Conspit CPP.LITE User manual

CONSPIT CPP.LITE
Quick Guide
Elite Sim-racing Development

Product Disclaimer
-1-
We hereby reminds you that：
If you have any questions about this Disclaimer or the following product safety tips and operating
specifications, you can consult through [e-mail]. In the process of reading this
Disclaimer and the following product safety tips and operating specifications, you should immediately
stop using this product if you do not agree with any of the contents. If you do use this product,
your behavior will be regarded as an acceptance of this Disclaimer and the following product
safety tips and operation specifications.
Before using this product, please ensure that you have carefully read and fully understood this
Product Disclaimer and all the following product safety tips and operation specifications. To the
extent permitted by the laws of the People's Republic of China,
Ensu (Shanghai) Electronic Technology Co., Ltd. is not responsible for all personal injury and/or
property damage caused by your failure to obey any of the following safety tips or operating
specifications.
It is essential to use this product under safe conditions:
Please ensure that the user has the ability to move independently and is conscious. Do not use
this product when sick, fatigued, or under the influence of alcohol/drugs.
Ensure proper installation of the product:
This product requires you to complete some installation work. Make sure that all parts of
the bracket are properly and securely installed. Please follow the steps and instructions
in the product manual during the installation process. Using the product without proper
installation may result in the following: partial fasteners coming loose and causing collision
injuries, parts detaching and causing injury to yourself or others.
Prevent excessive use of force.
During the design and production of this product, large structural strength and safety redundancy
have been considered to prevent parts from falling off. However, improper force application beyond
the normal use range may cause damage to the components, resulting in potential safety risks.

-2-
Situations that may pose hazards during normal use include, but are not limited to:
- Other people or pets coming close to the user's operating area.
- Electrical cables near the working area of pedals, steering wheels, and other moving parts.
- User's foot slipping off the pedal when applying force.
- Do not use this product without shoes
Follow all safety tips and operating procedures:
- Avoid using the product for an extended period - prolonged continuous use may cause fatigue,
muscle pain, or other negative effects. We recommend a maximum single-use time of 2 hours,
and the daily maximum recommended usage time should not exceed 6 hours.
- Prohibit independent use by children under 12 years old, this product is not designed for use
by children. Children should use this product under the supervision of their guardian.
Malfunctioning and damaged products:
- If the product is damaged or cannot be used properly, please stop using it immediately and consult
CONSPIT's after-sales customer service. Continuing to use it may cause further damage to the product.
- Do not attempt to repair the product or its accessories by yourself.
- CPP hydraulic brake system contains hydraulic oil. If user finds oil leakage, damage, etc.,
please contact customer service immediately. Unauthorized disposal of hydraulic oil
may cause injury (including swallowing, slipping and other injuries).
General preventive measures:
- Please store and protect the product and its accessories properly.
- Do not immerse the product in liquid.
- Do not use the product in any environment with flammable substances.
- Using the product in dusty or dirty locations may cause damage.
- Do not drop the product (or its components) or subject it to physical impact.

（A）
Base Mounting Plate
（B）
CPP.LITE 2
-Throttle and Brake Pedals
（C）
Stickers
（H）
Lubricating Grease
（I）
USB Cable
（J）
Power Adapter
（G）
Gloves
（K）
Adjustment Tool
(Hydraulic Preload)
（F）
Hex wrench 6.0
Hex wrench 5.0
Packing List
-3-
（D）
M8x12mm
Rounded head bolts
(6 pieces)
（E）
M8x16mm
Hex bolts
(4 pieces)
（B）
CPP.LITE 3
-Throttle, Brake and
Clutch Pedals

