TRENDnet TFC-110MSC - DATA SHEETS User manual

TFC-110MSC
10/100Base-TX to 100Base-FX Multi-Mode Fiber Converter with SC-Type Connector
FEATURES
TFC-1600: 16-slot EIA-19" (2 Unit-Height) Chassis
for TFC series Media Converters
TFC-110MSC: 10/100Base-TX to 100Base-FX Multi-
Mode Fiber with SC Connector
TFC-110MM: 10/100Base-TX to 100Base-FX Multi-
Mode Fiber with MT-RJ Connector
TFC-110MST: 10/100Base-TX to 100Base-FX Multi-
Mode 15 km Fiber with ST Connector
TFC-110S15: 10/100Base-TX to 100Base-FX
Single-Mode 15 km Fiber with SC Connector
TFC-110S30: 10/100Base-TX to 100Base-FX
Single-Mode 30 km Fiber with SC Connector
TFC-110S60: 10/100Base-TX to 100Base-FX
Single-Mode 60 km Fiber with SC Connector
TFC-110S100: 10/100Base-TX to 100Base-FX
Single-Mode 100 km Fiber with SC Connector
To Order Please Call:
1-888-326-6061
ORDERING INFORMATION
Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX /
100Base-FX standards
One 10/100Base-TX auto-negotiation RJ-45 port
Auto-negotiation 10/100Mbps connection speed and Half/Full-duplex mode on
TX port
Auto MDIX for 10/100Base-TX port
One 100Mbps fiber port with Multi-Mode SC-Type Connector
Half / Full-Duplex mode selector on Fiber port
Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed
Wall-Mountable
Optional 19” system chassis with redundant power supply (TFC-1600), holds
up to 16 TFC series Media Converters
5-year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
RELATED PRODUCT
SPECIFICATIONS
Standards:
• IEEE802.3 10Base-T, IEEE 802.3u
100Base-TX and 100Base-FX
Supported Frame Size:
• Standard Ethernet up to 1522-Byte
Network Media:
• 100Base-TX: Cat. 5, EIA/TIA-568
100-ohm UTP/STP, up to 100 meters.
• 100Base-FX: Multi-Mode fiber optic
cable 50/125 or 62.5/125 µm, up to 2
Km.
Wavelength:
• 1300nm
Protocol:
• CSMA/CD
Ports:
• 1 x 10/100Base-TX
• 1 x 100Base-FX
Data Transfer Rate:
• 100Mbps (Half-Duplex), 200Mbps
(Full-Duplex)
Diagnostic LEDs:
• Power, Link/Activity, Full-Duplex,
and Speed
Power Adapter:
• 7.5VDC, 1.5A (7.2 watts max.)
Temperature:
• Operating: 0° ~ 40° C (32° ~ 104° F)
• Storage: -25° ~ 70° C (-13° ~ 158° F)
Humidity:
• Operating: 10% ~ 90%
• Storage: 5% ~ 90%
(non-condensing)
TRENDnet's TFC-110 series Fiber Media Converter
transforms 10/100Base-TX UTP/STP media to 100Base-
FX media and vice versa. The 10/100Base-TX port auto-
sense 10 or 100Mbps connection speed, auto-negotiates
half-/full-duplex mode, and auto-selects MDI-X / MDI-II
media type. The fiber connection can be multi-mode SC,
MT-RJ, or single-mode SC Connector and it has a slide-
switch for selecting half- or full-duplex mode. This
converter will give your Switch/Hub the ability to interface
with fiber connection over a distance up to 2 km. With the
optional 16-slot EIA-19" rack-mount chassis; the TFC
series converters are the perfect solutions for various fiber
media conversions for your network.
TFC-110MSC (06-29-2004)
