Connection Technology Systems EPS-2018G User manual

Trademarks
CTS is a registered trademark of Connection Technology Systems
Inc. Contents subject to revision without prior notice.
All other trademarks remain the property of their owners.
Copyright Statement
Copyright Connection Technology Systems Inc.
This publication may not be reproduced as a whole or in part, in
any way whatsoever unless prior consent has been obtained from
Connection Technology Systems Inc.
FCC Warning
These devices have been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These standards are designed to provide reasonable
protection against harmful interference when these devices are
operated in a commercial environment. These devices generate,
use, and can radiate radio frequency energy and may cause
harmful interference to radio communications unless installed in
accordance with this Quick Installation Guide. Operation of these
devices in a residential area is likely to cause harmful interference
which will make the user responsible for the appropriate remedial
action at his / her own expense.
CE Mark Warning
These are Class A products. In a domestic environment these
products may cause radio interference in which case the user will
need to consider adequate preventative methods.
1. Checklist
The package should contain the following items:
-
PoE Switch
-
AC Power Cord
-
Four Rubber Feet
-
Rack-mounting Bracket Kit
-
Quick Installation Guide
-
SFP dust cap x 2
Please notify your sales representative immediately if any item is
missing or damaged.
As for power adapters, please refer to Section 8 for more detailed
information.
2. Overview
This PoE Switch is compact 19-inch, rack mountable, has 16-port
10/100BASE-TX 802.3at PoE+ with 2-port Gigabit TP/SFP combo
switch in front panel. This PoE Switch provides high performance
store and forward switching plus built-in DIP switch that provides
“Default”, “VLAN” and “CCTV” mode.
Clear, at-a-glance per-port LED indicators make users easier to
monitor network and PoE status. EPS-2018G supports IEEE
802.3af/at PoE technology, up to 30W per port and maximum
100-meter transmission distance and supports a maximum of
250/380W of total PoE budget..
Major Features:
3. Switch Front Panel
Figure 1 shows the front panel of EPS-2018G
Figure 1. EPS-2018G Front Panel
4. LED Description
Power LED
LED
Color
Function
Power
Off
Power is off.
Green
Indicates the switch has power.
Port LED 1~16
LED
Color
Function
Link/ACT
Off
No connection
Green
Light: Indicates the link through that port
is successfully established at
10/100Mbps.
Blink: Indicates the switch is actively
sending or receiving data over that port.
PoE
Off
No powered device (PD) connected
Orange
Light: There is a PoE PD connected to
be port, which supply power
successfully.
Blink: Indicates port abnormal power
supply.
TP & F/O Port LED 17~18
LED
Color
Function
Link/ACT
Off
No connection
Green
Light: Indicates the link through that port is
successfully established.
Blink: Indicates the switch is actively
sending or receiving data over that port.
Speed
Off
Indicates the link through established at
10/100Mbps
Green
Indicates the link through established at
1000Mbps
5. Switch Rear Panel
Figure 2 shows the rear panel of EPS-2018G
Figure 2. EPS-2018G Rear Panel
6. Network Installation
Please follow the steps described below to complete the network
installation.

Connect one end of a standard network cable to port-17 or 18.

Connect the other end of a standard network cable to the
network devices such as routers or workstations.

Install SFP transceiver and connect one end of a fiber cable to
port-17 or 18.

Connect the other end of fiber cable to the remote fiber device

Connect one end of a standard network cable to port-1 to
port-16 on the front of the PoE switch

Connect the other end of standard network cable to the
802.3af/at powered devices.

Connect one end of the power cable to the rear of the PoE
switch.

Connect the power plug of the power cable to a standard wall
outlet. When the PoE switch receives power, the Power LED
should remain solid Green.
7. DIP Switch
The front panel of EPS-2018G has one DIP switch that supports
“Default”, “VLAN” and “CCTV” modes. The detailed description are
shown in the following.
-
16 x 10/100Base-TX ports with 802.3af/at PoE Injector Mode
-
2 x 10/100/1000Base-T ports
-
2 x 1000Base-X SFP slots shared with port-17 to 18
-
DIP switch for Default, VLAN and CCTV mode
-
16K MAC address table
-
Supports PoE power up to 30 watts for each PoE port
-
Total 250/380 watts PoE budget
-
PD alive check
-
Supports +/- 6KV surge immunity

Note: After change the mode, in order to the corresponding
configuration take effect. The switch needs to restart manually.
Default DIP Switch Mode
The default DIP switch mode is general switch mode that can
normal communication between port 1~18.
VLAN DIP Switch Mode
The VLAN DIP switch mode is VLAN isolation mode that 1-16 port
can be isolated each other but 1-16 port can connect to 17~18
port.
CCTV DIP Switch Mode
The CCTV ON DIP switch mode is extension mode that allows
1-16 port to extend your network distance up to 250 meters at
10Mbps while remaining to support 30W PoE power output.
8. Technical Specifications
Standards
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-T
IEEE 802.3z 1000Base-X
IEEE 802.3x Flow Control,
IEEE 802.3af Power over Ethernet,
IEEE 802.3at Power over Ethernet Plus
Interface
16-Port RJ-45 for 10/100Base-TX, auto
MDI/MDIX
2-Port RJ-45 for 10/100/1000Base-T, auto
MDI/MDIX
2-Port SFP slot for 1000Base-X
PoE Injector Port
16-Port 802.3af/at PoE Injector (Port-1 to
Port-16)
PoE Power Output
Max. 30W per port
PoE Budget
250/380W
Jumbo Frame
9K
MAC Address Table
16K
LED
Power, Link/ACT, PoE, Speed
Power
AC Input Voltage: 100V-240V 50/60Hz
Shipping Weight
3kg
Dimensions
440(W) x 208(D) x 45(H)mm
Temperature
Operating: 0oC~50oC; Storage: -20oC~60oC
Humidity
5%~90% RH non-condensing
EMC Safety
FCC Part 15 Class A, CE
Media
TP:
Fiber
EIA/TIA-568 CAT 3/4/5/5e
50/125, 62.5/125µm multi-mode fiber
9/125, 10/125µm single-mode fiber
*Please contact us for further reports and updates.
NOTE: Specifications may change without prior notice.
Contact Information
Connection Technology Systems INC (CTS)
18F-6, No.79, Sec.1, Xintai 5th Rd., Xizhi Dist.,
New Taipei City 221, TAIWAN, R.O.C.
TEL: [phone] FAX: [phone]
E-Mail: [email protected]
EPS-2018G
16-Port 10/100Base-TX
802.3at PoE+
With 2-Port Gigabit TP/SFP
Combo Switch
User’s Guide
Version 1.0
