Data Translation DT3157 Parts list manual

DT3157
UM-18235-E
Getting Started Manual

Fifth Edition
August, 2002
Data Translation, Inc.
100 Locke Drive
Marlboro, MA 01752-1192
[phone]
www.datatranslation.com
Fax: [phone]
E-mail: [email protected]
Copyright © 2000, 2001, 2002 by Data
Translation, Inc.
All rights reserved. No part of this publication
may be reproduced, stored in a retrieval system,
or transmitted, in any form by any means,
electronic, mechanical, by photocopying,
recording, or otherwise, without the prior
written permission of Data Translation, Inc.
Information furnished by Data Translation, Inc.
is believed to be accurate and reliable; however,
no responsibility is assumed by Data Translation,
Inc. for its use; nor for any infringements of
patents or other rights of third parties which
may result from its use. No license is granted by
implication or otherwise under any patent rights
of Data Translation, Inc.
Use, duplication, or disclosure by the United
States Government is subject to restrictions as set
forth in subparagraph (c)(1)(ii) of the Rights in
Technical Data and Computer software clause at
48 C.F.R, 252.227-7013, or in subparagraph (c)(2)
of the Commercial computer Software -
Registered Rights clause at 48 C.F.R., 52-227-19 as
applicable. Data Translation, Inc., 100 Locke
Drive, Marlboro, MA 01752
Data Translationand GLOBAL LABare
registered trademarks, and Imaging OMNI
CD, DT-Open Layers, Frame Grabber SDK,
and DT Vision Foundryare trademarks of Data
Translation, Inc.
All other brand and product names are
trademarks or registered trademarks of their
respective companies.

iii
Table of Contents
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Intended Audience. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
What You Should Learn from this Manual. . . . . . . . . . . . . . . . . . . v
Conventions Used in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . vi
Related Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Where to Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Chapter 1: Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Key Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DT3157 Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Getting Started Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2: Preparing to Use the DT3157. . . . . . . . . . . . . . . . 5
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Checking the System Requirements . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing the Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing the DT3157 Documentation. . . . . . . . . . . . . . . . . . . . . . 11
Viewing the DT3157 Documentation . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 3: Installing the Board . . . . . . . . . . . . . . . . . . . . . . 15
Setting up the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Selecting an Expansion Slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Inserting the DT3157 Board in the Computer . . . . . . . . . . . . . . . 19
Chapter 4: Connecting Signals . . . . . . . . . . . . . . . . . . . . . . 21
Using the EP-299 Cable (Kodak Cameras) . . . . . . . . . . . . . . . . . . 24
Using the EP-300 Cable (EG&G Cameras) . . . . . . . . . . . . . . . . . . 28
Using the EP-301 Cable (Pulnix Cameras) . . . . . . . . . . . . . . . . . . 31

Contents
iv
Chapter 5: Installing and Configuring the Device Driver. . 35
Before Installing the Device Driver . . . . . . . . . . . . . . . . . . . . . . . . 37
Installing and Configuring the Device Driver in Windows 98 . 38
Installing and Configuring the Device Driver in Windows Me 41
Installing and Configuring the Driver in Windows 2000 . . . . . . 44
Installing and Configuring the Device Driver in Windows XP. 47
Chapter 6: Verifying Board Operation . . . . . . . . . . . . . . . . . 51
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Installing DT-Acquire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Using DT-Acquire. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Synchronously Acquiring a Single Frame to Memory . . . . 56
Performing a Passthru Operation. . . . . . . . . . . . . . . . . . . . . . 57
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

v
About this Manual
This manual describes how to get started using a DT3157 frame
grabber board.
Intended Audience
This document is intended for engineers, scientists, technicians, or
others responsible for setting up a DT3157 board to perform machine
vision and/or image analysis operations. It is assumed that you have
some familiarity with the operating characteristics of your video
source. It is also assumed that you are familiar with the Microsoft
Windows98, Windows Me (Millennium Edition), Windows 2000, or
Windows XP operating system.
What You Should Learn from this Manual
This manual will help you install and set up your board and device
driver successfully. It is organized as follows:
•Chapter 1, “Overview,” describes the key features of the DT3157
Series hardware and software, and provides an overview of the
getting started procedure;
•Chapter 2, “Preparing to Use the DT3157,” describes how to
unpack the board and software, check system requirements,
install the DT3157 software, and view the DT3157 documentation
online;
•Chapter 3, “Installing the Board,” describes how to install the
DT3157 board;
•Chapter 4, “Connecting Signals,” describes how to connect
signals to the board;
•Chapter 5, “Installing and Configuring the Device Driver,”
describes how to install and configure the device driver; and

