QuickBridge Wiring Diagram Manual 3
TABLE OF CONTENTS
SECTION 1 - OVERVIEW 4
SECTION 2 - WIRING DIAGRAMS 5
QB1 Bridge Receiver Wiring 5
QB1 Hoist Receiver Wiring 6
QB2 Bridge Receiver Wiring 7
QB2 Hoist Receiver Wiring 8
QB3 Bridge Receiver Wiring 9
QB3 Hoist "A" Receiver Wiring 10
QB3 Hoist "B" Receiver Wiring 11
QB4 Bridge Receiver Wiring 12
QB4 Hoist Receiver Wiring 13
QB5 Bridge Receiver Wiring 14
QB5 Hoist "A" Receiver Wiring 15
QB5 Hoist "B" Receiver Wiring 16
QB6 Bridge Receiver Wiring 17
QB6 Hoist "A" Receiver Wiring 18
QB6 Hoist "B" Receiver Wiring 19

4QuickBridge Wiring Diagram Manual
SECTION 1 - OVERVIEW
QuickBridge is a modern concept in bridge electrification to give your overhead cranes a clean, contemporary look. QuickBridge
eliminates traditional cable festoon and provides a lower profile than cable chain systems. QuickBridge features conductor bar for bridge
power and wireless radio remote controls for hoist control. This combination supplies crane bridge electrification that is efficient, safe,
rugged, and reliable. The QuickBridge design increases available bridge travel, maximizes below-the-hook working space, and reduces
downtime to ensurepeak equipment availability.
Please follow either the Safe-Lec 2 or 842 conductor bar installation manual for the conductor bar installation procedure and reference
the radio installation guide for mounting and installation.
The QuickBridge system has a modified wiring diagram which is listed in this installation manual. Please use the wiring diagram that
matches the ordered radio system for your configuration.
SECTION 1 - OVERVIEW

QuickBridge Wiring Diagram Manual 5
QB1 BRIDGE RECEIVER WIRING
SECTION 2 - WIRING DIAGRAMS
QB1 Bridge Receiver Wiring
250
Grey, SOUTH
White, NORTH
Yellow, UP
Blue, EAST
Violet, WEST
Green, DOWN
Brown, AC-1 (OR DC +)
Black, AC-2 (OR DC -)
Red, COM (MAIN)
Orange, MAIN (COM)
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Output of COM(MAIN) input voltage (if not needed, cap off)
Pink, RO (Aux)
Not used
Not used
Not used
Not used
Bridge South function
Bridge North function
Auxilary output; can be used for external horn, cap off if not needed
L8B Bridge Receiver wiring
Grey, SOUTH
White, NORTH
Yellow, UP
Blue, EAST
Violet, WEST
Green, DOWN
Brown, AC-1 (OR DC +)
Black, AC-2 (OR DC -)
Red, MAIN-IN
Orange, MAIN-OUT
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Pink, RO (Aux)
Trolley East function (cap off if not needed)
Trolley West Function (cap off if not needed)
Hoist Up function
Hoist Down function
Auxilary output; can be used for external horn, cap off if not needed
L8B Hoist Receiver wiring
Not used
Not used
Signal input needed to run function
Signal input needed to run function
Output of COM(MAIN) input voltage (if not needed, cap off)
QB1 RADIO WIRING
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
1
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

6QuickBridge Wiring Diagram Manual
QB1 HOIST RECEIVER WIRING
QB1 Hoist Receiver Wiring
250
Grey, SOUTH
White, NORTH
Yellow, UP
Blue, EAST
Violet, WEST
Green, DOWN
Brown, AC-1 (OR DC +)
Black, AC-2 (OR DC -)
Red, COM (MAIN)
Orange, MAIN (COM)
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Output of COM(MAIN) input voltage (if not needed, cap off)
Pink, RO (Aux)
Not used
Not used
Not used
Not used
Bridge South function
Bridge North function
Auxilary output; can be used for external horn, cap off if not needed
L8B Bridge Receiver wiring
Grey, SOUTH
White, NORTH
Yellow, UP
Blue, EAST
Violet, WEST
Green, DOWN
Brown, AC-1 (OR DC +)
Black, AC-2 (OR DC -)
Red, MAIN-IN
Orange, MAIN-OUT
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Pink, RO (Aux)
Trolley East function (cap off if not needed)
Trolley West Function (cap off if not needed)
Hoist Up function
Hoist Down function
Auxilary output; can be used for external horn, cap off if not needed
L8B Hoist Receiver wiring
Not used
Not used
Signal input needed to run function
Signal input needed to run function
Output of COM(MAIN) input voltage (if not needed, cap off)
QB1 RADIO WIRING
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
1
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

