Confetti Maker TCMFX Dropper Operator's manual

User documentation The Confetti Maker FX Ⓡ
TCMFX Dropper
Article : TCMFX Dropper
Version : 1.0
Product Code : TCM394
Date : 18-07-2017

User documentation The Confetti Maker FX Ⓡ
Foreword
Thank you for purchasing the TCMFX Dropper.
The Confetti Maker is manufacturer of biodegradable, colorfast and fireproof confetti
products and special effects.
The products we manufacture are used for various events, such as concerts, opening
ceremonies, sporting events and theater show productions. With our products your party
is guaranteed to be a great success.
“We create experiences.”
This manual describes the TCMFX Dropper.
All information in this manual is important for the safe and proper functioning of the
TCMFX Dropper.
Please read the manual carefully if you are not familiar with this device.
The Confetti Maker wishes you lots of fun with your purchase!
© Copyright 2017 The Confetti Maker FX®. This manual and its content is copyright of
the Confetti Maker FX®. All rights Reserved.
No part of this manual may be reproduced or transmitted in any form or by any means
including photocopying and recording without the written permission of the copyright
holder.
The Confetti Maker Reserves the right to make any changes without direct knowledge of
the customer.
Please contact your supplier for additional information regarding maintenance and
repair.
This user manual has been written with care and attention to detail; however, should you
find any errors or omissions, please contact your supplier and inform them of your
findings.
Please be aware that The Confetti Maker FX® shall not be held liable by the user for any
damages, losses or third party claims arising from any uses of this product.

User documentation The Confetti Maker FX Ⓡ
General Safety
WARNING!
Read the manual carefully before using the TCMFX Dropper.
The Confetti Maker ® is not liable for injury, damage and / or excessive wear
resulting from improper maintenance, improper use or modifications to the
device.
If you have any questions, issues or problems that do not get discussed in this
guide, please tell your supervisor or call/e-mail the technical support from
The Confetti Maker®.
TCMFX Dropper and the manual may not be modified without permission of
The Confetti Maker®.
In case of damage or problems, always consult The Confetti Maker® as soon as
possible.
Introduction
The Dropper has been designed to drop a backdrop from a truss with a control
panel.
The Dropper operates at a power supply of 230V~50/60Hz.
The TCMFX Dropper is powered by a power connector. The supplier is not
responsible for the misuse of this device.

User documentation The Confetti Maker FX Ⓡ
DECLARATION OF CONFORMITY
Manufacturer: The Confetti Maker
Product: TCMFX FX-Control
We declare that the above products meet the following European directives
and standards:
- Low Voltage Directive 2006/42/EC
- EMC Directive 2004/108/EG
- Machinery Directive 2006/42/EC
- NEN-EN-
Year of Manufacturing: 2017
Name: The Confetti Maker
Place: Rotterdam
Date: 11-07-2017
Director: H. S. Maikoe

User documentation The Confetti Maker FX Ⓡ
Specifications
Input : Powercon Connection
Output : Powercon Connection
Capacity : 30Kg
Including : Mounting Clamp
Voltage : 230V AC 50/60Hz
Size : 10, 5 x 25 x 6 cm
Weight : 3Kg
Ideal environmental values
Temperature : 0 – 45 ◦c
Humidity : max. 75%
Keep away from:
- Dust
- Corrosive gasses
- High concentrations of organic gasses.

User documentation The Confetti Maker FX Ⓡ
Components
1. Input
2. Release Hook
3. Truss Clamp
4. Indication LED
5. Release Lever
6. Release Hook
7. Safety Steel Attachment

User documentation The Confetti Maker FX Ⓡ
Accessories
Loop Through Cable
The function of the loop through cable is supplying multiple devices with a single power socket. Looping through
the device should only be done without power. The first Dropper is connected to a power socket with the power
socket to Powercon cable. The second Dropper is powered with the blue Powercon connector on the loop through
cable. The grey side of the loop through cable connects to the grey connector on the first Dropper. Connect the
Powercon by plugging the Powercon into the connector on the Dropper and turning it clockwise until you hear a
click sound. Repeat this process for the rest of the Droppers.
Power Socket to Powercon cable
The power socket to Powercon cable is the power cable of the Dropper. The power socket side connects to 230V
50-60HZ. The power connector connects to the Dropper. Connect the Powercon by plugging the Powercon into
the Dropper and turning it clockwise until you hear a click sound.

User documentation The Confetti Maker FX Ⓡ
TCM FX-Control
The TCM FX-Control is designed to control multiple TCM products.
Connect the power socket to Powercon cable to the blue connector on the side of the FX
Control.
Connect the Dropper to the FX-Control with the loop through cable. Connect the blue
side of the cable to the Dropper and the grey side of the cable to the back side of the FX
Control.
When firing the Dropper first switch the key switch to unlock the panel.
Switch the safety switch to the right so the white dot is pointing upwards. When the red fire button is pushed, the
Dropper will activate. Turn the safety switch to the left when the Dropper is not in use.
To connect multiple FX Control panels use the loop through cable. Connect the Blue side of the Powercon to the
second FX-Control. Connect the grey side of the loop through cable to the grey connector on the FX-Control.
Both FX-Controllers are now powered.
Installation
- Clamp the Dropper securely to a truss.
- Connect the safety steel to the attachment.
- Connect a Powercon to the input as shown in the pictures
- Make sure the indication led is working when powered.
- Test the dropper system by powering the dropper.

User documentation The Confetti Maker FX Ⓡ
Warranty
The Dropper has a 3 year warranty which will be void if the Dropper is handled
differently than described in this manual.
The warranty is void when the Dropper has been opened by anyone other than the
Confetti Maker.
The Confetti maker is not responsible for any paint or hardware damaged as a result
of rough handling.
CAUTION! Always contact your supplier in case of malfunctions.
Never try to repair the Dropper yourself.
WARNING
READ THIS DOCUMENT BEFORE INSTALLING OR USING THE TCMFX DROPPER
IMPROPER SELECTION, IMPROPER USE, USE BY ANYONE OTHER THAN TRAINED
USERS HAVING APPROPRIATE TECHNIAL EXPERTISE OF THE TCM FX DROPPER
CAN CAUSE DAMAGE TO EQUIPMENT OR PROPERTY.
This document and other information from the TCMFX Dropper, its subsidiaries and authorized
distributors together only provide product installation guidelines and product or system usage options,
each of which are intended to operate in conjunction with further investigation by trained users having
appropriate technical expertise to facilitate the safe handling and use of The Dropper. The Dropper is
not intended to be used or handled by any users other tan trained users having appropriate technical
expertise. The information and documentation contained in our catalog and on the website,
www.theconfettimaker.com, is only provided for technical illustration purposes only and may not be
used or relied upon as a statement of suitability for use in any particular application. Users, through
their own analysis and testing, are solely responsible for assuring that The Dropper is used in a safe
and intended manner with all performance, endurance, maintenance, safety and warning
requirements necessary for safe application being met.
