Condair DA Series User manual

INSTALLATION AND
OPERATION MANUAL
Desiccant dryer
Condair DA 35
XXXXXXX EN 1704
Dehumidication and Drying

Thank you for choosing Condair
Installation date (MM/DD/YYYY):
Commissioning date (MM/DD/YYYY):
Site:
Model:
Serial number:
Proprietary Notice
This document and the information disclosed herein are proprietary data of Condair Group AG. Neither this docu-
ment, nor the information contained herein shall be reproduced, used, or disclosed to others without the written
authorisation of Condair Group AG, except to the extent required for installation or maintenance of recipient's
equipment.
Liability Notice
Condair Group AG does not accept any liability due to incorrect installation or operation of the equipment or due
to the use of parts/components/equipment that are not authorised by Condair Group AG.
Copyright Notice
© Condair Group AG, All rights reserved.
Technical modications reserved.

CONDAIR DA35E / DA 35D / DA 35C OPERATING AND SERVICE HANDBOOK page 3/128
CONTENTS
SECTION 1 / GENERAL BACKGROUND 4!
ABOUT THIS HANDBOOK 4!
ABOUT MANAGING HUMIDITY 6!
ABOUT CONDAIR 7!
SECTION 2 / THE DEHUMIDIFIER 8!
ABOUT THE CONDAIR DA35E / DA 35D / DA 35C RANGE OF DEHUMIDIFIERS 8!
HOW IT WORKS 12!
FEATURES AND BENEFITS 16!
SECTION 3 / TECHNICAL DETAILS 18!
SERIAL NUMBER/IDENTIFICATION 18!
SPECIFICATIONS 19!
ASSEMBLIES AND COMPONENTS 27!
SOUND LEVELS 34!
SECTION 4 / INSTALLATION 35!
HOW TO INSTALL THIS DEHUMIDIFIER 35!
HOW TO INSTALL A CONDENSATION UNIT OR HEAT RECOVERY UNIT 39!
HOW TO INSTALL A DA 35C (COLD STORE MODEL) 42!
HOW TO COMMISSION THIS DEHUMIDIFIER 45!
SECTION 5 / OPERATION 48!
HOW TO OPERATE THIS DEHUMIDIFIER 48!
HOW TO OPERATE THE DA 35E/ DA 35D CONFIGURATION-A 104!
SECTION 6 / SERVICE AND REPAIR 106!
HOW TO SERVICE AND REPAIR THIS DEHUMIDIFIER 106!
SECTION 7 / FORMALITIES AND GENERAL/LEGAL INFO 118!
WARRANTIES 118!
LEGAL NOTICES 119!
EU DECLARATION OF CONFORMITY 120!
HOW TO UPDATE AND IMPROVE THIS CONDAIR DEHUMIDIFIER 122!
WHO TO CONTACT 123!
ELECTRICAL DIAGRAMS APPENDIX
