Contec SCP-8550-LLV User manual

SBC Series
Single Board Computer 6U
CompactPCI with LAN*2, Video
SCP-8550-LLV
User’s Manual
CONTEC CO.,LTD.

SCP-8550-LLV i
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that your package is complete. If you discover damaged or missing
items, contact your retailer.
Product Configuration List
-CPUboard
[SCP-8550-LLV] …1
- Product guide …1
- IPC Precaution List …1
- Driver disk utility *1 (CD-ROM) ...1
- Jumper short pin (2mm) …2
- Fixed bracket for on-board HDD …1
- HDD fixed screws (M3 x 4) …4
*1 The CD-ROM contains the driver software and User’s Manual (this Manual)
CD-ROM
(Driver disks utilities) Fixed bracket
for on-board HDD HDD fixed screws
M3 x 4
Jumper short pin
(2mm)
x 2
IPC Precaution List Product Guide
IPC Precaution
List Product
Guide
CPU board
[SCP-8550-LLV]

ii SCP-8550-LLV
Copyright
Copyright 2005 CONTEC CO., LTD. ALL RIGHTS RESERVED.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document. The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for results obtained by the user as a result of using this product.
Trademarks
Intel, Celeron and Pentium are registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
All Other product names or trademarks are properties of their respective owners.

SCP-8550-LLV iii
Table of Contents
Check Your Package ................................................................................................................................i
Copyright .................................................................................................................................................ii
Trademarks ..............................................................................................................................................ii
Table of Contents ...................................................................................................................................iii
1. INTRODUCTION 1
About the Board ...................................................................................................................................... 1
Features............................................................................................................................................. 1
Option List........................................................................................................................................ 1
Customer Support.................................................................................................................................... 2
Web Site ........................................................................................................................................... 2
Limited One Year Warranty.................................................................................................................... 2
How to Obtain Service ............................................................................................................................ 2
Liability ................................................................................................................................................... 2
Safety Precautions ................................................................................................................................... 3
Safety Information............................................................................................................................ 3
Handling Precautions ....................................................................................................................... 3
Environment ..................................................................................................................................... 4
Inspection ......................................................................................................................................... 4
Storage .............................................................................................................................................. 4
Disposal ............................................................................................................................................ 4
2. SYSTEM REFERENCE 5
Specification ............................................................................................................................................ 5
Power Management Features .................................................................................................................. 7
Power Requirements................................................................................................................................ 7
Power Consumption ......................................................................................................................... 7
Connector & Jumper Location................................................................................................................ 8
Daughter Board ................................................................................................................................ 8
CPU Board........................................................................................................................................ 9
Block Diagram....................................................................................................................................... 10

iv SCP-8550-LLV
3. HARDWARE INSTALLATION 11
Installation procedure ............................................................................................................................11
CPU Installation:....................................................................................................................................12
Main Memory Installation: DIMM1/DIMM2.......................................................................................12
On board HDD connector......................................................................................................................13
HDD attachment method ................................................................................................................14
Compact Flash Slot................................................................................................................................16
CF Master/Slave select switch: S1 ........................................................................................................17
External ATX control Power Connector...............................................................................................17
System FAN Connector: FAN1/FAN2 .................................................................................................18
External Battery Connector ...................................................................................................................18
CPCI connectors: J1/J2/J4/J5 ................................................................................................................19
4. FRONT PANEL CONNECTS CONFIGURATION 23
PS/2 Mouse Connector ..........................................................................................................................23
PS/2 Keyboard Connector .....................................................................................................................23
Printer Connector...................................................................................................................................24
LAN1 connector.....................................................................................................................................25
LAN2 connector.....................................................................................................................................25
USB1 - 4 Connectors .............................................................................................................................26
SER1/SER2 connectors .........................................................................................................................26
DVI-D Connector...................................................................................................................................27
VGA Connector .....................................................................................................................................28
RAS Connector ......................................................................................................................................28
5. JUMPER SETTING 29
Clear ROM: JP1.....................................................................................................................................29
Clear CMOS: JP2...................................................................................................................................29

