Comsoft DF PROFI II PCIe User manual

DFPROFIII PCIe
InstallationInstruction
V1.1
29.07.2008
ProjectNo.:4019
Doc-ID.:DFPROFIII PCIe
Ó
COMSOFT

d:\windoc\icp\doku\hw\dfprofiiipcie\dfprofiiipcie_e.doc
RevisionHistory
VersionDateDescription
V1.129.07.2008 CE Declarationcorrected
V1.021.05.2008 InitialVersion
COMSOFT GmbH
Wachhausstraße5a
D-76227Karlsruhe
Phone[phone]
Fax[phone]
Copyright Ó2008 by COMSOFT GmbH
Thisdocument is protectedby copyright. Reproduction, duplication,publishing, transferordisclosure ofthecontents ofthis
documentareonlypermittedafter priorwrittenagreement hasbeenobtained from COMSOFT GmbH.

DFPROFIIIPCIe -InstallationInstructionContents
ÓCOMSOFT V1.1/29.07.2008i
Contents
1InstallationoftheBoard................................................................................................1
2PinAssignment.............................................................................................................2
3TechnicalData..............................................................................................................3
4CE- ConformityDeclaration.........................................................................................4

Contents DFPROFIII PCIe -InstallationInstruction
iiV1.1/29.07.2008 ÓCOMSOFT
ListofFigures
Figure1:DFPROFIII PCIe-Board.......................................................................................1
Figure2:Profibus-Terminator................................................................................................2
ListofTables
Table1:PinAssignment........................................................................................................2
Table2:TechnicalData.........................................................................................................3

DFPROFIII PCIe-InstallationInstructionInstallationoftheBoard
ÓCOMSOFT V1.1/29.07.20081
1InstallationoftheBoard
TheDFPROFIIIPCIeisaplug&play-compatibleboardforPCI-Express-Slots.The
configurationentirelytakesplacebymeansofthedeliveredsoftwareortheBIOSofyourPC
respectively. Thus,nojumpersorDIP-switchadjustmentsarenecessary.
Tomounttheboard,pleaseproceedasfollows:
·Switchoff yourPCandunplugthemainsplug!
·RemovethescrewsofthePCcageandliftoff thecover. If necessary,
pleaseseealsotheoperating instructionsofyourPC.
·SelectafreePCI-ExpressX1slot.
·RemovetheslotcoverandplugtheDFboardintothedeterminedslot.Payattention
toaproperadjustmentoftheboardintheguidance(avoidcanting !).
·Screwdowntheboard.
·Fixthecoveragainandscrewit down.
Remark:Whenmounting, pleasefollowthesafetyinstructionsfor
electronicmodulesagainstelectrostaticcharge.
Figure1:DFPROFIII PCIe-Board

PinAssignmentDF PROFIII PCIe-InstallationInstruction
2V1.1/29.07.2008 ÓCOMSOFT
2PinAssignment
PinNumber Signal Function Direction
1-shielding
3RxD/TxD-PData+Input/Output
50V(potentialfree80mA)FeedingofbusterminatorInput
65V(potentialfree80mA)FeedingofbusterminatorOutput
8RxD/TxD-NData-Input/Output
Table1:PinAssignment
Remark: ToassurecorrectoperationofthePROFIBUS,aterminating resistormustbe
mountedateachbusend(PurchaseNo.:4000-7-002-H).
Figure2:Profibus-Terminator
220 W390 W390 W
0VData-
Data+
+5V 150 W390 W390 W
CabletypeA
CabletypeB

DFPROFIII PCIe-InstallationInstructionTechnicalData
ÓCOMSOFT V1.1/29.07.20083
3TechnicalData
ProcessorNet+Arm40,33MHz
ProfibusControllerASPC2,48MHz
Memory1MbyteSRAM
2MbyteFlashTypeMemory
PCIInterfacePCI-Express X1
ProfibusInterface1*Sub-D9pins
InterfacePhysicsRS485 (isolated)
LAN Interfaces(optional)1*RJ45
InterfacePhysicsEthernet10/100Mbit/s
ProfibusDataRates9600Bit/s–12000KBit/s
PROFIBUSIsolationVoltage500VDC
PowerConsumption+5V/1100mA
AmbientTemperatureRange0–55°C
Dimensions175mm*107mm
Table2:TechnicalData

CE-ConformityDeclarationDF PROFIII PCIe-InstallationInstruction
4V1.1/29.07.2008 ÓCOMSOFT
4CE-ConformityDeclaration
WeherewithdeclarethatthePC-interface
DFPROFIIIPCIe
correspondstotherequirementsstatedinthe
EUstandards89/336/EWGand 92/31/EWG.
Theinterface correspondstothefollowingstandards:
EN50082-1,EN50082-2and EN50081-1
Manufacturer:
COMSOFT GmbH
Wachhausstr.5a
D-76227Karlsruhe