QuickBridge Wiring Diagram Manual 7
QB2 BRIDGE RECEIVER WIRING
QB2 Bridge Receiver Wiring
250
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(19) AUX 1
(20) AUX 2
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
Output to South bridge 1-speed function
Output to North bridge 1-speed function
Not used
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Not used
Not used
Not used
Not used
Not used
Not used
Not used
K1 Bridge Receiver wiring
(8) DOWN 1S Not used
K1 Hoist Receiver wiring
Signal input needed to run function
Output of MAIN-IN input voltage (if not needed, cap off)
QB2 RADIO WIRING
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)
Signal input needed to run function
Output to Com1 (and Com2 if trolley present on hoist)
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
(8) DOWN 1S
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
2
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

8QuickBridge Wiring Diagram Manual
QB2 HOIST RECEIVER WIRING
QB2 Hoist Receiver Wiring
250
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(19) AUX 1
(20) AUX 2
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
Output to South bridge 1-speed function
Output to North bridge 1-speed function
Not used
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Not used
Not used
Not used
Not used
Not used
Not used
Not used
K1 Bridge Receiver wiring
(8) DOWN 1S Not used
K1 Hoist Receiver wiring
Signal input needed to run function
Output of MAIN-IN input voltage (if not needed, cap off)
QB2 RADIO WIRING
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)
Signal input needed to run function
Output to Com1 (and Com2 if trolley present on hoist)
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
(8) DOWN 1S
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
2
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

QuickBridge Wiring Diagram Manual 9
QB3 BRIDGE RECEIVER WIRING
QB3 Bridge Receiver Wiring
250
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(8) DOWN 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
Output to South bridge 1-speed function
Output to North bridge 1-speed function
Not used
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Not used
Not used
Not used
Not used
Not used
Not used
Not used
K3 Bridge Receiver wiring
Not used
Not used
Not used
Not used
Not used
Not used
Not used
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Output to Up 1-speed function
Output to East 1-speed function
Output to West 1-speed function
Not used
Output to Down 1-speed function
Input from SW A
Not used
Not used
Input from SW A (if trolley present on hoist)
Input from SW A (if functions needed)
Output to function
Output to function
Output to function
Output to function
Not used
Not used
Signal input needed to run function
Signal input needed to run function
Not used
K3 Hoist "A" Receiver wiring
Output to Com1 (and Com2 if trolley present on hoist)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
QB3 RADIO WIRING
(8) DOWN 1S Not used
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(8) DOWN 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Output to Up 1-speed function
Not used
Output to Down 1-speed function
Input from SW B
Not used
Not used
Input from SW B (if trolley present on hoist)
Input from SW B (if functions needed)
Output to function
Output to function
Output to function
Output to function
Not used
Not used
Signal input needed to run function
Not used
Output to East 1-speed function
Output to West 1-speed function
K3 Hoist "B" Receiver wiring
Output to Com1 (and Com2 if trolley present on hoist)
Output of MAIN-IN input voltage (if not needed, cap off)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
3
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

10 QuickBridge Wiring Diagram Manual
QB3 HOIST "A" RECEIVER WIRING
QB3 Hoist "A" Receiver Wiring
250
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(8) DOWN 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
Output to South bridge 1-speed function
Output to North bridge 1-speed function
Not used
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Not used
Not used
Not used
Not used
Not used
Not used
Not used
K3 Bridge Receiver wiring
Not used
Not used
Not used
Not used
Not used
Not used
Not used
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Output to Up 1-speed function
Output to East 1-speed function
Output to West 1-speed function
Not used
Output to Down 1-speed function
Input from SW A
Not used
Not used
Input from SW A (if trolley present on hoist)
Input from SW A (if functions needed)
Output to function
Output to function
Output to function
Output to function
Not used
Not used
Signal input needed to run function
Signal input needed to run function
Not used
K3 Hoist "A" Receiver wiring
Output to Com1 (and Com2 if trolley present on hoist)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
QB3 RADIO WIRING
(8) DOWN 1S Not used
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(8) DOWN 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Output to Up 1-speed function
Not used
Output to Down 1-speed function
Input from SW B
Not used
Not used
Input from SW B (if trolley present on hoist)
Input from SW B (if functions needed)
Output to function
Output to function
Output to function
Output to function
Not used
Not used
Signal input needed to run function
Not used
Output to East 1-speed function
Output to West 1-speed function
K3 Hoist "B" Receiver wiring
Output to Com1 (and Com2 if trolley present on hoist)
Output of MAIN-IN input voltage (if not needed, cap off)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
3
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

