Continental Fireplaces CDVS500N User manual

EN
W415-1430 / 01.13.15
FR
PG
53
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.continentalfireplaces.com • ask@continentalfire.on.ca
1.24C
$10.00
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
SAFETY INFORMATION
!WARNING
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by a
qualified installer, service agency or the supplier.
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
DANGER
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
Decorative Product: Not for use as a heating appliance.
BARRIER
CONFORMS TO AMERICAN NATIONAL STANDARDS: ANSI Z21.50, CERTIFIED TO CANADIAN CSA 2.22 FOR VENTED GAS FIREPLACES..
CDVS500N / CS500N
NATURAL GAS
CDVS500P / CS500P
PROPANE
SAFETY BARRIER

W415-1430 / 01.13.15
2
EN
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 GENERAL INSTRUCTIONS 6
2.3 GENERAL INFORMATION 7
2.4 RATING PLATE INFORMATION 8
3.0 VENTING 9
3.1 VENTING LENGTHS AND COMPONENTS 9
3.2 TYPICAL VENT INSTALLATION 10
3.3 SPECIAL VENT INSTALLATIONS 11
3.3.1 PERISCOPE TERMINATION 11
3.4 VENT TERMINAL CLEARANCES 12
3.5 VENTING APPLICATION FLOW CHART 13
3.6 DEFINITIONS 13
3.7 ELBOW VENT LENGTH VALUES 13
3.8 HORIZONTAL TERMINATION 14
3.9 VERTICAL TERMINATION 16
4.0 INSTALLATION 18
4.1 MINIMUM CLEARANCE TO COMBUSTIBLES 18
4.2 WALL AND CEILING PROTECTION 19
4.2.1 HORIZONTAL INSTALLATION 19
4.2.2 VERTICAL INSTALLATION 20
4.2.3 HORIZONTAL AIR TERMINAL INSTALLATION 21
4.2.4 VERTICAL AIR TERMINAL INSTALLATION 22
4.2.5 APPLIANCE VENT CONNECTION 23
4.2.6 VERTICAL THROUGH EXISTING CHIMNEY 24
4.3 B-VENT INSTALLATION - CS500 25
4.3.1 CHIMNEY INSTALLATION 25
4.3.2 INSTALLING FLASHING AND STORM COLLAR 25
4.3.3 ADDING VENT SECTIONS 26
4.3.4 INSTALLING NATURAL VENT 26
4.3.5 NATURAL VENT ADAPTATIONS 27
4.3.6 COMBUSTION AIR 27
4.4 GAS INSTALLATION 28
4.4.1 B-VENT - MODEL CS500 28
4.6 WALL SWITCH INSTALLATION 29
4.5 MOBILE HOME INSTALLATION 29
5.0 FINISHING 30
5.1 SAFETY SCREEN INSTALLATION AND REMOVAL 30
5.2 DOOR OPENING AND CLOSING 31
5.3 LOG PLACEMENT 32
5.4 LOGO PLACEMENT 33
5.5 TRIVET INSTALLATION 33
6.0 OPERATION 34
6.1 OPERATING INSTRUCTIONS 35
6.2 TURBO BURNER OPERATION 35
6.3 SPILL SWITCH - CS500 ONLY 35
7.0 ADJUSTMENTS 36
7.1 PILOT BURNER ADJUSTMENT 36
7.2 VENTURI ADJUSTMENT 36
7.3 FLAME CHARACTERISTICS 37
8.0 MAINTENANCE 37
8.1 ANNUAL MAINTENANCE 38
8.2 REPLACEMENT BLOWER INSTALLATION 39
8.3 CARE OF GLASS 39
8.4 CARE OF PLATED PARTS 39
9.0 REPLACEMENTS 40
10.0 OVERVIEW 41
11.0 VALVE TRAIN ASSEMBLY 42
12.0 ACCESSORIES 43
13.0 VENTING 44
14.0 TROUBLESHOOTING 45
15.0 WARRANTY 48
16.0 SERVICE HISTORY 49
17.0 NOTES 50

W415-1430 / 01.13.15
3
EN
1.0 INSTALLATION OVERVIEW
SAFETY BARRIER
Venting, see
“VENTING” section.
Door, see “DOOR
OPENING AND CLOSING”
section.
Trivet, see “TRIVET
INSTALLATION” section.
Logs, see “LOG
PLACEMENT” section.
Rating plate, see “RATING
PLATE INFORMATION”
section.

W415-1430 / 01.13.15
4
EN
2.0 INTRODUCTION
3.1D
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES TO THIS APPLIANCE OR IT’S CONTROLS CAN BE DANGEROUS AND IS PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to
operating instructions could cause fire or injury.
• Risk of fire or asphyxiation do not operate appliance with fixed glass removed.
• Do not connect 110 volts to the control valve.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges may be sharp.
• Do not burn wood or other materials in this appliance.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns
or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance.
Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the house. To restrict access to an appliance or stove, install an
adjustable safety gate to keep toddlers, young children and other at risk individuals out of the room and away from hot
surfaces.
• Clothing or other flammable material should not be placed on or near the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These
screens and guards must be fastened to the floor.
• Any safety screen, guard or barrier removed for servicing the appliance, must be replaced prior to operating the
appliance.
• The appliance is a vented gas-fired appliance. Do not burn wood or other materials in the appliance.
• The appliance area must be kept clear and free from combustible materials, gasoline and other flammable vapors and liquids.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance
and to replace any part of the control system and any gas control which has been under water.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should be done by a
licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• When equipped with pressure relief doors, they must be kept closed while the appliance is operating to prevent exhaust fumes
containing carbon monoxide, from entering into the home. Temperatures of the exhaust escaping through these openings can also
cause the surrounding combustible materials to overheat and catch fire.Only doors / optional fronts certified with the unit are to be
installed on the appliance.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all plastic bags, these
are not toys and should be kept away from children and infants.
• As with any combustion appliance, we recommend having your appliance regularly inspected and serviced as well as having a
Carbon Monoxide Detector installed in the same area to defend you and your family against Carbon Monoxide.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance. Elevated temperatures
on the wall or in the air above the appliance can cause melting, discolouration or damage to decorations, a T.V. or other electronic
components.
• A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance and shall be
installed.
• If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance.
• Installation and repair should be done by a qualified service person. The appliance should be inspected before use and
at least annually by a professional service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. It is imperative that control compartments, burners and circulating air passageways of
the appliance be kept clean.
• This appliance uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple supplied by Wolf Steel
Ltd.

