Contec PCA68PS-0.5P User manual

1PCA68PS-0.5P, PCA68PS-1.5P
Shielded Cable with One 68-pin Connector
PCA68PS-0.5P, PCA68PS-1.5P
User’s Guide
CONTEC CO.,LTD.
The PCA68PS-0.5P and PCA68PS-1.5P are cables for connecting a 68-pin connector on CONTEC board
with other devices.
External Dimensions
Specifications
Item Specification
Connector used
68-pin 0.8mm-pitch connector HDRA-E68MA1 [HONDA] or equivalent
Thumb screw: M2
Cable
68 core shield cable (34pair). Conductor size: AWG#30
Conductor composition: 7pcs/0.1mm UL20276
Round terminal V1.25-3[JST] or equivalent
Specification of
wire Terminals
It lamination-processes in 1.27mm pitch.
Weight 120g(PCA68PS-0.5P), 220g(PCA68PS-1.5P)
Line core color Line core color depends on the product revision. Please refer to the next page.
Notes!
- Do not strike or bend the product. Otherwise, the product may malfunction, overheat, cause a failure or breakage.
- Do not insert or remove the connector while the power is turned on to the PC. Failure to observe this precaution
may cause malfunction, overheating.
- Insert or remove the cable straightly. Otherwise, the part of connector may distort, cause a failure or breakage.
- The specifications of this product are subject to change without notice for quality improvement.
Even when using the product continuously, be sure to read the manual and understand the contents.
- Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may appear in this
document or for any results of using the product.
- All relevant issues have been considered in the preparation of this document. Should you notice an omission or
any questionable item in this document, please feel free to notify CONTEC CO., LTD.
1
2
67
68
135
68
34
9mm
42.7mm
15mm
8mm
33.69mm
PCA68PS-0.5P500mm
PCA68PS-1.5P1,500mm
150mm
Laminate Side

PCA68PS-0.5P, PCA68PS-1.5P User’s Guide
Copyright 2004 CONTEC CO., LTD. ALL RIGHTS RESERVED.
CONTEC CO., LTD.May 2019 Edition
3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan
https://www.contec.com/
A-46-922 (LYEC013)
05172019_rev3 [07232004]
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
Connection Diagram
Line core color depends on the product revision.
Revision No., please refer to the label of the connector.
Connector
Pin No.
Wire
No.
Revision No. Rxx
line core color
(marking No./color)
Shell Round Terminal
Shield
1
35
2
36
3
37
4
38
10
44
9
43
8
42
7
41
6
40
5
39
11
45
12
46
13
47
14
48
17
51
16
50
15
49
1
35
2
36
3
37
4
38
10
44
9
43
8
42
7
41
6
40
5
39
11
45
12
46
13
47
14
48
17
51
16
50
15
49
18
52
19
53
20
54
21
55
27
61
26
60
25
59
24
58
23
57
22
56
28
62
29
63
30
64
31
65
34
68
33
67
32
66
18
52
19
53
20
54
21
55
27
61
26
60
25
59
24
58
23
57
22
56
28
62
29
63
30
64
31
65
34
68
33
67
32
66
Orange (1Red)
Orange (1Black)
Gray (1Red)
Gray (1Black)
White (1Red)
White (1Black)
Yellow (1Red)
Yellow (1Black)
Pink (2Red)
Pink (2Black)
Yellow (2Red)
Yellow (2Black)
White (2Red)
White (2Black)
Gray (2Red)
Gray (2Black)
Orange (2Red)
Orange (2Black)
Pink (1Red)
Pink (1Black)
Orange (3Red)
Orange (3Black)
Gray (3Red)
Gray (3Black)
White (3Red)
White (3Black)
Yellow (3Red)
Yellow (3Black)
Gray (4Red)
Gray (4Black)
Orange (4Black)
Pink (3Red)
Pink (3Black)
Orange (4Red)
White (5Red)
White (5Black)
Gray (5Red)
Gray (5Black)
Orange (5Red)
Orange (5Black)
Pink (4Red)
Pink (4Black)
Yellow (4Red)
Yellow (4Black)
White (4Red)
White (4Black)
Yellow (5Red)
Yellow (5Black)
Pink (5Red)
Pink (5Black)
Orange (6Red)
Orange (6Black)
Gray (6Red)
Gray (6Black)
White (7Red)
White (7Black)
Gray (7Red)
Gray (7Black)
Orange (7Red)
Orange (7Black)
Pink (6Red)
Pink (6Black)
Yellow (6Red)
Yellow (6Black)
White (6Red)
White (6Black)
Yellow (7Red)
Yellow (7Black)
< Revision No. N/A >
< line core color
(marking No./color) >
<Orange (1Red)>
<Orange (1Black)>
<Gray (1Red)>
<Gray (1Black)>
<White (1Red)>
<White (1Black)>
<Yellow (1Red)>
<Yellow (1Black)>
<Pink (2Red)>
<Pink (2Black)>
<Yellow (2Red)>
<Yellow (2Black)>
<White (2Red)>
<White (2Black)>
<Gray (2Red)>
<Gray (2Black)>
<Orange (2Red)>
<Orange (2Black)>
<Pink (1Red)>
<Pink (1Black)>
<Orange (3Red)>
<Orange (3Black)>
<Gray (3Red)>
<Gray (3Black)>
<White (3Red)>
<White (3Black)>
<Yellow (3Red)>
<Yellow (3Black)>
<Gray (4Red)>
<Gray (4Black)>
<Orange (4Black)>
<Pink (3Red)>
<Pink (3Black)>
<Orange (4Red)>
<White (5Red)>
<White (5Black)>
<Gray (5Red)>
<Gray (5Black)>
<Orange (5Red)>
<Orange (5Black)>
<Pink (4Red)>
<Pink (4Black)>
<Yellow (4Red)>
<Yellow (4Black)>
<White (4Red)>
<White (4Black)>
<Yellow (5Red)>
<Yellow (5Black)>
<Pink (5Red)>
<Pink (5Black)>
<Brown (1Black)>
<Brown (1White)>
<Red (1Black)>
<Red (1White)>
<Green (2Black)>
<Green (2White)>
<Blue (2Black)>
<Blue (2White)>
<Red (2Black)>
<Red (2White)>
<Brown (2Black)>
<Brown (2White)>
<Green (1Black)>
<Green (1White)>
<Blue (1Black)>
<Blue (1White)>
<Brown (3Black)>
<Brown (3White)>
Connector
Pin No.
Wire
No.
Revision No. Rxx
line core color
(marking No./color)
< Revision No. N/A >
< line core color
(marking No./color) >
1
2
3
4
5
signs
No
Revision No. N/A:
The marking No. shows
the below signs.
1
2
3
4
5
6
7
signs
No
Revision No. R2, R3:
The marking No. shows
the below signs.
Rxx - xx indicates the revision
number
R2
Revision No.
