Computronic Q4M User manual

BLACK AND WHITE QUAD
Q4M
Q8M
Installation and user manual

IMPORTANT SAFEGUARDS
Q4M/Q8M
1
READ THE INSTRUCTIONS
Be sure to read all the safety and operating instructions before using the device.
KEEP THE INSTRUCTIONS
Be sure to keep all the safety and operating instructions for possible future need and queries.
FOLLOW THE INSTRUCTIONS
Be sure to follow all the safety and operating instructions.
WATER AND HUMIDITY
Do not use the unit near water –for example near a bath tub, or in any area showing evidences of
humidity.
POWER SUPPLY
This equipment can be fed only by the type of supply quoted by a production code on the device.
Do not overload electric adapters and extension cords as this can result in fire or electric shock.
REPAIR
Do not attempt to open covers and to service this unit yourself, refer all repairs to qualified service
personnel.
UNPACKING
Transfer package is a safe covering for device transportation. We recommend to keep the wrap-
ping for relevant future usage.

TABLE OF CONTENTS INTRODUCTION
Q4M/Q8M
2
INTRODUCTION ........................................2
MAIN CHARACTERISTICS........................2
OPERATING ELEMENTS
AND FUNCTIONS ......................................3
INSTALLATION..........................................5
MONITOR OUTPUTS..............................5
ALARM INPUTS ......................................5
ALARM OUTPUT.....................................5
ALARM CONNECTOR ............................5
POWER SUPPLY INPUT ........................5
QUAD CONTROLLING..............................5
BASIC MODE .........................................5
MANUAL SWITCHING ...........................5
AUTOMATIC SWITCHING......................5
CAMERA FREEZE IN QUAD SCREEN...5
MAIN MENU............................................6
CAMERA ACTIVATION...........................6
SWITCHING PERIOD .............................6
ALARM....................................................6
INTERLACE CORRECTION....................7
BEFORE LOOKING FOR HELP ................8
TECHNICAL SPECIFICATION...................9
Programmable quad Q4M (Q8M) is a digital
apparatus, which enables displaying of 4
cameras (two pages of four cameras) on one
output (QUAD).
It also enables switching of input video sig-
nals of the cameras and a quad screen. The
switching can be provided manually or with
the help of programmed sequence for the
main output (MAIN). It is possible to set up
cameras, which are at the right time available
for automatic switching. This makes possible
to disconnect temporarily uninteresting or
disconnected cameras. An operator attention
can be focused only on important camera
images.
The unit contains 4 (8) alarm inputs. The
quad itself remembers the last setting of ac-
tive cameras, a programmed sequence and
the time of switching an alarm output, even
after the unit had been switched off.
MAIN CHARACTERISTICS
o4 (8) video inputs
omain and auxiliary video output
ohigh differential ability
o512 TV lines (480 for EIA)
o256 gray scale
oon screen menu control
oautomatic norm detection of connec-
ted cameras
olight signaling of disconnected came-
ras on the operating panel
oprogrammable switching sequence for
the main monitor
oalarm input for each video input
opotentialless alarm output
ofreeze picture
o2 alarm setting modes
oacoustic and optical alarm signaling

OPERATING ELEMENTS AND FUNCTIONS
Q4M/Q8M
3
Pict.1: Front panel Q4M
MENU3 4
1 2 QUAD SEQ
QUAD PROCESSOR
Q4M
Pict.2: Front panel Q8M
QUAD2 MENU5 76 8
1 32 4 QUAD1 SEQ
DUAL PAGE QUAD PROCESSOR
Q8M
1 2 3
5
4
1. 1 - 8
Press the button 1 –8 to display the appro-
priate camera image.
2. QUAD1
Press the button QUAD1 to display the split
screen containing cameras 1 –4.
3. SEQ
Press the button SEQ to start the automatic
camera switching, according to the pro-
grammed sequence.
4. QUAD2
Press the button QUAD2 to display the quad
screen containing cameras 5 –8 (only for
quads Q8M).
5. MENU
Press the button MENU to display the control
menu on the screen.
Pict.3: Back panel Q4M
IN 1 QUAD MAIN
ALAR M
IN 3
IN 4 IN 2
POW ER
12V
-
+
Pict.4: Back panel Q8M
IN 1 QU AD M AIN
ALAR M
IN 3IN 5IN 7
IN 8 IN 6 IN 4 IN 2
POW ER
12V
-
+
67 8 9 10 11
6. IN1 –IN8
Video inputs for cameras 1 –8.
7. QUAD
Quad screen video output.
8. MAIN
Main video output.
9. ALARM
Connector for connecting alarm inputs and
outputs. This connector enables connecting
of alarm contact makers, sensors, etc.
10. POWER
Press the switch POWER to start the quad.
11. 12V
Connector for connecting power supply.

