Contech CCS Series User manual

ELECTRONIC WEIGHING SCALE
®
CCS - SERIES
OPERATING MANUAL

CONTENTS
1. Introduction
2. Crane scale sketch
3.
4.
5.
6.
7.
8.
9.
10.
11.
12
.
Installation
Operation of the Scale
Print Option
Bi-directional RS-232 interface
Storage of Weights in Memory
Auto Power Off
Piece Counting Mode
Set Point Facility
Operating in Tare / Zero Mode
Set up Function

INTRODUCTION
We thank you for choosing series weighing scale for your
weighing needs. These scales use some of the latest and most advanced
computing powers to give maximum flexibility and utility to the user.
CCS
Features:
weighing unit gram / kilo gram.
Feather touch membrane keyboard.
Optional Battery backup facility.
Piece counting facility, up to 25 different types.
Storage of weights in memory and printing, up to 100 weights.
Power saving mode.
Bi-directional RS232 interface to interface with computers and printers.
Selectable baud rate.
Set point facility up to 3 limits.
Auto Power off.
Peak Hold facility.
Date and time facility.
Multiple Print options with Sr. no., Date, Time and weight in Horizontal /
Vertical Mode.
Automatic zero tracking.
User selectable Tare/Zero mode option with Net/gross facility for
minimum use.

REAR VIEWREAR VIEW
MODEMODE
HOLD
ENT.
HOLD TARE
PRN
StableStable
Kg
Power
255
180
FRONT VIEW
C
H
R.H SIDE VIEWR.H SIDE VIEW
CRANE SCALE SKETCH
A
B

INSTALLATION
1. Unpacking:
2. Electrical Requirements:
3. Environmental Requirements:
4. Start Up:
Unpack the balance. Save the packing container for future use.
The balance requires very stable power. It works on 230V AC supply
with PROPER EARTHING. The power outlet used for the balance should not
be shared with any other devices which draws current in inconsistent manner
likeAir Conditioner or Refrigerator etc.
For best results, the balance should be placed on a level surface which
is free from drafts. It should not be exposed to direct sunlight or radiated heat.
Table used for balance should be sturdy and should not transmit vibration from
other equipments and free from the movement of people. No vibration
producing equipment should be operated on the same platform as balance.
Power is supplied to the scale through a 3 core AC mains cord attached
to the scale. Insert the 3 pin plug of the power supply onto a proper mains
outlet. Switch on the balance using the switch on the scale.
Scale goes through self test and subsequently starts displaying weight.
Press key to display zero weight.
NOW THE SCALE IS READY FOR WEIGHING.
With battery backup option, there is a need to charge the battery regularly
to prevent loss of backup time. The scale can be switched off using the switch
provide on the scale. Do not switch off the main power to the scale even when the
scale is not in use. Keeping the mains power on will charge the battery and will be
ready to use when the input power fails.
NOTE:
1
TARE

OPERATION OF THE SCALE
1) FOR CHANGING WEIGHING UNITS.
Press key, the scale will show for some time
and will display the current weighing unit, say grams
Use or keys to change the mode and
Press key to select or
Press key to discard the changes.
Note that all weighing functions except the basic weighing unit need to be
enabled using functions.
Refer section on for more details.
2) FOR CHANGING DATE, TIME AND SERIAL NO.
Press key, the scale will show for some time
and will display the current weighing unit, say grams
Press key once again, the scale will show,
(If Fill option is on)
Press SETUP key once again, the scale will show
(
Press SETUP key once again, the scale will show
(If fill option is on and limit is set to SET-3)
If fill option is on and limit is set to SET-2 or above)
2
MODE
ENTER
SET
UP
SET
UP
TARE

OPERATION OF THE SCALE
Press key once again, the scale will show
dt DD
where DD is the current date. Use and keys to change
date and press key to store the date.
Press key to skip date entry.
The scale will display
mn MM
where MM is the current month. Use and keys to change month
and press key to store the month.
Press key to skip month entry.
The scale will display
Yr YY
where YY is the current year. Use and keys to change year
and press key to store the year.
Press key to skip year entry.
The scale will display
hh.mm.ss
where hh.mm.ss is the current time.
3
ENTER
ENTER
ENTER
SET
UP
ZERO
ZERO
ZERO

OPERATION OF THE SCALE
Press key to change the time or
key to quit time entry.
Press key, the scale will show,
hh xx
where xx is the hour. Use and key to change hour.
Press key to save. Press key to skip hour entry.
Press key, the scale will display
mm xx
where xx is the minute. Use and key to change minute.
Press key to save. Press key to skip minute entry.
Press key, the scale will display
SS xx
where xx is the second. Use and key to change second.
Press key to save.
Press key to skip second entry.
Press key, the scale will display
Sr xxxx
where xxxx is the serial no. Use and key to change serial number.
Press key to save.
Press key to skip serial number entry.
Press
4
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
TARE
ZERO
ZERO
ZERO
ZERO