QuickBridge Wiring Diagram Manual 11
QB3 HOIST "B" RECEIVER WIRING
QB3 Hoist "B" Receiver Wiring
250
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(8) DOWN 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
Output to South bridge 1-speed function
Output to North bridge 1-speed function
Not used
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Not used
Not used
Not used
Not used
Not used
Not used
Not used
K3 Bridge Receiver wiring
Not used
Not used
Not used
Not used
Not used
Not used
Not used
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Output to Up 1-speed function
Output to East 1-speed function
Output to West 1-speed function
Not used
Output to Down 1-speed function
Input from SW A
Not used
Not used
Input from SW A (if trolley present on hoist)
Input from SW A (if functions needed)
Output to function
Output to function
Output to function
Output to function
Not used
Not used
Signal input needed to run function
Signal input needed to run function
Not used
K3 Hoist "A" Receiver wiring
Output to Com1 (and Com2 if trolley present on hoist)
Output of MAIN-IN input voltage (if not needed, cap off) Output of MAIN-IN input voltage (if not needed, cap off)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT) 110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
QB3 RADIO WIRING
(8) DOWN 1S Not used
(14) COM 3
(15) SOUTH 1S
(16) NORTH 1S
(18) COM 4
(28) COM 5
(29) SW A
(19) R1
(20) R2
(22) R3
(23) R4
(25) AUX 1
(26) AUX 2
(30) SW B
(5) COM 1
(6) UP 1S
(10) COM 2
(11) EAST 1S
(12) WEST 1S
(8) DOWN 1S
(1) AC-1 (OR DC +)
(2) AC-2 (OR DC -)
(3) MAIN-IN
(4) MAIN-OUT
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
Output to Up 1-speed function
Not used
Output to Down 1-speed function
Input from SW B
Not used
Not used
Input from SW B (if trolley present on hoist)
Input from SW B (if functions needed)
Output to function
Output to function
Output to function
Output to function
Not used
Not used
Signal input needed to run function
Not used
Output to East 1-speed function
Output to West 1-speed function
K3 Hoist "B" Receiver wiring
Output to Com1 (and Com2 if trolley present on hoist)
Output of MAIN-IN input voltage (if not needed, cap off)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
3
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

12 QuickBridge Wiring Diagram Manual
QB4 BRIDGE RECEIVER WIRING
QB4 Bridge Receiver Wiring
250
QB4 RADIO WIRING
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
Signal input needed to run function
Signal input needed to run function
Output to Com1 (and Com2 if trolley present on hoist)
Output to Trolley East & West 2-speed function
Output to Down 2-speed function
Output to Up 2-speed function
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
Not used
Not used
(21) AUX 2S
(17) S/N 2S
(13) E/W 2S
(8) DOWN 1S
(7) UP 2S
K2 Hoist Receiver wiring
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
Not used
(21) AUX 2S
Output to North & South bridge 2-speed functions (17) S/N 2S
Not used (13) E/W 2S
Not used (8) DOWN 1S
Not used (7) UP 2S
K2 Bridge Receiver wiring
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Output to North bridge 1-speed function
Output to South bridge 1-speed function
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
4
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

QuickBridge Wiring Diagram Manual 13
QB4 HOIST RECEIVER WIRING
QB4 Hoist Receiver Wiring
250
QB4 RADIO WIRING
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
Signal input needed to run function
Signal input needed to run function
Output to Com1 (and Com2 if trolley present on hoist)
Output to Trolley East & West 2-speed function
Output to Down 2-speed function
Output to Up 2-speed function
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
Not used
Not used
(21) AUX 2S
(17) S/N 2S
(13) E/W 2S
(8) DOWN 1S
(7) UP 2S
K2 Hoist Receiver wiring
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
Not used
(21) AUX 2S
Output to North & South bridge 2-speed functions (17) S/N 2S
Not used (13) E/W 2S
Not used (8) DOWN 1S
Not used (7) UP 2S
K2 Bridge Receiver wiring
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Output to North bridge 1-speed function
Output to South bridge 1-speed function
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
4
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

