: Ignition on and off
five times with key within 10 seconds. The parking light will flash
once.
Step 2: Within 6 seconds, press the button Lock for a half-second.
Step3: The parking light will flash twice to confirm Step 2.
Step 4: Program 2nd transmitter or 3rd transmitter by pressing any
button. The system will program up to 3 transmitters. The parking
light will flash once to confirm Step 3.
13. Programming Options with Transmitter
Step 1. Programming Option1. Press buttons Lock and Unlock for 2
seconds. Programming Option 2: Press buttons Lock and Start for 2
seconds. The siren will chirp once. Now you are in the programming
mode.
Step 2. Within 2 seconds, press Stop for the number of times to go
to the option number you want to change. You will hear a chirp and
see the parking lights flash each time you press button Stop.
Step 3. Wait few seconds. You will hear a number of chirps and see
a number of parking light flashes corresponding the number of the
option you want to change. If the number of chirps or flashes is not
what you wanted, go back to the Step 1.
Step 4. Press Lock for the factory setting; one chirp and one flash.
Press Unlock for the OptionSetting; two chirps and two flashes.
•If you hear a long chirp, you are going out of the
programming mode. Go back to the step one.
•If you want to change more options go back to the step I.

CompuStar 2000-AS User's Manual Page 7 of 10
Option Resetting:
No. Factory Setting -Button I Option Setting - Button II
1No unlock before remote
starting Unlock before remote starting for factory disarm.
2.5 sec lock/unlock pulse 2.0 sec lock/unlock pulse
Minimum Cranking Time for the Alternator Setting
3
1st Try 2nd Try 3rd Try
.8 sec .9 sec 1.0 sec 1st Try 2nd Try 3rd Try 1.0 sec 1.1 sec 1.2 sec
4Regular Unlock Safety Unlock (Lock, Unlock,
Unlock)
5Regular Unlock Double Unlock
6Regular Dome Light Dome Light Factory Rearm
(Dome Light before Lock Pulse)
O
p
tion 1
7Regular Remote Start
Activation Input Cold start with Temperature Sensor. With this option, the
minimum interval between
automatic starts will be 1.5
hour.

CompuStar 2000-AS User's Manual Page 8 of 10
No. Factory Setting - Button I Factory Setting - Button II
1Active Arming (Locking) Passive Arming but Active
Locking
2Active Arming (Locking) Passive Arming and Passive
Locking
3.5 sec Aux 1 Output LatchAux 1 Output
4.5 sec Aux 2 Output LatchAux 2 Output
5No Ignition Lock Ignition Lock
630 sec Siren Duration 60 sec Siren Duration
Option 2
7Arming (Locking) upon
reservation No Arming (Locking) upon reservation
To Reset Everything to the factory default settings.
Step 1: Press buttons Lock+Unlock simultaneously or Lock+Start
simultaneously for 2 seconds. Confirmed by chirp and parking light -
one time.
Step 2:Press button Start three times. Confirmed by a chirp and
parking light each time you press button Start and three chirps and
flash after your press button Start three times.

CompuStar 2000-AS User's Manual Page 9 of 10
14. Limited Lifetime Warranty
Firstech, Inc. Warrants to the original purchaser that this product
shall be free of defects in material and workmanship under normal
use and circumstances for the period of time that the original owner
of this product owns the vehicle in which it is installed; except that
the remote controller unit for the period of one year from the date of
installation to the original owner of this product. When the original
purchaser returns the product to the retail store where it was
purchased or pre-paid postal to Firstech, Inc., 801 E. 82nd Ave. Suite
1, Anchorage, Alaska 99518, USA within the warranty period, and if
the product is defective Firstech, Inc, will at its option repair or
replace such.
“TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL
WARRANTIES ARE EXCLUDED BY THE MANUFACTURER AND
EACH ENTITY PARTICIPATING IN THE STREAM OF COMMERCE
THEREWITH. THIS EXCLUSIONINCLUDES BUT IS NOT LIMITED
TO, THE EXCLUSION OF ANY AND ALL WARRANTY OF
MERCHANTABILITY AND/OR ANY AND ALL WARRANTY OF
FITNESS FOR A PARTICULAR PURPOSE AND/OR AHY AND ALL
WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE
UNITED STATES OF ANERICA AND/OF ABROAD. NEITHER THE
MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH
SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES
WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY
CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES,
DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS,
COMMERCIAL LOSS, LOSS OF ECOMONIC OPPORTUNITY AND
THE LIKE. NOTHWITHSTANDING THE ABOVE, MANUFACTURER
DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR
THE CONTROL MODULE AS DESCRIBED ABOVE. Some states
do not allow limitations on how long an implied warranty will last or
the exclusion or limitation of incidental or consequential damages.
This warranty gives you specific legal rights, and you may also have
other rights, which vary State to State.

CompuStar 2000-AS User's Manual Page 10 of 10
IMPORTANT NOTE:
A product’s warranty is automatically void if its date code or
serial number is defaced, missing, or altered. This warranty
will not be valid unless you have completed the warranty card
and mailed it to Firstech, Inc., within 10 days after purchase to
the address listed on the card.
Registration Card
Name________________________________________________
______________________________________________
Address_______________________________________________
_____________________________________________
City__________________ State___________________
Zip____________
Phone Number: Home ( )_____________ Office ( )___________
Place of Purchase__________________________
Date of Purchase______
Purchase Model___________________
Purchase Price__________
Vehicle Make___________________
Model:_________________________
How did you hear about this product?_______________________
____________________________________________________
Firstech Inc.
801 E. 82nd Ave. Suite 1
Anchorage, AK 99518