PRINT OPTION
CT/CP series weighing scales can be attached to a serial printer for your printing
needs. Print out can be programmed to suit most of the printing requirements.
Note that the printer should have a serial port and baud rate of the scale and printer
should be same. 2 baud rates are available with the scale i.e. 2400 and 4800.
Printing option and patterns are controlled by parameters.
They are
There are 4 options
i) - Press key to start printing weight
and other details programmed as per (b), (c) and (d) below.
ii) - Printing is initiated when the weight kept on the pan
becomes stable.
iii) - All the displayed weights are printed along with
other details programmed as per (b), (c) and (d) below.
iv) - To print weights stored in memory along with details
programmed as per (b), (c) and (d) below.
Printer format. Five printout formats are available.
i) - Only weight.
ii) - Serial no and weight.
iii) - Serial no, Date and weight.
iv) - Serial no., Time and weight.
v) - Serial no., Date, Time and weight.
a) Print :
b) Pr.fmt. :
4 SETUP
5
PRINT

PRINT OPTION
c) Print type (Horizontal or Vertical)
Details will be printed horizontally.
Sr.No. Date Time Weight
001 12.05.2002 13:25:00 4.545 kg
002 12.05.2002 13:27:05 4.234 kg
Details will be printed vertically in a slip form.
Sr.No. : 001 Date : 12.05.2002
Time : 13:25:00 Weight : 4.545 kg
d) : Title for printout.
i) TLE-YES - To enable title printing.
ii) TLE-no - To disable title printing.
Set the above parameters (a) to (d) to your requirements and effect printing.
These parameters are available in SETUP functions. Refer SETUP functions in
chapter.
P-TYPE:
i) – Horizontal
ii) – Vertical
TITLE
6
1
2

BI-DIRECTIONAL RS232-INTERFACE
Bi-directional RS-232 interface is provided in these scales to communicate with
devices like computer, printer etc. The interface is provided through a nine pin D-
type connector provided in the side connector plate of the scale. Connections are
as below.
Pin 2 – RXD – Receive Data
Pin 3 - TXD – Transmit Data
Pin 7 – Ground.
The Serial data transmitted and received are in standard ASCII mode ( +/- 5V) -
ASYNCHRONOUS , 8 BITS, NO PARITY, 1 STOP BIT.
Baud rate : 2400 OR 4800 SELECTABLE.
The data format for weight output is
<+/->WWWWWW.WWb <kg/lt> <CR><LF> ( 15 characters)
where WWWWWW.WW is the weight
b – blank space - 20 hex
CR- Carriage Return – 0D hex
LF – Line feed - 0Ahex
for example, weight 85.12 will be sent as
+000085.12bkg<CR><LF>
where <CR> is carriage return (0D hex) & LF is line feed (0A hex), b=BLANK
SPACE. The balance could be controlled by an external device like computer
with the following commands.
Z - Tares the balance.
W# - Number of times, the weight data is to be transmitted through the serial port.
# can be any number from 1-9.
7

STORAGE OF WEIGHTS IN MEMORY
Upto 100 weights can be stored in memory and recalled if required. The scale also
computes the total weight of all the weights in memory. To use this option, set
ACCU function to ON in SETUP functions. See relevant section.
Press key, the scale will display
Press key, the scale will display
Press key, the scale will display
--------
and weights in memory and total weight will be cleared.
Keep the weight on the pan.
Press key, the scale will display
Press key. Displayed weight will be stored in memory and
Total weight updated. Or
Press key to quit storage.
a) Clear weights in memory.
b) Storing weight in memory.
Immediately
Immediately
Press key
Press key
8
ENTER
ENTER
TARE
SET
UP
SET
UP
ZERO

STORAGE OF WEIGHTS IN MEMORY
Immediately Press key, the scale will display
Press key, the scale will display
followed by the stored weight
WWWW.WW
i) Press or keys to see weights stored.
ii) Press key to end weight view and display total weight.
iii) Press key to print the stored weights.
Refer Print option section for details.
c) Recalling weights from memory.
Press key
9
TARE
PRINT
SET
UP

