Contech URBANPOND User manual

URBANPOND®
Single Modules Installation Manual
English
Play Setup Video

©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INTRODUCTION
WARRANTY
The UrbanPond®is an underground modular storage system designed for stormwater retention,
detention, harvesting, or infiltration. UrbanPond®utilizes the strength and durability of precast
concrete to create an efficient and resilient stormwater management solution. A modular design
gives UrbanPond®the flexibility to meet nearly any site requirements with configurations ranging
from 2’ to 14’ inside height. Modules are delivered ready to be installed, minimizing staging
requirements and decreasing installation times.
UrbanPond®can be installed in a variety of configurations and heights. Taller systems are installed
stacked with top and inverted bottom modules. Shorter systems consist of the top modules only
placed upon a concrete slab. Either configuration can be combined with a membrane liner for leak
resistant applications. Installation procedures for each configuration are described herein.
2
Bio Clean provides a 1 year product warranty against defects in materials and
workmanship from the date of purchase. Please contact Bio Clean support for
more information.
Inspection
• The UrbanPond®and all parts contained in or shipped outside of the unit shall be inspected at time
of delivery by the site Engineer/Inspector and the Contractor. Any non-conformance with approved drawings
or damage to any part of the system shall be documented on the Bio Clean shipping ticket. Any damaged
sections must be addressed with Bio Clean prior to continuing with installation. No damaged pieces are to be
installed without Bio Clean’s written approval.
• Damage to the unit during and after unloading shall be corrected at the expense of the Contractor.
Any necessary repairs to the UrbanPond®modules, LinkUp slabs, or exterior walls shall be made to the
acceptance of the Engineer/Inspector.

©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS. 3
TOOLS CHECKLIST
Ensure that the following parts are included. These are crucial components for Installation.
CrowBar (Optional) Chalk With Line Gloves
Measuring Tape
Rotary Hammer Drill-3/4”
ConcreteBit
Sledge Hammer Marker Hand Level
Impact Wrench w/ 3/4”
Socket
Safety Goggles
PARTS CHECKLIST
Check your Project Drawings for a complete Parts List.

©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
OVERVIEW
Delivery & Unloading/Lifting
• Bio Clean Environmental Services, Inc. shall deliver the unit(s) to the site in coordi-
nation with the Contractor.
• The Contractor is required to provide spreader bars and chains/cables to safely
and securely lift the bottom modules, top modules, LinkUp slabs, and exterior walls along
with suitable lifting hooks, knuckles, shackles or eyebolts.
• Please see project specific drawings for weights and lifting details. Contact Bio
Clean for additional lifting details. Use 60 Degrees for Lifting positions.
4
Single Modules & LinkUP Slabs
• Check your project Drawings for the Type of Installation. There are single mod-
ules, and Double Stacked Modules.
• Check to see if LinkUp Slabs are required.

Determine if Membrane Liner is Needed
Most projects only require a single layer of geotextile fabric.
Projects with a containment membrane liner require placement
of a first layer of geotextile fabric, then the liner layer, followed
by another layer of geotextile fabric on top. This reduces
abrasion against the liner and prevents punctures. Check your
project drawings to see if a containment membrane liner is
required.
4.
©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS. 5
INSTRUCTIONS
Check Project Drawings
Set Fabric
Excavate Installation Location
Begin step 1 by checking your project drawings for the general
location and position of the modules. In this example, the
walls labeled A, are identical exterior walls. The wall labeled
A A is the inlet wall, and the wall labeled B B is the outlet wall.
Next, place a flattened layer of geotextile fabric on the bottom
surface. You may need to overlap multiple pieces to achieve
proper coverage. Check your project drawings to see if a
containment membrane liner is required.
Prepare the location where you are going to install the
UrbanPond system. Check the project drawings for installation
requirements such as soil type, backfill, and groundwater. The
modules have a 12 inch minimum cover requirement from the
top of module to the finished surface. Check project drawings
for all elevations. Excavate as required.
1.
3.
2.
Step 1 - Site Preperation

