Concept Pro VHSDIR-670EXT-AHD-B User manual

User Manual
No.:4001 31 001
VHSDIR-670EXT-AHD-B

Contents
Notice 1
Product Features 2
Keyboard Shortcuts of Speed Dome Operation 9
Wiring Schematic 20
Specifications
24
Product Components 3
Dimension 22
Installation-Product & Accessories 4
Menu Operation 10
Optional Brackets 21

!
WARNING
1
Installation should be carried out only by qualified personnel and in accordance with
any wiring regulations in force at the time.
The speed dome is heavy and could cause injuries if not correctly mounted in accordance
with these instructions. Use only the fittings supplied with the speed dome and ensure
that all lanyard safety cables are connected correctly during installation.
Adequate protection against lightning strikes and power surges should be installed to
prevent damage from the speed dome.
Any safety warnings on the product and in these instructions must be adhered to.
Do not use any brackets, mounts or other accessories not specifically designed for
using with this speed dome.
Do not attempt to service or repair the speed dome as opening or removing covers
may cause exposure to dangerous voltages or other hazards. Refer all servicing to
qualified service personnel.
This is a A-Class product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Warning
If cleaning is necessary, disconnect power to the speed dome first. Do not use abrasive
cleaners, as it will cause damage to the cover and cause poor image quality. Use a
damp cloth to gently clean the dome cover and dry off with a soft clean cloth.
Notice
1

Product Features
2
Up to 255 sets of positional and zoom level information can be
stored as presets. These can be called manually by the
operator, automatically by an alarm input, or grouped to form a
sequence of actions to run automatically.
Each preset can also be programmed with the following:
Alarm action - relay outputs can be triggered when particular
presets are easily be identified.
Preset function
Pattern tours
Any dome movement can be recorded - and subsequently played
back - as 8 separate pattern tours. These can be played back
individually or grouped to form a sequence of tours.
Scan function
Scan is a useful feature when the operator needs to ‘patrol’ a
perimeter fence. You can choose any two presets to define as
starting point and ending point. The scan function will smoothly
and accurately move from one end to the other and then back
again in a repeating sequence. Speed can be adjusted as
necessary and up to 8 scan can be defined. Title - each swing
can be titled with up to 10 characters so that zones can easily
be identified.
Group function
The group function is a powerful feature which allows the operator
to define a sequence of speed dome actions to form an automatic
patrol sequence. Actions can be a mix of presets, swings and
patterns. Up to 8 groups can be defined and each group can have
up to 10 actions, which repeat indefinitely until interrupted by the
operator or an alarm input. Specific parameters, such as preset
speed, lasting time and action loop can also be configured.
Schedule function
16 schedules can be defined and called within a defined period.
Schedule contains preset, swing, pattern and group. 4 alarm
outputs can be chosen in 1 schedule and can be triggered when
the schedule is called.
Alarm function
This speed dome has 8 alarm inputs and 4 alarm outputs. Any
alarm input can be set to call a predefined preset, swing, pattern
or group. Any preset can be configured to trigger any or all of the
alarm outputs. For example, a PIR detector connected to alarm
input 1 could call preset 7 to view a particular scene while
activating an external device connected to alarm output relay.
IR function
The IR function can be set in Auto, Manual, Auto-Manual. This
speed dome has altogether 7 IR LEDs. 3 IR LEDs control the
short distance. 2 IR LEDs control medium and long distance
respectively. In addition, the brightness of the IR LEDs can be
adjusted as needed.
On-Screen Display(OSD)
The operator can check if any or all of the following information
is displayed on screen during normal speed dome operation
camera ID, PTZ info, action No., action label, time, date,
privacy mask, etc can all be displayed on the screen.
Mask function
8 privacy masks can be defined. The image will move along with
the selected privacy zone. When the image is zoomed in, the
privacy mask will be zoomed in as well, but the selected zone
will always be in privacy mask.
Park function
The speed dome can be configured to run a specified swing,
pattern, group or preset after a defined period of inactivity.
Other
When select the OSD, buttons “near/far” on the keyboard and
“left/right” on joystick show the same function when operation.
Quick Install
*Three steps to install a PTZ camera— “Up push, Twist, and
Fasten screws”. *Free your hands when connecting cables.
*Easy removal of inner box to transfer from IP to Analog HD.
2

Product Components
3
1. Wall Bracket
2. Inner Box (function box)
4. Main Unit
8.Front Face
6. Bracket Cover
5. Camera module
7.IR PCB
3. Adaptor Plate
1
6
7
8
5
4
3
2
3