W415-1430 / 01.13.15
5
EN
2.1 DIMENSIONS
GAS LINE LOCATED IN PEDESTAL REAR
28 1/4" 718mm
14 1/8" 359mm
21 5/8" 549mm
8" 203mm
7" 178mm
Ø AIR INTAKE
4" 102mm
Ø FLUE
13 3/4"
349mm
21"
533mm
30 3/4"
781mm
SAFETY
BARRIER
2"
51mm

W415-1430 / 01.13.15
6
EN
2.2 GENERAL INSTRUCTIONS
4.1B
THIS GAS APPLIANCE SHOULD BE INSTALLED AND SERVICED BY A QUALIFIED INSTALLER to
conform with local codes. Installation practices vary from region to region and it is important to know the
specifics that apply to your area, for example in Massachusetts State:
• This product must be installed by a licensed plumber or gas fitter when installed within the commonwealth
of Massachusetts.
• The appliance damper must be removed or welded in the open position prior to installation of an appliance
insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches (914mm).
• A Carbon Monoxide detector is required in all rooms containing gas fired appliances.
• The appliance is not approved for installation in a bedroom or bathroom unless the unit is a direct vent
sealed combustion product.
The installation must conform with local codes or, in
absence of local codes, the National Gas and Propane
Installation Code CSA B149.1 in Canada, or the National
Fuel Gas Code, ANSI Z223.1 / NFPA 54 in the United
States. Suitable for mobile home installation if installed in
accordance with the current standard CAN/CSA Z240MH
Series, for gas equipped mobile homes, in Canada or
A
NSI Z223.1 and NFPA 54 in the United States.
A
s long as the required clearance to combustibles is
maintained, the most desirable and beneficial location
for an appliance is in the center of a building, thereby
allowing the most efficient use of the heat created. The location of windows, doors and the traffic flow in the
room where the appliance is to be located should be considered. If possible, you should choose a location
where the vent will pass through the house without cutting a floor or roof joist.
If the appliance is installed directly on carpeting, vinyl tile or other combustible material other than wood
flooring, the appliance shall be installed on a metal or wood panel extending the full width and depth.
Some appliances have optional fans or blowers. If an optional fan or blower is installed, the junction box must
be electrically connected and grounded in accordance with local codes, use the current CSA C22.1 Canadian
Electrical Code in Canada or the ANSI/NFPA 70 National Electrical code in the United States.
We suggest that our gas
hearth products be installed
and serviced by professionals
who are certied in the U.S.
by the National Fireplace
Institute
® (NFI) as NFI Gas
Specialists
www.ncertied.org
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT,
WITH THE GLASS DOOR OPENED OR REMOVED.
PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE.
PROVIDE ADEQUATE VENTILATION.
NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.
OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48” (1219mm) FROM
THE FRONT FACE OF THE APPLIANCE.
SURFACES AROUND AND ESPECIALLY ABOVE THE APPLIANCE CAN BECOME HOT. AVOID CONTACT
WHEN THE APPLIANCE IS OPERATING.
FIRE RISK. EXPLOSION HAZARD.
HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE PRESSURE TESTING GAS
LINE AT TEST PRESSURES ABOVE 1/2 PSIG. CLOSE THE MANUAL SHUT-OFF VALVE BEFORE PRESSURE
TESTING GAS LINE AT TEST PRESSURES EQUAL TO OR LESS THAN 1/2 PSIG (35 mb).
USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE.
USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENTING
COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION.
!
WARNING

W415-1430 / 01.13.15
7
EN
2.3 GENERAL INFORMATION
For elevations between 2,000ft (610m) and 4,500ft (1372m) above sea level, this appliance must be
de-rated by 10% using the certified high altitude kit. When the appliance is installed at elevations above 4,500ft
(1372mm), and in the absence of specific recommendations from the local authority having jurisdiction, the
certified high altitude input rating shall be reduced at the rate of 4% for each additional 1,000ft (305m).
Change in flame appearance from "HI" to "LO" is more evident in natural gas than in propane. Expansion /
contraction noises during heating up and cooling down cycles are normal and to be expected.
CDVS500: This appliance is approved for bathroom, bedroom and
bed-sitting room installations and is suitable for mobile homes. The
natural gas model is suitable for installation in a mobile home that is
permanently positioned on its site and fueled with natural gas.
CS500: This appliance is approved for bedroom and bed-sitting room
installations.
70%
CDVS500
CS500 CDVS500
NG LP NG LP
Altitude (FT) 0-2000 0-2000 0-2000 0-2000
Max. Input (BTU/HR) 44,000 40,000 44,000 40,000
Max. Output Steady State (BTU/HR) 31,200 30,000 37,000 34,400
Efficiency (w/the fan on) 77% 78% 84% 86%
Maximum A.F.U.E. 65% 67% 77% 79%
Min. Inlet Gas Supply Pressure 4.5" (11mb)
Water Column
11" (27mb)
Water Column
4.5" (11mb)
Water Column
11" (27mb)
Water Column
Max. Inlet Gas Supply Pressure 7" (17mb)
Water Column
13" (330.2mm)
Water Column
7" (17mb)
Water Column
13" (330.2mm)
Water Column
Manifold Pressure (Under Flow
Conditions)
3.5" (9mb)
Water Column
10" (25mb)
Water Column
3.5" (9mb)
Water Column
10" (25mb)
Water Column
FOR YOUR SATISFACTION, THIS APPLIANCE HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION
AND QUALITY!

