Contec PCA68PS-0.5P User manual

1PCA68PS-0.5P, PCA68PS-1.5P
Shield Cable with One 68-Pin Connector
PCA68PS-0.5P, PCA68PS-1.5P
User’s Guide
CONTEC CO.,LTD.
The PCA68PS-0.5Pand PCA68PS-1.5P are cables for connecting a 68-pin 0.8mm-pitch connector on
CONTEC PC Card with other devices.
External Dimensions LaminateSide
150mm
1
35
2
36
33
67
34
68
8mm
68
35
1
34
39.7mm11.7mm
43.3mm
PCA68PS-0.5P500mm
PCA68PS-1.5P1,500mm
Specifications
Item Specification
Connector used
68-pin 0.8mm-pitch connector HDRA-E68MA1 [HONDA] or equivalent
Thumb screw: M2
Cable 68 core shield cable(34pair). Conductor size: AWG#30
Conductor composition: 7pcs/0.1mm UL20276
Round terminal V1.25-3 [JST] or equivalent
Specification of
wire Terminals It lamination-processes in 1.27mm pitch.
Weight 120g(PCA68PS-0.5P), 220g(PCA68PS-1.5P)
Notes!
-Do not strike or bend the product. Otherwise, the product may malfunction, overheat, cause a
failure or breakage.
-Do not insert or remove the connector while the power is turned on to the PC. Failure to observe
this precaution may cause malfunction, overheating.
-The specifications of this product are subject to change without notice for quality improvement.
Even when using the product continuously, be sure to read the manual and understand the contents.
-Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for any results of using the product.
-All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD

PCA68PS-0.5P, PCA68PS-1.5P User’s Guide
Copyright 2004CONTEC CO., LTD. ALL RIGHTS RESERVED.
CONTEC CO., LTD.July 2004Edition
3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan
Japanese http://www.contec.co.jp/
English http://www.contec.com/ A-46-922 (LYEC011)
Chinese http://www.contec.com.cn/ [07232004]
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
Connection Diagram
Connector
PinNo.Wire No.
Colorandsign
inlinecoreConnector PinNo.Wire No.
Colorandsign
inlinecore
Thecolorandthesigninthelinecoreshows
[colorinthelinecore]+
[TheabovefigureofthesignsNo.],
[colorofthemark].
Shell Roundterminal
Shield
1:
2:
3:
4:
5:
1
35
2
36
3
37
4
38
10
44
9
43
8
42
7
41
6
40
5
39
11
45
12
46
13
47
14
48
17
51
16
50
15
49
1
35
2
36
3
37
4
38
10
44
9
43
8
42
7
41
6
40
5
39
11
45
12
46
13
47
14
48
17
51
16
50
15
49
18
52
19
53
20
54
21
55
27
61
26
60
25
59
24
58
23
57
22
56
28
62
29
63
30
64
31
65
34
68
33
67
32
66
18
52
19
53
20
54
21
55
27
61
26
60
25
59
24
58
23
57
22
56
28
62
29
63
30
64
31
65
34
68
33
67
32
66
Orange+1red
Orange+1Black
Gray+1red
Gray+1Black
White+1red
White+1Black
Yellow+1red
Yellow+1Black
Pink+2red
Pink+2Black
Yellow+2red
Yellow+2Black
White+2red
White+2Black
Gray+2red
Gray+2Black
Orange+2red
Orange+2Black
Pink+1red
Pink+1Black
Orange+3red
Orange+3Black
Gray+3red
Gray+3Black
White+3red
White+3Black
Yellow+3red
Yellow+3Black
Gray+4red
Gray+4Black
Orange+4Black
Pink+3red
Pink+3Black
Orange+4red
White+5red
White+5Black
Gray+5red
Gray+5Black
Orange+5red
Orange+5Black
Pink+4red
Pink+4Black
Yellow+4red
Yellow+4Black
White+4red
White+4Black
Yellow+5red
Yellow+5Black
Pink+5red
Pink+5Black
Brown+1black
Brown+1White
Red+1black
Red+1White
Green+2black
Green+2White
Blue+2black
Blue+2White
Red+2black
Red+2White
Brown+2black
Brown+2White
Green+1black
Green+1White
Blue+1black
Blue+1White
Brown+3black
Brown+3White