Manual CD
Installation-Product & Accessories
Wall Mount Type
Pendant Mount Type
Anchor Bolt(4pcs)
Hexagonal Wrench
MANUAL
User ManualScrew Tool Torx Wrench
4
Hole Template
102.0
144.0
φ6mm 4 Holes
Dep th min .60mm
(fo r )Anc hor Bo lt
φ35mm
(for P G19 wate r join t)
4
Cable Grand

5
Installation Using Wall/Pendant Mount Bracket
Wall Mount Bracket
Installation
Pendant Mount Bracket
Installation
Installation-Product & Accessories
4
Using the hole template, mark the holes on the wall/ceiling.
2
1
3
After drilling the holes, fix the four anchor bolts into the holes.
After locating the wall/ceiling mount bracket on the anchor
bolts properly, tighten the nuts for anchor bolts.

Inner Box and Wall Mount Bracket Cover Installation
6
1. Put the Inner Box into the Junction Box;
the positioning column will automatically lock the Inner Box;
2. Connect all the cables onto the Inner Box;
3. Cover the Junction Box and fasten the screws to finish
the bracket installation.
1. Hang the slip-proof chain onto the dome
2. Connect the cables between dome and the brackets
3. Up push and right twist the dome body
4. Fasten 3 screws and finish the installation
Installation-Product & Accessories
4

Cabling
7
BNC1
1
2
3
4
Speaker
Mic.
ALARM INPUT
GND
12 3 4 5678
COM
In 1
In 8
OUT1 OUT2 OUT3 OUT4
5
6
8
7
9
BNC2
Installation-Product & Accessories
4
Alarm Input/Sensor
3
“Video Output Details” on page 8.
1
Network Connection
2
Alarm Output
4
RS-485
(Keyboard Controller/DVR)
5
DC12V/AC24V
6
“Set Switches
Details” on page 8.
8
“Address ID Switches
Details” on page 8.
7
DC12V Output
9

8
Address ID switch:
Note: ID 0 should not be used. Where multiple speed domes
are connected, a unique ID must be assigned to each one.
1 2 3 4 5 6 7 8
ON
ON
OFF
ON
ON
ON
ON
OFF
OFF
OFF
---
OFF
ON
ON
OFF
ON
ON
OFF
ON
OFF
---
OFF
OFF
OFF
ON
ON
ON
ON
ON
OFF
---
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
---
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
---
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
---
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
---
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
---
1
2
3
5
7
255
4
6
8
-
1
12345678 D I P
2 4 8 1 6 3 2 6 4 1 2 8 Va l I D
Factory default
switch positions
Speed dome ID is set
using standard
binary notation
SET SWITCHES
1 2 3 4 5 6 7 8
ON
Factory default
switch positions
1 2 4 8 16 32 65 128
OFF
ON
ON
OFF
N O . 1
OFF
OFF
ON
ON
N O . 2
2400
4800
38400
9600
R a t e
OFF
ON
ON
OFF
N O . 3
OFF
OFF
ON
ON
N O . 4
CVBS
AHD
CVI
TVI
O u t p u t
VIDEO OUTPUT
BNC1: HD_CVBS connector, for AHD/TVI/CVI/CVBS output.
BNC2: HD_SDI connector, for EX-SDI/HD-SDI output.
The switch No. 1 and 2 are as following:
The switch No. 3 and 4 are as following:
Baud rate DIP switch table
The switch No.5:
ON: NTSC OFF: PAL
The switch No.6:
ON: P30 OFF: P60
The switch No.7:
ON: EX-SDI OFF: HD-SDI
The switch No.8: RS485 matching resistance switch, the
defaut setup is off. (The matching resistance value is 120 )
Ω
Basic Speed Dome Camera Operation
There are many different PTZ keyboards and DVR systems
capable of controlling this speed dome, and it would be impossible
to describe them all here. Therefore, examples given in the
following pages are based on the more popular control equipment
available. While the principles of operation are the same,
regardless of the control equipment used, reference may need to
be made to the manual supplied with your particular control
equipment.
Understanding the On Screen Display (OSD)
Output Pattern Table
Installation-Product & Accessories
4
7
8
1
NOTE:
CAMERA ID: Shows the
current ID defined by the dip
switch settings
07/01/2017 17:25:55 CAM 1
DATE/CLOCK: Shows
current time and date
PTZ INFORMATION: The current
pan/tilt position in degrees and
the current zoom level
28/121/x1