W415-1430 / 01.13.15
8
EN
2.4 RATING PLATE INFORMATION
For rating plate location, see "INSTALLATION OVERVIEW" section
INSTALLER: It is your responsibility to check off the appropriate box on the rating plate according to the
model, venting and gas type of the unit.
This illustration is for reference only. Refer to the rating plate on the appliance for accurate information.
SAMPLE
s
W385-1999
GDS50
GDS50-N
NATURAL GAS MODEL
CONFORMS TO / CONFORMEAUX:ANSI Z21.50-2014, CERTIFIEDTO / CERTIFIE CSA2.22-2014 VENTED GAS FIREPLACE / FOYER À GAZ VENTILÉ.
DIRECT VENT GAS FIREPLACEAPPROVED FOR BEDROOM, BATHROOM & BEDSITTING ROOM
INSTALLATION. SUITABLE FOR MOBILE HOME INSTALLATION IF INSTALLED INACCORDANCE WITHTHE
CURRENT STANDARD CAN/CSA Z240MH SERIES GAS EQUIPPED MOBILE HOMES, IN CANADAOR IN THE UNITED
STATES THE MANUFACTURED HOME CONSTRUCTION AND SAFETY STANDARD, TITLE 24 CFR, PART 3280.
WHEN THIS US STANDARD IS NOTAPPLICABLE USETHE STANDARD FOR FIRE SAFETY CRITERIA FOR
MANUFACTURED HOME INSTALLATIONS, SITES AND COMMUNITIES,ANSI / NFPA 501A. FOR USE ONLY WITH
BARRIER W565-0196. FOLLOW THE INSTALLATION INSTRUCTIONS LOCATED IN THE INSTALLATION MANUAL.
FOYER À GAZ VENTILÉS À ÉVACUATION DIRECTE. HOMOLOGUE POUR INSTALLATION DANS UNE CHAMBRE A COUCHER,
UNE SALLE DE BAIN ET UN STUDIO.APPROPRIE POUR INSTALLATION DANS UNE MAISON MOBILE SI SON INSTALLATION
CONFORME AUX EXIGENCES DE LANORME CAN/CSA Z240MH SERIE DE MAISONS MOBILES EQUIPEES AU GAZ, EN
VIGUEUR AU CANADAOU AUX ETATS-UNIS DE LANORME DE SECURITE ET DE CONSTRUCTION DE MAISONS
MANUFACTUREES,TITRE 24 CFR, SECTION 3280. DANS LE CAS OU CETTE NORME D'ETATS-UNIS NE PEUT ETRE
APPLIQUEE, SE REFERER ALA NORME RELATIVE AU CRITERE DE MESURES DE SECURITE CONTRE L'INCENDIE POUR
LES INSTALLATIONS DANS LES MAISONS MANUFACTURES, LES SITES ET LES COMMUNAUTES,ANSI/NFPA501A. POUR
UNE UTILISER SEULMENT AVEC BARRIÈRE W565-0196. SUIVEZ LES INSTRUCTIONS D'INSTALLATION SE TROUVENT
DANS LE MANUEL D'INSTALLATION.
MANIFOLD PRESSURE: 3.5 INCHES W.C. (NG)
PRESSION AU COLLECTEUR: 3.5" D'UNE
COLONNE D'EAU(GN)
MIN SUPPLY PRESSURE: 4.5" W.C.(NG)
PRESSION D'ALIMENTATION MIN: 4.5" D'UNE
COLONNE D'EAU (GN)
MAX. SUPPLY PRESSURE: 7" W.C. (NG)
PRESSION D'ALIMENTATION MAX: 7" D'UNE
COLONNE D'EAU (GN)
MANIFOLD PRESSURE: 10 INCHES W.C.(LP)
PRESSION AU COLLECTEUR: 10" D'UNE
COLONNE D'EAU (P)
MIN SUPPLY PRESSURE: 11" W.C. (LP)
PRESSION D'ALIMENTATION MIN: 11" D'UNE
COLONNE D'EAU (P)
MAX. SUPPLY PRESSURE: 13" W.C. (LP)
PRESSION D'ALIMENTATION MAX: 13" D'UNE
COLONNE D'EAU (P)
SERIAL NUMBER / NO. DESERIE
CDVS500-N GDS50-P CDVS50-P
PROPANE MODEL
WOLF STEEL LTD.
24 NAPOLEON ROAD, BARRIE, ON, L4M 0G8 CANADA
9700539 (WSL) 4001657 (NGZ)
4001658 (NAC) 4001659 (WUSA)
UTILISER AVEC LES PORTES VITREES HOMOLOGUEES SEULEMENT AVEC
CETTE UNITE.
AVERTISSEMENT: N'AJOUTEZ PAS ACETAPPAREILAUCUN MATERIAU
DEVANT ENTRER EN CONTACTAVEC LES FLAMMES AUTRE QUE CELUI QUI
EST FOURNIAVEC CETAPPAREILPAR LE FABRICANT.
PRODUIT DÉCORATIF: NE PAS UTILISER COMME APPARIEL DE CHAUFFAGE
*LES CONDITIONS DE BAISSE D’EVALUATION SELON L’ALTITUDE
S’APPLIQUENTAU CANADA SEULEMENT
ALTITUDE / ELEVATION
(0-610m) (610-1370m)
44,000 BTU/h 40,000 BTU/h *INPUT /ALIMENTATION*
20,000 BTU/h 18,000 BTU/h REDUCED INPUT /ALIMENTATION REDUITE
33,000 BTU/h 30,000 BTU/h OUTPUT(MODEL GDS50) RENDEMENT
31,200 BTU/h 28,400 BTU/h OUTPUT(MODEL GS50) RENDEMENT
GS50-N CS500-N GS50-P CS500-P
2000-4500FT 0-2000FT 2000-4500FT 0-2000FT
(0-610m)
40,000 BTU/h
21,000 BTU/h
30,400 BTU/h
30,000 BTU/h
26,400 BTU/h
27,400 BTU/h
18,000 BTU/h
36,000 BTU/h
(610-1370m)
*ALTITUDE DOWNRATING CONDITIONSAPPLY
TO CANADA ONLY /
P4 (NG/LP) / (GN/PL): 70% / 69.5%
70% / 69.5%
FOR USE WITH GLASS DOORS CERTIFIED WITH THIS UNIT ONLY.
WARNING: DO NOTADD ANY MATERIAL TO THEAPPLIANCE,
WHICH WILL COME IN CONTACT WITH THE FLAMES, OTHER THAN
THAT SUPPLIED BY THE MANUFACTURER WITHTHE APPLIANCE.
DECORATIVE PRODUCT: NOT FOR USE AS AHEATINGAPPLIANCE
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIAL /
DEGAGEMENTS MINIMAUX DES MATERIAUX COMBUSTIBLES:
A7" D17½"
B2" E6¼"
C1" F9½"
20" TO CEILING FROM STOVETOP
20" ENTRE LE DESSUS DU FOYER ET LE PLAFOND
ELECTRICAL RATING / CLASS.: 115V 1.5AMP 60HZ
NOT FOR USE WITH SOLID FUEL
UN COMBUSTIBLE SOLIDE NE DOIT PAS ETRE
UTILSE AVEC CET APPAREIL
MINIMUMAND MAXIMUM HORIZONTALVENTLENGTHSARE25INCHESAND 20FEETRESPECTIVELY.
LESLONGUEURS HORIZONTALESMINIMALE ETMAXIMALESONT25POUCES ET 20 PIEDSRESPECTIVEMENT.
B-VENT MODELS GS50/CS500
APPROVED FOR BEDROOM, & BEDSITTING ROOM INSTALLATION.
THIS APPLIANCE MUSTBE INSTALLED USINGAN ADAPTER
KIT GS-150KT.
B-VENT MODELS GS50/CS500
HOMOLOGUE POUR INSTALLATION DANS UNE CHAMBREA COUCHER, & UN STUDIO.
CETAPPAREIL DOITETRE INSTALLE EN UTILISANT UN ENSEMBLEADAPTATEUR
GS-150KT.
A barrier designed to reduce the risk of burns from the hot viewing glass is provided with the appliance
and shall be installed.

