1 IPC-ACAP12-02, IPC-ACAP12-03, IPC-ACAP12-04
AC Adapter
IPC-ACAP12-02, IPC-ACAP12-03
IPC-ACAP12-04 User’s Guide
CONTEC CO.,LTD.
Thank you for purchasing this product.
This product is the AC adapter for input : 100-240VAC and output : +12VDC. This product can be used for the
CONTEC’s following models. (It is not possible to use it excluding the target model.)
- IPC-ACAP12-02
Flat Panel Display: FPD-x7x Series, IPC-DT/x2x(PC)T Series
- IPC-ACAP12-03
BOX Computer: IPC-BX950Tx-DCxxx
- IPC-ACAP12-04
BOX Computer: IPC-BX955D-DCxxx, BX-100n-DCxxxx-C01*1, BX-100n-DCxxxx-C02,
CX-100n-DCxxxx-C02
Panel Computer *2*3: PT-955LX-DCxxxx, PT-955LXF-DCxxxx,
PT-955HX-DCxxxx, PT-955HXF-DCxxxx
*1 The AC adaptor cannot be installed in the box computer main body.
*2 The AC adapter cannot be installed in the main body of flat panel display or panel computer.
*3 Some restrictions apply when using it with a panel computer. Be sure to refer to "Restrictions in using the AC
adapter with a panel computer" on page 2.
Package Contents
The product you have purchased consists of the following items. Be sure that you have them all. If you find any item
either missing or damaged, please contact the sales representative you purchased the product from.
IPC-ACAP12-02 IPC-ACAP12-03 IPC-ACAP12-04
Name Pcs. Pcs. Pcs.
AC adapter 1 1 1
AC power cable (100VAC, 2pin) 1 1 1
Fixed bracket 1 - 1 -
Fixed bracket 2 - - 1
AC adapter clamp (250mm) - 2 2
Cable clamp (120mm) - 3 3
Washer assembled screw(M3 x 10) - 2 2
User’s Guide (this document) 1 1 1
Warranty Certificate 1 1 1
Serial number label 1 1 1
* This AC power cable is for the voltage of the 100VAC or less.
In the case that the voltage that this cable uses do not match you need to prepare other cable particularly.
AC adapter AC power cable
(100VAC, 2pin)
Fixed bracket 1
Fixed
bracket 2
Cable
clamp
(120mm)
AC adapter
clamp
(250mm)
User's Guide
Washer assembled
screw(M3x10)
Warranty
Certificate
Serial
number
label

IPC-ACAP12-02, IPC-ACAP12-03, IPC-ACAP12-04 User’s Guide
IPC-ACAP12-02, IPC-ACAP12-03, IPC-ACAP12-04 2
External Dimensions and Component Identification
Using method
- Make sure that the AC power cable is not plugged into a wall outlet.
- Connect the AC power cable to the main body of AC adaptor connector (CN1).
- Connect the DC cable of AC adapter to the AC adapter jack of device. For more details on the
position of AC adapter jack, refer to the manual for the device to which you will connect.
When using the IPC-ACAP12-03 or IPC-ACAP12-04, connect it to the target device.
- Plug the AC power cable into a wall outlet.
* This product has no power switch. When turning off, unplug the AC power cable from the wall
outlet.
Restrictions in using the AC adapter with a panel computer
This AC adapter can be used as a power supply for panel computers PT-955LX-DCxxxx,
PT-955LXF-DCxxxx, PT-955HX-DCxxxx and PT-955HXF-DCxxxx. However, some restrictions
mentioned below apply.
- The current consumption of USB + 5VDC should be 1.0A or less for four ports in total.
Installation Procedure of AC adapter
When installing the AC adapter on the box computer, refer to the following diagram.
CAUTION
- BX-100n-DCxxxx-C01, PT-955LX-DCxxxx, PT-955LXF-DCxxxx, PT-955HX-DCxxxx and
PT-955HXF-DCxxxx cannot install the AC adaptor in the main body.

