Contrik CPT CB Series User manual

Instruction manual
Power Turtle Active
CPT-*-CB
UNMATCHED RELIABILITY AND SAFETY
EN

2Instruction manual |BDA 684
CONTRIK IPower Turtle Xtreme IPGD-00XX
1. General
Product group:
PGD-0023
The information in this manual applies exclusively to
the devices described in this manual and all variants of
the CONTRIK CPT series. Depending on the design
of the devices and due to different components,
there may be optical deviations with the illustrations
in the manual. In addition, the devices may differ
from each other functionally or in their operation.
In addition to these operating instructions, other
instructions (e.g. device components) may be included
in the scope of delivery, which must be observed in
full. In addition, improper use can cause hazards
such as short circuits, fire, electric shock, etc. Only
pass the product on to third parties in its original
packaging or with this operating manual.
For the safe use of the product, the national, legal
regulations and provisions (e.g. accident prevention
and occupational health and safety regulations as
well as environmental regulations) of the respective
country must also be observed. All company names
and product designations contained herein are
trademarks of their respective owners. All rights
reserved. For safety and approval reasons (CE), you
may not modify and/or change the product. The
product is not intended for use in the medical field.
The product is not intended for use in explosive or
flammable environments.
Please pay attention to the national regulations:
For Germany, it is a mobile equipment and
therefore the instructions of the DGUV
regulation 3 have to be followed.
2. Check delivery
• Power Turtle Xtreme
• Electrical test report according to
VDE 0701/0702
CONTRIK
Power Turtle Active

3Instruction manual |BDA 684
CONTRIK IPower Turtle Xtreme IPGD-00XX
3. Safety instructions
Read the operating instructions
carefully and observe the safety
instructions in particular.
If you do not follow the safety
instructions and the information on
proper handling in this operating
manual, we will not accept any
liability for any resulting personal
injury/property damage.
In addition, the warranty/guarantee
will be voided in such cases.
This symbol means: Read the
operating instructions.
• The product is not a toy. Keep it away from
children and pets.
• It voids the warranty, in case of manual
modifications of the device.
• Do not look into activated lamp. Possibly harmful
to the eye.
• Wearing safety gloves is recommended to
avoid pinch injuries and burns at high ambient
temperatures.
• Protect the product from extreme temperatures,
direct sunlight, strong vibrations, high humidity,
strong water jets, falling objects, flammable gases,
vapors and solvents.
• Do not subject the product to very high mechanical
stress.
• If safe operation is no longer possible, take the
product out of operation and protect it from
unintended use. Safe operation is no longer
guaranteed if the product:
shows visible damage,
no longer functions properly,
has been stored under unfavorable ambient
conditions for an extended period of time, or
has been subjected to considerable transport
stresses.
• Handle the product with care. The product may be
damaged by shocks, impacts or dropping.
• Also observe the safety instructions and operating
instructions of the other devices that are connected
to the product.
• There are parts inside the product that are under
high electrical voltage. Never remove covers.
There are no user-serviceable parts inside the unit.
• Residual current circuit breakers (FI and FI/LS) must
be checked for their function by pressing the test
button before each use and at least once a month.
If the residual current circuit breaker does not trip,
it must be checked or replaced immediately.
• Use a properly insulated 5-pole CEE cable to
connect the device to the 400 V mains. Do not
make any changes to the CEE cable and the CEE
plug devices. Failure to do so may result in an
electric shock and pose a risk of fire or death. If
you are unsure, contact an authorized electrical
technician.
• Never plug in or unplug power plugs with wet
hands.
• Only use a proper 5-pin CEE mains socket (400 V/
AC, 50 Hz) approved by a qualified person as the
power source.
• When supplying power to the device, make sure
that the cable cross-section of the connecting
cable is sufficiently dimensioned according to
national norms.
• Never connect the product to the power supply
immediately after it has been moved from a cold
room to a warm room (e.g. during transport). The
resulting condensation water can possibly destroy
the device or lead to an electric shock! Allow the
product to come to room temperature first.
• Wait until the condensation water has evaporated,
this may take several hours. Only then may the
product be connected to the power supply and
put into operation.
• Do not overload the product. Observe the
connected load in the technical data.
• Do not operate the product covered! At higher
connected loads, the product heats up, which
can lead to overheating and possibly fire when
covered.
• The product is only de-energized when the mains
plug is pulled out.
• Make sure that the product is de-energized before
connecting a device to it.
• The mains plug must be disconnected from the
socket under the following conditions: before
cleaning the product during thunderstorms when
the product is not used for a long period of time.