W415-1430 / 01.13.15
9
EN
3.0 VENTING
7.1C
THIS APPLIANCE USES A 4” (102mm) EXHAUST / 7” (178mm) AIR INTAKE VENT PIPE SYSTEM.
Refer to the section applicable to your installation.
For safe and proper operation of the appliance follow the venting instruction exactly. Deviation from the
minimum vertical vent length can create difficulty in burner start-up and/or carboning. Under extreme
vent configurations, allow several minutes (5-15) for the flame to stabilize after ignition. Although not a
requirement, it is recommended for vent lengths that pass through unheated spaces (attics, garages, crawl
spaces) be insulated with the insulation wrapped in a protective sleeve to minimize condensation. Provide
a means for visually checking the vent connection to the appliance after the appliance is installed. Use a
firestop, vent pipe shield or attic insulation shield when penetrating interior walls, floor or ceiling.
NOTE: If for any reason the vent air intake system is disassembled; reinstall per the instructions
provided for the initial installation.
!
WARNING
RISK OF FIRE, MAINTAIN SPECIFIED AIR SPACE CLEARANCES TO VENT PIPE AND APPLIANCE.
IF VENTING IS INCLUDED WITH SPACERS THE VENT SYSTEM MUST BE SUPPORTED EVERY 3FT
(0.9m) FOR BOTH VERTICAL AND HORIZONTAL RUNS. USE SUPPORTS OR EQUIVALENT
NON-COMBUSTIBLE STRAPPING TO MAINTAIN THE REQUIRED CLEARANCE FROM
COMBUSTIBLES. USE WOLF STEEL LTD. SUPPORT RING ASSEMBLY W010-0370 OR EQUIVALENT
NON-COMBUSTIBLE STRAPPING TO MAINTAIN THE MINIMUM CLEARANCE TO COMBUSTIBLES
FOR BOTH VERTICAL AND HORIZONTAL RUNS. SPACERS ARE ATTACHED TO THE INNER PIPE AT
PREDETERMINED INTERVALS TO MAINTAIN AN EVEN AIR GAP TO THE OUTER PIPE. THIS GAP IS
REQUIRED FOR SAFE OPERATION. A SPACER IS REQUIRED AT THE START, MIDDLE AND END OF
EACH ELBOW TO ENSURE THIS GAP IS MAINTAINED. THESE SPACERS MUST NOT BE REMOVED.
3.1 VENTING LENGTHS AND COMPONENTS
Use only Wolf Steel, Simpson Dura-Vent, Selkirk Direct Temp, American Metal Amerivent or Metal-Fab venting
components. Minimum and maximum vent lengths, for both horizontal and vertical installations, and air terminal
locations for either system are set out in this manual and must be adhered to. For Simpson Dura-Vent, Selkirk
Direct Temp, American Metal Amerivent and Metal-Fab follow the installation procedure provided with the venting
components.
A starter adaptor must be used with the following vent systems and may be purchased from the corresponding
supplier:
* For Simpson Dura-Vent, Selkirk Direct Temp, American Metal Amerivent and Metal-Fab follow the
installation procedure found on the website for your venting supplier.
For vent systems that provide seals on the inner exhaust flue, only the outer air intake joints must be sealed using a
red high temperature silicone (RTV). This same sealant may be used on both the inner exhaust and outer intake vent
pipe joints of all other approved vent systems except for the exhaust vent pipe connection to the appliance flue collar
which must be sealed using the black high temperature sealant Mill Pac.
When using Wolf Steel venting components, use only approved Wolf Steel termination kits: wall terminal kit GD175
(7/12’ of venting included), or 1/12 to 7/12 pitch roof terminal kit GD110, 8/12 to 12/12 roof terminal kit GD111, flat
roof terminal kit GD112 or periscope kit GD180 (for wall penetration below grade) in conjunction with the appropriate
venting components.
PART 4”/7” (102mm/ 178mm) SUPPLIER WEBSITE
Duravent GDS924N Wolf Steel www.duravent.com
Amerivent 4DSC-N2 American Metal www.americanmetalproducts.com
Direct Temp 4DT-AAN Selkirk www.selkirkcorp.com
SuperSeal 4DNA Metal-Fab www.mtlfab.com

