Bt8960EVM Hardware User’s Guide
Introduction
Welcome to the Bt8960 Evaluation System from Brooktree Corporation. You can
use the Bt8960 Evaluation System to evaluate the performance of the Bt8960
device, to develop software for your Digital Subscriber Line (DSL) system, and
for many other applications. Brooktree has created this development platform to
help its customers get their communication system products to market as quickly
as possible.
Important Information
Bt8960EVM Contents
The Bt8960 Evaluation System Hardware User’s Guide is one part of the
Bt8960EVM package. If you have ordered the Bt8960EVM, please review the
Bt8960EVM Contents List to ensure that you have received all of the items on the
list.
Software
This user’s guide covers the operation and design of the Bt8960EVM. It does not
describe the software contained in the PROMs that are shipped with this system.
For a description of this software, please sign and return the Software License
agreement shipped as part of the Bt8960EVM package. In return, Brooktree will
send the source code (in C) of the software that resides in the PROM.

Bt8960EVM Hardware User’s Guide Bt8960
Important Information Bt8960EVM Hardware User’s Guide
2Conexant 100188B
Conexant Proprietary and Confidential
User Interface Program
A user interface program (UIP) is also provided by Brooktree to perform for more
advanced monitoring and testing of the Bt8960EVM. This program runs on a
standard IBM compatible personal computer (PC) and interfaces from the PC to
the Bt8960EVM through two RS-232 serial communication ports. Please see the
User Interface Program (UIP) User’s Guide (UGHDSL_1A) for additional
information.
Data Rate
The Bt8960EVM has been designed to operate at a data rate of 288 Kbits per
second. It can be modified to run at other data rates supported by the Bt8960
device. Please see the Bt8960 datasheet or the Interconnection Information
application note for more information on how to modify the line card for different
data rates. Each line card in the system also contains a line card ID which is set by
five 0 ohm resistors, R39 to R43 (see the 8960EVM line card schematic in
appendix A). These resistors may need to be modified so the EVM software is
configured for the correct data rate. The line card ID is defined according to
Table 1.
Ordering Information
Table 1 Line Card ID Definition
R39 to R43 (binary) Data Rate (kbps)
Center Range of Operation
00000 (default) 288 220 to 352
00001 416 352 and up
00010 160 Up to 220
All Others Reserved Reserved
Order Code Bt8960EVM
Description The Bt8960 evaluation system can be ordered using the order code listed
above. This order includes both the local (HTU-C/LTU) and remote
(HTU-R/NTU) units needed to perform full-duplex data transmission over a
twisted pair of wire. A power supply is also included for your convenience.
For a full list of the items shipped with the Bt8960EVM order, please see the
Bt8960EVM Contents List.

Bt8960 Bt8960EVM Hardware User’s Guide
Bt8960EVM Hardware User’s Guide Setup Instructions
100188B Conexant 3
Conexant Proprietary and Confidential
Setup Instructions
Basic Setup
In Figure 1, “C” designates the line interface card as being the central unit, also
referred to as the local unit, HTU-C, or LTU. The “R” designates the remote unit
line interface card. It is also referred to as the HTU-R or NTU.
Figure 1 Loop Performance Test Remote Unit Setup (C to R)
Tx Ext Tx
CLK
Data Rx
Data Rx CLK
Bit Error Rate Detector
BA
Wireline Simulator
8960EVM Line Card
J8, TDAT IN
J7, QCLK Out
J6, RDAT OUT
J5, BCLK OUT
J4
RS-232
J3, Power
J1 or J2, Line
To PC COM1
(Optional)
+5 Volt
Power Supply
(Provided)
To PC COM2
(Optional)
On/
Off
8960EVM Line Card
J8, TDAT IN
J7, QCLK Out
J6, RDAT OUT
J5, BCLK OUT
J4
RS-232
J3, Power
J1 or J2, Line
C
R
100188_001