Please use“PRESET"key on keyboard to call preset.
To go to a preset position which have been
programmed, press:
Other shortcuts please see below table:
The selected PATTERN tour will run indefinitely until a manual interference is made by the
SET - XXX - ENTER
To delete a preset position, press:
CLEAR - XXX - ENTER
PRESET - XXX - ENTER
Call Day/Night
Preset - 180 - Enter
Display OFF
Preset - 192 - Enter
Display ON
Preset - 193 - Enter
Mask Display OFF
Preset - 194 - Enter
Mask Display ON
Preset - 195 - Enter
Call High Light Control
Preset - 179 - Enter
Switch Focus modes among Auto, Semiauto, Manual
Preset - 190 - Enter
Display AUTO
Preset - 191 - Enter
Call DNR
Preset - 176 - Enter
Call Jog Max Speed
Preset - 177 - Enter
Shortcuts Function
Call OSD Menu
Preset - 95 - Enter
Call WDR
Preset - 171 - Enter
Call BLC
Preset - 172 - Enter
Call Auto White Balance
Preset - 173 - Enter
Call Brightness
Preset - 174 - Enter
Call Digital Slow Shutter
Preset - 175 - Enter
operator or an alarm input is received.
Where X is a PATTERN tour number between 1 & 8
1. To start a PATTERN tour press:
PRESET - 13X - ENTER
operator or an alarm input is received.
The selected SCAN function will run indefinitely until a manual interference is made by the
Where X is a number between 1 & 8SCAN function
PRESET - 14X - ENTER
2. To start a SCAN press:function
PRESET - 15X - ENTER
Where X is a number between 1 & 8GROUP
The selected will run indefinitely until a manual movement is made by the operatorGROUP
or an alarm input is received.
3. To start a press:GROUP
Keyboard Shortcuts of Speed Dome Operation
9
Where XXX is a preset number between
1 & 255 (but preset 95 and No.131~199
are reserved and cannot be used).
Confirmation is displayed on the OSD.
To program a preset position, move the
speed dome to the desired scene and
zoom level and press:
Where XXX is a preset number between
1 & 255 The preset position is cleared
from memory.
Where XXX is a preset number between
1 & 255 (but that preset 95 and No.131~199
are reserved and cannot be used).
The speed dome moves to the preset
position. Confirmation and preset title
(if defined) is displayed on the OSD.
To reprogramme a preset position, follow
the steps for programming a preset - it is
not necessary to delete the old preset
position first
Once the pattern tours, swing functions and groups have been
programmed in the speed dome setup menu, they can all be
accessed directly from the PTZ control equipment by using the
following sequences.
5
07/01/2017 17:25:55 CAM 1
16/23/x1
07/01/2017 17:25:55 CAM 1
16/23/x15