W415-1430 / 01.13.15
10
EN
3.2 TYPICAL VENT INSTALLATION
For optimum flame appearance and appliance operation, keep the vent length and number of elbows to a
minimum. It is recommended that all horizontal runs have a minimum 1/4” (6.4mm) rise per foot /meter. The
air terminal must remain unobstructed at all times. Examine the air terminal at least once a year to verify
that it is unobstructed and undamaged. Rigid and flexible venting systems must not be combined. Different
venting manufacturers components must not be combined.
These vent kits allow for either horizontal or vertical venting of the appliance. The maximum allowable horizontal
run is 20 feet (6m). The maximum allowable vertical vent length is 40 feet (12m). The maximum number of vent
connections is two horizontally or three vertically (excluding the appliance and the air terminal connections) when
using flexible venting.
Deviation from the minimum vertical vent length can create difficulty in burner start-up and/or carboning.
Use an adjustable pipe as the final length of rigid piping to the stove for ease of installation.
8.5A
16" (406mm)
MINIMUM
40 FT
(12m)
MAXIMUM
36" (914mm)
MINIMUM
30 3/4"
(781mm)
59 3/4"
(1518mm)
MINIMUM
PLUS RISE*
34" (864mm)
MAXIMUM
* See "VENTING" section
29" (737mm)
MINIMUM
30 3/4"
(781mm)

W415-1430 / 01.13.15
11
EN
3.3 SPECIAL VENT INSTALLATIONS
3.3.1 PERISCOPE TERMINATION
Use the periscope kit to locate the air termination above grade. The periscope must
be installed so that when final grading is completed, the bottom air slot is located a
minimum 12” (305m) above grade. The maximum allowable vent length is 10’ (3m)
for a fireplace and 8’ (2m) for a stove.
9.1B
29" (737mm) MIN
REGARDLESS OF
HORIZONTAL VENT LENGTH
12" (305mm)
MINIMUM
TO GRADE
30 3/4"
(781mm)

W415-1430 / 01.13.15
12
EN
3.4 VENT TERMINAL CLEARANCES
INSTALLATIONS
CANADA U.S.A.
A12” (305mm) 12” (305mm) Clearance above grade, veranda porch, deck or balcony.
B12” (305mm)Δ9”
(229mm)ΔClearance to windows or doors that open.
C12” (305mm)* 12” (305mm) * Clearance to permanently closed windows.
D18”
(457mm)** 18” (457mm)** Vertical clearance to ventilated soffits located above the terminal within a horizontal distance of 2’ (0.6m) from the center line of the terminal.
E12” (305mm)** 12” (305mm)** Clearance to unventilated soffit.
F0” (0mm) 0” (0mm) Clearance to an outside corner wall.
G
0” (0mm)*** 0”
(0mm)***
Clearance to an inside non-combustible corner wall or protruding non-combustible obstructions (chimney,
etc.).
2” (51mm)*** 2”
(51mm)***
Clearance to an inside combustible corner wall or protruding combustible obstructions (vent chase,
etc.).
H3’(0.9m) 3’ (0.9m)**** Clearance to each side of the center line extended above the meter / regulator assembly to a
maximum vertical distance of 15’ (4.6m).
I3’ (0.9m) 3’ (0.9m)**** Clearance to a service regulator vent outlet.
J12” (305mm) 9” (229mm) Clearance to a non-mechanical air supply inlet to the building or a combustion air inlet to any other
appliance.
K6’ (1.8m) 3’ (0.9m) † Clearance to a mechanical air supply inlet.
L7’ (2.1m) ‡ 7’ (2.1m) **** Clearance above a paved sidewalk or paved driveway located on public property.
M12”
(305mm)††
12”
(305mm)**** Clearance under a veranda, porch or deck.
N16” (406mm) 16” (406mm) Clearance above the roof.
O2’ (0.6m)†* 2’ (0.6m) †* Clearance from an adjacent wall including neighbouring buildings.
P8’ (2.4m) 8’(2.4m) Roof must be non-combustible without openings.
Q3’ (0.9m) 3’ (0.9m) See chart for wider wall dimensions.
R6’ (1.8m) 6’ (1.8m) See chart for deeper wall dimensions. The terminal shall not be installed on any wall that has an
opening between the terminal and the open side of the structure.
S12” (305mm) 12” (305mm) Clearance under a covered balcony
ΔThe terminal shall not be located less than 6 feet under a window that opens on a horizontal plane in a structure with three walls and a roof.
* Recommended to prevent condensation on windows and thermal breakage
** It is recommended to use a heat shield and to maximize the distance to vinyl clad soffits.
*** The periscope requires a minimum 18 inches clearance from an inside corner.
**** This is a recommended distance. For additional requirements check local codes.
† 3 feet above if within 10 feet horizontally.
‡ A vent shall not terminate where it may cause hazardous frost or ice accumulations on adjacent property surfaces.
†† Permitted only if the veranda, porch, or deck is fully open on a minimum of two sides beneath the floor.
†* Recommended to prevent recirculation of exhaust products. For additional requirements check local codes.
††* Permitted only if the balcony is fully open on a minimum of one side.
12.1D
NOTE: Clearances are in accordance with local installation codes and the requirements of the gas supplier.
COVERED BALCONY APPLICATIONS ††*
QMIN RMAX MAX
R
= 3 feet
(0.9m) = 2 x IHHW
(4.6m)
QACTUAL
R
QS
GP

