Connex SMART TECH CC-P2000 User manual

SMART Wi-Fi
&
BLUETOOTH
10 A SWITCH
USER MANUAL

Thank you for purchasing your
Connex Connect Smart Tech device.
Download the Connex Connect App
from Google Play or iOS store, and connect
your Smart Tech devices to your home
2.4 GHz Wi-Fi.
One App to manage all
your Smart Tech devices from your
mobile or tablet.

3
Contents
What’s in the Box 4
Requirements 4
Download App 5
Register Account 5
Plug In and Connect 6
Connect (Easy Mode) 8
Connect (AP Mode) 10
Specications 12
FAQ’s 13
System Requirements 14
CE Certication 14
Important Information 15
Cleaning & Care Instructions 16
Environmentally Friendly Disposal 16
Support 17
Warranty 18

What’s in the Box
Requirements
• Make sure you are connecting to a 2.4 GHz Wi-Fi network.
• Connex Connect won’t work on a 5 GHz Wi-Fi network.
• Have your Wi-Fi network name and password ready.
• Make sure your mobile device is running iOS® 8 or higher or
AndroidTM 4.1 or higher.
4
• Smart Wi-Fi 10 A Switch
• User Manual
• Voice Assistant Guide

Download the Connex Connect App
from Google Play or iOS store.
Step 1
5
Get the App!

Register an Account on the
Connex Connect App
Step 2
6

Plug In and Connect
Step 3
7
Plug in the Connex Connect Switch and switch on.
(The plug LED will ash repeatedly, 2 x per second: Easy Mode)
How to Reset the Device
• Power must be switched o.
• Long press to restore to factory settings.
• Reset again by pressing and holding the button for 3 seconds until
the indicator light ashes slowly. You will then be in “AP Mode”,
which is the back-up mode of connection, slowly ashing once every
3 seconds. 1
3
2
4
1. Neutral
2. Input Line
3. Reset Button
4. Output Line

Easy Mode Connection
Step 4
+
In the Connex Connect App
top right corner of the device
screen, click “+”.
Make sure the LED is ashing
rapidly indicating “ready to
connect”.
8

Enter your Wi-Fi network and
password.
The Connex Connect App will
connect to your device.
If the connection fails, then try
connecting using the AP Mode.
9

AP Mode Connection
Step 5
AP Mode
In the Connex Connect App
top right corner of the device
screen, click “+”.
Select “AP Mode”in top corner.
Select “next”and enter your
Wi-Fi and password details.
10

Follow the instructions to
choose the device from your
Wi-Fi list.
The Connex Connect App will
connect to your device.
11

12
Specifications
• App: Connex Connect
• Plug Dimensions: 88 x39 x 23 mm
• Technology: LED , Wi-Fi & Bluetooth
• Connectivity: Wi-Fi 802.11bgn 2.4 GHz (Wi-Fi 4)
• Maximum Load: 10 Amps / 2 300W
• Voltage In: 220 / 240 V
• Plug Control: Turn On and O with Timer
• Voice Assistant: Amazon Alexa, Google Assistant
• Materials: PVC, V0 Fireproof Material
• Load Shedding: Set the plug to ON / OFF / Last State after
loadshedding

MANUAL CONNECTION
13

FAQ’s
1. How many devices can I control?
Connex Connect App can control unlimited number of devices and
locations. Your router has a limit as to how many devices can connect
to it.
2. How do I group multiple Connex Connect devices?
You can group multiple similar devices together by room or
by location. The same device can form part of multiple groups.
From the Connex Connect App main screen, select the device you
want to group. Select edit in top right corner. Then select
“Create Group”. You can then select devices which you would like
to group and will be able to rename them.
3. How do I share devices with family and friends?
You can share devices by selecting the “Me” icon Home
Management Add Family. In order to share a family member
needs to have downloaded the Connex Connect App and registered.
4. What is the wireless range?
The range of your Wi-Fi is dependent on your home router
specications and the strength of your Wi-Fi signal.
5. Why does the plug appear o-line?
• Ensure the plug is turned ON (the plug power should always be ON
to operate correctly).
• Make sure your Wi-Fi router is on and in range (your Connex Connect
Smart device requires a Wi-Fi signal to function correctly).
14