14 QuickBridge Wiring Diagram Manual
QB5 BRIDGE RECEIVER WIRING
QB5 Bridge Receiver Wiring
250
QB5 RADIO WIRING
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Not used
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
Signal input needed to run functionSignal input needed to run function
Signal input needed to run function
Output to Com1 (and Com2 if trolley present on hoist)
Output to Com1 (and Com2 if trolley present on hoist)
Output to Trolley East & West 2-speed function
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Not used
Output to Down 2-speed function
Output to Up 2-speed function
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
Not used
Output to Trolley East & West 2-speed function
Output to Down 2-speed function
Output to Up 2-speed function
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
Not used
(21) AUX 2S
(17) S/N 2S
(13) E/W 2S
(8) DOWN 1S
(7) UP 2S
K2 Hoist "B" Receiver wiring
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
Not used
(21) AUX 2S
(17) S/N 2S
(13) E/W 2S
(8) DOWN 1S
(7) UP 2S
K2 Hoist "A" Receiver wiring
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
Not used
(21) AUX 2S
Output to North & South bridge 2-speed functions (17) S/N 2S
Not used (13) E/W 2S
Not used (8) DOWN 1S
Not used (7) UP 2S
K2 Bridge Receiver wiring
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Output to North bridge 1-speed function
Output to South bridge 1-speed function
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
5
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

QuickBridge Wiring Diagram Manual 15
QB5 HOIST "A" RECEIVER WIRING
QB5 Hoist "A" Receiver Wiring
250
QB5 RADIO WIRING
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Not used
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
Signal input needed to run function
Signal input needed to run function
Signal input needed to run function
Output to Com1 (and Com2 if trolley present on hoist)
Output to Com1 (and Com2 if trolley present on hoist)
Output to Trolley East & West 2-speed function
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Not used
Output to Down 2-speed function
Output to Up 2-speed function
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
Not used
Output to Trolley East & West 2-speed function
Output to Down 2-speed function
Output to Up 2-speed function
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
Not used
(21) AUX 2S
(17) S/N 2S
(13) E/W 2S
(8) DOWN 1S
(7) UP 2S
K2 Hoist "B" Receiver wiring
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
Not used
(21) AUX 2S
(17) S/N 2S
(13) E/W 2S
(8) DOWN 1S
(7) UP 2S
K2 Hoist "A" Receiver wiring
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
Not used
(21) AUX 2S
Output to North & South bridge 2-speed functions (17) S/N 2S
Not used (13) E/W 2S
Not used (8) DOWN 1S
Not used (7) UP 2S
K2 Bridge Receiver wiring
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Output to North bridge 1-speed function
Output to South bridge 1-speed function
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
5
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

16 QuickBridge Wiring Diagram Manual
QB5 HOIST "B" RECEIVER WIRING
QB5 Hoist "B" Receiver Wiring
250
QB5 RADIO WIRING
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Not used
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)Output of MAIN-IN input voltage (if not needed, cap off)
Signal input needed to run function
Signal input needed to run function
Signal input needed to run function
Output to Com1 (and Com2 if trolley present on hoist)
Output to Com1 (and Com2 if trolley present on hoist)
Output to Trolley East & West 2-speed function
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Not used
Output to Down 2-speed function
Output to Up 2-speed function
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
Not used
Output to Trolley East & West 2-speed function
Output to Down 2-speed function
Output to Up 2-speed function
Output to Trolley West 1-speed function
Output to Trolley East 1-speed function
Input from Aux 1 (if trolley present on hoist)
Output to Down 1-speed function
Output to Up 1-speed function
Input from Aux 1
Not used
Not used
Not used
Not used
(21) AUX 2S
(17) S/N 2S
(13) E/W 2S
(8) DOWN 1S
(7) UP 2S
K2 Hoist "B" Receiver wiring
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
Not used
(21) AUX 2S
(17) S/N 2S
(13) E/W 2S
(8) DOWN 1S
(7) UP 2S
K2 Hoist "A" Receiver wiring
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
Not used
(21) AUX 2S
Output to North & South bridge 2-speed functions (17) S/N 2S
Not used (13) E/W 2S
Not used (8) DOWN 1S
Not used (7) UP 2S
K2 Bridge Receiver wiring
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Output to North bridge 1-speed function
Output to South bridge 1-speed function
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(9) DOWN 2S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(6) UP 1S
(5) COM 1
(20) AUX 2
(19) AUX 1
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
5
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