4Instruction manual |BDA 684
CONTRIK IPower Turtle Xtreme IPGD-00XX
4. Requirements for installer and
operator
The operator is responsible for the proper use and
safe operation of the manifold. When the manifold
is operated by non-professionals, the installer and
operator must ensure that the following requirements
are met:
• Ensure that the manual is permanently stored and
available at the manifold.
• Ensure that the layperson has read and understood
the instructions.
• Ensure that the layperson is instructed in the
operation of the manifold before using it.
• Ensure that the layperson only uses the distributor
as intended.
• Ensure that persons who cannot assess the dangers
involved in handling the distributor (e.g. children
or persons with disabilities) are protected.
• Ensure that a qualified electrician is consulted in
the event of malfunctions.
• Ensure that the national accident prevention and
work regulations are observed.
5. Operating instructions ________
• Never pour out liquids on top of or next to
the product. There is a high risk of fire or
life-threatening electric shock. If liquid should
nevertheless get inside the device, immediately
switch off all poles of the CEE mains socket to
which the product is connected (switch off fuse/
automatic circuit breaker/FI circuit breaker of the
associated circuit). Only then disconnect the mains
plug of the product from the mains socket and
contact a qualified person. Do not operate the
product any longer.
• In commercial facilities, observe the
local accident prevention regulations.
For Germany:
German Federation of Institutions for Statutory
Accident Insurance and Prevention (Verband
der gewerblichen Berufsgenossenschaften) for
electrical systems and equipment. In schools,
training centers, hobby and do-it-yourself
workshops, the handling of electrical equipment
must be supervised by trained personnel
• Contact a specialist if you have any doubts about
the operation, safety or connection of the product.
• Have maintenance, adjustment and repair work
carried out exclusively by a specialist or a specialist
workshop.
• If you still have questions that are not answered
in this operating manual, contact our technical
customer service or other specialists.
6. Product Description
Unit design and variants
Variants
Pos. Description
ACEE 5 Pol. 32 A Input
BPhase control
CFuse protection 6 x MCB
DpowerCON®TRUE1 TOP®output with
self-closing hinged cover
ECEE 5 Pol. 32 A output/through-hole
A
B
C
D
E

5Instruction manual |BDA 684
CONTRIK IPower Turtle Xtreme IPGD-00XX
7. Commissioning
The activities described in this chapter may only be
carried out by a qualified electrician! If the device is
connected to a supply line with an insufficient cable
cross-section and/or insufficient back-up fuse, there is
a risk of fire which can cause injuries or an overload
which can cause damage to the device. Observe the
information on the type plate! Check the connection
of the sockets
Supply the power distributor with power via the
connection.
Switch on the protective devices.
8. Operation
This device is used to distribute electric current to
several connected consumers. The devices are used
as power distributors indoors and outdoors as mobile
distributors.
The device is designed for professional use and is not
suitable for use in households. Only use the device as
described in these operating instructions. Any other
use, as well as use under other operating conditions,
is considered improper and may result in personal
injury or property damage. No liability is accepted for
damage resulting from improper use. The device may
only be used by persons who have sufficient physical,
sensory and mental capabilities as well as appropriate
knowledge and experience. Other persons may only
use the device if they are supervised or instructed by
a person responsible for their safety. Only distributors
with a degree of protection that corresponds to the
degree of protection required at the place of use may
be used.
9. Protection against foreign
bodies and weather influences
The power distributors comply with protection class IP
44 according to DIN EN 60529 (VDE 0470-1), provided
that the position of use is observed.
IP 44 means in detail:
IP 4X: Protected against solid foreign bodies with a
diameter of 1.0 mm or more, e.g. a wire.
IPX4: Protectionagainstsplashingwaterfromallsides.
Both during storage and operation, the cPot plug
and input connector must be covered or plugged in to
comply with IP 44.
10. maintenance, inspection and
Cleaning
• The housing, mounting materials and suspensions
must not show any signs of deformation. Cleaning
of the interior of the device may only be carried
out by qualified personnel.
• Please check the local regulations for
the product inspection details.
For Germany:
According to DGUV regulation 3, this inspection
must be carried out by a qualified electrician
or an electrically instructed person using
suitable measuring and testing equipment.
A period of 1 year has proven to be the
testing interval. You must determine the
interval in accordance with DGUV Regulation 3
Implementation Instructions to suit your actual
operating conditions. The range is between 3
months and 2 years (office).
• Switch off the product before cleaning. Then
disconnect the plug of the product from the mains
socket. Then disconnect the connected consumer
from the product.
• A dry, soft and clean cloth is sufficient for cleaning.
Dust can be easily removed using a long-haired,
soft and clean brush and a vacuum cleaner.
• Never use aggressive cleaning agents or chemical
solutions, as this may damage the housing or
impair the function.

