Condor CondorScan User manual

CondorScan User Manual
CONDOR SAS
Route Nationale 113
38 rue du Languedoc
11200 Lézignan Corbières
Site : www.condorscan.com

Introduction CondorScan Instruction Manual
Version 1 Page 2 sur 65
This document is the exclusive property of SAS CONDOR, it may not be copied, reproduced or transmitted, totally or partially without
written permission.
1. Introduction
Dear Doctor,
Thank you for choosing the intraoral scanner CondorScan, designed and manufactured by Condor.
This scanner allows you to make an optical impression in colour of the teeth of your patient in a format usable by
everyone, including your dental laboratory regardless of which dental CADCAM equipment they are using.
This manual is the result of a collective effort involving engineers and clinicians.
It was written for you and is intended to let you know every element and every feature of your CondorScan.
This will also allow you to use it safely.
We invite you to read it carefully before you start handling your CondorScan and always keep it on hand.
To avoid risk of physical injury or material damage, thank you for observing the safety instructions.

Introduction CondorScan Instruction Manual
Version 1 Page 3 sur 65
1. Introduction_________________________________________________________________________________ 1
2. Summary __________________________________________________________________________________ 3
3. Overview ___________________________________________________________________________________ 5
3.1. Product description ______________________________________________________________________ 5
3.2. Proper Use & Certification _________________________________________________________________ 7
3.3. Copyright______________________________________________________________________________ 11
3.4. Open Source ___________________________________________________________________________ 11
3.5. Liability _______________________________________________________________________________ 11
4. Safety _____________________________________________________________________________________ 12
4.1. General instructions _____________________________________________________________________ 12
4.2. Safety instructions ______________________________________________________________________ 13
5. Installation_________________________________________________________________________________ 15
5.1. Reception and unpacking _________________________________________________________________ 15
5.2. List of equipment _______________________________________________________________________ 15
5.3. Handling and location____________________________________________________________________ 16
5.4. Hardware Overview _____________________________________________________________________ 16
5.5. Hardware Installation ____________________________________________________________________ 19
6. Start-up ___________________________________________________________________________________ 22
6.1. Software installation_____________________________________________________________________ 22

Introduction CondorScan Instruction Manual
Version 1 Page 4 sur 65
6.2. Power-up _____________________________________________________________________________ 22
6.3. Internet connection _____________________________________________________________________ 23
6.4. Logging on to the Condor software _________________________________________________________ 24
7. Use _______________________________________________________________________________________ 25
7.1. Program start __________________________________________________________________________ 25
7.2. 4 Icons________________________________________________________________________________ 30
7.3. View / Edit Settings______________________________________________________________________ 32
7.4. Patient Management ____________________________________________________________________ 42
7.5. Start a new case ________________________________________________________________________ 45
7.6. Scan progress __________________________________________________________________________ 48
7.7. Case management ______________________________________________________________________ 58
7.8. Discussions ____________________________________________________________________________ 60
7.9. Offline use_____________________________________________________________________________ 64
8. Maintenance _______________________________________________________________________________ 65
9. Troubleshooting ____________________________________________________________________________ 65

Overview CondorScan Instruction Manual
Version 1 Page 5 sur 65
3. Overview
3.1. Product description
The, intraoral scanner, Condor is used in dentistry for taking optical impressions of teeth on patients or models. This
method replaces the traditional, analogue, chemical based impressions.
This new technology distinguishes itself by its simplicity, ease of use, speed of execution and especially the generation
of Condor Open Files
Advantages3.1.1.
•Accuracy: eliminating problems related to material deformation.
•The reproducibility: It is possible to reproduce the impression without limits.
•The double impression: when an area is insufficiently scanned , it is possible to only re-scan this area
unlike with a conventional impression, which needs to be redone completely.
•Time Gain: chairside and laboratory side by removing the plaster casting, wax modelling and lost wax
technique). This leads to a decrease in the number of sessions.
•Patient comfort: it avoids the gag reflex in some patients, a shorter waiting time in the chair and the
patient spends less time with his mouth open.
•the diversity of materials: In CAM, all dental materials, insofar as they are biocompatible and milled,
can be used.
CondorScan is an open system3.1.2.
Working with digital technology is essential nowadays. To facilitate this integration into this new era, CondorScan
opted for the export of open files, such as STL and PLY (colour).

