Connect Tech M.2 GPS User manual

M.2 GPS
CTIM-000454 Revision 0.01 2021-03-01

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 2 of 13 Date: 2021-03-01
TABLE OF CONTENTS
Table of Contents .......................................................................................................................2
Preface.......................................................................................................................................3
Disclaimer ........................................................................................................................................ 3
Customer Support Overview ........................................................................................................... 3
Contact Information......................................................................................................................... 3
Limited Product Warranty ............................................................................................................... 4
Copyright Notice .............................................................................................................................. 4
Trademark Acknowledgment........................................................................................................... 4
ESD Warning .................................................................................................................................... 5
Revision History .........................................................................................................................5
Introduction ...............................................................................................................................6
Product Features and Specifications ............................................................................................... 6
Part Numbers / Ordering Information ............................................................................................. 6
Product Overview.......................................................................................................................7
Block Diagram .................................................................................................................................. 7
Connector Summary & Locations .................................................................................................... 7
Interface Pin-outs............................................................................................................................. 8
M.2 Edge Connector............................................................................................................... 8
External I/O Connector .......................................................................................................... 9
Active Antenna Connector ..................................................................................................... 9
Detailed Feature Description ....................................................................................................10
USB.................................................................................................................................................10
TIMEPULSE..................................................................................................................................... 10
W_DISABLE1# ................................................................................................................................ 10
External Interrupt Input/WHEELTICK Input ................................................................................... 10
FWD................................................................................................................................................ 11
External Battery .............................................................................................................................11
Local Battery and BAT_EN Header................................................................................................. 11
On-Board Indicator LEDs................................................................................................................11
Software Support for the NEO-7 and NEO-M8 GPS Receivers ......................................................12
Cables ......................................................................................................................................13
CBG162 – External I/O Cable ......................................................................................................... 13
CBG214 – Murata HSC to SMA Female Cable ................................................................................13

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 3 of 13 Date: 2021-03-01
PREFACE
Disclaimer
The information contained within this user’s guide, including but not limited to any product
specification, is subject to change without notice.
Connect Tech assumes no liability for any damages incurred directly or indirectly from any technical or
typographical errors or omissions contained herein or for discrepancies between the product and the
user’s guide.
Customer Support Overview
If you experience difficulties after reading the manual and/or using the product, contact the Connect
Tech reseller from which you purchased the product. In most cases the reseller can help you with
product installation and difficulties.
In the event that the reseller is unable to resolve your problem, our highly qualified support staff can
assist you. Our support section is available 24 hours a day, 7 days a week on our website at:
https://connecttech.com/support/resource-center/. See the contact information section below for
more information on how to contact us directly. Our technical support is always free.
Contact Information
Contact Information
Mail/Courier
Connect Tech Inc.
Technical Support
42 Arrow Road
Guelph, Ontario
Canada N1K 1S6
Contact Information
[e-mail]
[e-mail]
www.connecttech.com
Toll Free: 800-426-8979 (North America only)
Telephone: [phone]
Facsimile: 519-836-4878 (on-line 24 hours)
Support
Please go to the Connect Tech Resource Center for product manuals,
installation guides, device drivers, BSPs and technical tips.
Submit your technical support questions to our support engineers.
Technical Support representatives are available Monday through Friday,
from 8:30 a.m. to 5:00 p.m. Eastern Standard Time.