（A）
Base Mounting Plate
-4-
M8x12mm
rounded head bolts
(6 pieces)
M8x16mm
hex bolts
(4 pieces)
Hex wrench 6.0
Hex wrench 5.0
Accessories required for this step
Installation sequence
Install The CPP.LITE To The Base Mounting Plate
01
* Precautions during installation
The product contains small parts. Please avoid accidental swallowing.
It is forbidden to disassemble modular units such as hydraulic brake
system, clutch modules.
Avoid using excessive force to prevent screw damage and other potential risks.
（B）
Pedal Set
（1） Mount each pedal set to recommended position on the base mounting
plate (A).
* Please flip the base mounting plate first and connect all cables
(including USB cables) to the control board underneath before
installing the pedal to the rig.
or
CPP.LITE 3
throttle
CPP.LITE2
throttle
CPP.LITE3
brake
CPP.LIT2
brake
CPP.LITE3
clutch

-5-
（2） Thread all data and rumble motor cables through the lumbar hole on the
base mounting plate.
（3） Mount the pedal set to the base mounting plate.
The figure below takes the throttle pedal as an example
The brake and clutch pedals are installed in the same way
M8*12mm
Rounded head bolts

-6-
Connection Demonstration
Data Cable Connection
Data Cable
Connector
Rumble
Motor
Connector
（4） Flip the base mounting plate to the bottom side and connect all cables
shown as below.
* In order to ensure the stability of data transmission, the data cable must be ensured
no entanglement or crushing during assemble.

-7-
Rumble Motor Connection
Power and USB Connection
USB
connector
Power
connector
（5） Connect the power connector and USB connector to the control board
through the openings reserved for passing wire.

-8-
220
199
193.5
235
275.2
290
CPP.LITE Drilling Template
4×M6
4×M8
Install The Pedal Set To The Rig
02

（1） Mount CPP.LITE to the rig
M8*16mm hex bolts（4
pieces ）
-9-

-10-
（2） Mount CPP.LITE to Aluminum Profile-based Rig
M8*16mm hex bolts (4 pieces)
40 Series T-Slot Aluminum
Profile is recommended

CPP series provides versatile adjustable space, with throttle, brake, and clutch
supporting stepwise force adjustment as well as further fine-tuning without
limitations.
The angle adjustment range of the pad is 0° to 15°, with 0° being when the
plate is perpendicular to the pedal base.
*Angle recommendation:
-Formula posture: 0°~5°
-GT posture: 5°~15°
Pedal Pad Angle Adjustment
-11-
Fine Tune Your CPP.LITE
03

Different pedal force can be adjusted by changing the locking pin position.
The pedal force varies with the corresponding position. Pedal force increases
sequentially from bottom to top.
Throttle Pedal Feel Adjustment
Pedal Pads Height Adjustment
-12-
Max
Min

Brake Pedal Feel Adjustment
-13-
1. Turn the knob counter-
clockwise to completely
release the preload pressure 2. Press the brake pedal 1~2 times
3. Change the locking pin position 4. Turn the knob clockwise to
desired hydraulic preload
Pedal force and travel can be further fine-tuned by turning the knob.
By changing the locking pin position, the pedal force can be stepped change.

-14-
The four positions of the locking pin simulate different brake pedal feel of
various vehicles. When the hydraulic sensor reaches its maximum
capacity (100 bar), the corresponding pedal force on the pedal pad is shown
in the table below:
④ Sports Car
② GT Racing Car
③ Hyper Car
① Formula Racing Car
Formula Racing Car
GT Racing Car
Hyper Car
Sports Car
Type Pedal Force
800N
688N
556N
430N

The clutch travel and engagement point can be adjusted by turning the knob.
Clutch Pedal Feel Adjustment
-15-
Hydraulic Preload of the brake can be adjusted by turning the knob with the
adjustment tool.
* Do not increase the
Hydraulic Preload
(turning the knob
clockwise) excessively

(1) Visit www.conspit.com and download CONSPIT_LINK.
(2) Access the pedals settings page
(3) Calibration of the pedals
1
2
Driver Installation And Set-Up
04
-16-
2. Click "Min" to calibrate the
minimum value when the pedal
is completely released.
1. Select the
pedal to be
adjusted.
Time-Pedal Travel Curve Custom Mapping Curve
3. Click "Max" to calibrate
the maximum value when
the pedal is fully pressed.