Step 2 - Setting the Modules
©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INSTRUCTIONS
Mark 12’’ Clearance
Set the Corner Perimeter Module
6.
1.
Step 1 - Site Preperation
If using precast slabs, ensure slabs are set level, and at proper
elevation.
The foundation slab should have 12 inches of clearance around
all sides from the edge of slab to the UrbanPond walls and
modules. Use a chalk line to mark the 12 inch clearance all
around.
6
Locate the corner on your slab, and set the
UrbanPond module using the appropriate rigging
and lifting method.
If the first module you are installing requires a
perimeter wall, then you will need to mark a second
line 7 inches beyond the 12 inch chalk line, for a
total of 19 inches. Verify that you have a 12 inch
clearance on the solid side, and a 19 inch clearance
on the open side where the wall will be installed
later. The walls will be installed at a later step.
Make sure the module is flat and leveled before
setting additional modules. If needed, apply grout
at the bottom to set the module level.
Concrete Foundation Slab
Next, after setting the required fabric, set the poured-in-place
concrete foundation slab. Assemble rebar reinforcement
and pour a smooth and level base slab as required per the
construction documents.
Single module installations require a base slab to support the
modules and soil backfill. Ensure the base slab has cured to
proper strength prior to setting modules.
5.

Continue Installing Adjacent Modules
INSTRUCTIONS
Level
4.
Step 2 - Setting the Modules
In this configuration, the single modules on a slab will not
require LinkUp slabs. The modules shall be installed per
construction documents to ensure proper module orientation.
3.
Continue setting one module at a time.
Verify with a hand level and tape measure that the modules
are spaced and leveled properly. Only use a hand level if the
concrete structure is placed flat.
©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
Set the Corner Perimeter Module
7
Set The Second Module
Next, install the second module adjacent to the previously
installed module. The second module shall be placed as close
as possible, with a gap no greater than 3/4’’ inch.
Maintain the 12 inch clearance from the edge of the slab.
Continue installing the adjacent modules one at a time.
2.
Install all Remaining Modules
5.
Repeat the previous steps. Continue installing all
Modules per your project Drawings.

©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INSTRUCTIONS
Set the LinkUp Slab
Instalilng the LinkUP Slabs
Next, cover the opening by setting the LinkUP Slab in place.
Slowly lower the Linkup Slab to allow the 3 inch keyway to fit
between the 4 supporting modules, and equal overlap across
all 4 supporting modules for even weight distribution.
Check your project drawings for the proper location of each
LinkUP Slab.
To install the LinkUP slabs, first place the 4 supporting
modules in their final positions. It’s best to install LinkUP
slabs as you go, rather than waiting until the end to ensure
proper module spacing and optimal fit.
4.
2.
Step 2.1 - Setting the Modules With LinkUp Slabs
8
Apply Butyl Rubber Sealant
3.
Once the supporting modules are in place, apply butyl rubber
sealant to all 4 modules.
Make sure to cover all edges.
Assemblies with LinkUP Slabs
Check your project drawings. If your assembly does not
require a LinkUP Slab, then you may skip this step.
Install the first row of modules as shown on step 2. Reference
step 2 for instructions.
1.

Step 3 - Installing the Exterior Walls
Secure the Walls
The walls have slotted holes in them for anchoring.
Using a drill with a quarter inch drill bit, drill into the perimeter
modules. The drilled holes should match the slotted holes on
the walls.
2.
©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INSTRUCTIONS
Install the Exterior Walls One At A Time
Verify
The exterior walls will be installed after all the modules are
in place. Check the project drawings for the wall type and
location.
The inlet and outlet Walls will have holes in them for pipe
connections. Install the walls using the appropriate rigging,
and lifting method. Slowly lower the walls into place. Keep
lifting chains intact until walls are fully anchored.
When properly placed, the LinkUP slabs will sit level,
approximately 7 inches above the UrbanPond supporting
modules.
Verify that all Linkup Slabs with butyl rubber sealant are fully
in place.
1.
6.
Step 2.1 - Setting the Modules With LinkUp Slabs
9
Continue Setting the LinkUP Slabs
Repeat these steps and continue setting the LinkUP slabs as
shown on your project drawings.
5.