FOCUS MODE(AUTO/MANUAL/SEMIAUTO/ONE PUSH)
When AUTO is selected, the image will focus automatically and
get clear;
When MANUAL is selected, the image will not focus
automatically; operator will need to press “FAR/NEAR” button to
get a clear image;
When SEMIAUTO is selected, the image will focus automatically;
operator can also press “FAR/NEAR” button to get a clear image;
When ONE PUSH is selected, the image will focus automatically
only once when zooming stops; operator can also press
“FAR/NEAR” to get a clear image.
D-ZOOM(OFF/ON)
When the D-ZOOM is OFF, it will have a max zooming times
limitation; when the D-ZOOM is ON, operator can zoom in
without max zooming times limitation.
WHITE BALANCE (AUTO/MANUAL/INDOOR/OUTDOOR)
We have AUTO, MANUAL, Indoor and Outdoor for
selection, according to your need.
_RED ADJ(0-255)
_BLUE ADJ(0-255)
WHITE BALANCE can be adjusted only when under
MANUAL mode.
Operator can add or reduce the proportion of red and blue to
get the image effect you need.
DAY/NIGHT(AUTO/DAY/NIGHT)
When AUTO mode is selected, the speed dome will
automatically switch the mode to Day or Night when sunrise
and sunset;
These 3 modes can be selected according to your need.
AE MODE(AUTO/SHUT PRIOR/IRIS PRIOR/AGC
PRIOR/MANUAL)
5 patterns for AE MODE: AUTO, SHUT PRIOR, IRIS PRIOR,
AGC PRIOR, MANUAL SHUT PRIOR, IRIS PRIOR and AGC
PRIOR are mainly used for fields with depth, like scenery,
portrait or macrophotography, etc.
_SHUTTER LEVE(1/60sec-1/30000sec/8x/4x/2x)
SHUTTER LEVE RANGE(1/60sec-1/30000sec), 8x, 4x, 2x
When AE MODE, SHUTTER LEVE can only be adjusted
under SHUT PRIOR.
_IRIS LEVE(F2x/F28-F1.6)
IRIS LEVE RANGE(F28-F1.6), F2x When AE MODE, IRIS
LEVE can only be adjusted under IRIS PRIOR.
_AGC LEVE(0-15)
AGC LEVE RANGE(0-15) When AE MODE, AGC LEVE can
only be adjusted under AGC PRIOR.
BRIGHINESS(0-14)
BRIGHTNESS is used for adjusting the image brightness;
it can be adjusted in 0-14 grades;
_LEVEL
When choose BACKLIGHT-->HLC ON , LEVEL's available
value range(0~20).
When choose BACKLIGHT-->WDR ON , LEVEL's
available option(LOW/MIDDLE/HIGH).
BACKLIGHT(HLC ON/WDR ON/BLC ON/OFF)
There are 4 modes can be selected, HLC ON, WDR ON,
BLC ON, OFF;
Light intensity can be intelligently controlled under strict
backlighting condition.
This function can support you to clearly view any lighting
part and backlight part on the screen.
SENSE-UP(0-6)
This function ensures the clear image under low light.
It can be selected in 0-6 grades.
FLCKERLESS（OFF/ON)
OFF: Dissable FLICKERLESS function.
ON: Enable FLICKERLESS function.
<COLOR LEVEL>(0-14)
COLOR LEVEL is used for adjusting the image colors; it
can be adjusted in 0-14 grades;
10
6Menu Operation
The self-test image shown as picture;
System information displayed;
“OK” displayed when self-test passes.
The currently-selected item will be marked
as Yellow. Other Previous level of selected
items will be re-marked as Grey.
SYSTEM INFORMATION
COLOR SYSTEM
HDTV OUT
PROTOCOL
BAUD RATE
ADDRESS
FIRMWARE VER
ZOOM MODULE
ALARM MODULE
HOME POSITION
DATA MEMORY
PAL
HD-SDI
AUTO
2400
1
STA001TR30
OK
OK
WAIT
OK
2016-09-28
The joystick can be used to select the OSD by moving
left/right/up/down. Up/down is for parameter selection; right is
for parameter saved.
VIDEO SETUP
ACTION SETUP
OSD SETUP
SYSTEM SETUP
INFORMATION
EXIT
FOCUS MODE
D-ZOOM
WHITE BALANCE
_RED ADJ
_BLUE ADJ
DAY/NIGHT
PTZ SETUP
AE MODE
_SHUTTER LEVEL
_IRIS LEVEL
_AGC LEVEL
BACKLIGHT
SENS -UP
FLCKERLESS
SATURA TION
AUTO
OFF
AUTO
AUTO
AUTO
8
OFF
OFF
OFF
>> 12
BRIGHTNESS
_LEVEL

11
PTZ SETUP is highlighted and the contents of PTZ OSD is
displayed.
POWER UP ACTION(OFF/LAST
ACT/PRESET/PATTERN/SWING/GROUP)
LAST ACT: the PTZ will call to the last action when re-
started up after a power failure.
PRESET/PATTERN/SWING/GROUP: When the PTZ is re-
started up, it will automatically call the action
(PRESET/PATTERN/SWING/GROUP) that is set before.
OFF: When the PTZ is re-started up, it will not call any
action.
_ACTION NO.
When POWER UP ACTION is selected as
PRESET/PATTERN/SWING/GROUP, ACTION NO. is
necessary.
AUTO FLIP(OFF/ON)
ON: the PTZ flips 180deg automatically.
OFF: the PTZ flips 90deg automatically.
JOG SPEED(10-360)
JOG SPEED for adjusting the operating speed of the
joystick.
JOG DIRECTION(NORMAL/INVERSE)
When set to NORMAL, the PTZ direction is the same as
where the joystick moves.
When set to INVERSE, the PTZ direction is the opposite to
where the joystick moves.
VIDEO SETUP
ACTION SETUP
OSD SETUP
SYSTEM SETUP
INFORMATION
EXIT
POWER UP ACTION
_ACTION NO.
JOG SPEED
JOG DIRECTION
ZOOM PROPORTIONA
FREEZE IN PRESET
PTZ SETUP
PARK
PARK TIME
PARK ACT
PARK ACT NO.
LAST ACT
160
NORMAL
ON
OFF
OFF
5SEC
NONE
MOTION EDIT LOCK OFF
AUTO FLIP ON
IMAGE FLIP(OFF L/R U/D L/R+U/D)
OFF: Not Flipped; L/R: Flipped 180deg Horizontally;
U/D:Flipped 180deg Vertically; L/R+U/D: Flipped 180deg
Horizontally & Vertically
ZOOM SPEED(1-9)
The ZOOM SPEED can be adjusted in 1-9 grades.
DNR(LOW/MIDDLE/HIGH/OFF)
This adaptive filter reduces noise caused by movement. It’s
time based.4 levels can be selected in:
LOW MIDDLE HIGH OFF.
SHADING(OFF/1%-100%)
Range:(1%-100%), OFF.
SHARPNESS(0-15)
SHARPNESS defines the clearness of the image borders.
It can be adjusted in 0-15 grades, the default value is 2;
Note: a high sharpness value would create image noise.
GAMMA(0.45/0.55/0.65/0.75)
This function is used for adjusting the image brightness.
Selected parameters: 0.45, 0.55, 0.65, 0.75.
DIS(OFF/10%/20%/30%)
This function is used for zooming in. Selected parameters: OFF,
10%, 20%, 30%.
/ / /
_FILTER(LOW/MIDDLE/HIGH)
Selected patterns: LOW/MIDDLE/HIGH.
_AUTO C(HALF/FULL/OFF)
Special pattern. Selected in HALF, FULL, OFF.
AUTO/OFF/LOW/MIDDLE/HIGH
ACE(OFF/LOW/MIDDLE/HIGH)
This function is used for adjusting the image brightness.
Selected parameters: OFF, LOW, MIDDLE, HIGH.
FREEZE(OFF/ON)
Open FREEZE function for freezing image. It can lock up the
image in a specific frame.
DEFOG(OFF/ON)
DEFOG function:
6Menu Operation
VIDEO SETUP
ACTION SETUP
OSD SETUP
SYSTEM SETUP
INFORMATION
EXIT
IMAGE FLIP
ZOOM SPEED
DNR
SHADING
SHARPNESS
GAMMA
PTZ SETUP
DIS
_FILTER
OFF
8
HIGH
OFF
2
0.45
OFF
MIDDLE
<<
_AUTO C HALF
ACE
FREEZE
DEFOG
OFF
OFF
AUTO

