Contec PCP4-28 User manual

1 PCP4-28, PCP4-24, PCP4C-20
Pentium 4 2.8/2.4GHz, Celeron 2.0GHz CPU
with HeatSink-FAN
PCP4-28, PCP4-24, PCP4C-20
User’s Guide
CONTEC CO.,LTD.
Thank you for purchasing the product. The product is a combination of a CPU and a heat sink fan.
Follow the procedure in this manual to install the CPU and heat sink fan.
WARNING
Before starting installation, be sure to turn off the power to prevent electric shocks and burns.
Product configuration
- CPU…1
- Heat Sink fan…1
- User’s Guide (this booklet) …1
Target Model
-SPI-8450-LLVA
-SPI-8451-LLVA
-SPI-8451-LVA
Specification
Item PCP4-28 PCP4-24 PCP4C-20
Model Intel(R) Pentium(R) 4
Processor 2.8GHz
Intel(R) Pentium(R) 4
Processor 2.4GHz
Intel(R) Celeron(R) Processor
2.0GHz
External Bus Speed 533MHz 400MHz
Built-in L2 Cash 512KB 128KB
Core voltage 1.525V
C
P
U
Package FCPGA2 478Pin
Fan speed 5400rpm (Typ.) / 4860rpm (Min.)
Life time 40,000 hours
Speed sensor Built in
Safety features Reverse-connection protection, Stuck-burn prevention
F
A
N
Rated current 0.48A (Typ.) / 0.52A (Max.)
Operating temperature 0 - 50°C
Storage temperature -30 - 75°C
Operating/ Storage humidity
range
20 - 85%RH (No condensation)
Heat-Sink FAN dimensions
(mm)
90(D) x 95(W) x 62(H)
Heat-Sink FAN weight About 450g

PCP4-28, PCP4-24, PCP4C-20 Instruction Manual
PCP4-28, PCP4-24, PCP4C-20 2
How to attach
(1) Unlock the CPU socket following one of the procedures described below, depending on its type:
Lever type :
Pull up the lever.
Screw type :
Turn the screw and align it to the release position.
(2) Install the CPU onto the socket.
After the installation, lock the CPU socket following one of the procedures described below,
depending on its type:
Lever type :
Push down the lever.
Screw type :
Turn the screw and align it to the lock position.
(3) Mount the heat sink fan on the CPU. Make sure that the levers on the heat sink fan are positioned
as shown below.
Release position
Lock position

PCP4-28, PCP4-24, PCP4C-20 Instruction Manual
3 PCP4-28, PCP4-24, PCP4C-20
(4) Press the four corners of the heat sink fan from above to hook the four ends of the heat sink fan clips
into the retention frame on the CPU board.
(5) Push the right and left levers on the heat sink fan slowly down at the same time to fasten the heat sink
fan.
(6) Connect the fan cable to the fan connector on the CPU board.

PCP4-28, PCP4-24, PCP4C-20 Instruction Manual
Copyright 2005 CONTEC CO., LTD. ALL RIGHTS RESERVED.
CONTEC CO., LTD. Jun 2010 Edition
3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan
Japanese http://www.contec.co.jp/
English http://www.contec.com/ A-46-806 (LYDC022)
Chinese http://www.contec.com.cn/ 06212010_rev3 [09192003]