OPERATING ELEMENTS AND FUNCTIONS (CONTINUATION)
Q4M/Q8M
4
Pict. 5: Alarm connector CANNON 25 for Q4M
13 12 11 10 9 8 7 6 5 4 3
141516171819202122232425
2 1
(1) Alarm output –normally open contact 1
(2) Reserve
(3) Alarm input 1
(4) Alarm input 3
(5) Reserve
(6) Reserve
(7) Common conductor –ground (GND)
(8) Reserve
(9) Reserve
(10) Reserve
(11) Reserve
(12) Common conductor –ground (GND)
(13) Common conductor –ground (GND)
(14) Alarm output –normally open contact 2
(15) Reserve
(16) Alarm input 2
(17) Alarm input 4
(18) Reserve
(19) Reserve
(20) Common conductor –ground (GND)
(21) Reserve
(22) Reserve
(23) Reserve
(24) Reserve
(25) Common conductor–ground (GND)
Pict. 6: Alarm connector CANNON 25 for Q8M
13 12 11 10 9 8 7 6 5 4 3
141516171819202122232425
2 1
(1) Alarm output –normally open contact 1
(2) Reserve
(3) Alarm input 1
(4) Alarm input 3
(5) Alarm input 5
(6) Alarm input 7
(7) Common conductor –ground (GND)
(8) Reserve
(9) Reserve
(10) Reserve
(11) Reserve
(12) Common conductor –ground (GND)
(13) Common conductor –ground (GND)
(14) Alarm output –normally open contact 2
(15) Reserve
(16) Alarm input 2
(17) Alarm input 4
(18) Alarm input 6
(19) Alarm input 8
(20) Common conductor –ground (GND)
(21) Reserve
(22) Reserve
(23) Reserve
(24) Reserve
(25) Common conductor –ground (GND)

INSTALLATIONQUAD CONTROLLING
Q4M/Q8M
5
MONITOR OUTPUTS
Outputs QUAD and MAIN are individual video
outputs for connecting monitor or VCR. For
the correct function of the connected appa-
ratus the signal cables must have the imped-
ance load of 75.
ALARM INPUTS
One alarm input is suitable for one video in-
put. Alarm loops are connected between
alarm input and common conductor - ground
(GND).
ALARM OUTPUT
Quad has its own potentialless alarm output
made of the normally open contacts of the
relay.
ALARM CONNECTOR
Alarm connector is used for connecting alarm
inputs and outputs. The connection of 25
outlet connector CANNON is illustrated on
the pictures 5 and 6 (page 4).
POWER SUPPLY INPUT
Quads Q4M (Q8M) are supplied from a uni-
flow supply of 12 V. Energy input is 4 W
maximum. For connecting supply voltage is
used a concentric connector 5,5 x 2,1 mm.
The positive supply pole is on the inside con-
tact of the concentric connector, the con-
nector jacket is the negative pole.
BASIC MODE
After turning on, the quad cyclically switches
among active cameras according to the se-
quence, which has been set up. The auto-
matic switching is signaled by the SEQ light-
emitting diode (LED), the camera displayed
on the main video output (MAIN) is signaled
by the diode of the buttons 1 –4 or QUAD
(1 –8, QUAD1 AND QUAD2 for Q8M).
MANUAL SWITCHING
Press the corresponding button to display
cameras 1 –8 or quad screens QUAD,
QUAD1 and QUAD2.
AUTOMATIC SWITCHING
The automatic switching starts by pressing
the button SEQ.
If the quad does not start to switch automati-
cally, check the camera settings in the menu
SEQUENCE and TIME (page 6).
CAMERA FREEZE IN QUAD SCREEN
Be sure, there is a quad picture displayed on
the output MAIN.
Press and keep the button 1 –8, the camera
screen will stop (freeze) or run-up if it was
stopped. When the picture is frozen, the
camera LED is shining together with the quad
picture LED QUAD, QUAD1 and QUAD2.
If the LED above the buttons 1 –4 (1 - 8 by
Q8M) is shining, the video signal of corre-
sponding cameras is missing.