ZOOM PROPORTION(ON/OFF)
ON: Zooming proportionally.
OFF: Not zooming proportionally.
MOTION EDIT LOCK
FREEZE IN PRESET(OFF/ON)
ON: When a preset is called, the preset image will be
frozen and displayed on the screen directly without
proceeding the calling action.
OFF: FREEZE IN PRESET is OFF.
When set to on ,motion action programming......
PARK(OFF/ON)
ON: PARK function is ON.
OFF: PARK function is OFF.
PARK TIME(1-5)
PARK TIME defines the lasting time of the non-working
state of the PTZ.
PARK ACT
(NONE/PRESET/PATTERN/SWING/GROUP)
PRESET/PATTERN/SWING/GROUP: when the defined
park time is reached, PTZ will automatically call the setting
action.
NONE: NONE action when the defined park time is
reached.
PARK ACT NO.
Select the Number of
PRESET/PATTERN/SWING/GROUP.
12
VIDEO SETUP
ACTION SETUP
OSD SETUP
SYSTEM SETUP
INFORMATION
EXIT
PTZ SETUP
PRESET SETUP
SCAN SETUP
PATTERN SETUP
GROUP SETUP
SCHEDULE SETUP
ALARM SETUP
IR SETUP
>>
>>
>>
>>
>>
>>
>>
The ACTION SETUP is highlighted, and the ACTION OSD
contents are displayed.
<PRESET SETUP>
Full management and programming of individual preset.
<SCAN SETUP>
Full management and programming of scan function.
<PATTERN SETUP>
Full management and programming of pattern function.
<GROUP SETUP>
Full management and programming of group function.
<SCHEDULE SETUP>
Full management and programming of schedule function.
<ALARM SETUP>
Full management and programming of alarm function.
<IR SETUP>
Full management and programming of IR function.
PRESET NO. (1 - 255)
The preset number can be modified from 1-255.
If the preset number is already defined, the OSD will
display the specific preset number, otherwise it will be
shown as UNDEFINED.
CLEAR PRESET(NO/CLEAR)
CLEAR: Delete the selected preset.
NO: No clear preset.
<EDIT SCENE>
This option is for programming the preset position.
<LABEL>
This option is for programming the relay outputs required (if
any) when the preset is called.
This option is only available when the selected preset
position is already programmed.
RELAY OUT
This option is for programming the relay outputs required (if
any) when the preset is called.
This option is only available when the selected preset
position is already programmed.
SPECIAL PRESET
ON: setting a specific preset as special preset.
This option is only available when the selected preset
position is already programmed.
OFF: No special preset.
PRESET SETUP
PRESET NO.
CLEAR PRESET
EDIT SCENE
LABEL
EXIT
>>
BACK
RELAY OUT
SPECIAL PRESET
1
NO
----
OFF
UNDEFINED
6Menu Operation

