Contec IPC-CDD-02 User manual

IPC Series
CD-ROM/DVD-ROM Drive Unit
IPC-CDD-02
User’s Manual

CONTEC CO., LTD.
IPC-CDD-02 i
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, thatyour package is complete. If you discover damaged or missing items,
contact your retailer.
Product Configuration List
- Drive Unit [IPC-CDD-02] …1
- This User’s Manual…1
- IDE Cable(40cm)…1
- Power Cable (125VAC 2.5m)…1
- Cable cover…1
- Cable clamp…2
- Three-point screw and washer assembly(M3 x 8)…4
- DVD-ROM drive appended goods…1set
- DVD-ROM drive guarantee…1
IDECable
(40cm)
DriveUnit
[IPC-CDD-02]
PowerCable
(125VAC 2.5m)
ThisUser'sManual
ThisUser's
Manual
DVD-ROM
driveguarantee
Guarantee
Manual
DVD-ROM
driveappendedgoods
Cablecover
Cableclamp
x2
x4
Three-pointscrewand
washerassembly(M3x8)

CONTEC CO., LTD.
ii IPC-CDD-02
Copyright
Copyright 2003 CONTEC CO., LTD. ALL RIGHTS RESERVED
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document. The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document nor for results obtained by the user as a result of using this product.
Trademarks
MELSEC and CC-Link are trademarks of MITSUBISHI ELECTRIC CORPORATION. Other brand and
product names are trademarks of their respective holder.

CONTEC CO., LTD.
IPC-CDD-02 iii
Table of Contents
Check Your Package..........................................................i
Copyright..........................................................................ii
Trademarks.......................................................................ii
1.Before Using the Product ........................................... 1
About the Drive Unit........................................................1
Customer Support ............................................................2
Web Site http://www.contec.co.jp/en/...........................2
Limited One-Year Warranty............................................2
How to Obtain Service .....................................................2
Liability.............................................................................2
Safety Precautions............................................................3
Safety Information....................................................... 3
Handling Precautions..................................................3
Environment................................................................. 4
Inspection .....................................................................4
Storage..........................................................................4
2.About Hardware........................................................5
Specifications....................................................................5
External Dimensions........................................................7
Hardware setup................................................................8
Attachment of an IDE cable cover..............................8
3.Functions of Components ........................................... 9
Component Locations...................................................9
IDE Interface.............................................................. 10

CONTEC CO., LTD.
iv IPC-CDD-02

1. Before Using the Product
CONTEC CO., LTD.
IPC-CDD-02 1
1. Before Using the Product
This chapter provides information you should know before using the product.
About the Drive Unit
This product is a CD-ROM/DVD-ROM drive unit dedicated to the CONTEC box computers [IPC-
BX/M630 Series, IPC-BX/M600 Series], CONTEC panel computers [IPC-PT/x630x Series, IPC-
PT/x600x Series], and to the personal computer CPU unit[PPC-CPU686(MS)-128] compatible with the
Mitsubishi Programmable Logic Controller MELSEC-Q series.
The target device (personal computer) is hereafter abbreviated PC.
For configuration of the system using this drive unit and its connection, refer to the user's manual for
each PC.

1. Before Using the Product
CONTEC CO., LTD.
2IPC-CDD-02
Customer Support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
Web Site http://www.contec.co.jp/en/
Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price,
delivery time, or estimate information.
Limited One-Year Warranty
CONTEC Interface boards are warranted by CONTEC CO., LTD. to be free from defects in material and
workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original
invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office, from
which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and
Driver Unit. The warranty is not applicable if the device has been tampered with or damaged through
abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in which case
repairs will be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please
obtain a Return Merchandise Authorization Number (RMA) from the CONTEC group office where you
purchased before returning any product.
*No product will be accepted by CONTEC group without the RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor
be liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.

1. Before Using the Product
CONTEC CO., LTD.
IPC-CDD-02 3
Safety Precautions
Understand the following definitions and precautions to use the product safely.
Safety Information
This document provides safety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these labels
to operate the equipment safely.
DANGER DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNINGWARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTIONCAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury or in property damage.
Handling Precautions
CAUTION
-Do not use or store the product in a location exposed to extremely high or low temperature or
susceptible to rapid temperature changes.
Example: - Exposure to direct sun
- In the vicinity of a heat source
-Do not use the product in extremely humid or dusty locations. It is extremely dangerous to use the
product with its interior penetrated by water or any other fluid or conductive dust. If the product
must be used in such an environment, install it on a dust-proof control panel, for example.
-Avoid using or storing the device in locations subject to shock or vibration.
-Do not use the product in the vicinity of devices that generate strong magnetic force or noise. Such
devices will cause this device to malfunction.
-Do not use or store the product in the presence of chemicals.
-To clean the Drive Unit, wipe it gently with a soft cloth dampened with either water or mild
detergent. Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent pealing
or discoloration of the paint.
-CONTEC reserves the right to refuse to service a product modified by the user.
-In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power
cord immediately and contact the sales representative you purchased the product from or the
CONTEC Information Center.
-Use an AC cable that is compatible with both the rated supply voltage and the receptacle. (The cable
provided with the product is for 125VAC.)
-Component Life:
1. Fan--- Longevity of the fan is approx. 20000 hours when it continues operating at 25
degrees. But the temperature was fallen by used one (high).
*Replacement of expendables is handled as a repair (there will be a charge).

