Contro l4 C4-SR150RSK-B User manual

™
• C4-SR250RS-BRechargingStationw/Battery
(SR-250)&Cover,NoRemote
• C4-SR150RS-BRechargingStationw/Battery
(SR-150)&Cover,NoRemote
Optional Accessories
Theseproductsareavailableforpurchaseincaseyou
everneedtoreplaceyourbatteriesorcover:
• C4-RBATT-250-BReplacementBatteryand
CoverforSR-250
• C4-RBATT-150-BReplacementBatteryand
CoverforSR-150
What’sintheBox?
Ifyou’vepurchasedtherechargingstationwithout
aremote(C4-SR150RS-BorC4-SR250RS-B),make
surethefollowingitemsareinyourbox:
• RechargingStationCradle
• PowerSupply
• RechargeableBattery(LithiumPolymerforSR-
150andSR-250)
• BatteryCover(SR-150orSR-250)
• WarrantyCard
• SystemRemoteControlRechargingStation
QuickSetup
Ifyou’vepurchasedtherechargingstationwitha
remote(C4-SR150RSK-BorC4-SR250RSK-B),make
surethefollowingitemsareinyourbox.
• SystemRemoteControl(SR-150orSR-250)
• RechargingStationCradle
• PowerSupply
• RechargeableBattery(LithiumPolymerforSR-
150andSR-250)
• WarrantyCard
• SystemRemoteControlRechargingStation
QuickSetupGuide
Ifanyoftheseitemsismissing,contactyourControl4
Dealerimmediately.
Welcome!
CongratulationsonyourpurchaseoftheControl4®
SystemRemoteControlRechargingStation.With
thisproduct,younolongerhavetoworryaboutyour
SystemRemoteControlbatterylosingitschargeand
haltinginthemiddleofchangingchannelsonyour
TV,whilewatchingavideo,orperformingothertasks
withyourControl4system.
Ifthebatteryleveldrops,simplyplacetheremotein
thestationuntiltheremoteisfullychargedandready
touseagain.
Control4recommendsthatyoukeepthe
remoteontherechargingstationwhennotin
use.
AvailableProducts
TheseproductsareavailablefortheControl4®
SystemRemoteControlRechargingStation:
• C4-SR250RSK-BRechargingStation,including
SR-250andBattery
• C4-SR150RSK-BRechargingStation,including
SR-150andBattery
SystemRemoteControl
RechargingStation
SetupGuide
1

™
Installation
IMPORTANT! TheremoteneedstobeonOS
2.4.0orlatertoproperlyindicatethebattery
level;otherwise,a“LowBatteryWarning”alert
willappearontheSystemRemoteControlSR-
150(ifyourdealersetsupanalertforyou)or
intheSR-250window.
Whetheryourrechargingstationcamewithor
withoutaSystemRemoteControlSR-150orSR-250,
followthestepsbelowasindicated.
Remove the Old Batteries from Your
New or Existing Remote
1 Turntheremoteupsidedown.Onthebottom
oftheremote,pullthebatterycovertoward
youwithyourthumbandliftitooftheremote
(Figure1).
Figure1.RemoveBatteryCover
2 Withyourngertip,pullouttheoldbatteries
(Figure2).
SystemRemoteControl
RechargingStation
SetupGuide
Figure2.RemoveOldBatteries
Insert the Rechargeable Battery into
Your New or Existing Remote
1 Onthebottomoftheremote(withthecover
oandtheoldbatteriestakenout),insertthe
rechargeablebatterybyslidingthesmallendinto
theslotrst(Figure3).Notetheorientationof+
and-symbolsforproperbatteryinsertion.
Figure3.RechargeableBattery
2 Seatthebatterysecurelyintotheslotandpush
down(Figure4).
Figure4.BatteryInstalled
Place the New Cover on Your Existing
Remote
Ifyou’vepurchasedanewremotewithyour
rechargingstation,followStep2;otherwise,follow
bothsteps.
NOTE:Ifyouareusinganexistingremotewith
thenewbatterycover,itwillappearthatthe
paintcolorandtexturingmaybedierent.
Withnormalusage,thenewbatterycover
colorandtexturewillblendtomatchthe
2