Overview CondorScan Instruction Manual
Version 1 Page 6 sur 65
They are easily imported into any CAD/CAM software and can be transferred to any laboratory or collaborator.
CondorScan does not use powder3.1.3.
With CondorScan you do not need to powder the teeth to generate the 3D model. This simplifies handling and allows
colour scans, which can be re-scanned and are accurate.
CondorScan is ready to use3.1.4.
CondorScan is easy to use, however, a learning period is recommended.
Other advantages of CondorScan are:
•No calibration is required.
•An easy to use software.
•A user-friendly manipulation in the mouth.
CondorScan is lightweight and compact3.1.5.
The CondorScan is a compact and ergonomic intra oral scanner. It fits perfectly in your dental unit. Its low weight
(about 100g) allows you to manipulate it as easily as the other tools you usually use.
CondorScan is extremely realistic3.1.6.
The realism of highly detailed 3D images allows you to have much more than a simple optical impression device . It
allows for pathology diagnostics as an intraoral 2D camera .
It also opens your analysis to telemedicine (remote diagnosis).
Finally, it allows to visualize in 3D the mouth of your patient and explain the reasons for the proposed treatments.

Overview CondorScan Instruction Manual
Version 1 Page 7 sur 65
3.2. Proper Use & Certification
Certification3.2.1.
CondorScan has a CE marking in accordance with the requirements of Directive 93/42 EEC concerning medical devices.
This is a medical device taking intra oral scans and reconstructing them into 3D files. It should not be used for purposes
other than those to which it was intended under risk of damage and danger.

Overview CondorScan Instruction Manual
Version 1 Page 8 sur 65
a. Product labelling
Packing Label Camera Label

Overview CondorScan Instruction Manual
Version 1 Page 9 sur 65
b. Pictograms
Meaning of the pictograms on CE marking.
Symbol
Definition
Meets regulatory requirements. The product meets certain technical standards and
has the right of movement throughout the territory of the European Union.
M
Manufacturer
N
Date of manufacture
f
Serial number
h
Product reference
i
Read the instruction manual
The product should be disposed of in an appropriate recovery and recycling centre.

Overview CondorScan Instruction Manual
Version 1 Page 10 sur 65
Symbol
Definition
Device type BF according to IEC 878-02-03
Serial number in barcode format
Connection type, voltage and DC
L
Do not use if the packaging is torn or damaged
Keep dry: The shipping packaging should be kept away from rain
15 :l30 :
Use only between 15 ° and 30 ° C.
Attention, see the included documentation
Proper Use3.2.2.
The term "proper use" means, compliance with these instructions for use, cleaning, maintenance and disinfection.

Overview CondorScan Instruction Manual
Version 1 Page 11 sur 65
3.3. Copyright
The information contained in this manual is subject to change without specific notice.
The software and related documentation are protected by copyright. They should be treated like any other protected
system.
Anyone who would install, transfer the contents of this software and its peripherals to any other media than that
which came with your CondorScan without written permission, from the CONDOR company is acting illegally
3.4. Open Source
Our software contains open source libraries.
3.5. Liability
The manufacturer will not be held liable in case of:
•Non-compliance with manufacturer's recommendations during installation (line voltage).
•Interventions or repairs by persons not authorized by the company Condor.
•Operation by others than those specified in this manual.
•Non-compliance with safety instructions.
•non-compliance with manufacturer's recommendations during installation (line voltage).
The manufacturer reserves the right to modify the appliance and / or manual without prior notice.

Safety CondorScan Instruction Manual
Version 1 Page 12 sur 65
Counter indications :
CondorScan should not be used with accessories other than those supplied by the company CONDOR. The user must
not perform repairs or modifications to the device without prior authorization of the company CONDOR.
4. Safety
4.1. General instructions
Software4.1.1.
It is forbidden to use the device with software other than that provided by the company CONDOR. Only use the original
software.
It is strictly forbidden to install the software on a different computer than the one provided by the company CONDOR.
Equipment4.1.2.
It is strictly prohibited to continue to use the equipment if it is damaged.
Any changes that might endanger the safety of the user or third parties are prohibited. It is also prohibited to open the
equipment.
Repair4.1.3.
•Rehabilitation, for example during a service operation must only be carried out by the company
CONDOR.
•Defective components or the device consumables must be replaced by original spare parts.
In case of non-compliance with the above points CONDOR will in no way be liable.

Safety CondorScan Instruction Manual
Version 1 Page 13 sur 65
4.2. Safety instructions
Warning: Before using the medical device, read the entire chapter on safety instructions. The manufacturer's warranty
is applicable only to the extent that the information on the operation and device safety have been correctly applied.
These security measures include a good knowledge of dental and optical impression
1) This device must be used in full compliance with the instructions contained in this manual. The manufacturer
accepts no liability if these rules are not followed or if the device is used for any other application.
2) Never connect the camera to another computer or on a port other than the one specified in this notice. Use a
different power supply could cause irreversible damage to the unit and could injure the patient or user
3) The light rays produced by such devices can be dangerous and should never be looked at or into directly even
with protective eyewear. The action of this light should only cover the portion to be diagnosed / treated in the
oral cavity
4) If the unit should be moved to a place with a temperature difference in order of 10 ° C, it should not be used
immediately, but only after reaching ambient temperature.
5) Do not introduce or try to introduce metal objects into the device. This could cause an electric shock.
6) The manufacturer is not liable if the damaged parts or accessories are not replaced by those of the
manufacturer. In particular, the use of a computer other than the original one could be dangerous for the
patient and the user and / or compromise the correct use of the device.
7) In case of anomaly, unplug the unit immediately and make sure that nobody can use it before it is checked the
manufacturer or distributor.
8) Do not use the device near a heat source. Using non-recommended cleaning products, solvents or flammable
products on the device may cause damage, especially on the camera window.
9) The use of certain detergents on the device for cleaning can cause short circuits.
10) If a repair is necessary, only the manufacturer or distributor of the device is empowered to intervene.
11) The medical device CondorScan, should not be used on people who suffer or have suffered from photo
biological reactions (including those having Urticae Solarize or protoporphyria erythropoietic) or those