1. Before Using the Product
CONTEC CO., LTD.
4IPC-CDD-02
Environment
Use this product in the following environment. If used in an unauthorized environment, the module may
overheat, malfunction, or cause a failure.
Operating temperature
5 to 35°C
Humidity
20% to 80%RH (No condensation)
Corrosive gases
None
Pollution degree
2 or less
Inspection
Inspect the product periodically as follows to use it safely.
-Donotblocktheexhaustfan
.
Storage
When storing this product, keep it in its original packing form.
(1) Put the module in the storage bag.
(2) Wrap it in the packing material, then put it in the box.

2. About Hardware
CONTEC CO., LTD.
IPC-CDD-02 5
2. About Hardware
Specifications
Table 2.1. Function Specifications
Item Specification
Bus interface IDE
Cable Dedicated 40-pin cable, 40cm in length
Formats supportted DVD-ROM(single layer , dual layer )
DVD-R(3.95Gbyte, 4.7Gbyte)
DVD+R(Version 1.0)
DVD-RW(Rev 1.0, 1.1) *1
DVD+RW *1
DVD-RAM(2.6Gbyte/panel, 4.7Gbyte/panel) *1
CD-ROM Mode1&Mode2, CD-ROM XA
CD-I, Photo-CD, CD-Extra, CD-TEXT, CD-DA, VideoCD
Disk media supported *2 DVD-ROM, DVD-R, DVD+R, DVD-RW, DVD+RW,
DVD-RAM, CD-ROM, CD-R, CD-RW
Maximum data transfer rate 33.3MB/sec(Ultra DMA Mode2)
Maximum read speeds DVD-ROM: 16X speed (single layer), 12X speed (dual layer)
DVD-R:6X speed
DVD+R:6X speed
DVD-RW:2.5X speed
DVD+RW:2.5X speed
DVD-RAM:2X speed
CD-ROM:48X speed
CD-R:40X speed
CD-RW:40X speed
Average access time DVD-ROM:125ms
CD-ROM:100ms
Data buffer size 256KB
Master/Slave switching Selector switch
Cooling device Rear-panel fan(60mm emission)
External dimensions (mm) 207(W) x 285(D) x 68(H) (Excluding protrusions)
Power supply 90 to 264VAC(47 to 63Hz)continuous input
Power consumption 40VA(Max.)
Weight Approx. 2.8kg
*1 The drive unit can read only discs formatted in UDF 1.02 or 1.5; it cannot read those formatted in FAT or FAT32.
*2 The drive unit can only read but cannot write to DVD-RAM.

2. About Hardware
CONTEC CO., LTD.
6IPC-CDD-02
Table 2.2. General Specifications
Parameter Requirement description
Power supply specifications
Allowable instantaneous Less than 10ms
power outage One minute each for 1.5kVAC (input-FG)
Dielectric strength 50MΩ(500VDC)
Ambient specifications
Operating temperature 5 to 35°C
Storage temperature -10 to 60°C
Humidity 20 to 80%RH(No condensation)
Operating ambiance Not to be excessive
Operating altitude 2000m or less *1
Pollution degree *2 2 or less
Line noise AC line/2kV, Signal line/1kV
(IEC1000-4-4Level 3, EN61000-4-4Level 3)
Contact discharge/4kV
(IEC1000-4-2Level 2, EN61000-4-2Level 2)
Line-noise
resistance Static voltage
resistance Atmospheric discharge/8kV
(IEC1000-4-2Level 3, EN61000-4-2Level 3)
During
operation 10 to 150Hz, 2.45m/s2(0.25G) 40 min. each in x, y, and z directions
(JIS C0040-compliant, IEC68-2-6-compliant)
Vibration
resistance
Not during
operation 10 to 150Hz, 9.8m/s2(1.0G) 40 min. each in x, y, and z directions
(JIS C0040-compliant, IEC68-2-6-compliant)
During
operation 58.8m/s2 (6.0G) 11-ms half-sine wave. x, y, and z directions (JIS C0041-compliant, IEC68-2-27-compliant)
Impact
resistance Not during
operation 98m/s2 (10G)11-ms half-sine wave. x, y, and z directions (JIS C0041-compliant, IEC68-2-27-compliant)
Tray loard/eject 30,000 times
Mounting orientation Horizontal only *3
Tilt: Within ±5°horizontally (both lengthwise and widthwise)
Grounding Class D grounding (previous class 3 grounding)
*1 The drive may fail and cannot be used in an environment in which the air is compressed to over
theatmospheric pressure generated at an altitude of around 0m.
*2 The index indicating the degree to which conductive substances are generated in the operating environment.
Pollution level 2 indicates the environment that generates only nonconductive pollutants while allowing accidental
condensation to cause temporary conduction.
*3 The drive unit cannot be mounted vertically.