Bt8960EVM Hardware User’s Guide Bt8960
Setup Instructions Bt8960EVM Hardware User’s Guide
4Conexant 100188B
Conexant Proprietary and Confidential
Follow the steps below to set up the EVM for loop performance evaluation.
1. Connect all cables as shown in the Figure 1, Loop Performance Test Setup
(C to R).
a. Bit Error Rate Detector Connection—The FIREBERD 6000 (w/
lab interface) is recommended (see “Recommended Equipment”
section herein). If it is used, the lab interface should be set up as
follows (selected on rear panel):
1Mode: Unipolar Unbalanced
2Input Impedance: 8 Kohms
3Clock Phasing: TX and RX falling edges
The FIREBERD should also be configured as follows using the front panel
selections:
4Data: 2^23-1
5GEN CLK: INTF
6TIMING MODE: SYNC
7ANALYSIS MODE: CONTINUOUS
8MENU: INTF SETUP: LAB
9AUXILIARY: default settings (“AUX FUNC IN
USE” will illuminate if default is not used)
b. Wireline Simulator Connection—Connectors J1 (RJ-45) or J2
(screw tightened terminal strips) on the line interface cards
should be connected to points “A” and “B” on the wireline
simulator. If either of the J2 connectors are used, be sure the
polarity is the same at each line interface card. If the polarity is
reversed (i.e., tip/ring reversal), the 8960EVM will start up, but
the Bit Error Rate Detector may not synchronize. The wireline
simulator can also be bypassed by connecting J1 or J2 on the “C”
line interface card directly to J1 or J2 on the “R” line interface
card
c. Power Supply Connection—Connect the power supply as shown.
Make sure the power switch is in the “OFF” position.
d. PC Connection (optional)—If a PC is connected to the EVM
through the RS-232 COM1 and COM2 serial communication
ports, the User Interface Program (UIP) can be used to monitor
the status of the EVM during startup and normal operation. The
UIP can also be used to exercise a variety of other test modes and
functions of the EVM. Instructions for running the UIP are listed
below in the UIP Quick Start section. Please see the UIP User’s
Guide for more details.
2. Turn the power switch to the “ON” position.
3. After power is applied, both line cards in the EVM will perform self-test.
During self-test, the START-UP and ERROR LEDs will illuminate. If the
self-test fails, they will remain illuminated and the EVM will go into the
idle state. If both line cards pass self-test, the EVM will automatically try
to startup on the loop connected between the line terminals on the EVM

Bt8960 Bt8960EVM Hardware User’s Guide
Bt8960EVM Hardware User’s Guide Setup Instructions
100188B Conexant 5
Conexant Proprietary and Confidential
line cards (J1 or J2). Startup will take approximately 30 seconds to com-
plete (for 228 kbps operation only). During startup, the green START-UP
LED will blink to indicate that start-up is in process.
4. If startup fails, the red ERROR LED will illuminate momentarily and
startup will begin over again. If startup is successful, the green
START-UP LED will stop blinking and become steadily illuminated, and
the EVM will begin transmitting and receiving external data through the
BNC connectors on the line cards (J5, J6, J7 and J8). This state is
referred to as the Normal Operation state.
5. If during the Normal Operation state, one of the line cards detects an
error condition (i.e., Loss of Signal (LOS) or low noise margin), the line
card will deactivate and the red ERROR LED will blink for approxi-
mately 2 seconds. The line card will then attempt to re-startup on the
given loop.
UIP Quick Start
1. Verify the RS-232 connectors on the EVM line cards (J4) are connected
to COM1 for the central unit and COM2 for the remote unit on the PC.
Also verify the UIP is installed on the PC according to the instructions on
the UIP installation disk and in the UIP User’s Guide.
2. In the UIP directory, type “8960EVM” and press enter.
3. The UIP will default to the “EVM Configuration” form. “BT8960”
should be displayed in column #1 of the “Bitpump Type” field for both
the HTU-C and HTU-R. Press escape to exit.
4. In the main menu, select “Startup”. In the “Custom Startup Options”
form, select “Global Activate”. Startup should begin (verify the green
START-UP LEDs on the line cards are blinking). The UIP will indicate
the status of the EVM as it attempts to startup.
5. If startup is successful, the UIP will display the “Startup Successful”
message. Now the Bit Error Rate Detector should begin passing data (On
the FIREBERD the “sync” indicator will illuminate).
Recommended Equipment
Line Simulator
- Manufacturer: Consultronics
- Model: DLS 200
- Phone: [phone]
NOTE: Several versions of DLS 200 models are available to simulate ANSI and
ETSI ISDN and CSA loops. The model should be chosenaccording to the
application and data rate. Brooktree used the DLS 200 ISDN ANSI and
ETSI models to evaluate the 288 kbps loop performance of the Bt8960.

