CompuSTAR Pro P1BAMR User manual

1
User Manual
By Firstech LLC, Version: 1.1
Applicable to the following remote(s);
Pro 1BAMR (1-Way 1 Button Remote)
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions;
(1) This device may not cause harmful interference.
(2) This device may accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this device.
WWW.COMPUSTAR.COM

2
Table Of Contents
Introduction............................................................................................................................................3
Kit(s) Contents .......................................................................................................................................3
Warranty Coverage................................................................................................................................3
Remote Reference .................................................................................................................................3
Quick Reference ......................................................................................................................................4
Valet Mode.........................................................................................................................................4
Remote Maintenance – Battery Replacement ...................................................................................4
One-Way Remote: Pro 1BAMR .............................................................................................................4
1 Button Remote Functions................................................................................................................4
General System Functions....................................................................................................................4
Sending Commands...........................................................................................................................4
Active Lock/Arm and Unlock/Disarm..................................................................................................5
Automatic Transmission Remote Start Function................................................................................5
Manual Transmission Remote Start Function (Reservation Mode)....................................................5
Activating Reservation Mode .............................................................................................................5
Cancelling Reservation Mode ............................................................................................................6
Reservation Mode Settings................................................................................................................6
Anti Grind/Starter Kill..........................................................................................................................6
Secure Valet Switch...........................................................................................................................6
Remote Coding / Programming Routine(s) .........................................................................................7
Programming P1BAMR......................................................................................................................7
Remote Start Error Diagnostic .............................................................................................................7
Limited Lifetime Warranty.....................................................................................................................8
Notes:......................................................................................................................................................9

3
Introduction
Thank you for purchasing a CompuStar Pro system for your vehicle. In order to truly enjoy the benefits of
this system, we recommend that you fully review the following manual. Please note that this manual
applies to the Pro 1 Button Remote Starter system only. The P1BAM-S offers keyless entry and remote
start only. There may also be features listed in this manual that require additional installation or
programming before they can become active. If you have any questions, please contact the original
place of purchase. For further information you may also contact our customer support center by calling
888-820-3690.
Kit(s) Contents
- 1 x Pro 1BAMR Remote
- Starter Only Control Module
- 1 x ANT-AM Antenna
- 1 x Hood Pin
Warranty Coverage
Caution: The Manufactures warranty will be voided if this product is installed by anyone other than an
authorized CompuStar Pro dealer. For complete warranty details visit www.compustar.com or the last
page of this manual.
Warranty registration can be completed online by visiting www.compustar.com. Please complete the
registration form within 10 days of purchase. We no longer include a mail-in warranty registration card
with each unit – registration must be done online. To verify that an authorized dealer installed your
system, we highly recommend that you keep a copy of the original proof of purchase, such as the dealer
invoice in a safe place.
Remote Reference
P1BAMR (1-Way 1 Button Remote)
Applicable to the following models;
- P1BAM-S (remote start only)

4
Quick Reference
Valet Mode
When servicing or loaning your vehicle to others, the CompuStar Pro system should be placed in Valet
mode. Valet mode prevents the system from remote starting and disables all alarm functions.
IMPORTANT: While in Valet mode the CompuStar will still lock and unlock power lock systems.
The system can be put into valet one of two ways;
1. You can put the system into valet by turning the ignition key “on” and then “off” five
times within 7 seconds. The parking lights will flash once to confirm the system is in
valet mode. Shortly after the first flash, the parking lights will flash twice.
2. (Optional Feature) If your system is set up for a secure valet option, you will not be able to put the
system into valet until the proper code has been entered with the secure valet switch.
Remote Maintenance – Battery Replacement
The only regular maintenance this system requires is remote control battery replacement.
No programming is required when replacing the battery.
One-Way Remote: Pro 1BAMR
First, remove the small Phillips screw located on the back of the remote. Once the screw has been
removed, gently pull the remote apart being careful to not touch the circuit board. The P1BAMR requires
two CR2016 batteries. These specialty batteries can be purchased from your local CompuStar dealer or
an electronics store.
1 Button Remote Functions
Button Duration Additional Programming
Required Function / Description
1.0
second no Lock/Arm. Tap again to Unlock/Disarm your vehicle
3.5
seconds no Activates the remote start. Repeat and remote start will shut off.
General System Functions
The remote transmitter functions have been predetermined and programmed from the factory. The single
button configuration allows for keyless entry and/or remote start functionality. Although other CompuStar
PRO systems have numerous button functions and capabilities, please keep in mind that your system
has the option for future upgradeability to a 2-way system.
Sending Commands
When in range, and the button has been pressed, the remote bright blue LED will illuminate and vehicle’s
parking lights will flash. For example, to send a remote start command from the P1BAMR, hold down the
single button for 3.5 seconds. The remote bright blue LED will come on solid and then flash.