W415-1430 / 01.13.15
13
EN
13.1A
TOP EXIT
Horizontal Termination Vertical Termination
Vertical rise is equal
to or greater than
the horizontal run
Vertical rise is less
than horizontal run
Vertical rise is equal
to or greater than
the horizontal run
Vertical rise is less
than horizontal run
Horizontal run +
vertical rise to
maximum of 40 feet
(12m)
Horizontal run +
vertical rise to
maximum of
24.75 feet (7.5m)
Horizontal run +
vertical rise to Horizontal run +
vertical rise to
4.2 times the
vertical rise equal to
or greater than the
horizontal run
3 times the vertical
rise equal to or
greater than the
horizontal run
maximum of 40 feet
(12m) maximum of 40 feet
(12m)
14.1
For the following symbols used in the venting calculations and examples are:
> - greater than
> - equal to or greater than
< - less than
< - equal to or less than
HT- total of both horizontal vent lengths (Hr) and offsets (Ho) in feet
HR- combined horizontal vent lengths in feet
HO- offset factor: .03 (total degrees of offset - 90°*) in feet
VT- combined vertical vent lengths in feet
15.1A
FEET INCHES MILLIMETERS
1° 0.03 0.5 12.7
15° 0.45 6.0 152.4
30° 0.9 11.0 279.4
45° 1.35 16.0 406.4
90°* 2.7 32.0 812.8
* The first 90° offset has a zero value and is shown in the formula as - 90°
3.5 VENTING APPLICATION FLOW CHART
3.6 DEFINITIONS
3.7 ELBOW VENT LENGTH VALUES

W415-1430 / 01.13.15
14
EN
3.8 HORIZONTAL TERMINATION
16.10A
Simple venting configuration (only one 90° elbow)
02.5
(0.8) 5 (1.5) 7.5 (2.3) 10 (3.1) 12.5 (3.8) 15 (5.6)
40 (12.2)
10 (3.1)
20 (6.1)
30 (9.1)
17.5
(5.3) 20 (6.1)
39 (11.9)
REQUIRED
VERTICAL RISE
IN FEET
(METERS)VT
HORIZONTAL VENT RUN PLUS OFFSET IN
FEET (METERS) HT
(HT) < (VT)
For vent configurations requiring more than one 90° elbow, the following formulas apply:
Formula 1: HT< VT
Formula 2: HT+ VT< 40 feet (12.2m)
Example:
V1= 3 FT (0.9m)
V2= 8 FT (2.4m)
VT= V1+ V2= 3 FT (0.9m) + 8 FT (2.4m) = 11 FT (3.4m)
H1= 2.5 FT (0.8m)
H2= 2 FT (0.6m)
HR= H1+ H2= 2.5 FT (0.8m) + 2 FT (0.6m) = 4.5 FT (1.4m)
HO= .03 (three 90° elbows - 90°) = .03 (270° - 90°) = 5.4 FT (1.7m)
HT= HR+ HO= 4.5 FT (1.4m) + 5.4 FT (1.7m) = 9.9 FT (3m)
HT+ VT= 9.9 FT (3m) + 11 FT (3.4m) = 20.9 FT (6.4m)
Formula 1: HT< VT
9.9FT (3m) <11 FT (3.4m)
Formula 2: HT+ VT< 40 FT (12.2m)
20.9 FT (6.4m) < 40 FT (12.2m)
Since both formulas are met, this vent configuration is acceptable.
See graph to determine the required vertical
rise VTfor the required horizontal run HT.
The shaded area within the lines represents
acceptable values for HTand VT
90°
90°
90°
V1
V2
H1
H2

W415-1430 / 01.13.15
15
EN
(HT) > (VT)
Simple venting configuration (only one 90° elbow) See graph to determine the required vertical rise VTfor the
required horizontal run HT.
REQUIRED
VERTICAL RISE
IN INCHES
(MILLIMETERS)VT
For vent configurations requiring more than one 90° elbow, the following formulas apply:
Formula 1: HT< 4.2 VT
Formula 2: HT+ VT < 24.75 feet (7.5m)
Example:
V
1 = VT = 6 FT (1.8m)
H1 = 3 FT (0.9m)
H2 = 5 FT (1.5m)
HR = H1 + H2 = 3FT (0.9m + 5FT (1.5m) = 8FT (2.4m)
HO = .03 (two 90° elbows - 90°) = .03 (180° - 90°) = 2.7FT (0.8m)
HT =HR + HO = 8FT (2.4m) + 2.7FT (0.8m) = 10.7FT (3.3m)
HT + VT = 10.7FT (3.3m) + 6FT (1.8m) = 16.7FT (5.1m)
Formula 1: HT < 4.2 VT
4.2 VT =4.2FT (1.3m) x 6FT (1.8m) = 25.2 FT (7.7m)
10.7FT (3.3m) < 25.2FT (7.7m)
Formula 2: HT + VT < 24.75 FT (7.5m)
16.7FT (5.1m) < 24.75 FT (7.5m)
Since both formulas are met, this vent configuration is acceptable.
HORIZONTAL VENT RUN PLUS OFFSET IN FEET (METERS)HT
The shaded area within the lines represents acceptable
values for HT and VT
90°
V1
H1H2
90°
Example:
V
1 = 4 FT (1.2m)
V
2 = 1.5 FT (0.5m)
V
T = V1 + V2 = 4FT (1.2m) + 1.5FT (0.5m) = 5.5 FT (1.7m)
H1 = 2 FT (0.6m)
H2 = 1 FT (0.3m)
H3 = 1 FT (0.3m)
H4 = 1.5 FT (0.5m)
HR = H1 + H2 + H3 + H4= 2FT (0.6m) + 1FT (0.3m) + 1FT (0.3m) + 1.5FT (1.7m) = 5.5 FT (1.7m)
HO = .03 (four 90° elbows - 90°) = .03 (360° - 90°) = 8.1 FT (2.5m)
HT =HR + HO = 5.5FT (1.7m) + 8.1FT (2.5m) = 13.6 FT (4.2m)
HT + VT = 13.6 FT (4.2m) + 5.5 FT (1.7m) = 19.1 FT (5.8m)
Formula 1: HT < 4.2 VT
4.2 VT =4.2 FT (1.3m) x 5.5 FT (1.7m) = 23.1 FT (7m)
13.6 FT (4.2m) < 23.1 FT (7m)
Formula 2: HT + VT < 24.75 FT (7.5m)
19.1FT (5.8m) < 24.75 FT (7.5m)
Since both formulas are met, this vent configuration is acceptable.
90°
90°
90° 90°
H1
H2
V1
V2
H3
H4
29 (736.6)
05
(1.5) 15 (4.6) 20
(6.1)
100 (2540)
50 (1270)
150 (3810)
2.5
(0.8)
10
(3.1)
16.10_2A