QUAD CONTROLLING (continuation)
Q4M/Q8M
6
Quads Q4M and Q8M contain a graphical
menu, which enables the setting of the fol-
lowing functions.
oCameras activation for automatic
switching
oSwitching period set up
oAlarm functions set up
oInterlace correction
MENU - MAIN MENU
To display the main menu on the screen
press the button MENU. Choose the required
function by pressing the buttons 1, 2 and 3.
SEQUENCE –CAMERAS ACTIVATION
By pressing the button 1 is the menu for
cameras activation and deactivation for au-
tomatic switching displayed.
By pressing the buttons of individual cameras
activate or deactivate automatic switching
cameras. Activated cameras are marked by
sign .
If the cameras are set up, the quad will
switch automatically among cameras 1, 2, 3,
4, Q1, 1, 2, …
In case you make a mistake by sequence
programming (none or only one camera is
active) and you start the switching sequence
by pressing the button SEQ on the front pan-
el, notice „INCORRECT SEQUENCE“ will
appear. In that case is necessary to set up
cameras in the SEQUENCE menu properly.
TIME –SWITCHING PERIOD
By using the buttons 1 and 3 (1 and 5 by
Q8M) is possible to prolong or slow down the
switching time among individual cameras and
quad pictures, at intervals 1 –99 sec.
ALARM –ALARM SET UP
The quad detects an alarm, when the con-
nection is provided between the alarm input
1 –8 on the CANNON connector of the back
panel and the common conductor –ground
(GND). By the help of the buttons 1 and 3 (1
and 5 Q4M) set up quad reaction for an
alarm. The reaction can be:
OFF - alarm is off - quad does not
respond to the alarm.
FOLLOW - quad signalizes an alarm as
long as any alarm input is ac-
tive.
2-255 S -quad signalizes an alarm for
the set up time since the alarm
event had occurred.
If an alarm occurs, the quad makes the fol-
lowing steps:
1. it switches the alarm output (relay) –sig-
naled acoustically (beep).
2. it switches a camera corresponding to the
alarm input for the set up time.
The alarm stops after the end of the set up
time interval, after pressing any button or
after the end of the alarm event in the mode
FOLLOW
.

QUAD CONTROLLING (continuation)
Q4M/Q8M
7
INTERLACE CORRECTION ON/OFF
By pressing the button 4 switch ON/OFF the
interlace correction. Off interlace correction
of the life screen can cause a gliding effect,
which is evoked by projection of different
half-fields of the same camera. If you choose
the item (INT.ON), always the same half-field
will be shown. With the stability screen im-
provement will be the projection slower.

BEFORE LOOKING FOR HELP
Q4M/Q8M
8
YOUR TROUBLE
THE CAUSE AND ITS SOLUTION
After connecting the sup-
ply voltage device does
not work.
The power supply is not connected.
Check the supply connector and the polarity of power supply,
switch on the power breaker.
The supply adapter is not dimensioned sufficiently.
Check if the adapter power output and voltage agree with the quad
requirements.
After connecting the sup-
ply voltage the LEDs are
on, but the device does
not work.
The supply adapter is not dimensioned sufficiently.
Check if the adapter power output and voltage agree with the quad
requirements.
Horizontal stripes go over
the quad screen.
The supply adapter is not dimensioned sufficiently.
Check if the adapter power output and voltage agree with the quad
requirements.
Horizontal stripes appear
over the individual screen
quadrants.
Strong interference from power distribution has debased the cam-
era signal.
Check the camera connection.
Check the camera and monitor ground conductor.
Automatic switching se-
quence can not be
switched on.
Cameras listed in the switching sequence are off from the switch-
ing.
Correct the sequence and check the sequence period (page 6).
The picture in the quad
screen has stopped.
The picture has been stopped from the keyboard.
Check the LEDs on the display (page 5). Press and keep the but-
tons of the shining LEDs 1 –8.
Camera was disconnected or switched off.
Check the camera power supply and connection.
Device does not react to
alarm inputs.
The alarm processing is switched off in the main menu.
Set up the alarm with the function of ALARM (page 6).
The connection of the alarm signals is disconnected.
Check the connection of the alarm connector.
There is no picture on the
monitor.
The quad and monitor patchcord is defective.
Check the patchcord carefully.

TECHNICAL SPECIFICATION
Q4M/Q8M
9
PICTURE PARAMETERS
TV standard:
CCIR / EIA
Number of the active TV lines:
512 / 480
Samples per TV line:
864 / 856
Gray scale:
256
VIDEO INPUTS
Number:
4 (8 by Q8M)
Amplitude:
0,75 - 1,5 Vp-p
Input impedance:
75 
Connectors:
BNC
VIDEO OUTPUTS
Number:
2 individual
Standard:
CCIR / EIA
Amplitude:
1 Vp-p load 75 
Connector:
BNC
ALARM INPUTS
Number:
4 (8 by Q8M)
Loop connection:
input –ground (GND)
Activity:
normally open
Maximum alarm loop impedance:
1 k
Connector:
CANNON 25 pin socket
ALARM OUTPUT
Output:
2 low voltage relay contacts
Maximum switching voltage:
40 V
Maximum switching current:
0,5 A
TEMPERATURE CONDITIONS
Range of operating temperatures:
0 –40 C
Humidity:
max. 85 %
POWER SUPPLY
Input voltage:
12 VDC
Power consumption:
max. 4 W
Connector:
Concentric 5,5 × 2,1 mm
MECHANICAL PARAMETERS
Dimensions:
218(W) × 44,5(H) × 230(D) mm
Weight:
1,4 kg
ACCESSORIES
Alarm connector mate + cover:
1 p


2000 COMPUTRONIC
Printed in the Czech Republic
Producer reserves the right to alternation without prior notice