5
Active Lock/Arm and Unlock/Disarm
Tap the single button for 1 second to lock/arm and unlock/disarm. The remote bright blue LED
will flash four times indicating the signal has been sent to the vehicle.This feature is optional
and may require additional programming and/or installation. Please check with your dealer for details.
Automatic Transmission Remote Start Function
Hold the single button for 3.5 seconds to remote start an automatic transmission vehicle. If you are in
range and if the vehicle is ready to remote start, the vehicle parking lights will flash once.
If you are in range, the parking lights on the vehicle will flash three times followed by a certain number
after that, there is a remote start error. Refer to the “remote start error diagnostic” on the last page of this
manual for details.
Upon receiving confirmation that your vehicle is running, the parking lights will light solid. The remote-
start run-time can be programmed for 3, 15, 25, or 45 minutes - ask your local CompuStar dealer to
adjust Option 2-7 if you would like a run-time other than 15 minutes (default).
IMPORTANT: The vehicle’s key must be inserted into the ignition and turned to the “on” position prior to
driving your vehicle. If the foot brake is depressed prior to the key being in the “on” position, the vehicle
will shut off.
Manual Transmission Remote Start Function (Reservation Mode)
In order to remote start a manual transmission vehicle, the system must first be set in Reservation Mode.
Reservation Mode must be set each and every time you want to remote start a manual transmission
vehicle. The purpose of Reservation Mode is to leave the transmission in neutral before exiting the
vehicle.
IMPORANT:
•The transmission must be left in the neutral position.
•The vehicles windows must be rolled up.
•The vehicles door pins must be in working order.
•Do not install this remote start on a manual transmission vehicle that has a convertible or
removable top.
•Do not set reservation mode or remote start with people in the vehicle.
Activating Reservation Mode
STEP 1: While the vehicle is running, place the transmission in neutral, set the emergency / parking
brake, and remove pressure from the foot brake.
STEP 2: Remove the key from the vehicle’s ignition. The vehicle’s engine should remain running even
after the key has been removed. If the vehicle does not remain running visit your local authorized
CompuStar dealer for service.
STEP 3: Exit the vehicle and close the door. The vehicle’s engine should shut off within upon closing the
last door. If the vehicle’s engine does not shut off, your door trigger may be functioning improperly. Do
not use the remote-start feature and take your vehicle to a local authorized CompuStar dealer for
service.
IMPORTANT: By default, the system will lock/arm the vehicle upon setting reservation mode. Take care
to not lock your keys inside the vehicle.