15
FAQ’s
6. Why can’t I connect to my Wi-Fi?
• Ensure your device and your mobile are on the same home network.
• Make sure you entered the correct Wi-Fi password during set-up.
• Ensure your Wi-Fi signal strength extends to your device location.
System Requirements
• Mobile device running iOS® 8 or higher or AndroidTM 4.1 or higher.
• An existing 2.4 GHz Wi-Fi network.
• An existing 3-Pin South African Plug Point, Type M.
CE Certification
This device complies with CE Radio Equipment Directive [RED] 2014/53/
EU & Restriction of Hazardous RoHS Directive 2011/65/EU. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.

16
Important Information
Before using the plug, please read and follow all instructions, including
the following.
CAUTION: Risk of electric shock or burns and use in a dry location only.
Do not install the device with wet hands or when standing on a wet or
damp surface. Suitable for use in an operating environment between
-20 ˚C and 40 ˚C (-4 ˚F and 104 ˚F). Make sure that the voltage of the plug
is compatible with the main electricity supply of your country before
connecting to a plug socket. Ensure the pins of the plug matches the plug
socket. The plug has no serviceable parts.

Cleaning & Care Instructions
• Before Cleaning: Ensure that your Connex Connect plug is not
plugged into any socket before cleaning or maintaining it.
• Cleaning: Wipe down the surface of your Connex Connect plug
using a soft, slightly damp cloth.
• Do not use any harsh or abrasive cleaning chemicals or materials on
your Connex Connect plug as doing so may damage or scratch the
surface nish.
• Do not expose your Connex Connect plug to high temperatures
for extended periods of time.
• Do not store in temperatures over 60 °C / 140 ˚F.
Environmentally Friendly Disposal
Do not dispose of electrical appliances as unsorted municipal
waste, use separate collection facilities. Contact your local
government for information regarding the collection systems
available. If electrical appliances are disposed of in landlls or
dumps, hazardous substances can leak into the groundwater and
get into the food chain, damaging your health and well-being.
17

Support
Please visit us at www.connexconnect.com for answers to common
issues and to see the full selection of products. If you still have any queries
contact us at [e-mail]
The illustrated product and specications may dier slightly from those
supplied. Connex is a trademark of SMD Technologies (Pty) Ltd. iPhone,
Apple and the Apple logo are trademarks of Apple Inc., registered in the
U.S. and other countries. App Store is a service mark of Apple Inc.
Android Google Assistant, Google Play, and the Google Play logo are
trademarks of Google Inc. Google is a trademark of Google LLC. iOS is a
registered trademark of Cisco in the U.S. and other countries and is used
under license.
Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc
or its aliates. All other trademarks and trade names are those of their
respective owners.
©2021 Connex Connect (Pty) Ltd
23 Nguni Drive, Long Meadow Business Estate West, Modderfontien,
Johannesburg, South Africa, 1609.
18

19
Warranty
This Connex Connect Smart Wi-Fi Switch includes a standard 12-month
limited warranty against manufacturing defects and faults. Should your
product be unboxed with any faulty parts, poor nishing or visible damage,
or fail to perform due to a manufacturing defect or poor workmanship,
please return it with your proof of purchase (till slip or invoice) to the store of
purchase for an exchange, or repair, depending on the store’s returns policy.
This warranty commences from the date of purchase. Kindly retain your
proof of purchase as well as the packaging for your warranty period.
NOTE: The Warranty does not apply to a Product that:
a) Has failed due to excessive wear and tear beyond what is
considered to be reasonable.
b) Has been misused or neglected.
c) Has been damaged accidentally or by Force Majeure including
re and ooding.
d) Has been used or operated contrary to operating or
maintenance instructions outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products that
have not been returned in accordance to this warranty or which does not
follow their own Returns Policy. Please refer to the Store of Purchase / Sellers
Returns Policy for details.
Should you require any further assistance or have any questions on your
warranty, please contact the store of purchase.