QuickBridge Wiring Diagram Manual 17
QB6 BRIDGE RECEIVER WIRING
QB6 Bridge Receiver Wiring
250
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
Output to Com1 (and Com2 if trolley present on hoist)
Output to Com1 (and Com2 if trolley present on hoist)
K4 Hoist "B" Receiver wiringK4 Hoist "A" Receiver wiring
Output to function
Output to function
Output to Down 2-speed function
Output to Up 2-speed function
Output to East & West 2-speed functions
Output to West 1-speed function
Output to East 1-speed function
Not used
Signal input needed to run function
Not used
Not used
Not used
Output to function
Output to function
Output to function
Output to function
Input from SW A (if functions needed)
Input from SW B (if trolley present on hoist)
Not used
Not used
Not used
Input from SW B
Output to Down 1-speed function
Not used
Output to Up 1-speed function
Not used
Signal input needed to run function
Signal input needed to run function
Not used
Not used
Not used
Output to function
Output to function
Output to function
Output to function
Output to function
Output to function
Input from SW A (if functions needed)
Input from SW A (if trolley present on hoist)
Not used
Not used
Not used
Input from SW A
Output to Down 2-speed function
Output to Down 1-speed function
Not used
Output to East & West 2-speed functions
Output to West 1-speed function
Output to East 1-speed function
Output to Up 2-speed function
Output to Up 1-speed function
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
K4 Bridge Receiver wiring
Not used
Output to North & South bridge 2-speed functions
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Output to North bridge 1-speed function
Output to South bridge 1-speed function
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
QB6 RADIO WIRING
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
6
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

18 QuickBridge Wiring Diagram Manual
QB6 HOIST "A" RECEIVER WIRING
QB6 Hoist "A" Receiver Wiring
250
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)
Output to Com1 (and Com2 if trolley present on hoist)
Output to Com1 (and Com2 if trolley present on hoist)
K4 Hoist "B" Receiver wiringK4 Hoist "A" Receiver wiring
Output to function
Output to function
Output to Down 2-speed function
Output to Up 2-speed function
Output to East & West 2-speed functions
Output to West 1-speed function
Output to East 1-speed function
Not used
Signal input needed to run function
Not used
Not used
Not used
Output to function
Output to function
Output to function
Output to function
Input from SW A (if functions needed)
Input from SW B (if trolley present on hoist)
Not used
Not used
Not used
Input from SW B
Output to Down 1-speed function
Not used
Output to Up 1-speed function
Not used
Signal input needed to run function
Signal input needed to run function
Not used
Not used
Not used
Output to function
Output to function
Output to function
Output to function
Output to function
Output to function
Input from SW A (if functions needed)
Input from SW A (if trolley present on hoist)
Not used
Not used
Not used
Input from SW A
Output to Down 2-speed function
Output to Down 1-speed function
Not used
Output to East & West 2-speed functions
Output to West 1-speed function
Output to East 1-speed function
Output to Up 2-speed function
Output to Up 1-speed function
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
K4 Bridge Receiver wiring
Not used
Output to North & South bridge 2-speed functions
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Output to North bridge 1-speed function
Output to South bridge 1-speed function
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
QB6 RADIO WIRING
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
6
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