13
PRESET LABEL EDIT
OK
[ ]
1234567890
- - - - - - - - - -
CLEAR
ABCDEFGHIJ
KLMNOPQRST
UVWXYZabcd
efgghijklmn
opqrstuvwx
y z < > - / : . ! ?
EDIT SCENE
XX/XX/XX
MOVE TO TARGET POSITION
[CLOSE: SELECT/ OPEN: CANCEL]
Control the PTZ to a specific position and a certain zoom
level by operating the joystick, and then press key CLOSE
to save or press key OPEN to cancel.
PRESET 1
SCAN NO.(1-8)
The scan number can be modified.
<EDIT SCAN>
This option is for programming the scan action.
<LABEL>
This option is for using to edit the scan label.
This option is only available when the selected scan is
already programmed.
JOG SPEED(10-360)
This option is for adjusting the scan speed.
JOG DIRECTION(NORMAL/INVERSE)
When set as normal, the scan direction is the same as
where the joystick moves.
When set as inverse, the scan direction is the opposite to
where the joystick moves.
<RUN SCAN>
all the selected SCAN action.
This option is only available when the selected scan is
already programmed.
CLEAR SCAN(NO/CLEAR)
CLEAR: delete the selected scan action.
NO: No clear scan
SCAN SETUP
SCAN NO.
CLEAR SCAN
EDIT SCAN
LABEL
>>
1
NO
EXIT
BACK
JOG SPEED
JOG DIRECTION
RUN SCAN <>
60
NORMAL
XX/XX/XX
UNDEFINED
6Menu Operation
The solid white square shows the current cursor position.
The flashing white square shows the currently selected
character.
Move the joystick up / down / left / right to choose the
required character and press key CLOSE to insert it in the
preset label. The solid square moves to the next cursor
position. white Repeat until the preset label is complete.
Click OK to save the preset label; CLEAR to unsave;
CLOSE to exit.

14
SCAN LABEL EDIT
OK
[ ]
1234567890
- - - - - - - - - -
CLEAR
ABCDEFGHIJ
KLMNOPQRST
UVWXYZabcd
efgghijklmn
opqrstuvwx
y z < > - / : . ! ?
The solid white square shows the current cursor position.
The flashing white square shows the currently selected
character.
Move the joystick up / down / left / right to choose the
required character and press key CLOSE to insert it in the
preset label. The solid square moves to the next cursor
position. white Repeat until the preset label is complete.
Click OK to save the preset label; CLEAR to unsave;
CLOSE to exit.
PATTERN NO.(1-8)
The pattern number can be modified.
CLEAR PATTERN(NO/CLEAR)
CLEAR: Delete the selected pattern action.
NO: No clear pattern.
<EDIT PATTERN>
This option is for programming the pattern action.
<RUN PATTERN>
This option is only available when the selected scan is
already programmed.
PATTERN SETUP
PATTERN NO.
CLEAR PATTERN
EDIT PATTERN
RUN PATTERN
EXIT
>>
<>
BACK
1
NO
UNDEFINED
EDIT SCENE
XX/XX/XX
MOVE TO START POSITION
CLOSE: SELECT/ OPEN: CANCEL
SCAN 1
Control the PTZ to any positions you need and press key
CLOSE to confirm starting position or press key OPEN to
cancel. And then control the PTZ to another position you
need and press key CLOSE to confirm ending position or
key OPEN to cancel.
6Menu Operation

15
EDIT SCENE
XX/XX/XX
MOVE TO START POSITION
PATTERN 1
Control the PTZ to any position you need and press key
CLOSE to confirm starting position or press key OPEN to
cancel. And then control the PTZ to another position you
need and press key CLOSE to confirm ending position or
key OPEN to cancel.
GROUP NO.(1-8)
The group number can be modified.
CLEAR GROUP(NO/CLEAR)
CLEAR: delete the selected group action.
NO: No clear group
<EDIT GROUP>
This option is for using this option to program the group
action.
<RUN GROUP>
Call the selected group action.
This option is only available when the selected scan is
already programmed.
GROUP SETUP
GROUP NO.
CLEAR GROUP
EDIT GROUP
EXIT
>>
BACK
1
NO
RUN GROUP <>
UNDEFINED
Header explanation:
NO - the item number (between 1 & 10)
ACTION - the specific action for this item
NO - the action number (eg if ACTION is set to PRESET,
this value can be between 1 & 255.
DWELL - the amount of time before the next action in the
list is called.
OPT - for PRESET actions, this value is the speed at which
the dome moves to the preset. For SCAN and PATTERN,
this value is the number of times the action is repeated
before the next action is called.
Move the joystick up and down to choose the group item to
modify and press key NEAR. The ACTION is highlighted in
white.
Move the joystick up and down to change the action type
between NONE, PRESET, SCAN and PATTERN.
Move the joystick left and right to select and edit values for
###, DWELL & OPT.
EDIT GROUP
NO.
NONE
NONE
NONE
NONE
NONE
BACK
NONE
NONE
NONE
NONE
NONE
1
2
3
4
5
6
7
8
9
10
ACTION NO. DWELL OPT
6Menu Operation

