Contec PC-686CPCI-LV User manual

PC-686(CPCI)-LV
CompactPCI Single Board Computer
For socket 370 CPU (Celeron™, Pentium III™)
With LAN/VGA
User’s Manual

Copyright
Copyright 2001 CONTEC Co., Ltd. All RightsReserved. No part of
this document may be copied or reproduced in any form by any means
without prior written consent of CONTEC Co., Ltd.
CONTEC Co., Ltd. makes no commitment to update or keep current the
information contained in this document. The information in this
document is subject to change without notice.
All relevant issues have been considered in the preparation of this
document. Should you notice an omission or any questionable item in this
document, please feel free to notify CONTEC Co., Ltd.
Regardless of the foregoing statement, CONTEC assumes no responsibility
for any errors that may appear in this document nor for results obtained by
the user as a result of using this product.
Acknowledgments
IBM/AT and PS/2 are trademarks of International Business Machines
Corporation.
Award is a registered trademark of Award Software International, Inc.
Intel®,Celeron™and Pentium III™are registered trademarks of Intel
Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
All Other product names or trademarks are properties of their respective
owners.
Liability
The obligation of the warrantor is solely to repair or replace the product.
In no event will the warrantor be liable for any incidental or consequential
damages due to such defect or consequences that arise from inexperienced
usage, misuse, or malfunction of this device.

Limited One Year Warranty
CONTEC Industrial CPU board is warranted by CONTEC Co., Ltd. to be
free from defects in material and workmanship for up to one year from the
date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight
prepaid with a copy of the original invoice and a Return Merchandise
Authorization to the distributor or the CONTEC group office from which it
was purchased.
This warranty is not applicable for scratches or normal wear, but only for
the electronic circuitry and original boards. The warranty is not
applicable if the device has been tampered with or damaged through abuse,
mistreatment, neglect, or unreasonable use, or if the original invoice is not
included, in which case repairs will be considered beyond the warranty
policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of
the original invoice. Please obtain a Return Merchandise Authorization
Number (RMA) from our Sales Administration Department before
returning any product.
*No product will be accepted by CONTEC group without an RMA
number.
Caution about Battery
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.

Table of Contents
PC-686 (CPCI)-LV User’s Manual i
Table of Contents
CHAPTER 1INTRODUCTION......................................................................... 1
1.1 Specification.......................................................................................... 1
1.2 Mechanical & Environmental ............................................................... 2
1.3 Check List ............................................................................................. 3
1.4 Description............................................................................................ 4
1.5 Power Management Features................................................................ 7
1.6 Power Requirements.............................................................................. 9
1.7 Connector & Jumper Location ............................................................ 10
1.8 Block Diagram .................................................................................... 11
CHAPTER 2HARDWARE INSTALLATIONS..................................................... 13
2.1 Installation procedure ......................................................................... 13
2.2 CPU Installation: ................................................................................ 14
2.3 Main Memory Installation: DIMM1, DIMM2, DIMM3....................... 15
2.4 RJ-45 LAN connector: CN1................................................................. 20
2.5 Serial Port connector: CN2.................................................................. 21
2.6 Parallel Port Connector: CN3.............................................................. 23
2.7 PS/2 Mouse & Keyboard stack Connector: CN4 .................................. 24
2.8 USB Connector: CN5 .......................................................................... 24
2.9 VGA Connector: CN6.......................................................................... 26
2.10 LCD Connector: CN7.......................................................................... 27
2.11 CPU FAN Connector: CN8 ................................................................. 28
2.12 Floppy Disk Connector: CN9............................................................... 29
2.13 External Battery Connector: CN10...................................................... 30
2.14 Primary IDE port Connector: CN11.................................................... 30
2.15 CompactPCI connector P2: CN12 ....................................................... 32
2.16 CompactPCI connector P1: CN13 ....................................................... 33