About this Manual
vi
•Chapter 6, “Verifying Board Operation,” describes how to verify
the board’s operation using DT-Acquire.
• An index completes this manual.
Conventions Used in this Manual
The following conventions are used in this manual:
• Notes provide useful information that requires special emphasis,
cautions provide information to help you avoid losing data or
damaging your equipment, and warnings provide information to
help you avoid catastrophic damage to yourself or your
equipment.
• Items that you select or type are shown in bold.
•Courier font is used to represent source code.
Related Information
Refer to the following documents for more information on using a
DT3157 board:
•TheDT3157 User’s Manual (UM-15024), included on the Imaging
OMNI CDprovided with the DT3157 board, describes the
features of the DT3157 board and DT3157 Device Driver in detail.
•Frame Grabber SDK User’s Manual (UM-13442) and the Frame
Grabber SDK online help, included on the Imaging OMNI CD
provided with the DT3157 board, describes the Dynamic
Linkable Library (DLL) that you can use to write image
acquisition application software.
•DT-Active Open Layers User’s Manual (UM-17325), available from
Data Translation, describes DT-Active Open Layers, an ActiveX
control, which allows you to use Data Translation PCI frame
grabber boards within graphical programming environments
such as Microsoft Visual Basic® and Visual C++®.

About this Manual
vii
•GLOBAL LAB Image/2 User’s Manual (UM-17790) and GLOBAL
LAB Image/2 API Manual (UM-17792),available from Data
Translation, describe how to use GLOBAL LAB® Image/2 and
GLOBAL LAB Image/2 Streamlineto create scientific
applications using object-oriented image processing tools.
•DT Vision Foundry User’s Manual (UM-17755) and DT Vision
Foundry API Manual (UM-17757), available from Data
Translation, describe how to use DT Vision Foundryto create
machine vision applications using object-oriented image
processing tools.
Where to Get Help
Should you run into problems installing or using a DT3157 board, our
Technical Support Department is available to provide technical
assistance. Refer to the Troubleshooting chapter of the DT3157 User’s
Manual for more information (see page 11 for information on
installing and viewing this manual). If you are outside the United
States or Canada,call your local distributor, whose number is listed
in your Data Translation product handbook.

About this Manual
viii

1
1
Overview
Key Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DT3157 Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Getting Started Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Chapter 1
2
Key Hardware Features
The DT3157 frame grabber accepts video from digital input sources.
It is suitable for both image analysis and machine vision applications.
Key features of the DT3157 board are summarized as follows:
• Operates as a PCI bus master;
• Accepts 8-, 10-, 12-, 14-, or 16-bit monochrome video from a
single RS-422 video channel (programmable to 2 KB x 2 KB, 4 KB
x 1 KB, or 1 KB x 4 KB), or 8-bit monochrome from two RS-422
video channels (programmable to 1 KB x 1 KB);
• Supports Kodak dual 8-bit video format (such as the Model
ES1.0);
• Supports up to 20 MHz on a single channel (8 to 16 bits), and
40 MHz for dual channels;
• Provides real-time image transfer to host memory or to the
display frame buffer;
• Provides real-time scaling, using decimation, up to 1/16 size
(except in dual-channel mode);
• Accepts an external trigger;
• Provides an input look-up-table that supports single- and
dual-channel mode;
• Provides eight TTL lines, each programmable as either input or
output; and
• Provides a standard SCSI-II, 68-pin, D-shell connector for I/O
connections.
For more information on the boards, refer to the DT3157 User’s
Manual (see page 11 for information on viewing this manual).

Overview
3
1
1
1
1
1
1
1
1
1
DT3157 Software
The DT3157 software, which is provided on the Imaging OMNI CD,
includes the following components:
•DT3157 Device Driver −You must install this device driver to use
the DT3157 board with any of the supported software packages
or utilities.
•DT3157 User’s Manual, in PDF format −Describes the features of
the DT3157 board and how to use the DT3157 Device Driver with
the Frame Grabber SDK to write an application program.
• This manual in PDF format.
Refer to Chapter 2 starting on page 5 for information on installing the
DT3157 software.

Chapter 1
4
Getting Started Procedure
The flow diagram shown in Figure 1 illustrates the steps needed to
get started using the DT3157 board. This diagram is repeated in each
chapter; the shaded area in the diagram shows you where you are in
the getting started procedure.
Figure 1: Getting Started Flow Diagram
Install the Board
(see Chapter 3 starting on page 15)
Connect Signals to the Board
(see Chapter 4 starting on page 21)
Verify Board Operation
(see Chapter 6 starting on page 51)
Install and Configure the Device Driver
(see Chapter 5 starting on page 35)
Prepare to Use the DT3157 Board
(see Chapter 2 starting on page 5)

5
2
Preparing to Use the
DT3157
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Checking the System Requirements . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing the Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing the DT3157 Documentation. . . . . . . . . . . . . . . . . . . . . . 11
Viewing the DT3157 Documentation . . . . . . . . . . . . . . . . . . . . . . 13

Chapter 2
6
Install the Board
(see Chapter 3)
Connect Signals to the Board
(see Chapter 4)
Verify Board Operation
(see Chapter 6)
Install and Configure the Device Driver
(see Chapter 5)
Prepare to Use the DT3157 Board
(this chapter)