6
Cancelling Reservation Mode
Reservation mode will be cancelled for the following reasons;
•You did not activate the parking brake prior to turning off the ignition.
•You pressed the foot brake after the key was removed from the ignition.
•You released the parking brake after the key was removed from the ignition.
•You entered valet mode, opened the vehicles door, hood, or trunk.
Reservation Mode Settings
Reservation mode settings can be programmed with Option 1-6. It is recommended that reservation
mode settings are programmed by your local authorized CompuStar dealer.
Default 1: Locks doors when reservation mode is set.
Option 2: Does not lock doors when reservation mode is set.
Option 3: Reservation mode sets 10 seconds after the last door is closed, as opposed to immediately.
This option will allow you to access the vehicles rear doors, trunk or hatch prior to the system setting
reservation and passively locking/arming.
Anti Grind/Starter Kill
The optional anti-grind/starter kill feature prevents you from accidentally grinding your vehicle’s starter
motor when taking over with the key. This feature requires additional installation and programming. Also
your dealer can program a basic security feature that prevents your vehicle from starting when it is
locked/armed. Please see your dealer for more details.
Secure Valet Switch
The optional Secure Valet Switch prevents the remote start from being put into valet mode through
cycling the ignition on/off five times. The Secure Valet Switch is more secure than traditional toggle /
valet switches because it requires a two digit code. Follow the below procedures to program your secure
valet pass code:
STEP 1: Turn on Option 3-10-III. (Dealer programmed option)
STEP 2: Turn ignition key to the “on” position.
STEP 3: Hold down the valet switch for 1.5 seconds. The LED on the valet switch will begin to flash
rapidly with successful completion of this step.
STEP 4: Enter the first digit of the desired two-digit pass code by depressing the switch the number of
times that coordinates with the desired first number. For example, to enter 3, depress the switch 3 times,
then wait.
STEP 5: The LED will confirm the first number by flashing BLUE slowly. Once the LED begins to flash
rapidly, enter your second number by repeating step 4.
STEP 6: Turn the ignition off - the Secure Valet Switch is now programmed. Follow steps 3 – 5 to enter
your Secure Valet code.

7
Remote Coding / Programming Routine(s)
IMPORTANT: Every CompuStar Pro remote must be coded to the system prior to performing any
operations. All remotes must be coded at the same time.
Programming P1BAMR
STEP 1: Activate Valet/Programming mode by manually turning the ignition key on and off (between the
Acc & On positions) five times within 7 seconds. The vehicle’s parking lights will flash once with the
successful completion of this step.
STEP 2: Within a 3 second period after cycling the ignition for the 5th time, pressing the single button
once for 0.5 seconds. The parking lights will flash once to confirm the transmitter has been coded.
Exiting Programming: Programming is a timed sequence. The parking
lights will flash twice signaling the end of programming mode.
Programming Multiple Remotes: After the confirmation flash given in
step 2, code additional remotes by pressing the single buttonon
remote. The parking lights will flash once confirming each additional
remote. All systems can recognize up to three remotes.
Remote Start Error Diagnostic
If the remote start fails to start the vehicle, the parking lights will flash three times immediately. Following
those three flashes the parking lights will flash again corresponding to the error table.
Number of
Parking Light
Flashes Remote Start Error
1 Motor running
2 Key in ignition on position
3 Door open (manual transmission only)
4 Trunk open
5 Foot brake on
6 Hood open
7 Reservation off (manual transmission only)
8 Tach or voltage sensing failure
We recommend that you do not attempt any repairs on your remote starter. Contact your dealer or call us
directly.

8
Limited Lifetime Warranty
Firstech, LLC Warrants to the original purchaser that this product shall be free of defects in material and
workmanship under normal use and circumstances for the period of time that the original owner of this
product owns the vehicle in which it is installed; except that the remote controller unit for the period of
one year from the date of installation to the original owner of this product. When the original purchaser
returns the product to the retail store where it was purchased or prepaid postal to Firstech, LLC., 21911
68th Avenue South, Kent, WA 98032, USA within the warranty period, and if the product is defective,
Firstech, LLC, will at its option repair or replace such.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUDED BY
THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COMMERCE
THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO, THE EXCLUSION OF ANY
AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OR
PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD. NEITHER THE
MANUFACTURER OF ANY ENTITIES CONNECTED THEREWITH SHALL BE RESPONSIBLE OR
LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY
CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE.
NOTWITHSTANDING THE ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO
REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or
limitation on how long an implied warranty will last or the exclusion or limitation of incidental or
consequential damages. This warranty gives you specific legal rights, and you may also have other
rights, which vary State to State.
Firstech, LLC. is not RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING
BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES
FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC
OPPORTUNITY AND THE LIKE that may or may not resulted from the operation of Compustar. NOT
WITH STANDING THE ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO
REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE.
Your Warranty
The product's warranty is automatically void if the date code or serial number is defaced, missing or
altered. This warranty will not be valid unless you have completed the registration card at
www.compustar.com within 10 days of purchase.

9
Notes:
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________

10
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________

11

12
www.compustar.com
Toll Free: 888-820-3690
21911 68th Ave S
Kent, WA 98032