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 4 of 13 Date: 2021-03-01
Limited Product Warranty
Connect Tech Inc. provides a 2-year Warranty for this product. Should this product, in Connect Tech
Inc.'s opinion, fail to be in good working order during the warranty period, Connect Tech Inc. will, at its
option, repair or replace this product at no charge, provided that the product has not been subjected to
abuse, misuse, accident, disaster or non-Connect Tech Inc. authorized modification or repair.
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc. business
partner or to Connect Tech Inc. along with proof of purchase. Product returned to Connect Tech Inc.
must be pre-authorized by Connect Tech Inc. with an RMA (Return Material Authorization) number
marked on the outside of the package and sent prepaid, insured and packaged for safe shipment.
Connect Tech Inc. will return this product by prepaid ground shipment service.
The Connect Tech Inc. Limited Warranty is only valid over the serviceable life of the product. This is
defined as the period during which all components are available. Should the product prove to be
irreparable, Connect Tech Inc. reserves the right to substitute an equivalent product if available or to
retract the Warranty if no replacement is available.
The above warranty is the only warranty authorized by Connect Tech Inc. Under no circumstances will
Connect Tech Inc. be liable in any way for any damages, including any lost profits, lost savings or other
incidental or consequential damages arising out of the use of, or inability to use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. Connect Tech Inc. shall
not be liable for errors contained herein or for incidental consequential damages in connection with the
furnishing, performance, or use of this material. This document contains proprietary information that is
protected by copyright. All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent of Connect Tech, Inc.
Copyright 2021 by Connect Tech, Inc.
Trademark Acknowledgment
Connect Tech, Inc. acknowledges all trademarks, registered trademarks and/or copyrights referred to in
this document as the property of their respective owners. Not listing all possible trademarks or
copyright acknowledgments does not constitute a lack of acknowledgment to the rightful owners of the
trademarks and copyrights mentioned in this document.

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 5 of 13 Date: 2021-03-01
ESD Warning
Electronic components and circuits are sensitive to
ElectroStatic Discharge (ESD). When handling any
circuit board assemblies including Connect Tech
COM Express carrier assemblies, it is recommended
that ESD safety precautions be observed. ESD safe
best practices include, but are not limited to:
•Leaving circuit boards in their antistatic
packaging until they are ready to be installed.
•Using a grounded wrist strap when handling
circuit boards, at a minimum you should touch a
grounded metal object to dissipate any static
charge that may be present on you.
•Only handling circuit boards in ESD safe areas,
which may include ESD floor and table mats,
wrist strap stations and ESD safe lab coats.
•Avoiding handling circuit boards in carpeted
areas.
•Try to handle the board by the edges, avoiding
contact with components.
REVISION HISTORY
Revision
Date
Changes
0.00
2016-03-18
Initial Release
0.01
2021-03-01
Updated format
Replaced GPS-06T PN /w MSG095

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 6 of 13 Date: 2021-03-01
INTRODUCTION
Connect Tech’s M.2 GPS is a GNSS receiver based on the very small industry standard M.2 Type-2242-S3-
B form factor. Using the USB bus, the M.2 GPS provides global positioning and time-stamp information,
while taking up little space and power within a system. Also considering the existing support for
Windows and Linux, the M.2 GPS can be easily integrated into any existing system, as well as easily
implemented into new systems.
Product Features and Specifications
Specifications
Dimensions
42 mm x 22 mm (M.2 Type-2242-S3-B)
Antenna Connector
HSC (MHF4), support for active antennas only
GPS
GPS, GLONASS, QZSS, Galileo
UBX, RTCM, NMEA protocols
I/O
TIMPULSE output synchronized with GPS time grid
WHEELTICK input (used for Automotive Dead Reckoning)
FWD input (used for Automotive Dead Reckoning)
External Interrupt Input
External Battery Input
Cables
CBG162: External I/O Cable
CBG214: HSC (MHF4) to SMA Female Cable
Antenna
MSG095, VTGPSA-9, Active GPS/GLONASS antennas only
Environmental
-40ºC to +85ºC
Warranty and Support
2 Years
Part Numbers / Ordering Information
Part Number
M2G201
M.2 GPS Receiver (Battery not included) populated with NEO-7N module
M2G202
M.2 GPS Receiver (Battery included) populated with NEO-7N module
M2G203
M.2 GPS Receiver (Battery not included) populated with NEO-M8N module
M2G204
M.2 GPS Receiver (Battery included) populated with NEO-M8N module
M2G205
M.2 GPS Receiver (Battery not included) populated with NEO-M8L module,
supports Automotive Dead Reckoning
M2G206
M.2 GPS Receiver (Battery included) populated with NEO-M8L module,
supports Automotive Dead Reckoning