Preparing to Use the DT3157
7
2
2
2
2
2
2
2
2
2
Unpacking
Open the shipping box and carefully remove the DT3157 frame
grabber board.
Verify that the following items are present:
• DT3157 frame grabber board and
• Imaging OMNI CD-ROM.
If an item is missing or damaged, call Data Translation's Customer
Service Department at [phone] x394. Customer Service will
guide you through the appropriate steps for replacing missing or
damaged items. If you are located outside the USA, call your local
distributor, listed in your Data Translation Product Handbook.
Note: We suggest that you save the original packing material in the
unlikely event that your board requires servicing in the future.
WARNING!
Keep the DT3157 board in its protective antistatic bag until you are
ready to install it.

Chapter 2
8
Checking the System Requirements
For reliable operation, your DT3157 board requires the following
minimum system requirements:
• 120 MHz Pentium processor with an Intel PCI chip set that
supports and enables PCI-to-posted memory writes. The
following Intel PCI chip sets are known to work properly:
−Triton 8243xFX,
−Triton2 8243xHX,
−Triton VX 8243xVX,
−Triton TX 8243xTX,
−Natoma 8244xFX, or
−Natoma 8244xLX.
Note: The following Intel PCI chip sets are known not to work
properly: Saturn 8242x, Mercury 8243xLX, Neptune 8243xNX,
Orion 8245xKX, and Orion 8245xKG. If your system contains one
of these chip sets, please call your system manufacturer to replace
the chip set with one that is supported.
• A BIOS that complies with PCI specifications, such as one of the
following:
−AMI, or
−AWARD (version 4.51PG).

Preparing to Use the DT3157
9
2
2
2
2
2
2
2
2
2
Note: Version 4, revision 6 of the Phoenix BIOS works properly.
However, early versions of this BIOS are known not to work
properly. If your system contains an earlier version of the
Phoenix BIOS, please call your system manufacturer to upgrade
the BIOS to Version 4, revision 6.
• At least one available PCI 32-bit or 64-bit bus master expansion
slot.
• At least 16 MB of RAM for Windows 98 or Windows Me; at least
32 MB of RAM for Windows 2000 or Windows XP. Note that for a
640-by-480 image, using an 8-bit digital camera, 1 MB holds
approximately three frames.
• A PCI graphics card with a 16-bit or 24-bit color palette. A
DDI-compatible, PCI graphics card is recommended for real-time
display.
• An digital input source (8-, 10-, 12-, 14-, or 16-bit) with
appropriate cabling.
• At least one CD-ROM drive.
•Aharddisk.
• Windows 98, Windows Me, Windows 2000, or Windows XP.

Chapter 2
10
Installing the Software
To install the DT3157 software, perform the following procedure:
1. Insert the Imaging OMNI CD into your CD-ROM drive.
2. Click Start from the Task Bar, then click Run.
The Run dialog box appears.
3. In the Command Line edit box, enter x:\LAUNCH.EXE (where x
is the letter of your CD-ROM drive).
4. Click OK.
The Imaging OMNI CD splash screen appears.
5. Click Install Products.
6. Click Mach I Series.
7. Click Device Drivers.
8. Click DT3157, then click Next.
If you are using Windows 2000 or Windows XP, the installation
instructions are displayed. If you are using Windows 98 or Windows
Me, the files are copied.
9. If you are using Windows 2000 or Windows XP, click Print to
print the installation instructions, or go to the next section to
install and print the DT3157 documentation.
10. Click Main Menu, then click Exit.

Preparing to Use the DT3157
11
2
2
2
2
2
2
2
2
2
Installing the DT3157 Documentation
If you are using Windows 98 or Windows Me and installed the
DT3157 device driver, the DT3157 documentation is automatically
copied to your hard drive. Refer to the next section for information on
viewing these documents.
If you are using Windows 2000 or Windows XP, perform the
following steps to install the DT3157 documentation:
1. Insert the Imaging OMNI CD into your CD-ROM drive.
2. Click Start from the Task Bar, then click Run.
The Run dialog box appears.
3. In the Command Line edit box, enter x:\LAUNCH.EXE (where x
is the letter of your CD-ROM drive).
4. Click OK.
The Imaging OMNI CD splash screen appears.
5. Click Install Products.
6. Click Mach I Series.
7. Click Documentation.
8. Click Getting Started.
9. Click DT3157.
10. Browse to the directory in which to copy the manual on your
hard disk, the click Next.
The manual is copied to your hard disk.
11. Click OK.
12. Click Back.
13. Click User’s Manual.
14. Click DT3157.

Chapter 2
12
15. Browse to the directory in which to copy the manual on your
hard disk, the click Next.
The manual is copied to your hard disk.
16. Click OK.
17. Click Main Menu, then click Exit.
Refer to the next section for information on viewing these documents.