16
SCHEDULE NO.(1-16)
The schedule number can be modified.
ENABLE(OFF/ON)
ON: Enable the SCHEDULE.
OFF: Disable the SCHEDULE.
ACTION(NONE/PRESET/PATTERN/SWING/GROUP)
PRESET/PATTERN/SWING/GROUP: Select the schedule
action accordingly.
NONE: No actions in schedule.
ACTION NO.
Select the number of PRESET/PATTERN/SWING/GROUP
action.
RELAY OUT
This option allows the operator to set the relay out for the
schedule.
MONTH/WEEK(DAY/WEEK/MONTH)
This option allows the operator to set the
DAY/WEEK/MONTH for the schedule.
STARTING TIME
This option allows the operator to set the starting time for
the schedule. The time can be accurate to minute.
ENDING TIME
This option allows the operator to set the ending time for
the schedule. The time can be accurate to minute.
SCHEDULE SET
SCHEDULE NO.
ENABLE
ACTION
ACTION NO.
RELAY OUT
MONTH/WEEK
START TIME
END TIME
1
OFF
NONE
----
DAY
BACK
EXIT
00:00
00:00
There are altogether 7pcs of IR LED, including 3pcs for short
distance, 2pcs for middle distance and 2pcs for long distance.
IR MODE(AUTO/MANUAL/SEMI AUTO)
This option allows the operator to choose IR MODE
accordingly.
SENSITIVITY(1-8)
This option allows the operator to choose the level of sensitivity
accordingly.
IR NEAR(1-10/OFF)
1-10: This allows the operator to adjust the intensity of IR LEDs
for short distance.
OFF: Turn the IR LEDs off.
IR MIDDLE(1-10/OFF)
1-10: This allows the operator to adjust the intensity of IR LEDs
for middle distance.
OFF: Turn the IR LEDs off.
IR FAR(1-10/OFF)
1-10: This allows the operator to adjust the intensity of IR LEDs
for long distance.
OFF: Turn the IR LEDs off.
IR SETUP
BACK
SENSI
IR MODE
IR MIDDLE
IR NEAR
IR FAR
EXIT
0
AUTO
10
10
10
ALARM NO.(1-8)
There are 8 groups of ALARM INPUT can be selected.
INPUT ENABLE(OFF/ON)
ON: Enable the Alarm Input function
OFF: Disable the Alarm Input function
INPUT TYPE(N.O/N.C)
Select the Alarm Input Type: N. O/ N. C
ACTION(NONE/PRESET/PATTERN/SWING/GROUP)
PRESET/PATTERN/SWING/GROUP:Alarm action for
selection
NONE: No Alarm action
ACTION NO.
This option is for selecting the number of Alarm action
(PRESET/PATTERN/SCAN/GROUP)
OUT PUT TYPE(N.O/N.C)
Select the Alarm Output Type: N.O/N.C
RELAY OUT
There are 4 groups of Alarm Output can be selected.
ALARM SETUP
ALARM NO.
INPUT ENABLE
INPUT TYPE
ACTION
ACTION NO
RELAY OUT
RELAY RETAIN
1
OFF
N. O
NONE
3SEC
BACK
EXIT
RELAY TYPE N. C
----
6Menu Operation