IPC-ACAP12-02, IPC-ACAP12-03, IPC-ACAP12-04 User’s Guide
3 IPC-ACAP12-02, IPC-ACAP12-03, IPC-ACAP12-04
Specifications
Requirement Description
Power supply space
Rated input voltage 100VAC to 240VAC (continuous input), 50/60Hz
Permissible input voltage 90VAC to 264VAC (continuous input), 50/60Hz
Input current 1.3A Max. (AC IN 100V)
Rated output voltage +12VDC ±5%
Rated output current 4A (Max.)
Permissible momentary blackout 5ms or less
Dielectric strength (between Input P and S) 3.0kVAC for one minute
Insulation resistance (between P and S) Greater than 50MΩ(500VDC)
Environmental specs
Temperature Operating : 0 to 40 °C, non operating : - 25 to + 65 °C
Operating : 10 - 85%RH (No condensation)
Humidity
Non operating : 10 - 95%RH (No condensation)
Floating dust particles Not to be excessive
Corrosive gases None
Operating : 5 - 500Hz(Random) / 0.27G
Line-Noise resistance
Non operating : 2 - 200Hz(Sweep) / 1G
Construction
Length of cable AC Power cable : 1.5m, DC cable : 2m
External dimensions (mm) 72(W) x 120(D) x 27(H) (not include projection of cable)
Weight Main body : 400g, AC power cable : 200g
MTBF 100,000H or more
13,000H (temperature 25 °C 100% at the load)
Longevity (*1) 4,700H (temperature 40 °C 100% at the load)
*1 This product are designed to use under the good condition. When doing it under the severe condition and requiring the longer life
expectancy, purchase the optional power supply according to your needs.
Disposal
When disposing of the product, follow the disposal procedures stipulated under the relevant laws and
municipal ordinances.
Storage
When storing this product, keep it in its original packing form.
- Wrap it in the packing material, and then put it in the box.
- Store the package at room temperature at a place free from direct sunlight, moisture, shock,
vibration, magnetism, and static electricity.

IPC-ACAP12-02, IPC-ACAP12-03, IPC-ACAP12-04 User’s Guide
Copyright 2008 CONTEC CO., LTD. ALL RIGHTS RESERVED.
CONTEC CO.,LTD. February 2013 Edition
3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan
Japanese http://www.contec.co.jp/
English http://www.contec.com/ A-51-617 (LYJV415)
Chinese http://www.contec.com.cn/ 02152013_rev5 [08222008]
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
Handling Precautions
WARNING
Indicates dos and don'ts that are assumed to result in possible
death or serious injury if they are inappropriately handled
ignoring this icon.
- Do not use the product in locations exposed to a flammable
or corrosive gas. It may cause explosion, fire, electrical
shock, or malfunction.
- If you sense abnormality (smoke, odor, or noise),
immediately unplug the power cord from the wall outlet and
contact the CONTEC sales representative or sales office.
- To avoid electrocution do not use the product with a wet
hand.
- Be sure to connect the product to the stipulated power
supply voltage. Connecting to a different voltage might
cause a fire or electrical shock.
- Do not use the product with the other power device. It
may cause fire or malfunction.
- When the cable or main body is damaged, stop using and
repair it immediately. Using it as it is may cause fire,
electrical shock or malfunction.
- Never disassemble or modify the product or replace its parts
in order to prevent electrical shock, fire, or malfunction.
CONTEC reserves the right to refuse servicing the product
modified by the user. When any part of the product needs to
be replaced at the expiration of its life or due to breakdown,
please contact the CONTEC sales representative or sales
office.
- Use the product with the specified models by the CONTEC.
Not doing so may cause fire or malfunction.
- Use the product in the specified operating condition
(temperature and humidity)
- Please make sure to observe the restrictions in
using it with a panel computer.
CAUTION
Indicates dos and don'ts that are assumed to result in possible
injury or property damage if they are inappropriately handled
ignoring this icon.
- Do not use or store the product in a location exposed to
extremely high or low temperature or susceptible to a rapid
temperature change. Example:
- Exposure to direct sun - In the vicinity of
a heat source
- When unplugging the cable, hold the plug. Holding and
pulling the cable itself can cause a failure such as
discontinuity.
- To clean the product wipe it gently with soft cloth damp
with either water or mild detergent.
Do not use chemicals or a volatile solvent, such as benzene
and thinner, to prevent peeling or discoloration of the paint.
- When transporting the product, provide adequate measures
to protect it from vibration or shock.
- No part of this document may be copied or reproduced in
any form by any means without prior written consent of
CONTEC CO., LTD.
- The information in this document is subject to change
without notice.
- All relevant issues have been considered in the preparation
of this document. Should you notice an omission or any
questionable item in this document, please feel free to
notify CONTEC CO., LTD.
- Regardless of the foregoing statement, CONTEC assumes
no responsibility for any errors that may appear in this
document or for results obtained by the user as a result of
using this product.