Safety CondorScan Instruction Manual
Version 1 Page 14 sur 65
following treatments comprising photosensitizing medications (including methoxsalènes or chlorotetra-
cyclin). It should not be used on patients with epilepsy.
12) People, practitioner or patient, who suffered from the retina- or lens problems or having undergone eye
surgery, especially cataract, should consult their ophthalmologist before using this device.
13) Changes in the mains voltage or electromagnetic field, not in accordance with the standards, could disrupt the
operation of the unit. In case of problems turn off the device.
14) Electromagnetic interference: The device complies with standards (EN 60 601-1-2) whether emission
(radiation to the electric field and disruption of the supply voltage) or immunity (for radiation to the electric
fields , fast transient bursts supply, ESD and power shock waves).
15) The equipment must only be used by a professional dental practitioner and having received the necessary
training.

Installation CondorScan Instruction Manual
Version 1 Page 15 sur 65
5. Installation
5.1. Reception and unpacking
The device is controlled rigorously by the factory. Upon receipt, it is necessary to proceed to the next check: check with
the table below that the equipment is complete and shows no visible damage.
If the unit has been damaged during transport, you should refuse the package and contact the carrier and inform the
sender.
5.2. List of equipment
Description
Quantity
A compact, high-performance laptop.
Reference : MSI GS72S
1
A USB key containing this manual and a
marketing brochure.
1
An intraoral camera. 1

Installation CondorScan Instruction Manual
Version 1 Page 16 sur 65
5.3. Handling and location
When handling of CondorScan, it is important to always take the elements one by one.
The CondorScan needs to be installed to a flat surface of 70 x 50 cm minimum.
The computer system should not be positioned near important sources of moisture or dust.
5.4. Hardware Overview
CondorScan, the medical device, is composed of several sub-assemblies. One will not work without the other.
Assembly view5.4.1.

Installation CondorScan Instruction Manual
Version 1 Page 17 sur 65
Computer technical specification5.4.2.
a. Laptop
•Processor: Intel® Core™ i7–6820HK
•Graphics card NVIDIA® GEFORCE® GTX 980 G-SYNC
•Screen 17,3’’
•Network controller Killer™ E2200
•Wi-Fi Killer™ WIRELESS-N/A/AC 1535 Wireless Network Adapter
•Power supply certification EN 60950
•Weight : +/- 4 Kg
Camera Description5.4.3.
•Injection moulded polycarbonate body.
•Polycarbonate window on front of the LED’s and lenses.
•Waterproof type IP67 for full immersion in compatible liquid disinfectant.
•Power source 5v/0.9A USB3 SS (Super Speed) port.
•Use between 15 and 30 ° C / 30 to 80% RH (to limit condensation).
•2 x 15 images per second.
•Scan area 17x17 at 17.5mm (3 dents)
•Depth of field for scanning: 10mm mini / 21mm maxi
•15 ,high luminosity, white LED’s / 2 bleu LED’s
•Dimensions 200 x 25 x 20mm ; 110 grams

Installation CondorScan Instruction Manual
Version 1 Page 18 sur 65
Camera overview :
USB 3 key Description5.4.4.
•Plastic body
•Capacity 8 Gb
•Speed : 12 Mb/s read and 6 Mb/s write
•Type of memory : flash Samsung grade A
Tracking indicator
Button on/off/scan
Arch indicator

Installation CondorScan Instruction Manual
Version 1 Page 19 sur 65
5.5. Hardware Installation
Once the computer is placed on a flat, stable surface, you can connect the components as mentioned below. We
strongly recommend you to first read the user manual of the laptop.
Connections5.5.1.
1° connect the Camera (USB 3)
2° connecter the power supply

Installation CondorScan Instruction Manual
Version 1 Page 20 sur 65
Connections5.5.2.
a. Connecting the power supply
3° Connect the power cable to the power supply
and then to the mains.
Connect the power supply lead to the laptop
Warning ! This power supply is validated for
medical use.
Never change it with another type because there
would be a risk of shock.