17
ACTION SETUP
OSD SETUP
SYSTEM SETUP
INFORMATION
EXIT
ACTION LABEL
TIME/DATE
MASK EDIT
AUTO
AUTO
ON
>>
VIDEO SETUP CAMERA ID
PTZ INFO
ACTION TITLE
PTZ SETUP AUTO
ON
The SETUP is highlighted and the SETUP contents are
displayed on the screen.
CAMEAR ID(AUTO/ON/OFF)
AUTO/ON: Show the camera ID according to the DIP switch
settings, eg: CAM 1.
OFF: No CAMERA ID displayed
PTZ INFO(AUTO/ON/OFF)
AUTO/ON: Show the PTZ information
OFF: No PTZ information
ACTION TITLE(AUTO/ON/OFF)
AUTO/ON: Shows the current Action Title, eg: PRESET3.
OFF: No Action Title displayed.
ACTION LABEL( AUTO/ON/OFF)
AUTO/ON: When the LABEL is set in the action, the current
LABEL will be displayed on the screen (only preset and swing
have label)
OFF: No Action Label displayed.
TIME/DATE(AUTO/ON/OFF)
AUTO/ON: TIME displayed
OFF: No TIME displayed
<MASK EDIT>
Full management and programming of privacy zones.
MASK NO.(1-8)
The NO. of privacy zone can be modified.Altogether 8 privacy
zones can be set.
DISPLAY MASK(OFF/ON)
OFF: Turn off Mask No.
ON: Turn on Mask NO.
CLEAR MASK(NO/CLEAR)
CLEAR: Clear all the display masks.
NO: No Clear
MASK EDIT
Edit the MASK.
MASK COLOR
(GREEN/BLUE/CYAN/YELLOW/MAGENTA/BLACK/GRAY1-
GRAY6/WHITE/RED)
Select Mask Color
MASK TRANS (0/1/2/3)
Adjust the Mask Transparency.
DISPLAY MASK
MASK NO.
MASK_ SETUP
OFF
1
CLEAR MASK
MASK EDIT
NO
>>
EXIT
BACK
UNDEFINED
MASK COLOR
MASK TRANS
GREEN
0
EDIT MASK
XX/XX/XX
MOVE TO TARGET POSITION
[CLOSE: SELECT/ OPEN: CANCEL]
Control the PTZ to any positions you need and press key
CLOSE to confirm starting position or press key OPEN to
cancel. And then control the PTZ to another position you
need and press key CLOSE to confirm ending position or
key OPEN to cancel.
1
6Menu Operation

18
DATE/TIME SETUP
DATE
TIME
CANCEL
BACK
03/FEB/2013(SAT)
02:10:36
REBOOT SYSTEM（NO/YES）
YES: Reboot System.
NO: No Reboot System
START TEMP（0-10）
Set a Starting-up Temperature for PTZ; the PTZ will bot start up
if less than the starting temperature.
FAN TEMPSet a fan temperature; the PTZ will stop operating if
higher than Fan Temperature.
PASSWORD（OFF/ON）
ON: Use Password for OSD.
OFF: No Password for OSD.
<PASSWORD EDIT>
Edit Password.
PASSWORD EDIT
OK
[ ]
1234567890
ABCDEFGHIJ
KLMNOPQRST
UVWXYZabcd
efgghijklmn
opqrstuvwx
y z < > - / : . ! ?
- - - - - - - - - -
- - - - - - - - - -
CL ARE
The solid white square shows the current cursor position.
The flashing white square shows the currently selected
character.
Move the joystick up / down / left / right to choose the
required character and press key CLOSE to insert it in the
preset label. The solid square moves to the next cursor
position. white Repeat until the preset label is complete.
Click OK to save the preset label; CLEAR to unsave;
CLOSE to exit.
Remember: When CHECK PASSWORD is set to ON, each
time operator attempts to enter the speed dome setup
menu, the above screen will be displayed. The correct
password must be entered to continue with menu setup.
ACTION SETUP
OSD SETUP
SYSTEM SETUP
INFORMATION
EXIT
FACTORY RESET
_RESET VIDEO
_RESET PTZ
_RESET ACTION
_RESET OSD
REBOOT SYSTEM
START TEMP
PASSWORD
NO
NO
NO
NO
YES
NO
0
OFF
PASSWORD EDIT >>
FAN TEMP 36
VIDEO SETUP
PTZ SETUP
LANGUAGE
TIME SETTING
ENGLISH
>>
The SYSTEM SETUP is highlighted and the SYSTEM contents
are displayed on the screen.
LANGUAGE
The system provides 8 language types for selection.
<TIME SETTING>
Full management and programming of TIME.
FACTORY RESET(NO/YES)
YES: Reset all the setting to FACTORY values. (The parameter
OSD will display “wait” notice during the resetting.)
NO: No Factory Reset
_RESET VIDEO（NO/YES）
YES: Reset the VIDEO value.
NO: No Reset VIDEO value.
_RESET PTZ（NO/YES）
YES: Reset PTZ value.
NO: No reset PTZ value.
_RESET ACTION（NO/YES）
YES: Reset Action Value.
NO: No Reset Action Value.
_RESET OSD（NO/YES）
YES: Reset OSD Value.
NO: No Reset OSD Value.
6Menu Operation
Move the highlight to DATE, you can setup current year, mouth,
day, current year, mouth, day, After completing adjustment,
CLOSE to cancel. and the TIME setup is just like the DATE.