AUTO POWER OFF
CCS series weighing scales have a built in auto power off facility, where in the
displays will be switched off , if any keys are not operated for approx. 5 minutes.
This will reduce power consumption and if the scale is being used with battery, it
can enhance the discharge time of battery.
To come out ofAuto Power Off mode, Press key.
Ensure to enable this feature in the mode.
Power saving mode feature will further enhance the battery backup time by
making switching off the display whenever the weight displayed is zero. The scale
will come out of Power saving mode when the displayed weight is not zero.
Ensure to enable this feature in the mode.
Peak hold feature will enable the scale to hold the display to the maximum
weight (Peak weight) displayed. When used in this mode, the scale will be
continuously displaying the maximum or peak weight measured by the scale, even
after the weight is removed from the pan.
For using this mode, this function should be enabled in the mode.
For putting the scale into PEAK HOLD mode,
Press and keys simultaneously.
The scale will show,
Press key to exit peak hold mode, the scale will display
POWER SAVING MODE:
PEAK HOLD MODE:
10
SET
UP TARE
TARE
TARE

PIECE COUNTING MODE
Contech CCS series scales can be used for piece counting purposes. Piece
calibration of 25 items can be stored in memory. Accuracy of piece counting
depends on the uniformity in weight of the items and the sample size used for piece
calibration. Better the weight uniformity and more the sample size, better will be
the accuracy.
Use SETUP function to select proper piece counting mode before using. There is
an option to select 1, 10, 25 or none piece counting modes. See relevant section in
SETUP functions for more details.
Selection of piece counting memory (item).
Press key, the scale will display,
for some time
Then it display the current unit say grams
Press OR key repeatedly till the scale displays
Press key to select mode. Or
else Press key.
The scale will display
Press key to select and so on.
11
SET
UP

PIECE COUNTING MODE
Piece Calibration
Select proper piece counting memory as mentioned above.
Make the Weight read zero by pressing the key. Weight of any
container/bags used should also be made zero.
Keep known number of pieces on the pan.
Press key., the scale will display
PC xxxx
Use and keys to change the number of pieces and make it
equal to the pieces kept on the pan.
Press key. The scale will display
---------
Scale does piece calibration and displays the number of pieces on the pan, say
1 250
12
ENTER
ENTER
TARE

SET POINT FACILITY
This facility enables the user to set up to 3 weights for comparison with the current
weights to activate different events. This feature is controlled by 3 SETUP
functions.
1. Fill - Make it FL-on
2. SEt Pt. - Make it SET-1, SET-2
3. F-TYPE - Make it F-TYPE1 or F-TYPE2 for event swapping
depending on the requirement.
For setting weights, Press key, the scale will show
for some time
And will display the current weighing unit, say grams
Press key once again, the scale will show,
and followed by
XXXX.XX
Where XXXX.XX is the current set limit.
Use and keys to change the limit.
To discard changes, Press key
Press key to make the count zero.
Press key to save.
OR
13
ENTER
SET
UP
SET
UP
TARE
ZERO

SET POINT FACILITY
The scale will show
(If fill option is on and limit is set to SET-2 or above)
For some time and will display
XXXX.XX
Where XXXX.XX is the current set limit.
Use and keys to change the limit.
To discard changes, Press key.
Press key to save.
14
ENTER
ZERO

SET POINT FACILITY
Set Point 1:
Set Point 2:
User can set a weight any where in the range of the scale. Depending on the
weight on the pan, the following events occur. Buzzer will work only in case of models
where buzzer is provided.All outputs are TTL outputs provided additionally, if needed.
Type 1 Buzzer ON Buzzer OFF Buzzer ON
O/p O/p Low O/p High
Type 2 Buzzer OFF Buzzer ON Buzzer OFF
O/p low O/p high O/p Low.
---------------------------------------------------------------------------------------------------------
User can set two weights any where in the range of the scale. Depending on the
weight on the pan, the following events occur. Buzzer will work only in case of
models where buzzer is provided. All outputs are TTL outputs provided additionally, if
needed.
Type 1 Buzzer ON Buzzer OFF Buzzer ON
O/p 1 high, if weight is more than first limit,
O/p 2 high, if weight is more than second limit.
O/p 1 low, if weight is less than or equal to first limit,
O/p 2 low, if weight is less than or equal to second limit.
F-Type Weight < Set Wt. Weight = Set Wt. Weight > Set wt.
F-Type Weight within Weight = lower or Weight is beyond
Set Limit Upper limit. the limits.
High
15

SET POINT FACILITY
Type 2 Buzzer OFF Buzzer ON Buzzer OFF
O/p 1 low, if weight is more than first limit.
O/p 2 low, if weight is more than second limit.
O/p 1 high, if weight is less than or equal to first limit,
O/p 2 high, if weight is less than or equal to second limit.
F-Type Weight within Weight = lower or Weight is beyond
Set Limit Upper limit. the limits.
16