Table of Contents
ii PC-686 (CPCI)-LV User’s Manual
2.17 CompactPCI connector P3: CN14........................................................34
2.18 Reset button: S1 ...................................................................................34
2.19 LED Indicator......................................................................................34
CHAPTER 3 JUMPER SETTING ...................................................................35
3.1 Infrared (IrDA) port: JP1.....................................................................35
3.2 Watchdog Timer output selector: JP2...................................................35
3.3 CN16 RS-232C/RS-422/RS-485 Selector: JP3/JP5...............................36
3.4 RS-422/RS-485 Terminator: JP4..........................................................39
3.5 On board LAN selector: JP6.................................................................39
3.6 DISK ON CHIP Memory Add. Selector: JP7........................................40
3.7 Display Type Setting: JP8.....................................................................40
3.8 CPU frequency ration setting: JP9 .......................................................40
3.9 Clear CMOS Content: JP10 .................................................................41
3.10 External/Internal battery selector: JP11...............................................41
CHAPTER 4CPU BOARD RESOURCES .......................................................43
4.1. I/O MAP...............................................................................................43
4.2. MEMORY MAP...................................................................................44
4.3. DMA Channels.....................................................................................45
4.4. PCI Configuration Space Map .............................................................45
4.5. Interrupters..........................................................................................46
4.6. PCI Interrupters Routing Map .............................................................47
CHAPTER 5SOFTWARE UTILITIES ..............................................................49
5.1. Intel®440BX chipset Driver..................................................................49
5.2. Graphic Driver .....................................................................................50
5.3. LAN Driver ..........................................................................................53
5.4. Watchdog-Timer (WDT) Setting...........................................................54
5.5. Update new version BIOS.....................................................................55

Table of Contents
PC-686 (CPCI)-LV User’s Manual iii
5.6. Hardware Monitor............................................................................... 56
CHAPTER 6BIOS SETUP......................................................................... 65
6.1. Introduction ........................................................................................ 65
6.2. Main Menu.......................................................................................... 68
6.3. Standard CMOS Setup......................................................................... 70
6.4. BIOS Features Setup........................................................................... 72
6.5. Chipset Features Setup........................................................................ 76
6.6. Power Management Setup................................................................... 80
6.7. PnP/PCI Configuration....................................................................... 85
6.8. Defaults Menu..................................................................................... 88
6.9. Integrated Peripherals......................................................................... 89
6.10. Supervisor/User Password Setting .................................................... 92
6.11. Exit Selecting................................................................................... 93
6.12. POST Messages................................................................................ 94
6.13. POST Beep....................................................................................... 94
6.14. Error Messages ................................................................................ 95
6.15. POST Codes....................................................................................101

Table of Contents
iv PC-686 (CPCI)-LV User’s Manual

CHAPTER 1 –Introduction
PC-686 (CPCI)-LV User’s Manual 1
Chapter 1 Introduction
1.1 Specification
-Processor Socket: Socket 370
-Processor: Intel®Celeron™300MHz –566MHz; Pentium III™
(FSB:100MHz) 500MHz –700MHz
-Host Bus: CompactPCI Bus
for PICMG2.0 R2.1 Bus Master is supported till 4 Max.
-Chipset: Intel®440BX
-Cache Size: 128KB L2 cache is integrated in the Celeron™CPU
256KB L2 cache is integrated in the Pentium III™CPU
-Memory: Up to 768MB SDRAM
-Memory Sockets: Three 168-pin DIMM sockets for SDRAM in 8MB,
16MB, 32MB, 64MB, 128MB and 256MB configurations.
-BIOS: Award BIOS, PnP support
Flash EEPROM (256KB) for BIOS update
Power management
Frequency / Voltage control
-Bus Speed: 66MHz/100MHz
-Super I/O: Winbond W83977TF chipset
-Parallel port: One high-speed parallel port, SPP/EPP/ECP mode
-Series Port: Two 16550 UART port, COM2 is RS-232C/RS-422/RS-485
configurable
-Enhanced IDE: One EIDE port, up to 2 IDE devices, support Ultra
DMA 33
-FDD Interface: Two floppy drives (360KB, 720KB, 1.2MB, 1.44MB,
2.88MB, LS-120)
-USB Interface: One stack connector support 2 USB ports
-Watchdog Timer: Software programmable 16 levels, Reset or NMI
(Jumper selectable)