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 7 of 13 Date: 2021-03-01
PRODUCT OVERVIEW
Block Diagram
Connector Summary & Locations

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 8 of 13 Date: 2021-03-01
Interface Pin-outs
M.2 Edge Connector
The M.2 GPS pin-out is compliant to the M.2 Socket 2 with B Key. This module uses only +3.3V for input
power and all I/O is +3.3V signaling.
Function
M.2 Card Edge Connector
Location
P3
Pinout
Signal
Pin
Pin
Signal
NC
1
2
+3.3V
GND
3
4
+3.3V
GND
5
6
NC
USB_D+
7
8
W_DISABLE1#
USB_D-
9
10
NC
GND
11
12
Connector Key
Connector Key
13
14
Connector Key
Connector Key
15
16
Connector Key
Connector Key
17
18
Connector Key
Connector Key
19
20
NC
CONFIG_0
(GND)
21 22 NC
NC
23
24
NC
NC
25
26
NC
GND
27
28
NC
NC
29
30
NC
NC
31
32
NC
GND
33
34
NC
NC
35
36
NC
NC
37
38
NC
GND
39
40
M.2 GNSS SCL
NC
41
42
M.2 GNSS SDA
NC
43
44
M.2 GNSS IRQ
GND
45
46
NC
NC
47
48
NC
NC
49
50
RESET#
GND
51
52
NC

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 9 of 13 Date: 2021-03-01
NC
53
54
NC
NC
55
56
NC
GND
57
58
NC
NC
59
60
NC
NC
61
62
NC
NC
63
64
NC
NC
65
66
NC
NC
67
68
NC
CONFIG_1
(GND)
69 70 +3.3V
GND
71
72
+3.3V
External I/O Connector
The pinout for the I/O connector is outlined in the table below.
Function
External I/O Connector
501568-0507
Location
P2
Connector PN
501568-0507 - Manufacturer: Molex
Mating
Connector PN
501330-0500 - Manufacturer: Molex
CTI Cable #: CBG162
Pinout
Pin
Signal
Description
1
EXT_INT /
WHEELTICK
External Interrupt Input or
Speed pulse input
2
TIMEPULSE
Time pulse Output
3
FWD
Forward/Reverse indicator
4
GND
Digital Ground
5
EXT_BAT
External Battery Input
NOTE: WHEELTICK is only available on M2G205 and M2G206, otherwise this signal is EXT_INT
NOTE: FWD is only available on M2G205 and M2G206, otherwise it is not connected and should be left floating
Active Antenna Connector
Function
Active Antenna Connector
HSC - MHF4 Jack
Location
J2
Connector PN
MM4829-2702RA4 - Manufacturer: Murata
Mating Connector
PN
HSC – MHF4 Socket Standard
CTI Cable #: CBG214

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 10 of 13 Date: 2021-03-01
DETAILED FEATURE DESCRIPTION
USB
The M.2 GPS uses a USB 2.0 Full Speed (12Mb/s) interface as the primary communication bus. The USB
interfaces is connected between the GPS receiver and the M.2 card edge connector (pins 7/9).
TIMEPULSE
The TIMEPULSE output is a buffered and ESD protected signal from the GPS receiver. This signal
connects to pin 2 of the External I/O Connector. It also drives the TIMEPULSE LED. By default, when
satellites are not fixed this signal is High (3.3V). When satellites are fixed, this signal pulses at 1 pulse-
per-second (1Hz) with a 20% duty cycle (200ms High, 800ms Low). For more information see the
Receiver Description Including Protocol Specification document for your GPS receiver found in the
Software Support section of this document.
W_DISABLE1#
The W_DISABLE# input from the M.2 card edge connector (pin 8) can be used to enable and disable
power to the M.2 GPS module. When W_DISABLE1# is low, the module is disabled and no power is
applied to the M.2 GPS. When W_DISABLE1# is High, the module is enabled and powered on. This signal
is locally pulled up to 3.3V through a 100K ohm resistor.
External Interrupt Input/WHEELTICK Input
The external interrupt/WHEELTICK input is an ESD protected input signal from the external I/O
connector to the GPS receiver. On modules that do not support Automotive Dead Reckoning, this signal
will always be an External Interrupt input, and this input can be used for control of the GPS receiver or
for aiding. On modules that support Automotive Dead Reckoning (M2G205/M2G206), this signal is by
default used as the WHEELTICK input and is used to provide speed pulse information to the module. If
the speed pulse information is available from the host processor, then the information can be provided
using software messages in the UBX protocol. If using software messages to provide speed pulse
information, this signal can be configured as an external interrupt input. See the Receiver Description
Including Protocol Specification document for your GPS receiver found in the Software Support section
of this document. If this signal is not used, it should be left floating. Do not exceed 3.6V on this signal.