Bt8960EVM Hardware User’s Guide Bt8960
Functional Description Bt8960EVM Hardware User’s Guide
6Conexant 100188B
Conexant Proprietary and Confidential
Communications Analyzer Bit Error Rate Detector
- Manufacturer: Telecommunications Techniques Corporation
- Model: FIREBERD 6000 with Lab Interface Adapter
- Phone: [phone]
Personal Computer (optional)
- See the UIP User’s Guide
Functional Description
The 8960 EVM consists of two 8960 line cards, a power supply assembly, and a
mounting plate.
8960 Line Cards The 8960 line cards are described in detail in the Interface Descriptions
section.
Power Supply
Assembly The power supply assembly consists of a universal +5 volt power supply and the associated cabling. In addition to providing +5 volt power and
ground, the power supply assembly also provides a signal to each 8960
line card which determines if the line card will be configured as a local
unit (HTU-C/LTU), or a remote unit (HTU-R/NTU). The power
connectors to each line card are labeled as C, as in HTU-C, and R, as in
HTU-R, to indicate how the line card it is connected to will be
configured. See the “Power Supply/Line Card Configuration Interface
(J3)” section for more details on this interface.
Mounting Plate The mounting plate simply provides a mounting surface for the line
cards and power supply assembly.

Bt8960 Bt8960EVM Hardware User’s Guide
Bt8960EVM Hardware User’s Guide Interface Descriptions
100188B Conexant 7
Conexant Proprietary and Confidential
Interface Descriptions
Line Interface (J1, J2)
Connectors
Two connectors are included on the 8960 line card to provide connections to the
line. J1 is an RJ-45 style connector common to telecommunication equipment.
Only pins 4 (tip) and 5 (ring) are utilized on the connector. Pins 1, 2, 3, 6, 7 and 8
of J1 are left unconnected. J2, an all-purpose terminal strip connector, can also be
used to connect to the line tip and ring signals.
Prototyping Provisions
Test points and prototype space are included on the line card to facilitate the
testing of remote line powering and lightning protection circuits. See Table 2 to
determine which test points are provided for these purposes. In most cases, a 0
ohm resistor must be removed prior to adding the circuitry to be tested.
Power Supply/Line Card Configuration Interface (J3)
Power Supply (pins 1 and 2):
Power is provided to the line card through the J3 connector. Two test points are
provided so that power can be measured and/or supplied by an alternative source if
desired. If power is supplied though these test points, be sure to remove the mating
connector from J3 because the cable connected to J3 will create a short between
power and ground when thepower switch onthe power box is in the OFF position.
Two large capacitors (C11, C12) and a transorb (CR4) provide a steady 5 volt
power rail and protect circuits on the line card from dangerous transient power
spikes. The POWER LED (CR1) indicates when power is applied to the line card.
Remote/Local Unit Configuration (pin 3)
In addition to supplying the line card with 5 volts and ground, the 3-pin connector
also contains a control pin used by the 8032 microprocessor to indicate if the line
card is to be configured as the local (HTU-C/LTU) or remote (HTU-R/NTU) unit.
If pin three of J3 (J3-3) is connected to ground, the line card will be configured as
the local unit. Conversely, if J3 is left open, the line card will be configured as the
remote unit. Control of the local/remote configuration function can be removed
from the J3 connector and given to jumper J12 by removing the 0 ohm resistor,
R44, and installing jumper J12. Note that the 8032 microprocessor PORT1B7
signal (pin 9) contains an internal pull-up resistor that is connected to J3-3 so that
no external pull-up resistor is required.

Bt8960EVM Hardware User’s Guide Bt8960
Interface Descriptions Bt8960EVM Hardware User’s Guide
8Conexant 100188B
Conexant Proprietary and Confidential
RS-232 Interface (J4)
Connector J4 provides an RS-232 connection to the 80C32 microprocessor. The TX, RX and GND
are the only RS-232 signals utilized for this connection. TX and RX are labeled on the line card
PCB silk-screen.
Digital Data Interface (J5, J6, J7, J8)
Four BNC connectors are provided to connect the raw digital data and clocks to be transmitted and
received over the line to the Bt8960. These connectors are buffered through an HCT244 buffer to
protect the Bt8960 from improper connections and to provide extra drive strength for coax cables.
All outputs include a source resistance of 50 ohms to prevent ringing. The TDATA IN input (J8) is
pulled up to 1 Kohm to prevent ringing while also providing a high enough input impedance so it
can be driven by a typical CMOS driver. After these signals are buffered, they connect to the channel
unit interface section of the Bt8960. See the Bt8960 datasheet for details on the channel unit
interface timing and functionality. Test points are provided for all of the Bt8960 channel unit
interface signals so that the signals can be connected to a customized framer if desired. Prototype
space is also available on the line card for this purpose.
Test Points
A variety of test points are included on the Bt8960 to accommodate test measurements and to
provide solder points forprototyping.Table 2 lists all of the test points on the Bt8960 line card along
with their associated signal names. These test points have been numbered in an orderly fashion on
the 8960 line card so that they are easy to locate.
Table 2 8960 Line Card Test Point
Test Point Name Signal Name
TXP Transmit (positive)
TXN Transmit (negative)
TP1 SMON
TP2 RST*
TP3 HCLK
TP4 XOUT
TP5 TIP / R46
TP6 TIP (line side)
TP7 TIP (circuit side)
TP8 Split Transformer / TIP
TP9 BCLK (buffered)
TP10 Split Transformer / RING
TP11 RING / R45
TP12 RING