Step 4 - Sealing the Modules & Installing the Pipes
©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INSTRUCTIONS
Step 3 - Installing the Exterior Walls
10
Drill Holes on the opposite side
Next, secure the wall by using the provided anchor bolts.
Insert the bolts through the wall and into the perimeter
module. Use a hammer and power tool to fully secure the
anchors.
3.
Place Wedge Anchor Bolts in bracket holes
4.
Repeat these steps, and ensure all walls are fully secured.
Apply Joint Tape
Apply joint tape along the seams between each module.
The top and all sides shall have joint tape applied to keep soil
out and water in. The joint tape shall be at least 6 inches
wide.
1.
Apply Joint Tape To All Seams
Apply Joint Tape to all Vertical, and Horizontal Seams. Make
sure to apply tape along the exterior wall seams as well.
2.

©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INSTRUCTIONS
Locate the Maintenance Access Holes
Fully Secure the Inlet Pipe
Finally, check the project drawings for the locations of the
maintenance access holes.
Unless otherwise noted, the outlet pipe shall be flush with
the floor. Use a chisel as required to ensure the interior of the
wall pipe is flush with the interior floor so there is no ponding
water.
Insert the pipe, and grout it as required.
6.
4.
Step 4 - Sealing the Modules & Installing the Pipes
11
Install the Inlet Pipe
5.
Next, locate the exterior wall that has the inlet pipe pre drilled
hole.
Insert the pipe, and grout it as required.
Install the Outlet Pipe
After applying the Joint Tape, install the inlet and outlet pipes.
Check the project drawings for the location of all pipes.
To install the outlet pipe, locate the exterior wall with a pre
drilled hole in the bottom of the wall.
3.

Step 4.1 - Sealing the Modules (LinkUp Slab Configuration)
©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INSTRUCTIONS
Apply Joint Tape To All Seams
Apply Joint Tape
Make sure to apply tape along the exterior wall seams as well.
After applying Joint Tape to all seams, continue inserting the
Inlet and Outlet Pipes on Step 4.
Applying joint tape to the LinkUP Slab configuration.
Check your project drawings. If your assembly does not
require a LinkUP Slab, then you may skip this step. Apply
joint tape along the vertical and horizontal seams between
each module. Cut the tape at each LinkUP slab.
3.
1.
Step 4 - Sealing the Modules & Installing the Pipes
12
Apply Joint Tape
2.
Apply Joint Tape on both sides of the LinkUp Slab.
Install the Risers, Grade Rings, and Covers
Place butyl rubber sealant between all concrete pieces. Set
the risers, grade rings, and maintenance access covers per the
project specifications. You may need to use bricks and grout
to match the frames and covers with finished grading.
7.

©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INSTRUCTIONS
Step 5 - Bakfill & Compaction
13
Secure the Geotextile Fabric
Before adding the backfill, fold the geotextile fabric out of
the excavation pit to cover the modules. You can secure the
geotextile in place using strips of joint tape if needed.
If your assembly does not require a containment membrane
liner, then fold and tape the single layer of geotextile fabric a
minimum of 12 inches up from the base of the module.
1.
Check Project Drawings If Liner Is Needed
2.
If your assembly requires a containment liner, then the liner
and geotextile fabric layers will cover the perimeter walls
completely and fold 18 inches over the top of each module.
Pipe penetrations will require the geotextile fabric and liner
to be cut and fitted with a pipe boot per the manufacturer’s
recommendations. Fold and tape the fabric as required to
stay in place during backfill and compaction activities.
Backfill One Side At a Time
Begin backfilling only after all modules, walls, and pipe
connections have been installed, and all fabric is properly
folded.
Finally, add the backfill one side at a time.
3.
Check Project Drawings
Make sure to leave a minimum of 12 inches of clearance
between the top of the modules and the final surface. See
plans for elevations.
4.

©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
INSTRUCTIONS
Compact As Required
Apply cover material and compact as required, to achieve
final grading elevations. Keep in mind that UrbanPond
modules are rated for HS-20 traffic and cannot support all
construction machinery. Contact Bio Clean if you have any
questions.
Check all connections before using the Urban Pond, and
installation checklist to ensure all safety requirements have
been met.
6.
Step 5 - Bakfill & Compaction
14
Continue Backfilling
Continue backfilling equally around and compacting, until the
top is reached.
5.

©2022 COPYRIGHT | CONTECH ENGINEERED SOLUTIONS.
Technical support
Contech Engineered Solutions
9100 Centre Pointe Drive
West Chester, OH 45069
https://www.conteches.com/technical-guides/
Contact Us:
Phone: [phone]
Email Us: [e-mail]
