Contacta IL-PL20 Operation manual

Portable Loop
Installation &
User Guide
August 2019
IL-PL20

Contacta has a policy of continuous product development, therefore small specication changes may not be reected in this
manual. Images, labels, packaging, accessories and product colours are subject to change without notice.
Contents
Product Overview
Components
Status Light
Setting Up
Using the System
Additional Connections
Important Information
4
4
5
6
7
8
9

4
Product Overview
Our Portable Loop is a versatile solution, providing mobile desktop
assistance for your customers.
It can be moved between rooms as required and is used in small
rooms where conversation between two people takes place.
4
23
1. Hearing Loop Sticker
2. Portable Loop
3. Power Supply
4. Installation & User Guide
Please note: A Portable Loop Shelf is available as an accessory. It is an
ideal storage unit and charging location for the Portable Loop.
1
Components

5
Version 1
Status Light
• The status LED ashing GREEN indicates that the unit is in use and
audio is being transmitted.
• When the status LED is a steady RED, the unit is charging.
• If the unit is both in use and charging, the status LED will alternate
between GREEN and RED.
• When the status LED RED ashes red twice every 25 seconds,the
unit’s battery is running low.
• The status LED ashing GREEN indicates that the unit is in use and
audio is being transmitted.
• When the status LED is ashing RED, the unit is charging or
receiving long-term conditioning. This ashing is not a fault and
may continue for several hours.
• Two RED ashes every 25 seconds indicate that the unit’s battery
is running low.
Version 2 (2019)
There are two versions of the Portable Loop currently in circulation.
Each have dierent status light congurations, with diering
instructions beneath the status light:
