Contest IPAirLED 5x12six User manual

USER GUIDE
10411 - Version 3 / 01-2019
5 X 12W 6-IN-1 LEDS, AIRDMX, BATTERY-OPERATED WATERPROOF PROJECTOR

English IPairLED-5x12six - 5x12W 6-in-1 LEDs, airDMX, battery-operated waterproof projector
Page 2
This symbol signals an important
safety precaution. The CAUTION symbol signals a risk of product
deterioration.
The WARNING symbol signals a risk to the user’s physical integrity.
The product may also be damaged.
Important safety information
Symbols used
Any maintenance procedure must be performed by a
CONTEST authorised technical service. Basic clea-
ning operations must thoroughly follow our safety
instructions.
This product contains non-isolated electrical com-
ponents. Do not undertake any maintenance opera-
tion when it is switched on as it may result in electric
shock.
WARNING : This unit contains no user-serviceable parts. Do not
open the housing or attempt any maintenance by yourself. In the
unlikely even your unit may require service, please contact your
nearest dealer.
Risk of electric shock
In order to avoid any electrical malfunction,
please do not use any multi-socket, power
cord extension or connecting system without
making sure they are
perfectly isolated and
present no defect.
Recycling your device
• As HITMUSIC is really involved in the environmental cause, we only commercialise clean, ROHS compliant products.
• When this product reaches its end of life, take it to a collection point designated by local authorities. The separate collection
and recycling of your product at the time of disposal will help conserve natural resources and ensure that it is recycled in a
manner that protects human health and the environment.
Note : The legislation requires that every device set up in a public space
features a double fixation bracket. This security system must hold 10 times the
weight of the device.
1 - Safety information
Warning
This product is equipped with Class 2 LEDs.
Please avoid looking directly at the beam as it
may cause severe eye injuries.

English
IPairLED-5x12six - 5x12W 6-in-1 LEDs, airDMX, battery-operated waterproof projector
Page 3
1 - Please read carefully :
We strongly recommend to read carefully and understand
the safety instructions before attempting to operate this unit.
2 - Please keep this manual :
We strongly recommend to keep this manual with the unit for
future reference.
3 - Operate carefully this product :
We strongly recommend to take into consideration every
safety instruction.
4 - Follow the instructions:
Please carefully follow each safety instruction to avoid any
physical harm or property damage.
5 - Avoid water and wet locations :
Do not use this product in rain, or near washbasins or other
wet locations.
6 - Installation :
We strongly encourage you to only use a
fixation system or support recommended by
the manufacturer or supplied with this product.
Carefully follow the installation instructions and
use the adequate tools.
Always ensure this unit is firmly fixed to avoid
vibration and slipping while operating as it may result in
physical injury.
7 - Ceiling or wall installation :
Please contact your local dealer before attempting any ceiling
or wall installation.
8 - Ventilation :
The cooling vents ensure a safe use of this product, and avoid
any overheating risk.
Do not obstruct or cover these vents as it may result in
overheating and potential physical injury or product damage.
This product should never been operated in a closed non-
ventilated area such as a flight case or a rack, unless cooling
vents are provided for the purpose .
9 - Heat exposure :
Sustained contact or proximity with warm surfaces may cause
overheating and product damages. Please keep this product
away from any heat source such as a heaters, amplifiers, hot
plates, etc...
10 - Electric power supply :
This product can only be operated according to
a very specific voltage. These information are
specified on the label located at the rear of the
product.
11 - Power cords protection:
Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at lugs, convenience receptacles
and the point where they exit from the fixture.
Instructions and recommendations
12 - Cleaning precautions :
Unplug the product before attempting any cleaning
operation. This product should be cleaned only with
accessories recommended by the manufacturer.
Use a damp cloth to clean the surface. Do not
wash this product.
13 - Long periods of non use :
Disconnect the unit’s main power during long
periods of non use.
14 - Liquids or objects penetration :
Do not let any object penetrate this product as it
may result in electric shock or fire.
Never spill any liquid on this product as it may
infiltrate the electronic components and result in
electric shock or fire.
15 - This product should be serviced when :
Please contact the qualified service personnel if :
- The power cord or the plug has been damaged.
- Objects have fallen or liquid has been spilled into
the appliance.
- The appliance has been exposed to rain or water.
- The product does not appear to operate normally.
- The product has been damaged.
16 - Inspection/maintenance :
Please do not attempt any inspection or maintenance by
yourself. Refer all servicing to qualified personnel.
17 - Operating environment :
Ambient temperature: +5 - +35°C.
Do not operate this product in a non-ventilated or
warm place..