2. About Hardware
CONTEC CO., LTD.
IPC-CDD-02 7
External Dimensions
285
68
(3)
[mm ]
(44)
CONTEC
10
207
Figure 2.1. External Dimensions

2. About Hardware
CONTEC CO., LTD.
8IPC-CDD-02
Hardware setup
Attachment of an IDE cable cover
Attach the supplied cable cover or clamp using the supplied screw (M3 x 8) or it that has been installed
on the main unit.
Don’tremovethisscrew(twopoint).
Attachthecablecoverusingthescrewsthat
havebeeninstalledonthemainunit.
Figure 2.2. Attachment of an IDE cable cover

3. Functions of Components
CONTEC CO., LTD.
IPC-CDD-02 9
3. Functions of Components
Component Locations
Forntpanel
(1)Disktray
(2)Ejectbutton(3)Forcibleejectbutton(4)Access lamp(6)Powerlamp
(5)Powerswitch
Reapanel(7)Master/Slaveselector
(8)AC inlet(9)IDEconnector
Unused
(Cannotbeused)
Figure 3.1. Component Locations
Component Functions
Table 3.1. Component Functions
No. Name Function
(1) Disk tray Loads a Disk
(2) Eject button Opens and closes the Disk tray.
(3) Forcible eject button Accepts a forcible eject pin used when the eject button fails to eject
the Disk tray.
(4) Access lamp Comes on when data is read from the CD.
(5) Power switch Turns on the drive unit.
(6) Power lamp Remains on when AC power has been supplied to the drive unit
with the AC power switch on.
(7) Master/slave selector Sets the drive unit as the master or slave device.
1: Master 2: Slave 0, 3 to 6: Invalid
Use the up and down buttons to switch between master and slave.
Default 1: Master
(8) AC inlet Connect the attached AC cable.
(9) IDE connector Connect the attached IDE cable.

3. Functions of Components
CONTEC CO., LTD.
10 IPC-CDD-02
CAUTION
-Turn on this drive unit before turning on the PC.
-When this drive unit has been connected to the PC, the PC may fail to operate normally with the
drive’s power off. To use the PC with the drive’s power off, unplug the IDE cable in advance.
-Before changing the master/slave setting or plugging or unplugging the cable, always ensure that
both of the drive unit and PC are off. Performing such operations with the drive unit or PC powered
can cause their malfunction or fault.
-To manually unload a disc using the forcible eject hole, turn off the drive unit, leave it for at least
one minute, then insert a pin or straightened paper clip into the eject hole to eject the disc tray.
-To connect this drive unit to a disk unit [PPC-HDD(MS) or PPC-SDD(MS)-xx], connect the IDE
interface connector on the disk unit to the PC CPU unit [PPC-CPU686(MS)-128] using an IDE cable
and the IDE connector on this drive unit to the extended IDE interface connector on the disk unit
using another IDE cable. After connecting them, set the master/slave selector appropriately.
IDE Interface
Use the attached IDE cable to connectthis drive unit to the IDE connector on the PC or on the front of the
disk unit. For the system configuration and connections, consult the user manual for your PC.
Table 3.2. IDE Connector
Connector type 40-pin Half-pitch connector(1.27 mm pitch)
Pin No. Single name Input/Output Pin No. Single name Input/Output
1RESET#Output 21 GND …
2DD7 I/O 22 DD8 I/O
3DD6 I/O 23 DD9 I/O
4DD5 I/O 24 DD10 I/O
5DD4 I/O 25 DD11 I/O
6DD3 I/O 26 DD12 I/O
7DD2 I/O 27 DD13 I/O
8DD1 I/O 28 DD14 I/O
9DD0 I/O 29 DD15 I/O
10 GND --- 30 N.C. ---
11 DDRQ Input 31 GND ---
12 DIOW#Output 32 GND ---
13 DIOR#Output 33 GND ---
14 IO CHRDY#Input 34 DALE Output
15 DDACK#Output 35 GND ---
16 INTRQ Input 36 Reserve ---
17 DA1 Output 37 Reserve ---
18 DA0 Output 38 DA2 Output
19 CS1#Output 39 CS3#Output
20 DACT#Output 40 GND ---
2
0
1
40 21
