1 POA200-20
F&eIT Series AC Power Adaptor
POA200-20 User’s Guide
CONTEC CO.,LTD.
This product is AC-DC power adaptor to supply 5VDC power supply to the F&eIT series.
Dimensions
105±1
1500±50
+5V
GND
N.C.
40±1
30±1
1500±50 [mm]
Connector
MC1,5/3-ST-3,5 [made by Phoenix Contact Corp.]
Specifications
Item Specifications
Input voltage range 90 - 264VAC
Rating input current 0.3A (Max.)
Rating output voltage 5VDC±5%
Rating output current 2.0A (Max.)
Operating requirements 0 - 40°C, 20 - 80%RH (No condensation)
holding time 16ms (Typ.) (AC IN 100V, Io=100%)
16ms (Typ.) (AC IN 200V, Io=100%)
Service life It is three years (Io=100%) at the circumference temperature of 25°C
It is one year (Io=100%) at the circumference temperature of 40°C

POA200-20 User’s Guide
Copyright 2005 CONTEC CO., LTD. ALL RIGHTS RESERVED.
CONTEC CO., LTD. August 2009 Edition
3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan
Japanese http://www.contec.co.jp/
English http://www.contec.com/ A-51-070 (LYFC852)
Chinese http://www.contec.com.cn/ 08042009_rev2 [07152005]
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
Regarding CE EMC Instruction Class A Notice
The product may suit CE EMC Instruction Class A by installing the attached ferritic core.
Install in this vicinity of the product of the DC output side, and two turns (Roll it once).
Ferritic core installation chart
DC output side
A
C input side The attached ferritic core :
04SR200935A (mede by SEIWA)