W415-1430 / 01.13.15
16
EN
3.9 VERTICAL TERMINATION
(HT) < (VT)
Simple venting configurations. See graph to determine the required vertical rise VTfor the
required horizontal run HT.
REQUIRED
VERTICAL
RISE IN FEET
(METERS) VT
HORIZONTAL VENT RUN PLUS OFFSET IN FEET (METERS) HT
For vent configurations requiring one or more 90° elbows the following formulas apply:
Formula 1: HT< VT
Formula 2: HT+ VT < 40 feet (12.2m)
Example:
V1 = 5 FT (1.5m)
V2 = 6 FT (1.8m)
V3 = 10 FT (3.1m)
VT = V1 + V2 + V3 = 5FT (1.5m) + 6FT (1.8m) + 10FT (3.1m) = 21FT (6.4m)
H1 = 8 FT (2.4m)
H2 = 2.5 FT (0.8m)
HR = H1 + H2 = 8FT (2.4m) + 2.5FT (0.8m) = 10.5 FT (3.2m)
HO = .03 (four 90° elbows - 90°)
= .03 (360° - 90°) = 8.1 FT (2.5m)
HT =HR + HO = 10.5FT (3.2m) + 8.1FT (2.5m) = 18.6FT (5.7m)
HT + VT = 18.6FT (5.7m) + 21FT (6.4m) = 39.6FT (12.1m)
Formula 1: HT < VT
18.6FT (5.7m) < 21FT (6.4m)
Formula 2: HT + VT < 40 FT (12.19m)
39.6FT (12.1m) < 40FT (12.2m)
Since both formulas are met, this vent configuration is acceptable.
90°
V1
V2
H1
H2
The shaded area within the lines represents acceptable
values for HT and VT
90°
90°
90°
05
(1.5) 10 (3.1) 15 (4.6) 20 (6.1)
40 (12.2)
10 (3.1)
20 (6.1)
30 (9.1)
3 (0.9)
V3
18.1A

W415-1430 / 01.13.15
17
EN
(HT) > (VT)
Simple venting configurations. See graph to determine the required vertical rise VTfor the
required horizontal run HT.
REQUIRED
VERTICAL
RISE IN FEET
(METERS) VT
HORIZONTAL VENT RUN PLUS OFFSET IN FEET (METERS) HT
For vent configurations requiring more than two 90° elbows the following formulas apply:
Formula 1: HT< 3VT
Formula 2: HT+ VT < 40 feet (12.2m)
Example:
V1 = 2 FT (0.6m)
V2 = 1 FT (0.3m)
V3 = 1.5 FT (0.5m)
VT = V1+V2+V3= 2FT (0.6m) + 1FT (0.3m) + 1.5FT (0.5m) = 4.5FT (1.4m)
H1 = 6 FT (1.8m)
H2 = 2 FT (0.6m)
HR = H1 + H2 = 6FT (1.8m) + 2FT (0.6m) = 8 FT (2.4m)
HO = .03 (four 90° elbows - 90°)
= .03 (360° - 90°) = 8.1 FT (2.5m)
HT =HR + HO = 8FT (2.4m) + 8.1FT (2.5m) = 16.1FT (4.9m)
HT + VT = 16.1FT (4.9m) + 4.5FT (1.4m) = 20.6 FT (6.3m)
Formula 1: HT < 3VT
3VT = 3FT (0.9m) x 4.5FT (1.4m) = 13.5FT (4.1m)
16.1FT (4.9m) > 13.5FT (4.1m)
Since this formula is not met, this vent configuration is unacceptable.
Formula 2: HT + VT < 40 feet (12.2m)
20.6FT (6.3m) < 40 (12.2m)
Since only formula 2 is met, this vent configuration is unacceptable and a new appliance location or vent configuration will
need to be established to satisfy both formulas.
The shaded area within the lines represents acceptable
values for HT and VT
05
(1.5) 10 (3.1) 15 (4.6) 20 (6.1)
10 (3.1)
20 (6.1)
3 (0.9)
25
(7.6) 30 (9.1)
19 (5.8)
90°
V1V2
H1
H2
90°
90°
90°
V3
18.1_2B