Bt8960 Bt8960EVM Hardware User’s Guide
Bt8960EVM Hardware User’s Guide Interface Descriptions
100188B Conexant 9
Conexant Proprietary and Confidential
80C32 Processor Circuitry
RESET
The RESET button provides an active-high reset signal to the 80C32 processor. The 80C32
processor contains an internal pull-down resistor so that an external pull-down resistor is not
needed. The length of the reset pulse is controlled with capacitor C34.
Memory
A 64 Kbyte PROM (27C512) provides program memory to the 80C32. The 80C32 contains 256
bytes of internal RAM. No external RAM is provided. The upper address line of the 80C32
processor (ADDR15) is used as chip select for the Bt8960 device. The memory is mapped
according to Table 3.
TP13 RING (circuit side)
TP14 GND
TP15 RDAT (buffered)
TP16 TCK (JTAG)
TP17 TMS (JTAG)
TP18 TDI (JTAG)
TP19 TDO (JTAG)
TP20 TBCLK
TP21 RBCLK
TP22 TQ0 (buffered)
TP23 +5V
TP24 QCLK (buffered)
TP25 TDAT (buffered)
Table 2 8960 Line Card Test Point
Test Point Name Signal Name
Table 3 Memory Mapping
Memory Type Address Range R/W Size (bytes) Description
Internal RAM 0x00–0xFF R/W 256 80C32 Internal Memory
Program 0x0000–0xFFFF R 64 K ROM
Data 0x0000–0x00FF R/W 256 Bt8960
Data 0x0100–0x7FFF - 32 K–256 Phantom Bt8960
Data 0x8000–0xFFFF - 32 K Unused

Bt8960EVM Hardware User’s Guide Bt8960
Interface Descriptions Bt8960EVM Hardware User’s Guide
10 Conexant 100188B
Conexant Proprietary and Confidential
Status LEDs
In addition to the power LED, two LEDs labeled ERROR and START-UP are included to provide
status tothe Bt8960EVM user. They are connectedto Port 1 onthe 80C32 and are controlled viathe
Bt8960EVM software.
Line Card ID
Five signals are provided to the 80C32toindicatethe ID of theline card to the EVM software.They
are connect to Port 1 of the 80C32. See Table 1 for a description of the line card ID values.
Layout Considerations
The Bt8960 line card analog and digital power and ground planes are isolated from each other. The
analog and digital planes are connected at a single point under the Bt8960 device. Voltage bypass
and compensation capacitors are located as close to their associated devices as possible. In addition,
capacitors C5 and C6 are located as close to the Bt8960 device as possible to minimize noise at the
Bt8960 analog inputs.

100188B Conexant 11
Conexant Proprietary and Confidential
Appendix A
Schematics, Layout Drawings and BOMs
The schematic, layout drawing and BOM for the 8960 line card are presented on the following
pages.
Figure 2. Detail “A” for Page 1 of the Bt8960 Schematic
NOTE(S):
Please note above changes for your design.
SEROUT T1IN
T2IN
R1IN
R2IN
C1P
C1M
VM1
VM2
VP
T1OUT
T2OUT
R1OUT
R2OUT
C2P1
C2P2
C2M1
C2M2
VCC
GND1 GND2
6 9 MAX233
SERIN
CC
C30 .1UF
+5V
U4
5
18
3
20
12
15
11
16
2
1
4
19
13
14
10
17
8
3
2
7
8
4
6
1
9
5
TX
RX
RTS
CTS
DTR
DSR
DCD
RI
GND
J4
DSUB
>
100188_002

Appendix A Bt8960
Schematics, Layout Drawings and BOMs Bt8960EVM Hardware User’s Guide
12 Conexant 100188B
Conexant Proprietary and Confidential