CHAPTER 1 –Introduction
2PC-686 (CPCI)-LV User’s Manual
-Hardware Monitor: Winbond W83781D
-IrDA: One 1x6 Pin-header
-Keyboard connector: PS/2 keyboard connector
-Mouse connector: PS/2 Mouse connector
-VGA Connector: C&T 69000 Controller, 15 pin D-type VGA
Connector
-LCD: C&T 69000 Controller, 41pin VESA Connector (for OEM)
-LAN: Intel 82559 LAN controller, RJ-45 connector
-SSD: DIP socket supports DiskOnChip flash disks (2MB~144MB)
-RTC: battery backup by Lithium Battery (CR2032)
The coin type Lithium battery specification is shown in table
Specification CR2032
Nominal Voltage 3V
Nominal Capacity 220mAh
Nominal Weight 3.1g
1.2 Mechanical & Environmental
-POWER CONSUMPTION
(Pentium III 700MHz)
+5VDC @6.50A Max.
+12VDC @250mA Max.
+3.3VDC @4.00A Max.
(Celeron 566MHz)
+5VDC @4.50A Max.
+12VDC @250mA Max.
+3.3VDC @3.50A Max.
-OPTERATING TEMPERATURE: 0 ~ 60ºC.
-STORAGE TEMPPERATURE: - 40 ~ 80ºC.
-HUMIDITY: 10% to 90%

CHAPTER 1 –Introduction
PC-686 (CPCI)-LV User’s Manual 3
-BOARD DIMENSION: 160mm(L) x233.35mm(H) / 6.23inch x
9.19inch.
-BOARD WEIGHT: 500g
1.3 Check List
Please check that your package is complete and contains the items below. If
you discover damaged or missing items, please contact your dealer.
-The PC-686(CPCI) Industrial CPU Board
-This User’s Manual & Registration Card
-1 IDE 40pin Ribbon Cable
-1 Floppy Ribbon Cable
-Driver disks utilities(floppy)
-Jumper Short Pin:6pcs.
-1 5pin DIN to 6pin mini-DIN Cable
-LCD exchange Display Board (for OEM)
-Memory (optional)
168PIN DIMM PC100 SDRAM 32MB “PC-MSD32-100”
168PIN DIMM PC100 SDRAM 64MB “PC-MSD64-100”
168PIN DIMM PC100 SDRAM 128MB “PC-MSD128-100”
168PIN DIMM PC100 SDRAM 256MB “PC-MSD256-100”
168PIN DIMM PC100 SDRAM 64MB with ECC
“PC-MSD64E-100”
168PIN DIMM PC100 SDRAM 128MB with ECC
“PC-MSD128E-100”
168PIN DIMM PC100 SDRAM 256MB with ECC
“PC-MSD256E-100”

CHAPTER 1 –Introduction
4PC-686 (CPCI)-LV User’s Manual
1.4 Description
The PC-686(CPCI) is a CompactPCI standard Industrial CPU board based
on Intel’s 440BX chipset and is fully designed for harsh industrial environment. It
features socket 370 compatible with Intel’s processor. This board accommodates
up to 768MB of SDRAM memory.
The PC-686(CPCI) comes with onboard CPU temperature sensor to protect
your processor from overheating (Winbond W83977HF chipset). Wired for
Management (WFM) 2.0 specification compliance.
The PC-686(CPCI) has a LAN I/F that uses Intel 82559 PCI LAN
controller.
The PC-686(CPCI) has a LCD Graphics that uses Chips 69000 graphic
accelerator. The Chips 69000 features are show as following:
Integrated SDRAM Memory
-2MB integrated memory
-83 MHz SDRAM operation
Low Power Consumption
-650mw
HiQColor™Technology
The 69000 uses CHIPS proprietary TMED™algorithm STN displays to
produce:
-256 Gray Shades
-16.7M Colors
-Reduced motion artifacts
-Brighter cris per display.

CHAPTER 1 –Introduction
PC-686 (CPCI)-LV User’s Manual 5
Graphics Acceleration
-64-bit Single Cycle BitBLT engine
-System/Screen-Screen BitBLT
-256 3-op Raster Operations
-Color Expansion
-Instant Full Screen Page Flip
Simultaneous Hardware Cursor and Pop-up Window
-64x64 pixels by 4 colors
-128x128 pixels by 2 colors
Standards Supported
-Fully IBM® VGA Compatible
-ACPI
-VESA DPMS and DDC 1/2
Flexible Panel Support
-TFT, DSTN
-Color and Monochrome
-VGA, SVGA, XGA
-Auto Panel Power On/Off Sequencing
Multimedia video Acceleration
-Zoomed Video Port
-YUV/RGB data capture from video port or host bus
-Color Space Conversion (YUV-RGB)
-Horizontal and vertical interpolation
-Double Buffering
-Hardware Interrupt Support for VPE
-Color Key for Video Overlay
-Interlace/FRAME/Bob video capture