6Instruction manual |BDA 684
CONTRIK IPower Turtle Xtreme IPGD-00XX
11. Disposal
Electronic devices are recyclable
materials and do not belong in
household waste.
Dispose of the product at the end of
its service life in accordance with the
applicable legal requirements.
By doing so, you fulfill the legal
obligations and make your
contribution to environmental
protection.
Send the device to the manufacturer
for disposal free of charge..
12. Technical data
General specifications
Supply voltage 415 V/AC, 50 Hz
Rated current 32 A Power Turtle Xtreme Outdoor
Output connections 32 A Power Turtle Xtreme Outdoor
Output connections powerCON
TRUE1: 250 V 16 A
32 A CEE flat socket 415 V
LINK looped through and not
fused
Protection class IP65
Operating temperature -25 to +40°C
Due to operating temperatures
> 20° C changesthe tripping
behavior of the circuit breakers.
Relative
Humidity
Indoor:
95 % at –5 °C to +30 °C
70 % at +35 °C
57 % at +40 °C
Outdoor:
100 % at –25 °C to +27 °C
60 % at 35 °C
46 % at 40 °C
Dimensions approx. ca. 255 mm x 155 mm x 188 mm
Label:
Pos. Description
1Article description
2QR code for further options such as: Manual
3Protection class (IP)
4Rated voltage
5Number of outer conductors
6Input connector
7Serial number (& batch number)
8Product group
9Mandatory self-declaration (WEEE Directive)
10 CE marking
11 Part number
Further technical data can be found in the corresponding
data sheets or at
www.contrik.com
1
9
10
8
7
3 4
11
5 6
2

7Instruction manual |BDA 684
CONTRIK IPower Turtle Xtreme IPGD-00XX
Imprint
Subject to change due to technical progress! These operating instructions correspond to the state of
the art at the time of product delivery and not to the current development status at Neutrik.
If any pages or sections of these operating instructions are missing, please contact the manufacturer
at the address given below.
Copyright ©
This user manual is protected by copyright. No part or all of this user manual may be reproduced,
duplicated, microfilmed, translated or converted for storage and processing in computer equipment
without the express written permission of Neutrik.
Copyright by: © Neutrik® AG
Document Identification:
Documenten No.: BDA 684 V1
Version: 2023/02
Original Language: German
Manufacturer:
Connex GmbH / Neutrik Group
Elbestraße 12
DE-26135 Oldenburg
Germany
www.contrik.com

www.contrik.com
UNMATCHED RELIABILITY AND SAFETY
LIECHTENSTEIN (HEADQUARTERS)
Neutrik AG, Im alten Riet 143,
9494 Schaan, Liechtenstein
T [phone], F [phone], [email protected]
GERMANY / NETHERLANDS / DENMARK / AUSTRIA
Neutrik Vertriebs GmbH, Felix-Wankel-Straße 1,
85221 Dachau, Germany
T [phone], [email protected]
GREAT BRITAIN
Neutrik (UK) Ltd., Westridge Business Park, Cothey Way Ryde,
Isle of Wight PO33 1 QT
T [phone], [email protected]
FRANCE
Neutrik© France, 52 Rue d’aguesseau,
92100 Boulogne
T [phone], [email protected]
USA
Neutrik Americas., 4115 Taggart Creek Road,
Charlotte, North Carolina, 28208
T [phone], [email protected]
JAPAN
Neutrik Limited, Yusen-Higashinihonbashi-Ekimae Bldg., 3-7-19
Higashinihonbashi, Chuo-ku, Tokyo 103
T [phone], [email protected]
HONG KONG
Neutrik Hong Kong LTD., Suite 18,
7th Floor Shatin Galleria Fotan, Shatin
T [phone], [email protected]
CHINA
Ningbo Neutrik Trading Co., Ltd., Shiqi Street, Yinxian Road West
Fengjia Village, Hai Shu District, Ningbo, Zhejang, 315153
T [phone], [email protected]
SWITZERLAND
Contrik AG, Steinackerstrasse 35,
8902 Urdorf, Switzerland
T [phone], [email protected]
BDA 684 V1 - Power Turtle Xtreme - EN - 2023/02 – Data subject to change without prior notice. © 2023 Neutrik AG.