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 11 of 13 Date: 2021-03-01
FWD
The forward/reverse signal is an ESD protected input used on modules that support Automotive Dead
Reckoning. This signal is used to indicate the moving direction of the module. An active high indicates
moving forward and a low for moving backwards. If the forward/reverse information is available from a
host processor, then this information can be provided to the module using software messages in the
UBX protocol. For more information see the Receiver Description Including Protocol Specification
document for your GPS receiver found in the Software Support section of this document. On modules
that do not support Automotive Dead Reckoning, this signal should be left floating. Do not exceed 3.6V
on this signal.
External Battery
The external battery input in an ESD protected input from the External I/O Connector to the backup
voltage supply of the GPS receiver. The purpose of a battery signal is to power internal memory for GPS
almanac, ephemeris, and last position retention through power cycles. The voltage on this input signal
should be greater than 2.0V and less than 3.6V. The supply of this signal should be able to provide at
least 20uA continuous at room temperature, and 50uA at +85 degrees Celsius.
Local Battery and BAT_EN Header
There is a local battery supply on the M.2 GPS. The purpose of a battery signal is to power internal
memory for GPS almanac, ephemeris, and last position retention through power cycles. The design
includes a MS621 rechargeable battery which recharges itself when the unit is powered on. When
power is removed from the unit the GPS receiver will typically consumer 15uA on its battery supply
input at room temperature and 24uA at 85 degrees Celsius.
On-Board Indicator LEDs
LED
Description
TIMEPULSE
TIMEPULSE visual indicator. This LED will blink at the rate and duty cycle of the
TIMEPULSE output.
PWR
ON: indicates the module is powered on and enabled
OFF: indicated the module is not powered and is disabled
*the module is enabled/disabled using the W_DISABLE1# input from the M.2 card
edge connector

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 12 of 13 Date: 2021-03-01
Software Support for the NEO-7 and NEO-M8 GPS Receivers
The USB drivers for the NEO-7 and NEO-M8 GPS Receivers can be found on the u-Blox website:
https://www.u-blox.com/en/product-
resources?f[0]=property_file_product_filter%3A2668&f[1]=field_file_category%3A221
For configuration and setting options for the NEO-7 GPS receiver, please refer to the u-Blox 7 Receiver
Description Including Protocol Specification V14 found on the u-Blox website:
https://www.u-blox.com/en/product-resources?f[0]=field_file_category%3A209
For configuration and setting options for the NEO-M8N GPS receiver, please refer to the u-Blox M8
Receiver Description Including Protocol Specification found on the u-Blox website:
https://www.u-blox.com/en/product-resources?f[0]=field_file_category%3A209
Changing the configuring of the NEO modules is best accomplished using the u-center application
provided by u-Blox. To get the u-center application for windows, please see the link below:
https://www.u-blox.com/en/product/u-center-windows

M.2 GPS
Users Guide
www.connecttech.com
Document: CTIM-000454
Revision: 0.01
Page 13 of 13 Date: 2021-03-01
CABLES
CBG162 – External I/O Cable
501330-0500
Signal
Open End
(Un-terminated)
1
See I/O Connector Section for pin-out
Un-terminated
2
Un-terminated
3
Un-terminated
4
Un-terminated
5
Un-terminated
CBG214 – Murata HSC to SMA Female Cable
HSC TO SMA Female
(Socket)