W415-1430 / 01.13.15
18
EN
4.0 INSTALLATION !
WARNING
ENSURE TO UNPACK ALL LOOSE MATERIALS FROM INSIDE THE FIREBOX PRIOR TO HOOKING UP
THE GAS AND ELECTRICAL SUPPLY.
IF YOUR APPLIANCE IS SUPPLIED WITH A REMOTE ENSURE THE REMOTE RECEIVER IS IN THE
“OFF” POSITION PRIOR TO HOOKING UP THE GAS AND ELECTRICAL SUPPLY TO THE APPLIANCE.
FOR SAFE AND PROPER OPERATION OF THE APPLIANCE, FOLLOW THE VENTING INSTRUCTIONS
EXACTLY.
ALL INNER EXHAUST AND OUTER INTAKE VENT PIPE JOINTS MAY BE SEALED USING EITHER RED
RTV HIGH TEMP SILICONE SEALANT W573-0002 (NOT SUPPLIED) OR BLACK HIGH TEMP MILL PAC
W573-0007 (NOT SUPPLIED) WITH THE EXCEPTION OF THE APPLIANCE EXHAUST FLUE COLLAR
WHICH MUST BE SEALED USING MILL PAC.
IF USING PIPE CLAMPS TO CONNECT VENT COMPONENTS, 3 SCREWS MUST ALSO BE USED TO
ENSURE THE CONNECTION CANNOT SLIP OFF.
DO NOT CLAMP THE FLEXIBLE VENT PIPE.
RISK OF FIRE, EXPLOSION OR ASPHYXIATION. IMPROPER SUPPORT OF THE ENTIRE VENTING
SYSTEM MAY ALLOW VENT TO SAG AND SEPARATE. USE VENT RUN SUPPORTS AND CONNECT
VENT SECTIONS PER INSTALLATION INSTRUCTIONS.
RISK OF FIRE, DO NOT ALLOW LOOSE MATERIALS OR INSULATION TO TOUCH THE VENT PIPE.
REMOVE INSULATION TO ALLOW FOR THE INSTALLATION OF THE ATTIC SHIELD AND TO
MAINTAIN CLEARANCES TO COMBUSTIBLES.
68.2B
4.1 MINIMUM CLEARANCE TO COMBUSTIBLES
As long as clearance to combustibles is kept within required distances, the most desirable and beneficial location for an
appliance is in the centre of a building, thereby allowing the most efficient use of the heat created. The location of windows,
doors and the traffic flow in the room where the appliance is to be located should be considered. If possible, you should
choose a location where the vent will pass through the house without cutting a floor or roof joist.
MAINTAIN THESE MINIMUM CLEARANCES TO COMBUSTIBLES:
A. 7" (178mm) B. 2" (51mm) C. 1" (25mm)*
D. 17 1/2" (445mm) E. 6 1/4" (159mm) F. 9 1/2" (241mm)
Minimum 20" (508mm) from appliance top to ceiling
* At a distance of 1" (25mm) from the wall, access to the blower switch, on-off switch or the blower power cord
may not be practical.
EB
A
D
B
A
A45°
C
F
SIDE WALL
BACK WALL
SIDE WALL
BACK WALL
ALCOVE
CDVS500:
HORIZONTAL VENT SECTIONS: A minimum clearance of 2" (51mm) at the top and 1" (25mm) at the bottom
and sides of the vent pipe on all horizontal runs is required.
VERTICAL VENT SECTIONS: A minimum of 1" (25mm) all around the vent pipe on all vertical runs to
combustibles is required.
CS500:
A minimum of 1" (25mm) all around the B-vent pipe on both horizontal and vertical runs to combustibles is
required

W415-1430 / 01.13.15
19
EN
4.2 WALL AND CEILING PROTECTION
For clearances to combustible materials from the vent pipe, see “MINIMUM CLEARANCE TO
COMBUSTIBLES” section.
For optimum performance it is recommended that horizontal runs have a 1/4" (6.4mm) per rise per 1 ft (0.3m).
All inner exhaust and outer intake vent pipe joints may be sealed using either red high temp silicone sealant or
black high temp Mil Pac with the exception of the appliance exhaust flue collar which must be sealed using Mil
Pac (not supplied).
!
WARNING
DO NOT FILL THE SPACE BETWEEN THE VENT PIPE AND ENCLOSURE WITH ANY TYPE OF
MATERIAL. DO NOT PACK INSULATION OR COMBUSTIBLES BETWEEN CEILING FIRESTOPS.
ALWAYS MAINTAIN SPECIFIED CLEARANCES AROUND VENTING AND FIRESTOP SYSTEMS.
INSTALL WALL SHIELDS AND FIRESTOPS AS SPECIFIED. FAILURE TO KEEP INSULATION OR
OTHER MATERIALS AWAY FROM VENT PIPE MAY CAUSE FIRE.
70.1
This application occurs when venting through an exterior wall.
Having determined the correct height for the air terminal
location, cut and frame a hole in the exterior wall as
illustrated to accommodate the firestop assembly.
Dry fit the firestop assembly before proceeding to
ensure the brackets on the rear surface fit to the
inside surface of the horizontal framing.
The length of the vent shield may be cut shorter
for combustible walls that are less than 8 1/2”
(215.9mm)thick but the vent shield must extend the
full depth of the combustible wall.
A
. Assemble the shield to the spacer as shown,
using the 3 shorter screws supplied.
B. Place the firestop top so that the vent shield covers the top
of the vent within the opening. Ensure that both spacer and
shield maintain the required clearance to combustibles.
C. Secure the spacer in place using the 4 longer screws supplied. Once the vent pipe is installed in its
final position, apply sealant between the pipe and the firestop spacer.
DETERMINE
THE
CORRECT
HEIGHT
FIRESTOP
SPACER
VENT
SHIELD
FINISHING
MATERIAL
CAULKING
20.5B
!
WARNING
THE FIRESTOP ASSEMBLY MUST BE INSTALLED WITH THE VENT SHIELD TO THE TOP.
TERMINALS MUST NOT BE RECESSED INTO A WALL OR SIDING MORE THAN THE DEPTH OF THE
RETURN FLANGE OF THE MOUNTING PLATE.
4.2.1 HORIZONTAL INSTALLATION

W415-1430 / 01.13.15
20
EN
4.2.2 VERTICAL INSTALLATION
This application occurs when venting through a roof. Installation kits for
various roof pitches are available from your authorized dealer / distributor. See
accessories to order specific kits required.
A. Determine the air terminal location, cut and frame a square opening as
illustrated in the ceiling and the roof to provide the minimum 1“ (25mm)
clearance between the vent pipe and any combustible material. Try to center
the vent pipe location midway between two joists to prevent having to cut
them. Use a plumb bob to line up the center of the openings. A vent pipe
shield will prevent any materials such as insulation, from filling up the 1”
(25mm) air space around the pipe. Nail headers between the joist for
extra support.
B. Apply a bead of caulking (not supplied) to the framework or to the Wolf
Steel vent pipe shield plate or equivalent (in the case of a finished ceiling),
and secure over the opening in the ceiling. A firestop must be placed on the
bottom of each framed opening in a roof or ceiling that the venting system passes
through. Apply a bead of caulking all around and place a firestop spacer over
the vent shield to restrict cold air from being drawn into the room or around the
fireplace. Ensure that both spacer and shield maintain the required clearance to
combustibles. Once the vent pipe is installed in its final position, apply sealant between the
pipe and the firestop assembly.
C. In the attic, slide the vent pipe collar down to cover up the open end of the shield and
tighten. This will prevent any materials, such as insulation, from filling up the 1” (25mm) air
space around the pipe. 21.1
CAULKING
VENT PIPE
SHIELD
FIRESTOP
UNDERSIDE OF
JOIST
VENT
PIPE
COLLAR
VENT
PIPE
SHIELD