English IPairLED-5x12six - 5x12W 6-in-1 LEDs, airDMX, battery-operated waterproof projector
Page 4
2 - Introduction
3 - Technical specifications
4 - Optional accessories
• Its strength:
- 6-in-1 LEDs
- Unprecedented colours via UV light
- Manual and DMX modes, customisable user
programs, and auto programs.
- Multi-function remote control supplied
- Infrared sensor (front)
- Power input/output
• Functions:
- DMX Addressing
- Channels selection: from 3 to 10
- Built-in programs selection
- Preset colours selection
- Master/Slave mode
- Edit and play your own 20-step program
- Infrared remote control giving you access to every
remote function
• Package contents:
The package must contain the following products :
- A projector
- A user guide
- A double mounting bracket
- An infrared remote control
- A 2-pole + earth power cord
- 2 x IP/DMX cord (input and output)
This waterproof projector features 6-in-1 LEDs allowing you to create a whole palette of exclusive colours.
The 12W LEDs are perfect to deliver a powerful light output for ambient lighting or animations.
Its multi-function remote control and countless control modes allow it to perfectly fit any installation while offering a
vast selection of programs.
The double mounting bracket can be attached to a structure or directly on the ground, and adapts to the angle.
• Optical:
- 5 x 12W 6-in-1 LEDs - 30.000 hours
- Light output: 844 Lux at 3m
- Clear Crystal lenses allowing a perfect light diffusion
- Angle d’ouverture des lentilles : 25°
• Connectors:
- DMX IN and OUT via 3-pin IP plug
- POWER IN/OUT via 4-pin IP plug
-
• Power supply: 100-240V/50-60Hz
• Power consumption: 65 W
• IP level: IP65
• Finish: Noir
•
Dimensions : 240 x 165 x 280 mm
• Weight: 3,5 kg
• IP68 connectors:
- FICIP-DMXm - Male waterproof DMX connector: H10465
- FICIP-DMXf - Female waterproof DMX connector : H10466
- FICIP-POWm - Male waterproof Power connector: H10467
- FICIP-POWf - Female waterproof Power connector: H10468

English
IPairLED-5x12six - 5x12W 6-in-1 LEDs, airDMX, battery-operated waterproof projector
Page 5
5 - Description
1Power input socket
4-pin IP socket. Please use the supply cable to
connect it to the mains.
Please make sure the voltage is in adequation with
the product indications.
2DMX Input
3-pin male IP DMX connector hardwired as follows:
Mass: 1 / Négative signal: 2 / Positive signal: 3.
Use the supplied cable to send the signal to your
projector, either from another projector or from a
DMX controller.
3Power Button
Connects the internal battery.
Press this button to use your projector when it is not
connected to the mains.
Press this button to charge the battery when your
projector is connected to an electrical outlet.
4Power output socket
4-pin IP plug.
The IP cable required for this plug is not supplied.
Get the optional female IP connector FICIP-POWf
(10468) to use this socket.
Caution: Do NOT go over 650W on the same power
source.
5DMX Output
3-pin female IP socket.
3-pin female XLR socket hardwired identically to the
DMX input.
Use the supplied DMX cable to connect your
projector to other projectors.
Get the optional IP FICIP-DMXm (10465) and
FICIP-DMXf (10468) connectors to create DMX IP
connections.
6Release valve
Temperature variations during use and inactivity
periods affect the internal pressure.
7Display
This intuitive display allows you to configure your
projector. Please refer to the next paragraphs for
more details about the projector configuration.
8Display buttons
MODE
Allows you to access menus and select a function.
SETUP
Allows you to configure the parameters of the
functions chosen with the MODE button.
UP
Press UP to increase the adjustable values or browse
the sub-menus.
DOWN
Press DOWN to decrease the adjustable values or
browse the sub-menus.
9Stand
Allows you to handle the projector on the ground
and adjust its angle.
Power In
DMX In
Power Out
DMX Out
1
7
8
9
2
3 6
5
4