SCP-8550-LLV v
6. RAS FUNCTIONS 31
Watch dog timer ....................................................................................................................................32
Specifications ................................................................................................................................. 32
How to Use the Watchdog Timer .................................................................................................. 33
External I/O Circuit........................................................................................................................38
DIP-SW(S1), LED1/2 .................................................................................................................... 39
7. CPU BOARD RESOURCES 41
I/O MAP ................................................................................................................................................41
MEMORY MAP....................................................................................................................................42
DMA Channels...................................................................................................................................... 43
Interrupters............................................................................................................................................. 43
8. BIOS SETUP 45
Introduction ........................................................................................................................................... 45
keystrokes .............................................................................................................................................. 45
Main Menu ............................................................................................................................................46
Advanced Menu.....................................................................................................................................48
Security Menu........................................................................................................................................ 58
Power Menu........................................................................................................................................... 59
PC Health Menu ....................................................................................................................................61
Boot Menu ............................................................................................................................................. 63
Exit Menu .............................................................................................................................................. 64
POST Codes .......................................................................................................................................... 66

vi SCP-8550-LLV

1. Introduction
SCP-8550-LLV 1
1. Introduction
About the Board
This product, which is equipped with an 855GME chip set, is a Compact PCI bus compliant PC/AT
compatible 6U double slot single board computer that supports Intel(R) Pentium(R) M Processor
1.6G - 2.0GHz (FSB400MHz) CPU, Intel(R) Celeron(R) M Processor 1.3G - 1.5GHz (FSB400MHz)
CPU. It features all-in-one-design with a variety of interfaces including LAN x 2, DVI-D, EIDE,
USB2.0 x 4, serial, parallel and PS/2 Keyboard/Mouse. This product is also equipped with a CF card slot
(Type I/II), enabling boot-up from a CF card.
One 2.5inch HDD can be attached on board. Rear Panel I/O correspondence, optional rear panel I/O
board (SCP-RPIO-01) is able to convert to the standard I/F connectors through the J4, J5 connectors.
Please read this manual carefully and connect the external devices or build the system.
Features
- The supported CPU is as follows:
Intel(R) Pentium(R) M 1.6G - 2.0GHz(FSB400MHz), Celeron(R) M 1.3G - 1.5GHz(FSB400MHz)
- CompactPCI compliant 6U double-slot CPU board equipped with 2 LANs and 2 display I/Fs (analog
RGB, DVI-D)
- Intel(R) 855GME+ICH4 chipset
- Accommodates up to 2GB DDR SDRAM of main memory (ECC function support)
- Equipped with CF card slot (Type I/II), bootable from CF card. One onboard frame for 2.5-inch
HDD can be mounted.
- Supports rear panel I/O (IDE, FDD, KEY/MOUSE, SERIAL, PARALLEL, analog RGB, USB),
optional rear panel I/O board (SCP-RPIO-01)
Option List
CPU
- PCPM-16F Pentium M 1.6GHz (with heat sink-fan)
- PCPMC-13F Celeron M 1.3GHz (with heat sink-fan)
Memory (PC2700 DDR SDRAM DIMM, No parity)
- PC-MDD256-184A DDR SDRAM DIMM, 256MB
- PC-MDD512-184A DDR SDRAM DIMM, 512MB
OTHER
- SCP-RPIO-01 Rear Panel I/O Board

1. Introduction
2SCP-8550-LLV
Customer Support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
Web Site
Japanese http://www.contec.co.jp/
English http://www.contec.com/
Chinese http://www.contec.com.cn/
Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price,
delivery time, or estimate information.
Limited One Year Warranty
CONTEC Industrial CPU board is warranted by CONTEC CO., Ltd. to be free from defects in material
and workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original
invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office from
which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and
original boards. The warranty is not applicable if the device has been tampered with or damaged through
abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in which case
repairs will be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please
obtain a Return Merchandise Authorization Number (RMA) from our Sales Administration Department
before returning any product.
* No product will be accepted by CONTEC group without an RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor
be liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.

1. Introduction
SCP-8550-LLV 3
Safety Precautions
Understand the following definitions and precautions to use the product safely.
Safety Information
This document provides safety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these
labels to operate the equipment safely.
DANGER DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury or in property damage.
Handling Precautions
CAUTION
- Do not modify the product. CONTEC will bear no responsibility for any problems, etc., resulting
from modifying this product.
- Do not strike or bend the board.
Otherwise, the board may malfunction, overheat, cause a failure or breakage.
- Do not touch the board's metal plated terminals (edge connector) with your hands.
Otherwise, the board may malfunction, overheat, or cause a failure. If the terminals are touched by
someone's hands, clean the terminals with industrial alcohol.
- There are switches and jumpers on the board that need to be set in advance. Be sure to check these
before installing to the expansion slot.
- Only set the switches and jumpers on the board to the specified settings.
Otherwise, the board may malfunction, overheat, or cause a failure.
DANGER
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