QuickBridge Wiring Diagram Manual 19
QB6 HOIST "B" RECEIVER WIRING
QB6 Hoist "B" Receiver Wiring
250
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
110VAC (or voltage needed for Mainline contactor on MAIN-OUT)110VAC (or voltage needed for Mainline contactor on MAIN-OUT)
Output of MAIN-IN input voltage (if not needed, cap off)
Output of MAIN-IN input voltage (if not needed, cap off)Output of MAIN-IN input voltage (if not needed, cap off)
Output to Com1 (and Com2 if trolley present on hoist)
Output to Com1 (and Com2 if trolley present on hoist)
K4 Hoist "B" Receiver wiringK4 Hoist "A" Receiver wiring
Output to function
Output to function
Output to Down 2-speed function
Output to Up 2-speed function
Output to East & West 2-speed functions
Output to West 1-speed function
Output to East 1-speed function
Not used
Signal input needed to run function
Not used
Not used
Not used
Output to function
Output to function
Output to function
Output to function
Input from SW A (if functions needed)
Input from SW B (if trolley present on hoist)
Not used
Not used
Not used
Input from SW B
Output to Down 1-speed function
Not used
Output to Up 1-speed function
Not used
Signal input needed to run function
Signal input needed to run function
Not used
Not used
Not used
Output to function
Output to function
Output to function
Output to function
Output to function
Output to function
Input from SW A (if functions needed)
Input from SW A (if trolley present on hoist)
Not used
Not used
Not used
Input from SW A
Output to Down 2-speed function
Output to Down 1-speed function
Not used
Output to East & West 2-speed functions
Output to West 1-speed function
Output to East 1-speed function
Output to Up 2-speed function
Output to Up 1-speed function
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
K4 Bridge Receiver wiring
Not used
Output to North & South bridge 2-speed functions
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
AC Neutral (or 12-24VDC -)
110VAC (or 12-24VDC+)
Not used
Output to North bridge 1-speed function
Output to South bridge 1-speed function
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
(4) MAIN-OUT
(3) MAIN-IN
(2) AC-2 (OR DC -)
(1) AC-1 (OR DC +)
(13) E/W 2S
(9) DOWN 2S
(8) DOWN 1S
(12) WEST 1S
(11) EAST 1S
(10) COM 2
(7) UP 2S
(6) UP 1S
(5) COM 1
(27) AUX 2S
(24) R3/R4 2S
(21) R1/R2 2S
(17) S/N 2S
(30) SW B
(26) AUX 2
(25) AUX 1
(23) R4
(22) R3
(20) R2
(19) R1
(29) SW A
(28) COM 5
(18) COM 4
(16) NORTH 1S
(15) SOUTH 1S
(14) COM 3
QB6 RADIO WIRING
RELEASED
XA-574435
CAD SYSTEM: SOLIDWORKS
11/07/2016
D SAMPSON
K COCHRAN
11/07/2016
70051
ER APPR:
ER DATE:
ER ENGR:
ER NO.
STATUS:
11/07/2016
This drawing and the information shown constitute trade secret and confidential property
of Conductix, Inc. It is subject to recall, and is loaned for use only in connection with the
authorized manufacture or installation of Conductix, Inc. products, and on the condition
that it will be treated as confidential and will not be disclosed, published or reproduced in
whole or in part, or permitted to be viewed or used by any other party, without specific
written permission. Receipt and use of the drawing and information constitutes
acceptance and agreement to the above.
MINIMUM
MACHINED
SURFACE
0
10102 F Street
Omaha, NE 68127
800-521-4888
WEIGHT(REF): 0.00 LB
MAT'L: Material <not specified>
PROPRIETARY AND CONFIDENTIAL
UNLESS OTHERWISE SPECIFIED
INTERPRET GEOMETRIC TOLERANCING
PER: ASME Y14.5
PRIMARY UNITS ARE IN INCH POUND SECONDS
SECONDARY UNITS IN MILLIMETERS KILOGRAMS SECONDS
TOLERANCES ARE AS FOLLOWS
DECIMAL=
X.X
0.1 IN [2,5 MM]
X.XX 0.03 IN [0,8 MM]
X.XXX 0.010 [0,25 MM]
ANG. 1
FRAC. 1/16
THREAD CLASS: 2
ALL DIMENSIONS GREATER THAN 24.00 INCHES HAVE A
TOLERANCE OF .063 IN UNLESS OTHERWISE SPECIFIED
DRAWN:
APPR:
DESCRIPTION:
SIZE
B
MATERIAL NO. 2:
REV
SCALE:
1:4
K COCHRAN
D SAMPSON
SHEET
6
OF
6
RADIO SCHEMATICS FOR QUICK BRIDGE

QuickBridge Wiring Diagram Manual XA-577406
Contact us for our Global Sales Offices
www.conductix.us
USA / LATIN AMERICA
10102 F Street
Omaha, NE 68127
Customer Support
Phone [phone]
Phone [phone]
Fax [phone]
[email protected]
[email protected]
CANADA
1435 Norjohn Court
Unit 5
Burlington, ON L7L 0E6
Customer Support
Phone [phone]
Phone [phone]
Fax [phone]
[email protected]
MÉXICO
Calle Treviño 983-C
Zona Centro
Apodaca, NL México 66600
Customer Support
Phone [phone]
([phone]
([phone]
Fax [phone]
[email protected]
BRAZIL
Rua Luiz Pionti, 110
Vila Progresso
Itu, São Paulo, Brasil
CEP: 13313-534
Customer Support
Phone [phone]
Fax [phone]
[email protected]
© Conductix-Wampfler | 2017 | Subject to Technical Modifications Without Prior Notice
20