CHAPTER 1 –Introduction
6PC-686 (CPCI)-LV User’s Manual
Integrated Clock Synthesizers
-135 MHz RAMDAC
-83 MHz Memory Clock with PLL
Advanced On-chip Power Management
-Standby mode
-Panel-off power saving mode
-Zero volt suspend
-Eight GPIO pins
-Activity Detection Output Pin
C&T 69000 Graphic Accelerator Refresh Rates
Resolution Color 60(Hz) 75(Hz) 85(Hz)
8bbp O O O
16bbp O O O
640x480
24bbp O O O
8bbp O O O
16bbp O O O
800x600
24bbp O O O
8bbp O O O 1024x768 16bbp O O O
1280x1024 8bbp O O ---

CHAPTER 1 –Introduction
PC-686 (CPCI)-LV User’s Manual 7
1.5 Power Management Features
1.5.1. Overview
The PIIX4 power management function provides a wide range of
capabilities and configuration options allowing a system designer to implement a
wide range of power saving modes.
PIIX4 provides for four main areas of power management:
-Clock Control and Processor Complex Management
-Peripheral Device Management
-System Management (SMI Generation, System Management Bus)
-System Suspend and Resume
Brief descriptions of primary power management function follow.
Clock Control: When the operating system, application program, or system software
is not performing useful work, the processor complex (Processor, Host Bridge, DRAM,
L2 cache) does not need to be executing cycles and, therefore, can be placed in Standby
mode.
Peripheral Device Management: Peripheral device resources are monitored to
detect when a specific device is idle. PIIX4 then informs system power management
software, which can place that individual device into a power managed condition (such
as Local Standby or Powered Off). Accesses targeting that device are then monitored.
System Suspend: Once the power management software has determined that the
system is fully idle or that a critical system event has occurred, it can place the system
into a suspend state, which allows for increased power savings. The software
configured PIIX4 for the typesof suspend, types of resume or wake-up events, and the
PIIX4 automatically transitions the system into suspend. When an enabled resume
event is detected, PIIX4 automatically restores the system operation.
-Three suspend states

CHAPTER 1 –Introduction
8PC-686 (CPCI)-LV User’s Manual
-Power-on-Suspend (POS) with three system reset options
-Suspend-to-RAM (STR)
-Suspend-to-Disk (STD) or Soft OFF (SOff)
-Global Standby Timer (also active during suspend) to monitor for overall system
idleness and as a resume timer
-Power Button Input
-Override feature forcing immediate transition to Soft Off
-Battery Low indication pin
-Shadow registers for standard AT write only registers to save and restore system
state information
-“Resume Well”to monitor wake-up events during suspend
-Resume power and reset sequencing

CHAPTER 1 –Introduction
PC-686 (CPCI)-LV User’s Manual 9
1.6 Power Requirements
Your system requires a clean, steady power source for reliable performance
of the high frequency CPU on the PC-686(CPCI) Industrial CPU board, the quality
of the power supply is even more important. For the best performance make sure
your power supply provides a range of the following table DC power source.
1.6.1. Power Consumption
For typical configurations, the CPU board is designed to operate with at
least a 200W power supply. A higher-wattage power supply should be used for
heavily-loaded configurations. The power supply must meet the following
requirements:
ŸRise time for power supply: 2ms to 20ms
ŸMinimum delay for reset to Power Good: 100ms
ŸMinimum Powerdown warning: 1ms
Ÿ3.3V output must reach its minimum regulation level within 20ms of the +5V
output reaching its minimum regulation level
The following table lists the power supply’s tolerances for DC voltages:
DC Voltage Acceptable Tolerance
+3.3 V ± 4%
+5 V ±5%
+12 V ±5%

CHAPTER 1 –Introduction
10 PC-686 (CPCI)-LV User’s Manual
1.7 Connector & Jumper Location

CHAPTER 1 –Introduction
PC-686 (CPCI)-LV User’s Manual 11
1.8 Block Diagram
LAN
DIMM X 3
KB / MS
COM #1, #2
443BX
PIIX4E
FDD
USB #1, #2
BIOS
LPT
TERMINATOR
GTL
SOCKET 370
VRM
SUPER I/O
VGA
MONITOR
CLK GEN.
IDE#1, #2
COMPACT PCI CONNECTOR
H/W
(W83977TF)
(82559ER) (69000)(82371EB)
GTL+ BUS
PCI BUS
ISA BUS

CHAPTER 1 –Introduction
12 PC-686 (CPCI)-LV User’s Manual