c (Optional)Toremovethepowerplug
adapter,pressthePushbuttonandslidethe
plugout.
3 Insertthepowerplugintoapoweroutletto
beginrecharging.
4 Forconvenience,placetherechargingstation
closetowhereyouuseyourremote.
Set the Charging Indicator on Your
Recharging Station
Thissectionappliestorechargingstationsforexisting
ornewremotes.
1 Turntherechargingstationover.
2 NoticetheChargingIndicatorbuttonlabeled
‘High,O,andLow’(Figure8).
Figure8.ChargingIndicatorButton
3 Movethebuttontothedesiredlightlevel.
• High.Setstothehighestlightlevel.
• O.Setsthelighttoo.
• Low.Setsthelighttolow.
4 Turntherechargingstationovertoitsupright
position.
Place the Remote on Your Recharging
Station
Thissectionappliestorechargingstationsforexisting
ornewremotes.
1 Ifyoupurchasedarechargingstationwithout
aremote,ensurethatyou’vereplacedyourold
batterieswiththenewrechargeablebatteriesand
newcover.
2 Whileholdingtheremoteinahorizontalposition,
placeitontothechargingstation.
3 Ensurethatitisproperlyseated.Thetwometal
remotecontrol.Youshouldexpectthisto
occuroveraperiodof1-2months.
1 Inserttheremote’snewbatterycoverintothe
remote.Noticethetwometalplatesonthecover;
that’showyoucandierentiatetheoldcover
fromthenewone(Figure5).
Figure5.ReplaceCover
2 Slidethebatterycoverintotheslotandthen
pushdownuntilthecoverishorizontal.Slidethe
coverintotheslotuntilitsnapsintoplace.
Attach the Power Supply to Your
Recharging Station
Thissectionappliestorechargingstationsforexisting
ornewremotes.
1 InsertthesmallendoftheUSBcableinto
thebackoftherechargingstation(insidethe
indentation)andthreadthepowercordthrough
theindentationinthestation(Figure6).
NOTE:Youcanthreadthecordstraightout
orwinditaroundtotheoppositeendofthe
rechargingstation.
Figure6.InsertPowerCord
2 AttachtheUSBcabletothepowersupply.
a Removetheplasticshieldfromthepower
supply.
b Attachthecorrectpowerplugadapterto
thepowersupplybyslidingitintothepower
supply’sslotuntilitclicksintoplace.
3
Charging
Indicator
Button

©2013 Control4. All rights reserved. Control4, the Control4 logo, the Control4 iQ logo and the Control4 certified logo are registered trademarks or trademarks of Control4 Corporation in
the United States and/or other countries. All other names and brands may be claimed as the property of their respective owners.
control4.com |
™
platesonthebackoftheremotemusttouchthe
metalpinsintherechargingstation(Figure7).
Dependingonyourlightsettinganindicatorlight
maycomeonatthebottomoftherecharging
station.
Figure7.EnsureProperInstallation
Recharging Station Lights
Thissectionappliestorechargingstationsforexisting
ornewremotes.
DependingontheChargingIndicatorbrightness
youselect,theindicatorlightwillbeHighorLow
brightnessorBlack/O.Whenyourrecharging
stationison,youmayseethefollowinglights.
• Red.Theremoteisrecharging,andisnotfully
chargedyet.
• Green.Theremoteisfullycharged.
• Black.Thelightiso.EithertheCharging
Indicatoristurnedo,ortheremoteisnotseated
properlyintherechargingstation.
Set Up Your Existing Remote for the
Recharging Station
Ifyou’vepurchasedthekitwithoutaremote(C4-
SR150RS-BorC4-SR250-RS-B),you’llneedtoupdate
yourremotetorecognizethenewrechargeable
battery.
(Optional)YoucancheckEnable Recharge Stationin
ComposerPro(SR-150orSR-250remoteProperties
page)toacknowledgethebattery.Thisviewalso
showsyouthepercentbatterylevel.
4
IfyouhaveanSR-150,usethisbuttonsequenceon
theremote:
1 Ontheremote,press Room O
2 Press #
3 Press *
4 Press 4
5 Press 5
6 Press 6
7 Press 0
IfyouhaveanSR-250thatisonline,followthese
steps:
1 Ontheremote,pressList.
2 PressInfo.
3 PressConfig.
4 SelectRecharge Station.
5 PressYes.
IfyouhaveanSR-250thatisoine,followthese
steps:
1 Ontheremote,pressList.
2 PressConfig.
3 SelectRecharge Station.
4 PressYes.
For More Information
Ifyouhaveanyquestionsaboutthisproductor
requireassistance,pleasecontactyourControl4
Dealer.
Toorderanewrechargeablebatterywithcover,see
“OptionalAccessories”inthisguide.
Warranty
• Limited2-YearWarrantyontheRecharging
StationandSystemRemoteControl.
• Limited1-YearWarrantyontheRechargeable
Battery.
Gotohttp://www.control4.com/warrantyfordetails.
About this Document
PartNumber:200-00325,RevB,3/11/2013
